Roughneck V894CSH User manual

Vicon part number 8006-8935-25-00 Rev 1110
X935-25-00
MODEL V894CSH CORNER-MOUNTED
SERIES OF HIGH- SECURITY CAMERAS
Copyright © 2010 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Loctite is a trademark of Loctite Corporation.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: [phone] FAX: [phone] TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44 (0) 1489 566300 WEB: www.vicon-security.com

X935-25-00 Rev 1110 V894CSH High-Security Cameras FCC Notice •i
FCC Notice
Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a
Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in
strict accordance with the manufacturer’s instruction, may cause interference to radio and television
reception. It has been type tested and found to comply with the limits for a Class A computing device in
accordance with the specification in subpart B of part 15 of the FCC rules, which are designed to provide
reasonable protection against such interference in a commercial installation. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause interference to radio
and television reception, which can be determined by turning equipment off and on, the user is encouraged to
try and correct the interference by one or more of the following measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the
equipment and receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional
suggestions.
The user may find the following booklet prepared by the Federal Communications Commission helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of Documents, Mailstop
SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
Warning: Power must be removed from this unit before removing circuit modules or ribbon cables.
Caution: This unit contains circuit cards with integrated circuit devices that can be damaged by static
discharge. Take all necessary precautions to prevent static discharge.

Contents
Introduction......................................................................................................................... 1
Installation........................................................................................................................... 2
Unpacking and Inspection............................................................................................................................ 2
Physical Installation ...................................................................................................................................... 2
Mounting the Housing ..................................................................................................................................4
Cable Connections.......................................................................................................................................4
Camera/Lens Adjustments ........................................................................................................................... 5
Camera Settings...........................................................................................................................................5
Lens/Autoiris Adjustment ........................................................................................................................... 11
Camera Positioning....................................................................................................................................11
Final Installation Steps...............................................................................................................................12
Maintenance...................................................................................................................... 12
Shipping Instructions....................................................................................................... 12
Coaxial Cable Recommendations................................................................................... 13
Technical Information ...................................................................................................... 14
Vicon Standard Equipment Warranty ............................................................................. 17

