Appro SD-7800 User manual

Before trying to connect or operate this product, please read this manual completely
INSTALLATION &
OPERATION MANUAL
Sequentially Rotating Dome Camera
SD-7800

1
CONTENTS
I Before Installing ………………………………….………….………… 2
II Key Features ……………………………………………………. …… 2
III Environmental requirement ………………………………………… 2
IV Dome setting Instruction …………………………………………… 2
Camera ID Setting…………………………………………………………………. 4
Camera Module Setting…………………………………………………………. . 5
V Basic High Speed Dome Operation ………………………………… 6
OSD Operation………………………………………………………………. …… 7
Enter OSD …………………………………………………………………………. . 7
Menu function instructions……………………………………………………… 7
Camera Exposure………………………………………………………………….
7
White Balance……………………………………………………………………… 8
Privacy Mask ……………………………………………………………………… 9
Others of the Camera menu………………………………………………………
.
9
Camera Mode………………………………………………………. . ……………
…
9
Zoom Speed ……………………………………………………………………… 10
Focus Speed ……………………………………………………………………… 10
Pan…………………………………………………………………………………… 10
Shortcut Key………………………………………………………………………… 10
Leisure Time ……………………………………………………………………… 11
VI High Speed Dome Camera Menu…………………………………… 11
SONY Camera module……………………………………………………………
…
11
HITACHI Camera module………………………………………………………… 12
CNB Camera module …………………………………………………………… 13
LG Camera module ………………………………………………………………. 15
VII Analysis on Common Malfunctions and Maintenance… 16

IBefore Installing
 Installation should be carried out only by qualified personnel and in accordance with
any wiring regulations in force at the time.
 Please read this instruction and warnings before installing.
 Do not attempt to service or repair the speed domes as opening or removing covers
may expose dangerous voltages or other hazards. Refer all servicing to qualified
service personnel.
 Adequate protection against lightning strikes and power surges must be installed to
prevent damage to the speed dome.
II Key Features
 360º Panning, speed is 0.1º-300º/s.
 Auto flip 180º
 128 presets, the accuracy of preset is less than 0.1º
 4 dynamic privacy zones (SONY Camera Module)
 Auto cruise by preset, the leisure time is 1s-250s.
 Image freeze while panning
 Manifold of scan, scan speed could be set from 1º/s to 80º/s
 Left limit and right limit scan.
 7 alarm input and 2 relay output.
 Easy fixing configuration
 24V power supply built in
 Static proof and thunder proof design
III Environmental requirement:
Operation Temperature: -40-+60
Humidity: <90%
Air pressure: 86-106Kpa
Power supply: AC24V/2.5A, 50/60Hz
IV Dome setting
Bracket Configure
2

Setting Attention:
Adequate protection against high speed dome falling and damage when installing.
The dome should be hang setting, and please avoid up side down.
Please install the dome at the low humidity condition and keep it sealing for avoiding any damage to
dome.
Please set the power switch correct.
3
Ceiling mount Wall mount
Model NO. MK-1409
Model NO. MK-1410
Communication PCB
Open Up the PCB
PCBLocker
DIP table of Communication PCB board
Note: The PCB can be locked by the PCB locker as the picture showed, and it can be turned
over when do the setting works as below (Please turn the locker to the housing side to
open it):
ThesystemsettingSwitch CameraID
SW1 SW2
Alarm connector 8P Short connector
RS485 communication 2P
AC24V power supply
AUX4P

1、Power supply and
communication cable：
AC24V
AC24V RS485
2、Video output：
Alarm signal
 Alarm Relay Output “AUX1”
 Alarm Relay Output “AUX2
 Alarm Input GND
 Alarm input signal：l -7
AL1、AL2、AL3、AL4…AL7：Alarm input.
The switch setting SW1 ON=1 OFF=0
Protocol setting Baud rate setting Alarm Alarm mode
DIP Switch 1 2 3 4 5 6 7 8
Description
SW1234=0000
(PELCO-D/PELCO-P
Auto identify)
SW5,6=
00=2400
01=4800
10=9600
11=19200
1=Alarm
enable
0=Alarm
disable
1=Always short circuit.
(Alarm while open)
0=Always open circuit.
(Alarm while short)
Note ： PELCOD 、 PELCOP could be identifying automatically. On and off is the corresponding
switch position.
Camera ID Setting:
SW2 switch: address DIP table
CAM ID 1 2 3 4 5 6 7 8
1 OFF OFF OFF OFF OFF OFF OFF OFF
2 OFF OFF OFF OFF OFF OFF OFF ON
3 OFF OFF OFF OFF OFF OFF ON OFF
4 OFF OFF OFF OFF OFF OFF ON ON
5 OFF OFF OFF OFF OFF ON OFF OFF
6 OFF OFF OFF OFF OFF ON OFF ON
7 OFF OFF OFF OFF OFF ON ON OFF
8 OFF OFF OFF OFF OFF ON ON ON
4

