Rosenbauer RS 14 EFI SUPER SILENT EFI User manual

Operation manual
Power Generator
RS14 EFI / RS14 EFI Super silent
Item number: 319852-003
Release: 12/2018
Language: English
Abbreviation: JWin

2 / 81
Table of contents
1 Legal notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.2 Manufacturer and customer service address. . . . . . . . . . . 4
2 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1 Declaration of conformity RS 14 EFI . . . . . . . . . . . . . . . . . 5
2.2 Declaration of conformity RS 14 SUPER SILENT EFI . . . 6
3 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Liability and injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Use of the operation manual . . . . . . . . . . . . . . . . . . . . . . . 9
3.4.1 Validity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.4.2 Signs and Symbols . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Markings and warning signs . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 Other regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4 Training and qualifications . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.5 General Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 14
4.6 List of conventional signs. . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.6.1 Meaning of the warning signs . . . . . . . . . . . . . . . . . 15
4.6.2 Meaning of the prohibitory signs . . . . . . . . . . . . . . . 17
4.6.3 Meaning of the caution signs. . . . . . . . . . . . . . . . . . 18
4.7 Warning notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.1 Functional and working principle . . . . . . . . . . . . . . . . . . . . 26
5.2 General description of RS14 EFI power generator . . . . . . 27
5.3 Control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.4 Function switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.5 Ground wire testing device . . . . . . . . . . . . . . . . . . . . . . . . 30
5.6 Warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5.7 Operating mode indicators. . . . . . . . . . . . . . . . . . . . . . . . . 32
5.8 Page navigation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.9 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.9.1 Optional equipment . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.9.2 Functional options . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.1 Transporting the power generator . . . . . . . . . . . . . . . . . . . 51
6.1.1 Manual transport . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.1.2 Transport by means of wheel set (optional) . . . . . . 51

3 / 81
6.2 Preparation for initial operation . . . . . . . . . . . . . . . . . . . . . 52
6.3 Preparation for startup . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.3.1 Positioning the power generator. . . . . . . . . . . . . . . 53
6.4 Monitoring during operation . . . . . . . . . . . . . . . . . . . . . . . 54
6.5 Warning notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.6 Start power generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.7 Check ground wire (if available) . . . . . . . . . . . . . . . . . . . . 57
6.8 Connect consumer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.9 Shut down power generator . . . . . . . . . . . . . . . . . . . . . . . 59
6.10 Fuelling and refuelling: . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
6.10.1 Fuelling process . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7 Servicing and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.1 Service plan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.1.1 Maintenance according to the manufacturers opera-
tion manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.2 Inspection procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.3 Service procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.1 Power generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
9 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
10.1 Power generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
11 List of spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
11.1 List of spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
12 List of abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

4 / 81
ORIGINAL OPERATION MANUAL
1 Legal notice
1.1 Copyright
All rights to this manual and its attachments lie with Rosenbauer
International AG.
The documents are only entrusted to the recipient for their personal use.
Reproduction, reprinting (electronically or mechanically), translations in
other languages or all other duplication, also of parts of the manual, are
only allowed with written permission.
Information from this manual may not be passed on to or made accessible
to third persons, in particular competitors.
1.2 Manufacturer and customer service address
Rosenbauer International AG
Paschinger Strasse 90
4060 Leonding, Austria
The Rosenbauer customer service department or one of our worldwide
representatives will gladly assist you if you need further information.
Telephone: [phone] - 0
Fax: [phone] - 312
Email: [e-mail]
Internet: www.rosenbauer.com

5 / 81
2 Declaration of conformity
2.1 Declaration of conformity RS 14 EFI
According to EC Machinery Directive 2006/42/EC, Annex II, part 1A
Herewith declares
Rosenbauer International AG
Fire fighting technology
A - 4060 Leonding, Paschinger Str. 90
Address: Postbox 176, 4021 Linz, Austria
Telephone: +43 (0)732 / 6794-0
that the Power generator
Type RS 14 EFI
Serial number A0515
complies with the following regulations:
1) 2006/42/EC - EC Machinery Directive
2) 2014/30/EU - Directive on the harmonization of regulations relating to
electromagnetic compatibility
3) ECE R10 - Electromagnetic compatibility for vehicles
The following harmonized standards (or parts thereof) have been ap-
plied:
1) ÖBFV-RL ET-01 (Austrian Federal Fire Brigade Association)12
2) DIN 14685-13
3) EN 55012 / EN 61000-6-2
4) IEC 60364-5-55:2010
1apart from Chap. 3.4, subchap. 6
2except for devices with special voltage
3except for devices with special voltage