Important Safeguards - Indoor Use
GRAPHIC SYMBOL EXPLANATION
The lightning bolt symbol alerts the user to the presence of
dangerous voltage that may present the risk of electric shock.
The exclamation point symbol alerts the user to the presence
of important operating and maintenance instructions.
WARNING
To reduce a risk of fire or electric shock, do
not expose this product to rain or moisture.
1. Read Instructions - Read all safety and operating
instructions before the product is operated.
2. Retain Instructions - Retain all safety and operating
instructions for future reference.
3. Heed Warnings - Pay attention to all product warnings.
4. Follow Instructions - Follow all operating instructions.
5. Cleaning -(Do not use caustic, abrasive or aerosol
cleaners)
a) For units that CAN BE DISCONNECTED from the power
source, use a damp cloth for cleaning.
b) For units that CANNOT BE DISCONNECTED from the
power source, use a damp cloth for cleaning and do not
allow moisture or liquids to enter vents.
6. Attachments - Use only UL Listed Vicon recommended
attachments to prevent unit damage and personal injury.
7. Water and Moisture - Use only products designed for
outdoor environments where they will be exposed to water or
moisture.
8. Accessories - Do not place the unit on an unstable surface
to avoid falling. Use only UL Listed Vicon recommended mounting
accessories.
9. Ventilation - Do not block ventilating slots and openings as
they ensure reliable operation. Do not place the unit near a
heat source or into an enclosure unless recommended by
Vicon.
10. Grounding - Only products equipped with a 3-prong
grounded plug should be inserted into a grounded power outlet.
Contact an electrician to replace an obsolete outlet. Do not
force a plug into a non-grounded outlet.
11. Power Cord Protection - Power supply cords should not
be routed in trafficked areas or in tight spaces where they will
be pinched or used to bear weight. Allow some slack in the
cord where it enters the unit.
12. Lightning - Disconnect the product from its power source
and cable system when possible to prevent damage due to
lightning and power-line surges.
13. Power Lines - Do not locate outside cables over power or
utility lines where they can fall and make direct contact. Contact
with power lines can be fatal.
14. Overloading - Do not overload wall outlets and extension
cords to prevent risk of fire and electric shock.
15. Object and Liquid Entry - Never probe through, or spill
liquid into, enclosure openings to prevent risk of fire or electric
shock.
16. Servicing - Refer all servicing to qualified service
personnel.
17. Damage Requiring Service - Obtain service when:
a) The power-supply cord or plug is damaged.
b) Objects have fallen or liquid has been spilled into the
product.
c) The product is not designed for outdoor use and has been
exposed to water or moisture.
d) The product does not operate per the operating
instructions. Perform Vicon recommended adjustments,
modifications and troubleshooting only to avoid unit
damage and personal injury.
e) The product has been dropped.
f) The product shows a significant change in performance.
18. Replacement Parts - Use only Vicon specified
replacement parts or an approved equivalent to prevent unit
damage and injury.
19. Safety Check - Request safety checks to be performed
following repair or maintenance to verify proper operation.
20. ESD Precaution - Take all normal electrostatic discharge
precautions to avoid component damage during installation and
operation.
21. For 230 VAC Devices Only - When the disconnect device
is not incorporated in the equipment or when the plug on the
power supply is intended to serve as the disconnect device,
follow the guidelines below:
a) For permanently connected 230 VAC units, a readily
accessible disconnect device must be incorporated into
the site wiring.
b) For 230 VAC units with a plug, the outlet must be installed
near the unit and be easily accessible.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Introduction •1
Introduction
The information in this manual provides installation and maintenance procedures for the V894CSH Corner-
Mounted Series of High-Security Camera/Housings. These units should only be installed by a qualified
technician using approved materials in conformance with federal, state, and local codes. Read these
instructions thoroughly before beginning an installation.
The V894CSH is an integrated housing/camera/lens corner-mounted unit. It is constructed of brushed
stainless steel with a polycarbonate plastic window. Each unit is equipped with a high-resolution color
camera, with an isolated power input, and an autoiris varifocal lens. Refer to Table 1 for a list of model
descriptions.
The V894CSH series complies with FCC requirements for a Class A device.
Model Number Product
Code Description
Corner-Mounted
V894CSH-C312/
V894CSH-C312-P 8763-02/ 8763-01 Indoor, high-resolution 1/3-in. color camera with Sony Super HAD II CCD and isolated power input, 3.3-12 mm autoiris varifocal lens,
brushed stainless steel finish; NTSC/PAL
V894CSH-C26/
V894CSH-C26-P 8750-02/ 8750-01 Indoor, high-resolution 1/3-in. color camera with Sony Super HAD II CCD and isolated power input, 2.6-6 mm autoiris varifocal lens,
brushed stainless steel finish; NTSC/PAL
Table 1: Models and Descriptions

