Roughneck 57141 User manual

READ & SAVE THESE INSTRUCTIONS
Air-Operated Waste Oil Suction Kit
Owner’s Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #57141

Page 2 of 12
Thank you very much for choosing a Roughneck™product!
For future reference, please complete the owner’s record below:
Serial Number/Lot Date Code: ________________________________
Purchase Date: ____________________________________________
Save the receipt, warranty, and this manual. It is important that you read
the entire manual to become familiar with this product before you begin
using it.
This oil suction kit is designed for certain applications only. Northern Tool
and Equipment is not responsible for issues arising from modification or
improper use of this product such as an application for which it was not
designed. We strongly recommend that this product not be modified
and/or used for any application other than that for which it was designed.
For technical questions, please call 1-800-222-5381.

Page 3 of 12
Table of Contents
Intended Use..........................................................................................................................................4
Technical Specifications......................................................................................................................4
Important Safety Information...............................................................................................................4
Specific Operation Warnings...............................................................................................................6
Main Parts of Product...........................................................................................................................7
Assembly Instructions..........................................................................................................................7
Before Each Use....................................................................................................................................7
Operating Instructions..........................................................................................................................8
After Each Use.......................................................................................................................................8
Maintenance ..........................................................................................................................................8
Parts Diagram........................................................................................................................................9
Parts List..............................................................................................................................................10
Replacement Parts..............................................................................................................................10
Limited Warranty.................................................................................................................................11

Page 4 of 12
Intended Use
The Roughneck Air-Operated Waste Oil Suction Kit is suitable for suctioning and delivering various
oils, waste oil, diesel oil, and similar fluids.
Technical Specifications
Air inlet pressure
70-115 psi
Pump
1:1
Noise level
82db
Suction hose
1/2" x33’
Draining hose
1/2" x13’
Suction speed
0.26-0.92 gallon/min
Hose reel
1/2" x33’
Tube material
NBR Rubber hose
Suction hose assembly
Flexible probe: Φ5mm x 1pcs, Φ6mm x 1pcs,
Φ7mmx1pcs, Φ8mm x 1pcs
Copper probe: Φ5mm x 1pcs, Φ6mm x 1pcs]
Important Safety Information
⚠WARNING
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
Do not allow persons to operate or assemble the product until they have read this manual and
have developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product. There are specific applications for which the product
was designed.
Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
Industrial or commercial applications must follow OSHA requirements.
⚠WARNING

Page 5 of 12
WORK AREA SAFETY
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit.
Cluttered, wet, or dark work areas can result in injury. Using the product in confined work areas
may put you dangerously close to cutting tools and rotating parts.
Do not use the product where there is a risk of causing a fire or an explosion; e.g., in the presence
of flammable liquids, gases, or dust. The product can create sparks, which may ignite the
flammable liquids, gases, or dust.
Do not allow the product to come into contact with an electrical source. The tool is not insulated
and contact will cause electrical shock.
Keep children and bystanders away from the work area while operating the tool. Do not allow
children to handle the product.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in your
work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
⚠WARNING
PERSONAL SAFETY
Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use
the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating the tool may result in serious personal injury.
Dress properly. Do not wear loose clothing, dangling objects, or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving
parts. Air vents on the tool often cover moving parts and should be avoided.
Wear the proper personal protective equipment when necessary. Use ANSI Z87.1 compliant safety
goggles (not safety glasses) with side shields, or when needed, a face shield. Use a dust mask in
dusty work conditions. Also use non-skid safety shoes, hardhat, gloves, dust collection systems,
and hearing protection when appropriate. This applies to all persons in the work area.
Do not overreach. Keep proper footing and balance at all times.
Remove keys or wrenches before connecting the tool to an air supply, power supply, or turning on
the tool. A wrench or key that is left attached to a rotating part of the tool may cause personal
injury.
Secure the work with clamps or a vise instead of your hand when practical. This safety precaution
allows for proper tool operation using both hands.
⚠CAUTION
OIL SUCTION KIT USE AND CARE
Do not force the oil suction kit. Products are safer and do a better job when used in the manner for
which they are designed. Plan your work, and use the correct product for the job.
Check for damaged parts before each use. Carefully check that the product will operate properly