CAM ID 1 2 3 4 5 6 7 8
9 OFF OFF OFF OFF ON OFF OFF OFF
10 OFF OFF OFF OFF ON OFF OFF ON
11 OFF OFF OFF OFF ON OFF ON OFF
12 OFF OFF OFF OFF ON OFF ON ON
13 OFF OFF OFF OFF ON ON OFF OFF
14 OFF OFF OFF OFF ON ON OFF ON
15 OFF OFF OFF OFF ON ON ON OFF
16 OFF OFF OFF OFF ON ON ON ON
∶
∶
∶
128 OFF ON ON ON ON ON ON ON
129 ON OFF OFF OFF OFF OFF OFF OFF
130 ON OFF OFF OFF OFF OFF OFF ON
131 ON OFF OFF OFF OFF OFF ON OFF
132 ON OFF OFF OFF OFF OFF ON ON
∶
∶
∶
252 ON ON ON ON ON OFF ON ON
253 ON ON ON ON ON ON OFF OFF
254 ON ON ON ON ON ON OFF ON
255 ON ON ON ON ON ON ON OFF
Note ： The address of the some protocol are from 0, and the others are from 1, please setting
the address(±1) as your protocol.
Alarm
7 alarm input. The dome will alarm when alarm input port connect the GND. The AUX will be closed
when has alarm, and open when no alarm in. The capacitance of the relay is AC24V/1A.
The relay output:
2 relay switch AUX1, AUX2, the biggest capability is AC24V/1A. AUX1 connect with the alarm, the
master or keyboard controls AUX2.
Camera Module Setting Switch
The dome can be fit different camera, and they have different switch
5

Camera Switch 1 Switch 2 Switch 3 Switch 4
DIP-1 DIP-2 DIP-3 DIP-4
SONY OFF OFF OFF OFF
HITACHI OFF OFF ON OFF
LG OFF ON OFF OFF
CNB-200L OFF ON ON OFF
CNB-M1560 OFF ON ON ON
SAMSUNG(SDM300/SDM330) ON OFF OFF OFF
Note: Please make sure the camera parameters are correct or the camera
cannot work or cannot work well. If this, please enter the camera menu
and restore factory settings first, then setting the parameters as
request.
V Basic high speed dome operation
When power on , the version, protocol, baud rate and ID will display on the monitor, and the dome will
automatic self-check both the vertical and level then display the specs of camera.
Example:
High Speed Dome
Ver：1 00
PELCO D P
2400
ID：001
Tile reference OK
Pan reference OK
SONY FCB-EX480CP
The operation by keyboard controller
Function Control
Level / Vertical Joystick left, right / up and down
OSD Confirm OPEN
Cancel and Back CLOSE
OSD Display Call 95 preset
Original Position Call 34 preset
Level Scan Call 99 preset
Auto Flip Call 33 preset
Left limit: call 92 presetLevel Scan Limit
Point Right limit: call 93 preset
Call preset scan 1 Call 81 preset
Call preset scan 2 Call 82 preset
Call preset scan 3 Call 83 preset
Call preset scan 4 Call 84 preset
6

Function Control
Camera mode 1 Call 100 preset
Camera mode 2 Call 101 preset
Camera mode 3 Call 102 preset
4 Privacy mask, only fit to SONY480, SONY980 and SONY1000 camera.
Level area increase: FAR
Level area reduce: NEAR
Vertical area increase: TELE
Privacy Mask
Vertical area reduce: WIDE
OSD Operation
Enter OSD
Please call the number 95 preset to display the OSD on the screen.
At figures the current item, figures the enabled item, and the ►after the item which have
submenu. You can change the item state when it has been enabled. Please press OPEN key to enter
or confirm and CLOSE key to back or cancel, and the key UP and DOWN control the cursor up and
down.
Menu function instructions
Call the number 95 preset to enter the OSD, and you could set the shortcut key to display the OSD.
Main Menu
Camera ►
7
Exposure ►
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
Pan ►
Shortcut Key
Self act Nothing
Leisure Time 030
Camera OSD (SONY)
Camera ►Press Key Open to enter the camera menu.
Camera Exposure
Exp Mode Auto
Shutter speed 006
Iris 016
Exposure ►Press OPEN key to enter the camera exposure
submenu.
Exposure operation
Gain 001
1, How to change the exposure
Bright 016
Back Light Off Exp Mode press OPEN key, enable Exp Mode, then
Slow Shutter Off
operate up and down by the joystick, the parameters
are: Auto, Manual, Shutter, Iris and bright