2 •Installation X935-25-00 Rev 1110 V894CSH High-Security Cameras
Installation
Unpacking and Inspection
All Vicon equipment is inspected and tested before leaving the factory. It is the carrier’s responsibility to
deliver the equipment in the same condition in which it left the factory.
Inspection for Visible Damage
Immediately inspect the cartons upon delivery. On all copies of the carrier’s freight bill, make a note of any
visible damage.
Make sure the carrier’s agent (the person making the delivery) signs the note on all copies of the bill. If the
agent does not have claim forms, contact the carrier’s office.
Inspection for Concealed Damage
As soon as possible after delivery, unpack the unit and inspect it for concealed damage. Do not discard the
carton or packing materials. If the unit is damaged, contact the carrier immediately and request forms for filing
a damage claim. Make arrangements for a representative of the carrier to inspect the damaged equipment.
If the equipment must be returned for repair, follow the Shipping Instructions at the end of this document.
Physical Installation
The V894CSH series is designed to fit into a corner where two walls and a ceiling meet. It may be fastened to
either or both walls or to the walls and the ceiling. Refer to Figure 1. Cable access is provided on one side.
The camera may be rotated 360º and be tilted slightly to give a higher or lower angle of view. The varifocal
lens allows for lens adjustment capability.
The wall/ceiling material must provide suitable strength to support the weight of the unit (2.75 lb/1.2 kg). Be
sure the area around the selected location is clear of obstacles (such as steel beams, headers, pipes,
electrical wiring, etc.) that would interfere with mounting. Video and power cables must be routed to the
installation location.
Before beginning installation, read the Coaxial Cable Recommendations at the end of this manual and verify
that the accessory pack contains the items listed in Table 2.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Installation •3
Figure 1
Installation Diagram
Item Quantity Function
Rubber grommet 1 Seals cable access hole against dust,
prevents cable abrasion
No. 8 Torx™ bit 1 Use to remove and install tamperproof
screws
No. 8-32 tamperproof Torx screw 2 Supplied as spares
Cable tie mount, adhesive base 3 Secures camera power cables
Cable tie 3 Secures camera power cables
Video focus adjustment cable
(for connection to portable/local
monitor)
1 Video focus adjustment cable
(for connection to portable/local monitor)
Tool for set screw roll adjustment 1 Tool for set screw roll adjustment
Table 2: Accessory Pack Contents
Required tool: The Torx bit that is supplied is designed for a socket or screwdriver-type holder designed for
hexagonal bits.

4 •Installation X935-25-00 Rev 1110 V894CSH High-Security Cameras
Mounting the Housing
The housing consists of two main assemblies, the outer or front cover and the back corner or wall mount
assembly. The front of the housing is secured to the back of the housing with Torx tamperproof screws. A
special tool is supplied in the accessory pack for removing and replacing these screws. When the installation
is complete, retain the Torx bit in case access to the interior of the housing is required later. Two extra Torx
screws are provided in the accessory pack
Note: The camera mounting bracket assembly can be removed if desired. Loosen the self-locking nut and
disconnect the cable at the camera PCB.
There are four (4) 0.22-inch (5.6-mm) holes that are provided for mounting the housing assembly to the wall
and/or ceiling to assure a secure mounting. A 0.750-inch (19-mm) hole is provided for cable access.
1. Remove the front cover. Using the housing back as a template, mark the location of the cable access
opening in the wall and the locations of the mounting screws.
2. Cut the cable opening in the wall. The cable opening diameter should be slightly larger than the outer
diameter of the rubber grommet from the accessory pack. This allows the housing to fit flush against the
wall when installed. Optionally, a conduit fitting (not supplied) can be used.
3. Drill suitable holes for whatever type of hollow-wall hardware has been selected. The use of No. 10
hardware is recommended. Use hollow-wall anchors or, if the housing is being mounted on a sheet metal
surface, use rivet nuts.
4. The cable access hole in the housing accommodates standard cable access fittings as used with
electrical junction boxes. If such a fitting is not to be used, install the rubber grommet from the accessory
pack. The grommet has been split for preterminated coaxial cable. The grommet protects video and
power cables from abrasion and prevents dust from entering the housing through the cable access hole.
5. Pull enough power cable and coaxial cable through the grommet into the housing to allow for convenient
handling during termination.
6. Fasten the housing to the wall with four fasteners appropriate for the mounting surface.
Cable Connections
Power and video connections are pre-connected to the PCB. Refer to Figure 1 and the Coaxial Cable
Recommendations at the end of this manual.
Coaxial Video Cable
1. Attach the customer male BNC connector on the video cable to the mating female BNC connector on the
pendant cable. (Note: Pendant cable is taped to housing for shipping. Remove shipping tape before
making connections.)
2. Push excess coaxial cable back through the grommet and arrange the coaxial cable as desired in the
housing.
Camera Power Connections
Note: Vicon systems and components, like most electronic equipment, require a clean, stable power source.
Voltage irregularities such as surges, drops, and interruptions can affect the operation of your
equipment and, in severe cases, damage certain components.
A UL listed Class 2 power supply with 24 VAC is required for powering the V894CSH camera. Connect the
power cables from the camera to the power source; red is + (plus) and black is – (minus). Push excess wires
through the grommet and arrange in housing as required.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Installation •5
Camera/Lens Adjustments
After all cabling is complete, the camera and lens can be adjusted. The camera/lens is set through an OSD
menu system using a joystick control.
Figure 6
Camera Control Joystick
Camera Settings
There is a joystick control along the rim of the camera that is used to enter the OSD for camera settings. This
is used to navigate the OSD for camera setup. The analog camera must be connected to a portable (local)
monitor to use the menu system; the IP version can see the menus on the PC monitor. Use the cable
included in the accessory kit to connect the spot monitor. Refer to Figure 6.
Pressing the joystick down (Center) accesses the menu mode and confirms settings. Push the Center key for
3 seconds to access the Main menu. From there, using the joystick, select the feature to be programmed.
Moving the joystick up or down chooses the desired menu selection. Moving the joystick to the right or left
chooses the desired menu feature adjustment. (Right direction is marked.) A "indicates submenus.
Below is a summary of the OSD screens for camera setup of the day/night version. An explanation of the
individual screens follows.
2n
d
Video Connector
Joystick
UP
DOWN
RIGHT LEFT
CENTER
RS-232 Serial
Connection
Camera
Connection

