Ropeflex RXP3 User manual

PLEASE REGISTER YOUR NEW PRODUCT
To register your product online please go to:
www.hipeq.com/product-registration
Product serial number is located on equipment or is shown in the box below
SERIAL NUMBER
If serial number is not sown
please check equipment
RXP3 PULLEY BRACKET
Product Manual
DOC: 32-4111-03
Configuration subject to change

R X 5 0 5 W I T H U P R I G H T B R A C K E T 3 2 - 4 1 1 1 - 0 3 R E V . A
1
IMPORTANT PRECAUTIONS
WARNING: To reduce the risk of serious injury, read the following important precautions before
using this equipment.
1. Read all instructions in this manual and
assemble as described before using this
equipment.
2. It is the responsibility of the owner to ensure
that all users of this equipment are
adequately informed of all precautions.
3. Use this equipment only on a level surface.
Cover the floor beneath to protect the
surface.
4. Keep children under 12 and pets away from
the equipment at all times.
5. Make sure all parts are properly tightened
each time you use this machine. Replace
any worn parts immediately.
6. Make sure the adjustment knobs are fully
engaged / disengaged before using the
equipment.
7. Always wear athletic shoes for foot
protection while exercising.
8. This equipment is designed to support a
maximum user weight of 300 pounds.
9. Pull on one the rope only and never grab a
rope in a way that prevents the drum from
rotating. Never attempt to hang on the rope
or frame. Pull rope with hands only.
10. If you feel pain or dizziness at any time
while exercising, stop immediately and
begin cooling down.
WARNING: Before beginning this or any exercise program, consult your physician. This is
especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. HiPEQ assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

R X 5 0 5 W I T H U P R I G H T B R A C K E T 3 2 - 4 1 1 1 - 0 3 R E V . A
2
RXP3 PULLEY CONFIGURATION
Assembled configuration

R X 5 0 5 W I T H U P R I G H T B R A C K E T 3 2 - 4 1 1 1 - 0 3 R E V . A
3
CONFIGURING ADAPTER TO YOUR UPRIGHT
Use included screws and spacers to adjust upright adapter opening to fit properly. Make sure
there is at least a 1 mm (0.03 inch) clearance on each side. Locking pull pin may not work on all
upright configurations and could require drilling. Please consult with original manufacturer before
doing any modifications.
Quantity Description
1 Hex L-Key 5/32" Size, 4-1/4" Length
4 Nylon Round Spacer 1/16" Long
2 Nylon Round Spacer 3/4" Long
2 Nylon Round Spacer 5/16" Long
2 Nylon Round Spacer 7/16" Long
2 Nylon Round Spacer 7/8" Long
2 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 1-1/4"
4 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 1-3/8
2 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 3/4"
6 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 7/16"
4 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 7/8"
2 SS Hex Drive Flat Head Screw 1/4"-20 Thread Size, 9/16"
1 UPRIGHT POST ADAPTER SLEEVE FOR 1" HOLE

R X 5 0 5 W I T H U P R I G H T B R A C K E T 3 2 - 4 1 1 1 - 0 3 R E V . A
4

5
If you have any questions regarding HiPEQ
equipment or any instruction found in this document,
please call 650.549.5888 for assistance.