2, Confirm Exposure.
• Exp Mode press OPEN key, select effect, the menu change to Exp Mode
3, Cancel Exposure
Exp Mode press CLOSE to cancel the Exposure mode change, the menu change to Exp
Mode
Back the main camera menu
• Exp Mode press CLOSE key to cancel the last menu.
Other operation of Exposure Menu
Exp Mode, control the joystick up or down to let the up and down, press OPEN key to
enable the item, then go on control up and down with joystick, and press OPEN key to confirm, the
cursor will change to .
White Balance
The dome has the function of Manual White Balance and Auto White Balance.
White Balance ►press OPEN key, enter the White
Balance submenu, then change the parameter,
Exposure ►
White Balance ►
Privacy ►WB Mode Auto
Other ►R Gain 214(0-255)
Camera Model ►B Gain 175(0-255)
Zoom Speed 005
Focus Speed 001
White Balance Mode operation:
1、WB Mode
8
WB Mode Auto
R Gain 210
B Gain 175
2、At WB Mode, press OPEN key to enable the Exp Mode
menu, then it will change to WB Mode, control the
joystick to change the parameter which order is: Auto,
Manual, ATW, OPW, Outdoor and Indoor. R Gain
WB Mode Auto
R Gain 210
B Gain 175
3, R Gain
At WB Mode, operate the joystick down let the
cursor come to R Gain, press OPER key to enter the menu.
Then operate the joystick up (increase) and down (reduce) the
R Gain. The homologous parameter is 0-255. Press OPEN
key to confirm and back or press CLOSE to cancel and back.
WB Mode Auto
R Gain 210 4, B Gain
B Gain 175
At
WB Mode operate the joystick to control the
cursor come to B Gain,press OPEN key to enter the B Gain
setting, joystick up and down to increase and reduce the
parameter which from 0-255. Press OPEN key to confirm and
back or press CLOSE to cancel and back.

Privacy Mask
Exposure ►
White Balance ►
9
Digital Zoom On
Auto ICR Off
ICR Off
Display Off
Camera Mode Save：
Normal
Day
Night
Camera Mode Exec：
Normal
Day
Night
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
At Exposure ►operate the joystick to let the cursor
come to Privacy press OPEN to enter the submenu, then set
the parameter.
There are 4 privacy masks, which have the same operation
1. How to set privacy mask?
Privacy1
Privacy2
Privacy3
Privacy4
At the submenu of the Privacy, press OPEN key to enter the
adjust image, adjust the privacy zone by OPEN (confirm),
CLOSE(cancel), FAR (level increase), NEAR (level reduce),
TELE(vertical increase), WIDE (vertical reduce). Then press
OPEN key to confirm and back.
2 . How to clear privacy mask?
a, Restart the speed dome, all of the privacy mask will be cleared.
b, Enter the menu of the Privacy mask, press OPEN key to enter and press CLOSE to clear the
privacy mask you want to clear.
Others of the Camera menu
Press OPEN key to enable the submenu, operate joystick to
change the states of ON and OFF. Press OPEN to confirm
and back and CLOSE to cancel and back.
Camera Mode
Exposure ►Camera Mode setting menu:
White Balance ►
Privacy ►
Other ►
Camera Model ►
Zoom Speed 005
Focus Speed 001
Press OPEN to enter the menu.
There are three save mode under the Camera Mode Save
menu, move the cursor to the mode going to be change,
press OPEN the cursor will change to , the setting will be
saved and it will back to after 1 second.
The three items under Camera Mode Exec is opposite the
three modes above. Move the cursor to the mode you want
to call and press OPEN to confirm and back. The saved mode
could be called by the shortcut preset: Normal---call 100 preset; Day --- call 101 preset; Night --- call