6 •Installation X935-25-00 Rev 1110 V894CSH High-Security Cameras
LENS MASK 1
E. SHUTTER MASK 2
BLC MASK 3
MAX_DR MASK 4
AGC MASK 5
SENSE_UP MASK 6
WB MODE SYNC MODE
R-Y GAIN V_PHASE
B-Y GAIN
D&N MODE CAMERA ID
C-SUP TITLE
A-SUP DPC
MONITOR
LANGUAGE
BAUDRATE
OMNI LENS
MIRROR EXIT
SHARPNESS SAVE & EXIT
GAMMA FACTORY SET
FREEZE
NEGA
3D_DNR
D_ZOOM
SLC
HME
DIS
MOTION
SET WINDOW
ALL SET
ALL CLEAR
SENSITI
SHOW INDI
DELAY OUT
9. EXIT
5. MOTION
6. PRIVACY
2. COLOR 7. SYNC
3. DAY&NIGHT 8. SETUP
4. FUNCTION
1. EXPOSURE

X935-25-00 Rev 1110 V894CSH High-Security Cameras Installation •7
Exposure
The Exposure menu allows for the selection of Lens, Electronic Shutter, BLC, Maximum Dynamic Range,
AGC and Sense Up.
Lens
From the Lens screen, select MANUAL for a fixed lens or DC for a varifocal lens. Both choices offer a Level
adjustment (0-99) to adjust the brightness of the lens. (Note: All cameras in this series have an autoiris DC
lens.)
E. Shutter
Electronic Shutter allows the shutter speed to be adjusted from X256 to 1/100,000, including a choice for
flicker mode. In FLK mode, shutter speed is fixed at 1/100 sec to avoid image flicker when there is a
discrepancy between current and frequency. (If MANUAL mode is selected in Lens, this will be AUTO.)
BLC
Backlight Compensation can be turned ON or OFF (default). With BLC ON, iris is adjusted so that a distinctive
subject and background is delivered at the same time. When ON, there are 5 preset areas that can be
customized with sensitivity settings of from 1-256.
Max DR
The dynamic range can be turned ON or OFF (default). With Max DR ON, the picture adjusts when there are
differing light levels in the image. The level can be adjusted from 1-20.
AGC
Automatic Gain Control can be set to LOW, MEDIUM, HIGH or OFF. In a dark environment, when AGC is set
to High, the image becomes brighter. The setting here is related to the setting in Day & Night mode.
Sense Up
Sense Up can be set to X2 to X256 (X4 is default) or turned OFF. When it is on, the camera controls
sensitivity as it automatically detects the light level in dark environments and maintains a clear picture.
Color
The Color menu allows the settings for White Balance Mode and Red and Blue Gain.
WB Mode
The White Balance provides settings of AWC (default), ATW, Manual or Push Lock. AWC mode finds the
optimal setting for the current luminance environment. Use the ATW mode when for viewing objects with
changing color temperature. Holding a piece of white paper in front of the camera, the camera is fixed at the
best color temperature; push the joystick to set and lock. White Balance can be directly adjusted by user in
Manual mode. In that case, select R-Y or B-Y Gain to adjust the value of Red and Blue Gain (125 is default).