Declaration of conformity
6 / 81
Declaration of conformity RS 14 SUPER SILENT EFI
2.2 Declaration of conformity RS 14 SUPER SILENT EFI
According to EC Machinery Directive 2006/42/EC, Annex II, part 1A
Herewith declares
Rosenbauer International AG
Fire fighting technology
A - 4060 Leonding, Paschinger Str. 90
Address: Postbox 176, 4021 Linz, Austria
Telephone: +43 (0)732 / 6794-0
that the Power generator
Type RS 14 SUPER SILENT EFI
Serial number A0516
complies with the following regulations:
1) 2006/42/EC - EC Machinery Directive
2) 2014/30/EU - Directive on the harmonization of regulations relating to
electromagnetic compatibility
3) ECE R10 - Electromagnetic compatibility for vehicles
The following harmonized standards (or parts thereof) have been ap-
plied:
1) ÖBFV-RL ET-01 (Austrian Federal Fire Brigade Association)1
2) DIN 14685-12
3) EN 55012 / EN 61000-6-2
4) IEC 60364-5-55:2010
1except for devices with special voltage
2except for devices with special voltage

Introduction
7 / 81
Preface
3 Introduction
3.1 Preface
This manual is to be read through carefully and all regulations and advice
observed before commissioning the product.
Also observe the documents of the corresponding manufacturers supplied
in addition to this manual.
All persons, who deal with the operation and maintenance of the product,
must be correspondingly qualified, have read this manual fully and follow it
exactly.
The manual is always to be kept at the site of operation of the product.
3.2 Liability and injury
Due to the information in this manual Rosenbauer fundamentally accepts
no liability for direct damage or consequential damage, which arise from in-
correct operation or maintenance, as well as by unauthorised changes of
components or this manual.
The product may only be operated by persons who are familiar with the
manual, the product as well as the national laws, guidelines and regulations
pertaining to work, safety and accident prevention.
Rosenbauer assumes no responsibility for injury to persons or material
damage, which are caused by untrained personnel, also through non-com-
pliance with the regulations regarding work, safety and accident prevention.
If this manual contains a technical error or a typographical error,
Rosenbauer reserves the right to make change at any time and without no-
tice.
This manual may contains figures and descriptions, that are not built into
the delivered product.
No claims may be made for products that have already been delivered from
the information, figures and descriptions in this manual.
For your own safety only use spare parts and accessory products from
Rosenbauer. Rosenbauer accepts no liability for the use of other products
and the resulting damage!
Check the delivery immediately for transport damage and completeness.
• Faults and damages must be documented in writing immediately.
• Photograph damaged components.
• Send written damage report to the manufacturer - see chapter "Manu-
facturer and customer service address".

Introduction
8 / 81
Identification
3.3 Identification
Identifying the serial number is important when referring to the manufactur-
er in regards to part and technical issues.
The serial number of the power generator is stamped on the type plate. The
type plate is on the bottom of the battery box cover,
RS 14 EFI power generator:
RS 14 SUPER SILENT EFI power generator:
► Enter the serial number of the power generator into the table.
A0515L
A0516L

Introduction
9 / 81
Use of the operation manual
3.4 Use of the operation manual
3.4.1 Validity
This manual contains information needed for the operation of the product.
This manual contains descriptions of special equipment as well as some
abstractions and exemplary illustrations. The actual equipping of your prod-
uct may therefore differ in part from the descriptions and illustrations.
3.4.2 Signs and Symbols
Highlighted Text
To simplify legibility and clarity, there are marked various pieces of informa-
tion.
These symbols indicate the following meaning:
► Perform action in the hierarchy to be maintained as described.
Reactions to the actions performed (results).
•Lists.
Further Information about this topic.
Notes for additional information to operate the unit.
Read/obey additional information in the manufacturer documentation.
Figures
Where necessary, the text is illustrated with drawings. A caption is provided
below the illustration. The reference from the text to a position within the il-
lustration is given by inserted figures (e.g. S1).