102 preset
Zoom Speed
At the submenu of Exposal, move the cursor to Zoom Speed, press OPEN, the cursor will change
to , then the parameter can be changed. Press OPEN to confirm and back or CLOSE cancel and
back.
Focus Speed
Move the cursor to Focus Speed, press OPEN, the cursor will change to , then the parameter can
be changed. Press OPEN to confirm and back or CLOSE cancel and back.
Pan
This operation can control the home place of the dome,
adjust the auto panning speed and 4 cruise line with presets,
also the auto flip function.
Home place Of
f
AS speed 060
PS1 Speed 120
PS1 time 005 Home Place OFF (001-032, OFF)
PS2 Speed 120 AS Speed 060(000-080) Auto Pan speed
PS2 time 005
PS3 Speed 120 PS1 Speed 120(100-120) Presets cruise 1 speed
PS3 time 005 PS1 Time 005(5-120) ) Presets cruise 1 stop time.
PS4 Speed 120
PS4 time 005 PS2 Speed 120 Presets cruise 2 speed
Auto Flip On PS2Time 005 Presets cruise 2 stop time.
PS3 Speed 120 Presets cruise 3 speed
PS3 Time 005 Presets cruise 3 stop time.
PS4 Speed 120 Presets cruise 4 speed
PS4 Time 005 Presets cruise 4 stop time.
AutoFlip On(On/Off)
Shortcut Key
The functions can be setting by presets number, and can be called by the preset number which be
set.
Note: The right side number is the default short cut key, they are the number of presets. The
number can be saved by new shortcut but the old one will not be cancel.
Example: Change the number 095 into 16 that after Open Menu, the Menu can be called by 16 preset,
Open Menu 095
Auto Flip 033
Reference 034
Left Limit
10
092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Auto Scan 099
Camera ►
Pan ►
Shortcut Key
Self act Nothing
Leisure Time 030
and also can be called by 95 preset.
In the presets, the preset scan line 1 will cruise from presets
1-8, and preset scan line 2 will cruise from presets 9-16, the
preset scan line 3 will cruise from presets 17-24, and the
preset scan line 4 will cruise from 25-32. Every line will back
the first preset when it met the point never be set, and it will
quit cruise if the first preset is not be set. The function Auto
Scan is right and left limit scan.
Note: The changing of the shortcut key can not be identical
with the shortcut key already have.
Operation: Move the cursor to the item which going to be
changed, press OPEN, then change the parameter, press
OPEN to confirm and back or CLOSE cancel and back.
Self Act.
The dome will check itself when electric and it will act the
program automatic.

Nothing
P Scan 1 Preset scan 1
P Scan 2 Preset scan 2
P Scan 3 Preset scan 3
P Scan 4 Preset scan 4
A Scan Auto scan (left and right limit scan
Home Homeplace
Operation: Press OPEN the cursor will change to , and the parameter can be change. Press OPEN
to confirm and back or CLOSE to cancel and back.
Leisure Time
Camera ►
11
Pan ►
The dome will back to the home place after a while if it is
moved manually, and the time is Leisure Time
Shortcut Key
Self act Nothing The parameter is from 1-240.
Leisure Time 030
Operation: Press OPEN the cursor will change to , and the
parameter can be change. Press OPEN to confirm and back
or CLOSE to cancel and back.
VI High speed dome camera menu
High speed dome with SONY CAMERA MODULE MENU
Menu Submenu Third Menu Parameter
Exp Mode Auto（Auto，manual；shutter，iris，bright）
Shutter speed 006(0~19)
Iris 015(0~17)
Gain 001(0~15)
Bright 015(0~18)
Back Light OFF(ON/OFF)
Exposure
Slow Shutter OFF(ON/OFF)
WB Mode Auto( Auto，Manual；ATW，OPW，Outdoor，Indoor)
R Gain 210(0~255)
White Balance
B Gain 175(0~255)
Privacy1
Privacy2
Privacy3
Privacy
Privacy4
Digital Zoom On(On/ Off)
Auto ICR Off(On/ Off)
ICR Off(On/ Off)
Other
Display Off(On/ Off)
Camera Model Save：
Day Mode
Night Mode 1
Night Mode 2
Camera Model Exec
Day Mode
Night Mode 1
Camera
Camera Model
Night Mode 2