8 •Installation X935-25-00 Rev 1110 V894CSH High-Security Cameras
Day & Night
The Day & Night menu allows the selection of the day/night mode as well as color and aperture suppression.
D&N Mode
Day & Night Mode can be set to Auto, Color or Black-and-White. Auto is a true day/night function where the
camera automatically switches between color and b/w depending on the light level. In Color mode, the
camera stays in day mode and in B/W mode, the camera stays in night mode. From D&N mode, select to turn
color Burst ON or OFF in night mode and select the amount of time to switch from color to B/W or B/W to
color. The Read Time setting adjusts the delay time for the filter to switch.
C-SUP and A-SUP
Use these settings to reduce (suppress) the color or aperture settings. For C-SUP and A-SUP to function, 3D-
DNR must be set to OFF. The range can then be set from 0-100 (default is 40); the higher the number, the
more reduction.
Function
The Function menu has settings for Mirror, Sharpness, Gamma, Freeze, Nega (negative), 3D DNR (Digital
Noise Reduction), Digital Zoom, SLC (Side Light Compensation), HME (Highlight Mask Exposure), and DIS
(Digital Image Stabilization)
Mirror
Use the Mirror setting to MIRROR (reverse), FLIP (vertical) or ROTATE the image. These can be turned OFF
(default).
Sharpness
Adjust the sharpness of the image from 0-49 (17 is default).
Gamma
Adjust the gamma level to 0.45 (default), 0.6 or 1.
Freeze
The freeze function can be turned ON or OFF (default). ON allows viewing a still image.
Nega
The nega setting can be turned ON or OFF (default). On reverses the color, appearing as a negative image.
3D DNR
The Digital Noise Reduction function adjusts the illuminance noise level in low light situations. It can be set to
OFF, LOW, MIDDLE (default) or HIGH.
D-Zoom
Digital Zoom can be turned ON or OFF (default). When ON, there are settings for digital zooming up to 3X,
setting pan and tilt positions (left/right or up/down) and turning ON or OFF a display of the PTZ amounts.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Installation •9
SLC
Side Light Compensation can adjust the brightness of the image in the corners of the screen. It can be turned
ON or OFF (default). ON allows settings of 0-50.
HME
Highlight Mask Exposure is ON or OFF (default) selectable. When ON, the camera cuts peak white levels,
masking highlight areas of a scene. This can be adjusted from 1-60.
DIS
Digital Image Stabilization can be turned ON or OFF (default); this would be turned on when the camera is in
an environment of high vibration. This is not available if Max DR is enabled.
Motion
The motion screen permits setting up motion detection areas on the screen with a range of sensitivities.
Motion
Motion detection can be set to ON or OFF (default). This feature allows the detection of movement in 240
areas of the screen and display an alarm on the screen.
Set Window
When motion detection is set to ON, the Set Window screen displays to show the 240 areas. Individual areas
can be selected for motion detection. To exit this screen, navigate to any outermost corner of the screen.
All Set/All Clear
An All Set to select all the areas and a Clear All that deselects all areas can be used.
Sensiti
Each area has an individual sensitivity level of 0-120; a higher sensitivity level detects smaller movement.
Show Indi
After the areas are setup, there is a choice of how motion detection is indicated during live video, icon or
trace. If icon is selected, a small motion icon displays on the screen when motion is detected; trace shows an
overlay of the motion areas on the image to indicate motion.
Delay Out
Delay out of 1-15 sec can be selected, which delays the display of the alarm signal on the screen.
Privacy Mask
Up to six privacy mask zones can be created on the screen to block video that is desired to be hidden.
Privacy masks can be turned ON or OFF (default). When turned ON, the mask range is used to shape and
locate the mask on the screen. One of eight colors of the mask can be selected.

