ROSITEK RMP2 Operating instructions

CONTACT
Rositek Technologies E-mail；[e-mail] © 2021 Rositek
www.rositek.com All rights reserved
MANUAL HEAT PRESS
MODEL No: RMP2
USER GUIDE AND TROUBLESHOOTING

PAGE 1
USER GUIDE AND TROUBLESHOOTING -- RMP2
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
PAGE 2 INTRODUCTION
Read Before Operating Machinery
Disclaimer
PAGE 2 SAFETY PRECAUTIONS
PAGE 3 HANDLING PRECAUTIONS
PAGE 3 UNPACKING
Unpacking Precautions
Unpacking Instructions
Item Checklist
PAGE 4 - 6 GETTING FAMILIAR
RMP2 Features and Controls - Front
RMP2 Features and Controls - Back
RMP2 Product Size
PAGE 7 - 10 OPERATING INSTRUCTIONS
Preparing Press
Starting Press
PID Control Instruction
How to Set Back to Default Settings
Setting Control Panel
#1 Method Workbench Operation
#2 Method Ground Operation
Turning Off Press
Cleaning Press Plates
PAGE 11
PAGE 11 TECHNICAL SPECIFICATIONS
TABLE OF CONTENTS
PAGE 10
WARRANTY
TROUBLESHOOTING
How to Replace PID Module
More Information

PAGE 2
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
INTRODUCTION
READ BEFORE
OPERATING
MACHINERY
Thank you for purchasing this Rositek product.
Before using this device, please read these instructions and Safety
Precautions carefully.
After reading and familiarizing yourself with the device, store the manual in a
safe place for future references.
RMP2 is Rositek 2-ton manual heat press with a customized leverage system with an extra-long
handle. It’s portable, small, and effortless; Solid frame, non-rusting & non-breaking.
The following precautions are provided to prevent harm or injury to yourself and others.Please make
sure to thoroughly read, understand, and follow these precautions before using. After reading and
familiarizing yourself with the equipment, store the manual in a safe place for future references.
• Use this product only as described in this manual.
• Keep the equipment out of the reach of children at all times.
• Unplug the heat press from the electrical outlet and let it cool down
COMPLETELY before cleaning, performing maintenance, or repair.
• DO NOT operate the product after the appliance malfunctions or is dropped or
damaged in any way.
• Clean the plates with isopropyl alcohol and wipe them dry with a clean cloth.
Ensure both plates are completely dry before use.
• DO NOT leave any cords near a heat source.
• DO NOT handle a power plug or other components of the press with wet hands.
• DO NOT connect too many power plugs to the same power outlet.
• Remove dust around the plug and power cord with a clean dry cloth.
• DO NOT disassemble the press or make any modifications to the equipment
without professional instructions.
WARNING: Follow the warnings below.
SAFETY PRECAUTIONS
The units are intended for LEGAL use only, in accordance with your
federal, state, and local laws, ordinances, and regulations.
DISCLAIMER

PAGE 3
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
HANDLING PRECAUTIONS
• The press must be operated on a hard, level surface, away from its edges to
prevent accidental tipping over.
• Always attach the power cord to the press first, then plug it into the wall outlet.
• To unplug the press, turn OFF the power switch, only then remove the plug from
the outlet.
• DO NOT touch the press’s hot surfaces. Use heat-resistant gloves or tools.
• Keep your hands and other body parts away from the moving parts to
prevent injury.
• This press comes with a power cord that fits into a standard household 3-
prong outlet (110V American market ).
• DO NOT attempt to use the equipment with a two-prong electrical cord or
any other way without proper grounding.
• DO NOT exceed the rated capacity.
• Always turn the machine OFF and unplug it when done using.
UNPACKING
UNPACKING
INSTRUCTIONS
1. Place the box on a flat surface.Open the box and remove the user guide
and all parts that came with the device.
2. Examine the device after unpacking for any damage. If found one, take a
picture and contact Rositek at [e-mail] immediately.
Before starting, please make sure that the following items are included with
your device. If anything is missing, contact Rositek.
ITEM
CHECKLIST
1. 1pc x Heat Press.
2. 1pc x Power Cord.
3. 1pc x User Guide.
4. 1pc x Tools Bag.
5. 1pc x Silicone Mat.
UNPACKING
PRECAUTIONS
Keep the packaging materials (foam, plastic bags,etc.)
It is designed to protect the product and should be used in case you need to
return the device for repair or warranty maintenance in the future.
DO NOT attempt to ship the device in different packaging materials.

PAGE 4
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
GETTING FAMILIAR
RMP2
FEATURES AND
CONTROLS -
FRONT
Top Platen
Bottom Platen
Pluggable Single PID
Temperature
Controller
Machine Base
①
⑥
⑤
ON / OFF Switch
⑧
Bamboo Insulators
Customized Lever System
Made of Blackened Steel
Extra-long
Pressure Handle
③
②
Pressure Adjusting Knob
(Clockwise to increase the
pressure)
Frame
④
⑦
⑨
⑩
⑪Pedal ⑫
Armrest

PAGE 5
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
RMP2
FEATURES AND
CONTROLS -
BACK
Power Cord Socket
⑬Thermocouple
Heating Rods
⑭
⑮
GETTING FAMILIAR (continued)
USER GUIDE AND TROUBLESHOOTING -- RMP2

PAGE 6
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
GETTING FAMILIAR (continued)
RMP2
PRODUCT SIZE
Left view size(mm) Front View Size (mm)