Menu Submenu Third Menu Parameter
Zoom Speed 005(001~007)
Camera
Focus Speed 001(001~007)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Shortcut
Key
Auto Scan 099
Self act Nothing (Nothing , Home ,P Scan 1,P Scan 2,P Scan 3 ,
P Scan 4, Pattern 1, Pattern 2, Pattern 3)
Leisure 030(001~014)
High speed dome with HITACHI CAMERA MODULE MENU
HITACHI Camera module OSD Operation way:
FAR Confirm NEAR Cancel and Back
Joystick Control the cursor up and down or setting the parameters
►Which have submenu, and press FAR key to enter.
Currently menu.
Menu Submenu Third Menu Parameter
Exposure Exp Mode Auto(Auto/AE DSS)
Back light Off(On/Off)
BLC Level 016
Iris
091(000～255)
White Balance WB Mode Auto(Auto/Manual)
R Gain
652(640～767)
Camera
B Gain
462(384～511)
12

Menu Submenu Third Menu Parameter
Lens Digital Zoom On (On/Off)
D
Zoom MAG mag12(mag 0～mag12)
Zoom Speed High(High,Super h,Normal)
Camera
Focus Speed 016(0～31)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Shortcut
Key
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Shortcut
Key
Auto Scan 099
Self act Nothing (Nothing , Home ,A Scan,P Scan1,P Scan2,P Scan3,
P Scan 4, Pattern1,Pattern2,Pattern 3)
Leisure 030(001~014)
High speed dome with CNB CAMERA MODULE MENU
CNB Camera module OSD Operation way
NEAR Exit FAR Confirm
TELE Control the cursor up and
setting the parameters WIDE Control the cursor down and setting the parameters
CLOSE Quite camera menu and back.
Currently menu
13

14
Menu Submenu Third Menu Parameter
BACKLIGHT OFF(ON/OFF)
SLOW
SHUTTER FLD24(OFF , FLD2, FLD 4, FLD 8, FLD 12, FLD 16,
FLD 24, FLD 32, FLD 64, FLD128)
DAY/NIGHT AUTO(ON,OFF,AUTO)
WB CONTROL AUTO(AUTO/PUSH)
SHUTTER AUTO
CAMERA ID 000(000～255)
ZOOM START X001(x001～X022)
ZOOM STOP
X220(X220,X209,X198,X187,X176,X165,X154,X143,
X132,X121,X110,X098,X088,X077,X066,X055,
X044,X033,X022,X011,X001)
BRIGHTNESS
10(0～15)
SHARTNESS
25(0～48)
FOCUS PUSH(PUSH/AUTO)
Camera
INIT SET OFF(ON/OFF)
Home place OFF(001-032,OFF)
AS speed 060(000-080)
PS1 Speed 120(100-120)
PS1 time 005(005-120)
PS2 Speed 120(100-120)
PS2 time 005(005-120)
PS3 Speed 120(100-120)
PS3 time 005(005-120)
PS4 Speed 120(100-120)
PS4 time 005(005-120)
Pan
Auto Flip On(On/Off)
Open Menu 095
Auto Flip 033
Reference 034
Left Limit 092
Right Limit 093
Preset scan 1 081
Preset scan 2 082
Preset scan 3 083
Preset scan 4 084
Shortcut
Key
Auto Scan 099
Self act Nothing (Nothing , Home ,A Scan,P Scan1,P Scan2,P Scan3,
P Scan 4, Pattern1,Pattern2,Pattern 3)
Leisure 030(001~014)

High speed dome with LG CAMERA MODULE MENU
LG Camera module OSD Operation way
NEAR Confirm or decrease the
parameter FAR Confirm or increase the parameter
TELE Up WIDE Down
NOT USE Can’t be use Have submenu and back
FUNCTION OSD Format Description Remarks
Non display Auto Mode
1 Focus Mode
Manual/ Push Auto mode
Non display Back Light OFF
2 Back Light “BL’’display BLC ON/ Auto BLC Mode
Non display Normal Shutter：NTSC：1/60
PAL：1/50
“F1”display Flickerless Mode
3 Shutter
Speed 1/125
：
：
1/10，000
28 variable steps
4 Motion
Detect MOTION DETECTED Display when motion
is detected
5 STAND-BY
Mode Indicate the camera stand-by during the camera’s power turning on
DX270 Digital Zoom Model
6 Zoom
Display X27 Optical Zoom Model
7 CAMERA ID According to write the identification number to each camera,
multi-point control is available are available (PC Control 000-255)
AWB White Balance Auto
SWB
Special Auto White Balance; Adjustment Mode
according to change of external illuminant. RED
ADJUST and BLUE ADJUST (0-255) are
available. After changing R/W value, the
maintenance mode is AUTO.
WB Preset for Indoor
WB Preset for Outdoor
Manual WB Adjustment; In manual mode the
HUE control is available 0-99
8 WBC Mode
PWB
Push Auto White Balance; Turn this mode ON,
the white trace automatically. Turn this mode
OFF, preserve the white of final auto tracing
action (Manual)
15