10 •Installation X935-25-00 Rev 1110 V894CSH High-Security Cameras
Sync
Synchronization type, INTERNAL or AUTO (Line Lock), for the camera is selected from this menu.
Sync Mode
Select the synchronization, INTERNAL (default) or AUTO, which is line locked to prevent picture roll when
switching between cameras in multiple camera installations.
V-Phase
If synchronization is line lock, the V-PHASE is selectable from 0 to 299.
Setup
The Setup menus provide for configuration of the Camera ID, Title display, DPC (Dead Pixel Cancellation),
Monitor type, Language of the display, Baud Rate and Omni Lens.
Camera ID
Set up a unique camera identifier. The camera ID is a user selectable title for the camera that is up to 16
characters (default is 0).
Title
The camera title ID display can be turned ON or OFF (default). If turned ON, the title can be edited using the
joystick, reset to clear the title, and positioned on the screen.
DPC
Dead Pixel Cancellation can be set to OFF (default) or AUTO. When this is used, the camera will automatically
remove defective pixels from an image and “fill in” the image. Select the White and Black Threshold from 0-255;
the DPC Level can be adjusted for an overall setting.
Monitor
Select monitor mode, CRT (default) or LCD.
Language
Select language from ENGLISH (default) or KOREAN.
Baud Rate
Select the data communication speed from 2400, 4800, 9600 (default), 14400, 19200 or 38400.
Omni Lens
This camera does not support the Omni lens at this time.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Installation •11
Exit
The Exit menu offers a choice of ways to exit the OSD menu system.
From the Exit menu, select to Exit the OSD menu, Save & Exit to save current settings before exiting the OSD
menu or revert to factory default with Factory Set.
Lens/Autoiris Adjustment
The lens can be manually adjusted for focus and zoom. On the lens, focus [Near∞(Far)] is the front ring
and the zoom (TelephotoWide) is the back ring. A video focus adjustment connector is provided for use with
a portable/local monitor for making adjustment on the camera joystick control. To make the lens adjustments,
loosen the Zoom and Focus lever screws and turn the ring. When adjustment is complete, retighten the
screws.
Note: When adjusting the focus, it is recommended that the iris be completely open (a dark condition, either
at night or using a filter) so that the depth of field does not influence the adjustment.
On autoiris lenses, iris adjustment may be required if the picture appears dark or grainy or has poor color; the
OSD menu selections to improve the picture quality.
Camera Positioning
The camera position can be adjusted in three axes, vertically (tilt), vertical height of the camera/lens assembly
and rotation about the lens axis (roll). Swivel the assembly for tilt position. The vertical height of the
camera/lens assembly can be adjusted by loosening the lock nut, changing the vertical position of the camera
mounting bracket within the slot in the mounting bracket and retightening the nut. The picture may be
“squared up” by rotating the camera about its own axis up to 360° (roll adjustment).
Note: After all adjustments are made, be sure to tighten all bracket screws.

12 •Maintenance X935-25-00 Rev 1110 V894CSH High-Security Cameras
Final Installation Steps
The last installation steps include repositioning the camera and fastening the outer cover in place.
1. If the camera was removed, rotated or tilted during the cable connection, reinstall the camera and adjust
until it is directed at about the center of the black mask on the inside of the housing window. Be certain
the lens doesn’t touch the window when reinstalling the cover. It is best if the picture from the camera can
be viewed on a monitor for this procedure in order to achieve the best positioning of the camera. Make
sure camera is oriented correctly. There is a label with the camera “1800” number on the camera/lens
assembly; this marks the TOP of the camera. Make sure the camera/lens is installed so that the label is
on the top for proper video display.
2. Secure the outer cover with the three (3) tamperproof screws provided. A screw locking compound such
as Loctite™ is recommended. Save the special tool and the two spare tamperproof screws.
Maintenance
The V894CSH requires no maintenance except the occasional cleaning of the housing and window. Use a
soft cloth and plain soap and water. Do not use abrasive cleansers that can scratch the window surface or the
finish on the housing.
Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name
of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: [phone]; Toll-Free: 1-800-645-9116; Fax: [phone]
For service or returns from countries in Europe, contact:
Vicon Industries (U.K.) Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for maximum protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.