Page 6 of 12
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Do not use a product with a malfunctioning switch. Any power tool that cannot be controlled with
the power switch is dangerous and must be repaired by an authorized service representative
before using.
Disconnect the power/air supply from the product and place the switch in the locked or off position
before making any adjustments, changing accessories, or storing the tool. Such preventive safety
measures reduce the risk of starting the tool accidentally.
Store the product when it is not in use. Store it in a dry, secure place out of the reach of children.
Inspect the tool for good working condition prior to storage and before re-use.
Use only accessories that are recommended by the manufacturer for use with your product.
Accessories that may be suitable for one product may create a risk of injury when used with
another tool. Never use an accessory that has a lower operating speed or operating pressure than
the tool itself.
Keep guards in place and in working order. Never operate the product without the guards in place.
Do not leave the tool running unattended.
Specific Operation Warnings
⚠WARNING
To prevent serious injury or property damage, read and understand owner’s manual before
operating.
Always wear the proper personal protective gear including ANSI Z87.1 compliant safety goggles
and heat-resistant rubber gloves when using this product.
Use only on a dry, clean, level surface capable of supporting the weight of the vehicle.
Engine exhaust contains carbon monoxide; an odorless, invisible gas that can cause injury or
death. Do not run the vehicle’s engine while using this product.
Never work under a vehicle without the proper support devices. An incorrectly supported vehicle
can tilt or fall and cause injury or death.
Do not exceed the maximum rated pressure.
Do not use to pump water or any other liquid other than oil.
Hot oil can cause severe burns. Allow the engine oil to cool down completely before pumping the
oil.
Fire hazard. Flame or heat sources may ignite oil resulting in fire, injury or death. Never use or
store this product near open flames or other heat sources.
Remove this product and clear the work area before lowering the vehicle.
Used engine oil is toxic and should be properly disposed of or recycled.
Do not use with corrosive or flammable fluids.
Not for use by or around children.

Page 7 of 12
Main Parts of Product
Part No.
Description
Qty.
Part No.
Description
Qty.
1
Hose reel
1
6
Vacuum meter
1
2
Inlet hose assembly (1/2"*2m)
1
7
Wall bracket
1
3
Oil pump
1
8
Wall bracket
1
4
Outlet hose assembly (1/2"*4)
1
9
Probes container
1
5
Suction probes
1
10
Connector
1
Assembly Instructions
⚠WARNING
Use only on a dry, clean, level surface capable of supporting the weight of the vehicle.
Engine exhaust contains carbon monoxide; an odorless, invisible gas that can cause injury or
death. Do not run the vehicle’s engine while using this product.
Never work under a vehicle without the proper support devices. An incorrectly supported vehicle
can tilt or fall and cause injury or death.
Do not exceed the maximum rated pressure.
Do not use the pump with water or any other liquid other than oil.
Fire hazard: flame or heat sources may ignite oil resulting in fire, injury, or death. Never use or
store this product near open flames or other heat sources.
Do not use with corrosive or flammable fluids.
Not for use by or around children.
Attach the #1 hose reel to the wall with the #7 and #8 wall brackets.
Connect the #2 inlet hose assembly to the #1 hose reel suction.
Attach the #3 oil pump to the #7 wall bracket.
Install the #6 vacuum meter at the side of the #3 oil pump (holes).
Connect the #2 inlet hose assembly to the #3 oil pump bottom hitch.
Attach the #10 connector to the #1 hose reel outlet port.
Attach the #4 outlet hose assembly to the #1 hose reel draining position.
Before Each Use
⚠WARNING
Always wear the proper personal protective gear including ANSI Z87.1 compliant safety goggles
and heat-resistant rubber gloves when using this product.

Page 8 of 12
Use only on a dry, clean, level surface capable of supporting the weight of the vehicle.
Engine exhaust contains carbon monoxide; an odorless, invisible gas that can cause injury or
death. Do not run the vehicle’s engine while using this drainer.
Never work under a vehicle without the proper support devices. An incorrectly supported vehicle
can tilt or fall and cause injury or death.
Check for damaged parts before each use. Carefully check that the product will operate properly
and perform its intended function. Replace damaged or worn parts immediately. Never operate the
product with a damaged part.
Hot oil can cause severe burns. Allow the engine oil to cool down completely before pumping the
oil.
Operating Instructions
To start the equipment for the first use, the working pressure needs to be adjusted to 29 psi to fulfill
the empty hose slowly. Carefully follow these instructions:
Insert #4 (outlet hose assembly) into waste oil tank.
Pull out the hose from the hose reel and stretch it to the desired length.
Connect the #5 suction probes with the #10 connector and place it into the car engine.
With the air pressure from the #3 oil pump, open the valve near the #10 connector. Begin to
pump the waste oil.
After Each Use
⚠WARNING
Store the equipment in a dry place with good ventilation. Do not expose it to excessive heat,
humidity, or sunlight. Never let it touch any corrosive substances.
Used engine oil is toxic and should be properly disposed of or recycled.
When you finish pumping the waste oil, close the valve near the #10 connector.
If there is not air pressure coming from the oil pump, separate the #5 suction probes from the
#10 connector.
Place the #5 suction probes into the container.
Return the hose from the hose reel back to the original position.
Maintenance
Maintain the product by adopting a program of conscientious repair and maintenance in accordance
with the following recommended procedures. It is recommended that the general condition of any tool
be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from
oil and grease. Also refer to the engine manufacturer’s instruction manual for additional information
about engine maintenance. The following chart is based on a normal operation schedule.
Maintenance Interval
Maintenance Point