PAGE 7
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
PREPARING
PRESS
1. Prepare materials you wish to press.
2. Make sure the press stands on a shorter flat workbench or ground.
3. Ensure the press is clean and free of residue or dust buildup.
4. Make sure the switch is turned OFF.
5. Insert the included power cord into the power cord socket and then
plug the other end into an electrical outlet.
OPERATING INSTRUCTIONS
STARTING
PRESS
1. Flip the ON / OFF switch to turn the press on. The PID temp controller and
the power switch both become lit.
PID CONTROLLER INSTRUCTION FOR RMP2
PV (Process Value)
Red color
SV (Set Value)
Green color
UP Key
DOWN Key
SHIFT Key
Press this key to shift left
and right position.
SET (Parameter Setting)
Press this key to shift digit
of parameter value setting.
OUT(Output Lamp)
Green light on while
heating up
AL1, AL2(Alarm Lamp)
Red light while working
AT(Autotune Lamp)
Flash Green while working
℃ and ℉Pilot Lamp
Red light while working
USER GUIDE AND TROUBLESHOOTING -- RMP2

PAGE 8
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
OPERATING INSTRUCTIONS (continued)
PID DEFAULT PARAMETERS FOR RMP2
AL1=0030 ATU=0000 d=0060 P=0030 I=0240
5C=0000
T=0002 LCk=1000
Ar=0080
Tips: We do not recommend changing the internal parameters, it will cause a lot of problems.
Once a problem occurs after the modification, please set the default setting back as below
steps:
1. Hold the "SET" key over 5 seconds to activate the controller.
2. Press the "SET" again to switch parameters.
3. Press the "SHIFT" key to switch between the hundreds, tens, and ones place.
4. To set the parameter with the key of " down" or "up".
5. Please ensure all parameter is the same as above value.
6. Hold the "SET" key over 5 seconds to exit the setting mode.

PAGE 9
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
OPERATING INSTRUCTIONS (continued)
#1 METHOD
WORKBENCH
OPERATION
1. Place the machine on a shorter workbench in order to operate effortlessly.
2. Wait until the platens heat up to the setting temperature after plug-in.
3. Load the prepared material in the center of the bottom platen.
4. Hold the armrest of the machine while pressing the handle down until hear
a sound of "click".
5. Hold down your hand on the machine pedal, and then pull up the handle
after time is up.
6.You need to re-press material after adjusting the pressure knob (clockwise
to increase the pressure) for a better yield.
7. Remove the pressed material using heat resistant gloves or tools and
exercising extreme caution.
SETTING
CONTROL
PANEL
The PID control panels are used to set temperature for deal heated platen.
Please follow the steps below to record the desired settings:
1. Use “SHIFT” key to shift left and right position.
2. Press “UP” and “DOWN” keys to set the desired temperature.
3. Press “SET” key to record all control panel’s setting.The platens start heating,
and PV is now displayed on the screen.
Tips: (1) We recommend loading 3.5-5g material at a time for a better result.
(2) The parchment paper is a must during the extraction, but filter bags and prepress
mold is optional. ( 2x4.5” pressing bags and 30mm cylinder/round prepress mold is
a recommendation; 2x4.5” bags allows cutting into half for double use.)
1. Operating the miachine on the ground is the first recommended method.
2. Wait until the platens heat up to the setting temperature after plug-in.
3. Place the prepared material in the center of the bottom platen.
3. Hold the armrest of the machine, then tilt the machine backward at a 45-
degree angle, while pressing the handle down until hear a sound of "click".
4. Step your foot on the machine pedal, and then pull the handle up after
time is up.
5.You need to re-press material after adjusting the pressure knob (clockwise
to increase the pressure) for a better yield.
6. Remove the pressed material using heat resistant gloves or tools and
exercising extreme caution.
#2 METHOD
GROUND
OPERATION

PAGE 10
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
TROUBLESHOOTING
How to Replace PID Module?
1. Unplug the power cord.
2. Lay down the machine backward with the pedal facing up.
2. Between the pedal and the base, you will find the locking mechanism of the PID module.
3. Use a small flathead screwdriver to depress in on the locking mechanism of the PID
module.
4. While depressing the locking mechanism, simply slide out the front of the box, the PID module
from the housing.
5. Install the replacement PID module received (remove it from the included housing first).
6. Once the PID module is installed and locked into place,reinstall the power cord.
7. Turn on the power switch.
Please see our website for more tips, innovations, industry news, and
promotional discounts.
MORE
INFORMATION
TURNING OFF
PRESS
1. Turn the machine off by flipping ON / OFF switch when done pressing.
2. Unplug and then disconnect the power cord from the press.
3. Wait until the press cools down completely to clean and store it.
CLEANING
PRESS PLATES
1. Make sure the press plates are completely cooled down before cleaning.
2. Apply a small amount of alcohol to a clean cloth and wipe down the plates
until clean. Use rubbing alcohol that contains at least 80% by volume of
isopropyl alcohol.
3. Wipe plates with a dry clean cloth.
4. Repeat these steps for cleaning all associated tools.
OPERATING INSTRUCTIONS (continued)
USER GUIDE AND TROUBLESHOOTING -- RMP2

PAGE 11
Rositek Technologies
www.rositek.com
© 2021 Rositek
All rights reserved
Email: sup[email protected]
USER GUIDE AND TROUBLESHOOTING -- RMP2
TECHNICAL SPECIFICATIONS
PARAMETER
USA MARKET
Model
RMP2
Press Force
2 Ton
Power
300 W
Voltage
110 V
Frequency
50 / 60 Hz
Dual Heating Plates
Yes
Platen Size
3 x 3 inch / 76 x 76 mm
Temperature Range
up to 400 °F
Certifications
CE / RoHS
WARRANTY
We provide One Year Warranty. Please contact Rositek at [e-mail] immediately of
any issues with the product.We will attempt to troubleshoot the product and solve your issue in a
timely manner.