The Menu shortcut List of HIGH SPEED DOME WITH LG
Main Submenu Last Menu Parameters(optical)
Exp Mode Auto（Auto，manual；shutter up，iris，bright）
Shutter speed 006(0~19)
Iris 015(0~17)
Gain 001(0~15)
Bright 015(0~18)
Back Light OFF(ON/OFF)
Exposure
Slow Shutter OFF(ON/OFF)
WB Mode Auto( Auto，Manual；ATW，OPW，Outdoor，Indoor)
R Gain 210(0~255)
White Balance
B Gain 175(0~255)
Privacy1
Privacy2
Privacy3
Privacy
Privacy4
Digital Zoom On(On/ Off)
Auto ICR Off(On/ Off)
ICR Off(On/ Off)
Other
Display Off(On/ Off)
Camera Model Save：
Day Mode
Night Mode 1
Night Mode 2
Camera Model Exec
Day Mode
Night Mode 1
Camera Model
Night Mode 2
Zoom Speed 005(001~007)
Camera
Focus Speed 001(001~007)
High speed dome with SUMSUNG CAMERA MODULE MENU
OPEN Confirm (SET) JOYSTICK Cursor Up/ Down
NEAR Control the cursor Up/Right
to change the parameter
FAR Control the cursor Down/ Left
to change the parameter
►Currently menu（You can change the parameter only when at the currently
menu）
Which have submenu, and press OPEN key to enter
16

Attention and operation advice for Samsung camera module.
Enter the Camera menu:
MAINSETUP
►CAM TITLE ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
SPECIAL
RESET
EXIT
CAM TITLE
ABCDEFGHIJKLMNO
1. CAM TITLE
PQRSTUVWXYZabcd
efghijklmnopqrs
tuvwxyz01234567
89 ( )<>-/#!?, .
17
←→ CLR POS END
_ _ _ __ _ _ __ _ _ __ _ _ __ _
ATWSETUP
►MODE SEL OUTDOOR
Press SET to Return
2, WHITE BAL
Please chose AWC-SET mold when at these situation
below:
 The scenes have high COLOR TEMP things, for
example the sky or setting sun.
 Caliginous scenes.
 The camera point to the fluorescent lamp.
3, BACKLIGHT
WDRSETUP Attention:
►WDR LIMIT MIDDLE
 If the SHUTTER setting as MANUAL, the WDR function
can not use.
 Please pay attention with the brightness of the monitor
when setting the parameter.
Press SET to Return  Add WDR may induce the abnormality.
 Please do not use WDR when at these condition:
abnormally color appears; ripple showed at the bright part.
4, MOTION DET
MOTION DETECTION
Attention:
►SENSITIVITY 50
 Please confirm if the camera could work normally
after every adjust
 This function will not working if the bright light
coruscates.
Press SET to Return
 The other function will carry out more time if this
function opens.

5. EXPOSURE
18
EXPOSURE SETUP
►BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC MIDDL
SSNR MIDDL
SET SHUTTER .
SENS-UP AUTO
END
►SHUTTER 1/60
Press SET to Return
SHUTTER:
Attention:
 When setting the BACKLIGHT as OFF, the A.FLK will show the best effect.
 If camera setting as ESC, the image will not steadily when fact to the high light.
 Can not use WDR when setting as MANUAL.
 SEND-UP will can not use if under the MANUAL and A.FLK mode.
6. SPECIAL
SPECIAL SETUP
►USER PRESET OFF
PRIVACY OFF
DAY/NIGHT COLOR
SYNC INT
FREEZE OFF
H-REV OFF
V-REV OFF
IMAGE ADJ
COMMUNICATION
EXIT
COMMUNICATION
Attention:
The COMMUNICATION parameter are setting previous, please do not change the parameters if
not sure, or it will induce the camera abnormally.