Introduction
10 / 81
Use of the operation manual
Warning notices
The safety information warns the user of risk and informs them how these
risks can be avoided.
Safety information stands at the beginning of a chapter before handling in-
structions from which a dangerous situation can occur. Further safety infor-
mation is found at the start of this manual.
Safety instructions that must be followed without fail are highlighted as fol-
lows:
DANGER!
This symbol warns of an extremely dangerous situation, in which non-
observation of the danger warning will lead to death or serious irreversible
injury.
WARNING!
This symbol warns of a dangerous situation, in which non-observation of
the danger warning can lead to death or serious irreversible injury.
CAUTION!
This symbol warns of a dangerous situation, in which non-observation of
the danger warning can lead to slight reversible injury.
NOTICE
This symbol warns of situations, in which non-observation of the warning
can lead to material damage.
Additionally the information in the operation manual in the “Technical data“
chapter and the safety information in the supplier documentation supplied
must be observed.

Safety
11 / 81
Intended use
4Safety
4.1 Intended use
Improper use of the product can result in personal injury. Additionally, the
product or other material assets of value may be damaged.
Rosenbauer can warrant the safety, reliability and performance of its prod-
uct only if the product is used in accordance with the stipulations in this
manual.
Unauthorised changes, unauthorised conversions or improper operation
can detract from the intended use and result in personal injury or property
damage.
Firefighting products may be used only in a flawless technical condition by
qualified personnel for the following purposes:
• Implementation of technical assistance
• Rescue of people from emergencies
• Firefighting
Only manufacturer-authorised persons may perform modifications, conver-
sions and repairs. Unauthorised changes, unauthorised conversions or im-
proper use will nullify all manufacturer liability for resulting damages.
The power generator generates electrical energy for feeding into a mobile
distribution system as part of a network replacement operation. In order for
the generator to be used for the supply of stationary consumers (building
feed), the power generator and the system must have a corresponding
electrical installation.
The power generator must not be connected to other power distribution
(e.g. public power supply) and power generation systems (e.g. other power
generators) (grid-parallel operation). The power generator may only be
used outdoors within the specified limits for voltage, power and rated speed
(see type plate). In emergency situations, use on a vehicle or equipment ex-
tension or swivel/rotary compartment in the inserted or swivelled state is
also permitted if the equipment is supplied with fresh air through sufficiently
dimensioned air intake openings in the body and, in particular, the air flow
at the air intake and air exhaust openings is not impaired and heat accumu-
lation is avoided. The exhaust gases must be discharged into the open air.

Safety
12 / 81
Markings and warning signs
4.2 Markings and warning signs
Safe use is only possible, if all necessary information for a safety operation
are observed. These informations are especially including safety- and
warning instructions.
In addition to the instructions in this operating manual read and observe all
the safety- and warning signs affixed to the product.
4.3 Other regulations
In addition to this manual the relevant national legislation, regulations and
directives in the latest version are to be observed (e.g. guidelines for per-
sonal protective equipment, road traffic regulations, country-specific train-
ing regulations for the fire department, accident prevention guidelines, fire
department duty regulations, occupational medicine and technical environ-
mental rules, country legislation for fire and disaster protection).

Safety
13 / 81
Training and qualifications
4.4 Training and qualifications
Operator errors caused by inadequate qualifications can cause serious ac-
cidents or jeopardise the success of the operation. Safe operations can be
assured only when operation and consistent maintenance of the product is
performed exclusively by specially trained personnel.
Only qualified training and continuous practice of the operating procedures
ensure safe use.
One-time instruction is not sufficient!
Personnel must exhibit physical and mental aptitude. Minors and persons
without qualified training may not operate the product.
The operator is responsible for defining responsibilities and supervision of
personnel as well as for adequate instruction and training according to ap-
plicable regulations.
Even during operation, make sure that persons without technical knowl-
edge never operate the product.
Modifications and conversions to the product and its accessories may be
performed only with written authorization from Rosenbauer and must be
performed by a manufacturer-authorised person.