X935-25-00 Rev 1110 V894CSH High-Security Cameras Coaxial Cable Recommendations •13
Coaxial Cable Recommendations
Caution: Careful selection of proper cable is essential to obtain the best performance from this equipment. Vicon assumes no
responsibility for poor performance when cables other than those recommended, or equivalent, are installed. In all cases, coaxial cable
impedance should be 75 ohms.
Materials
Use only a pure copper center conductor. Do not use a copper-plated steel or aluminum center conductor, as they will
result in poor quality video. Solid-core bare copper conductor is the best type, where flexing and bending will be minimal.
If severe bending and flexing is required for installation, use a stranded center conductor. Never exceed the
manufacturer’s minimum bend radius specification. Use cellular (foam) polyethylene dielectric except where heavy
moisture exists. For moisture conditions, use solid polyethylene dielectric cable with a heavy exterior insulation. The
shield must be copper braid providing 95% or better coverage.
Cable Types
The cable types listed below are the most common 75-ohm types used. They vary in size (diameter), dielectric type and
net DC resistance. The larger cable results in a lower DC resistance and better video quality, with increased difficulty in
handling and installation. Let the required picture quality and cable distance provide a guide in choosing the best cable
type. For cables other than the approved Vicon types below, contact the manufacturers listed below. Note that “BC” refers
to bare copper and “TC” refers to tinned copper.
Recommended Coaxial Cable Types
Cable
Type Belden Type No. Alpha Type No. West Penn Type No. Type Center Conductor Type Shield and % Coverage DC Resistance ohms/1000 ft (km)
RG-11/U 8213 9847 811,4811 14 Solid BC BC braid (95%) 2.6 (8.5)
RG-6/U 9248 9804C 806,4806 18 Solid BC Foil + 61% TC braid (100%) 7.5 (24.6)
RG-59/U 8281* ---- 815 20 Solid BC 2 TC braids (96%) 9.9 (32.5)
RG-59/U 9259 9803 816 22 Stranded BC BC braid (95%) 15.0 (49)
RG-59/U 9659 ---- ---- 22 Stranded BC BC braid (95%) 15.0 (49)
*Requires special BNC-M connector due to 0.305 nominal O.D.
Belden Inc. http://www.belden.com/ [phone]
Alpha Wire Company http://www.alphawire.com/ (800)-52 ALPHA (522-5742)
West Penn Wire http://www.westpenn-cdt.com/ (800)-245-4964
Picture Quality vs. Cable Length
Picture Quality Maximum Cable Run** ft (m)
RG-59/U RG-6/U RG-11/U
Usable picture 1100 (350) 1500 (450) 2400 (750)
Clean picture 820 (250) 1000 (300) 1600 (500)
Best picture 400 (120) 530 (160) 820 (250)
** For longer cable runs, use a Vicon Video Amplifier to obtain a suitable picture.

14 •Technical Information X935-25-00 Rev 1110 V894CSH High-Security Cameras
Technical Information
ELECTRICAL
Input Voltage: 12 VDC/24 VAC ±20%, isolated input.
Current Rating: 0.11 A @ 12 VDC.
0.18 A @ 24 VAC.
Power Consumption: 1.3 W @ 12 VDC.
2.1 W @ 24 VAC.
Maximum Operating Distance @ 24 VAC:
Wire Size (AWG)
(Annealed Copper Wire) Maximum Distance ft (m)
20 1068 (326)
18 1707 (520)
16 2712 (827)
14 4307(1312)
12 6859 (2091)
Connectors: Power: 2-pin screw terminal block.
Video: BNC on pendant cable.
Certifications: FCC Class A; CE.
OPERATIONAL
Control Display: On-screen, menu-driven system allowing full configuration of
camera.
Tilt and Horizontal Adjustment: 3 axis adjustment, tilt, vertical height of camera/lens and roll
(lens may be rotated on its axis 360º).
Lens Adjustment: Focus: focus lever screw.
Zoom:zoomleverscrew.
OPTICAL
Light Loss through Window: Negligible.
Camera/Lens Specifications: Refer to Table 3.