Page 9 of 12
Daily before operating:
Clean the unit. Use only soap and a damp cloth to clean the oil
drain. Many household cleaners are harmful to plastics and
other insulation.
Parts Diagram

Page 10 of 12
Parts List
Part No.
Description
Qty.
Part No.
Description
Qty.
1
Hose reel
1
6
Vacuum meter
1
2
Inlet hose assembly (1/2"*2m)
1
7
Wall bracket
1
3
Oil pump
1
8
Wall bracket
1
4
Outlet hose assembly (1/2"*4)
1
9
Probes container
1
5
Suction probes
1
10
Connector
1
Replacement Parts
For replacement parts and technical questions, please call Customer Service at 1-800-222-5381.
Not all product components are available for replacement. The illustrations provided are a
convenient reference to the location and position of parts in the assembly sequence.
When ordering parts, the following information will be required: item description, item model
number, item serial number/item lot date code, and the replacement part reference number.
The distributor reserves the rights to make design changes and improvements to product lines
and manuals without notice.

Page 11 of 12
Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only
("You'' or "Your") that the Roughneck product purchased will be free from material defects in both
materials and workmanship, normal wear and tear excepted, for a period of one year from date of
purchase. The foregoing warranty is valid only if the installation and use of the product is strictly in
accordance with product instructions. There are no other warranties, express or implied, including the
warranty of merchantability or fitness for a particular purpose. If the product does not comply with this
limited warranty, Your sole and exclusive remedy is that We will, at our sole option and within a
commercially reasonable time, either replace the product or product component without charge to You
or refund the purchase price (less shipping). This limited warranty is not transferable.
Limitations on the Warranty
This limited warranty does not cover: (a) normal wear and tear; (b) damage through abuse, neglect,
misuse, or as a result of any accident or in any other manner; (c) damage from misapplication,
overloading, or improper installation; (d) improper maintenance and repair; and (e) product alteration
in any manner by anyone other than Us, with the sole exception of alterations made pursuant to
product instructions and in a workmanlike manner.
Obligations of Purchaser
You must retain Your product purchase receipt to verify date of purchase and that You are the original
purchaser. To make a warranty claim, contact Us at 1-800-222-5381, identify the product by make
and model number, and follow the claim instructions that will be provided. The product and the
purchase receipt must be provided to Us in order to process Your warranty claim. Any returned
product that is replaced or refunded by Us becomes our property. You will be responsible for return
shipping costs or costs related to Your return visit to a retail store.
Remedy Limits
Product replacement or a refund of the purchase price is Your sole remedy under this limited warranty
or any other warranty related to the product. We shall not be liable for: service or labor charges or
damage to Your property incurred in removing or replacing the product; any damages, including,
without limitation, damages to tangible personal property or personal injury, related to Your improper
use, installation, or maintenance of the product or product component; or any indirect, incidental or
consequential damages of any kind for any reason.
Assumption of Risk
You acknowledge and agree that any use of the product for any purpose other than the specified
use(s) stated in the product instructions is at Your own risk.
Governing Law
This limited warranty gives You specific legal rights, and You also may have other rights which vary
from state to state. Some states do not allow limitations or exclusions on implied warranties or
incidental or consequential damages, so the above limitations may not apply to You. This limited
warranty is governed by the laws of the State of Minnesota, without regard to rules pertaining to
conflicts of law. The state courts located in Dakota County, Minnesota shall have exclusive jurisdiction
for any disputes relating to this warranty.

Page 12 of 12
Distributed by:
Northern Tool & Equipment Company, Inc.
Burnsville, Minnesota 55306
www.northerntool.com
Made in China