Safety
14 / 81
General Safety Instructions
4.5 General Safety Instructions
The following instructions provide an overview of how to use the product
safely.This general overview is supplemented by the safety instructions in
the detailed descriptions of the various sections.
Always remember the possibility of danger when operating machines.
Always use the prescribed personal protective equipment.
The condition of the product must meet the local safety regulations and the
local fire fighting regulations. Ensure that the product is ready for action at
all times.
Pay attention to the operation and service manual of the engine manufac-
turer.
If faults cannot be solved or if repairs cannot carried out by special trained
personnel, immediately contact Rosenbauer International AG or your near-
est Rosenbauer representative.

Safety
15 / 81
List of conventional signs
4.6 List of conventional signs
4.6.1 Meaning of the warning signs
Danger from electricity.
Impending fire risk.
Impending risk of explosion.
Risk from oxidising materials.
Risk of harmful or irritating materials.
Impending risk of explosion.
Impending acid burn risk.
Impending hearing damage.
Risk of inhalation of toxic vapours.
Risk from hot surfaces.

Safety
16 / 81
List of conventional signs
Impending crushing risk.
Threat of environmental contamination.
Threat of shearing.

Safety
17 / 81
List of conventional signs
4.6.2 Meaning of the prohibitory signs
Handling fire and naked flames forbidden!
Do not touch or reach in!
Do not stay in the danger area!

Safety
18 / 81
List of conventional signs
4.6.3 Meaning of the caution signs
Use hearing protection.
Wear a protective helmet.
Wear a protective suit.
Maintain distance.
Special caution.

Safety
19 / 81
Warning notes
4.7 Warning notes
DANGER!
Mortal danger or serious injury from electric shock!
Maintenance work on live parts may only be carried out by qualified
specialist personnel.
Observe the safety distance from voltage-carrying parts at all times.
Danger of fatal injury or health hazard due to inhalation of toxic
exhaust fumes!
Combustion engines working in enclosed areas build toxic exhaust fumes.
Is there the need of working in enclosed areas, obey following:
Extract the exhaust fumes outside using exhaust hoses.
Make sure for adequate ventilation.
WARNING!
Danger of injury and accidents!
Danger of injury and accidents due to malfunctioning or improper used
safety devices!
Do not override safety and protective devices.
Do not manipulate or render safety and protective devices.
Check safety and protective devices for proper function.

Safety
20 / 81
Warning notes
Danger of serious injury and damage due to explosion, fire and
chemical burns!
When charging vehicle batteries, a highly explosive electrolytic gas mixture
(hydrogen and oxygen) is released; it is easily flammable and may release
highly acidic battery acid.
Wear safety goggles whenever servicing a battery.
Follow safety instructions on the outside of the battery.
Do not smoke.
Avoid fire, open flame and sparks.
Avoid sparks when handling cables and electrical devices, and through
electrostatic discharge.
Do not connect the minus pole of the battery jumper cable near to the
discharged battery (generates sparks).
Always remove negative battery ground cables first and install them
last to avoid sparks.
The vehicles must not touch (sparks will occur on connecting the
positive poles).
Never short-circuit the battery.
Ventilate batteries thoroughly before any external start.
When connecting the connecting lead, do not bend over the battery.
Avoid skin and eye contact with any battery acid that escapes.
Keep unauthorized persons clear of the battery.
Ensure that the battery voltage matches.
Never disconnect the batteries while the engine is running.
Danger of explosion due to flammable fuel!
During work on the fuel system, fuel can ignite and cause potentially fatal
injuries.
Do not smoke.
Keep fuel away from open flame.
When handling fuel, always keep a fire extinguisher at hand.
Personal injuries and damage to property can occur due to a
restricted view of movable machine parts.
Do not linger in the danger zone.
Follow the training and operation manual.
Failure to wear proper protective gear could result in death or serious
injury.
Wear protective gear.
