USER MANUAL - SL1 MIX & MINI MIX 1
USER MANUAL - &
WHAT ARE THE SL1 MIX AND MINI MIX?
• MINI: 58.5 x 20.5 x37 CM - 23 x8 x1.4 "
SL1: 112 x 20 .5x3.7 CM - 44 x 8 x1.4 "
• MINI: 100 W Max Consumption
SL1: 200 W Max Consumption
• MINI: 2.56 KG - 5.6 LBS
SL1: 4.18 KG - 9.2 LBS
•MINI: 12-35 VDC
SL1: 24-35 VDC
• 1700°K TO 10000°K
• FLICKER FREE
•

USER MANUAL - SL1 MIX & MINI MIX 2
USER MANUAL - &
25,00
43,00
36,00
54,00
204,96
1118,60
A A
B B
C C
D D
E E
F F
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
MATERIAL:
TITLE:
SCALE:
SHEET 3 OF 5
A3
WEIGHT:
SL1-HL-MIX-FACES-VIEWS-181206
1:5
Note :
All rights reserved and belong to
DMG Technologies / Lumiere. This document is confidential and intended solely for the use of the individual or entity to whom they are addressed.
X
Unit : mm
SL1 MINI
SL1 AC Power Supply
SL1-EPS-V4 MINI AC Power Supply
MINI-EPS-V4
Battery Mounting Plate
SL1-MINI-VL-V4 or AB
MIX Controller
SL1/MINI CT-MX
Standard Single Ball Mount
SL1-FX-K1
Goose-Neck Mount
SL1-FX-K2
Quick-t Handle
SL1-FX-2

USER MANUAL - SL1 MIX & MINI MIX 3
USER MANUAL - POWERING OPTIONS
1. CONTROLLER MIX FOR MINI 2. CONTROLLER MIX FOR SL1
SL1/MINI MIX Controller + SL1 EPS or VL/AB plate required to power SL1/MINI MIX Controller + MINI EPS or VL/AB plate required to power
AND/OR AND/OR

USER MANUAL - SL1 MIX & MINI MIX 4
USER MANUAL - &
MOUNTING THE SL1 :
• Attaching the mount :
With the SL1, you have either purchased a K1, K2 or handle mount.
• Place the Mount at the center of the SL1 and apply a quarter turn until the
spring loaded pin drops in it’s lodging.
D
SAFETY WARNING : Make sure the mount is properly xed and the pin is all
the way down before setting the SL1 on a stand or overhead.
• Secure the SL1 with the safety cables :

USER MANUAL - SL1 MIX & MINI MIX 5
DMG Lumière lights or any DMX enabled light
DMX Light 1 Light 2
DMX Light 1 Light 2
DMG Lumière lights or any Wireless DMX enabled light
Our wireless DMX is compatible with any powered devices.
USER MANUAL - MIX CONTROLLER USAGE EXAMPLE
Light console
DMX
LAN
WIFI
WDMXWIFI
WDMX WDMX
Light 1
Light 1
Light 2
Light 2
Light 3
Light 3
WDMX WDMX
MYMIX APP IS COMPATIBLE WITH ANY MIX CONTROLLERS.
Up to 14 MIX controllers at the same time.
DMG Lumière lights or any DMX enabled light

USER MANUAL - SL1 MIX & MINI MIX 6
USER MANUAL - &
General precautions
• DMG Lumière products are made to be used by trained professionals only.
DMG Lumière products are not for household use.
Risk of falling
• If the SL1 SWITCH, the MINI SWITCH or the MAXI SWITCH are not secured with their
two security cables on the lights, there is a risk of falling and death.
• Make sure the slings or chains chosen to secure the light complies with standards in
the country you are in.
Risk of electric shock and fire
• High voltage when using with the powerbox and External power supply !
• Use only the power supplies sold by DMG Lumière to power the lights.
• When inputting 220V or 110V AC current, make sure the POWERBOX is connected to
the ground before using.
• Do not open the product. There are no user serviceable parts inside.
Overheating
• Do not operate the product if the ambient temperature exceeds 45° C.
• Intensive use can cause the surface to become hot .
• Let the product cool down completely before you handle it.
• Do not cover the air vents !
Intense light
• Do not look at the light directly
Warnings
• Stage and Studio Use Only
• Dry Location Only
• Hazardous Voltage
• Risk of Electrical Shock
• Disconnect Power Before Servicing
• Not For Residential Use
SAFETY AND PRECAUTIONS :
Approvals
EU Safety :
• EN 55015:2013
• EN 61547:2009
• EN 61000-3-2:2014
• EN 61000-3-3:2013
• EN 61000-4-2:2009
• EN 61000-4-3:2006+A1:2008+A2:2010
• EN 61000-4-4:2012
• EN 61000-4-5:2006
• EN 61000-4-6:2009
• EN 61000-4-8:2010
• EN 61000-4-11:2004
• EN 62471
FCC :
• 47 CFR of part 15
CSA and UL :
• CSA C22.2 No. 250.4-14
• CAN/CSA C22.2 No. 250.13-14
• UL Standard No. 153
• UL Standard No. 8750
ROHS :
• EPA3050B:1996
• EN1122B:2011
• EPA3052:1996
• EPA7196A:1992
• APE3540C:1996
• EPA8270D:2007
