Roule RL-B17F User manual

USER MANUAL
COLOR VIDEO DOORPHONE
MODEL:RL-B17F
Version 1.1
Product Description...................................1
Features.....................................................1
Package Contents......................................1
Safety Instruction.......................................2
System Installation.....................................2
Operation Instruction.................................6
Technical Specifications............................8
Trouble Shooting.......................................10

Safety Instruction
Product Description
The RL-B17F color video doorphone can be used to monitor, call, intercom
and unlock.It is a product that is very suitable for villa, single house, hotel,
office and etc, giving you the combined benefit of security and
convenience.
1) 7" TFT s creen w ith lo w p ower c onsumption, n o r adiation a nd h igh d efinition.
2) Ultra-thin designed indoor unit with touch keys which leads the new trend of
color video door phone.
3) Waterproof, damage-proof, oxidation-proof and abrasion-proof metal alloy
panel outdoor unit.
4) Electrically controlled lock release function.
5) Outdoor gate lock release function.
6) Monitor the outdoor.
7) Talking volume,brightness and chroma can be adjusted.
8) Enclosed with an adapter and 15m cable for DIY installation.
9) Indoor unit can be hung on the wall.
10) 16 chord melodies for option.
Features
Package Contents
12
Caution
·Keep the indoor unit away from high temperature such as near an oven or
under direct sunlight, and high humidity such as bathroom and greenhouse.
·Do not install the indoor unit close to a television or position with strong
jamming- the signals the TV and the intercom use can be interfered with
each other.
·Do not touch the unit with wet hands.
·Avoid throwing, dropping or hitting the units.
·Clean the camera or screen with a soft cloth. Do not use detergent,thinner,
volatile or corrossive liquid.
·Do not expose the camera of the outdoor unit to direct sunlight.
·Use the product under the circumstance of barrier-free and no inteference.
·When a car or a motorbike passes by, the image may become blurred or be
cut off due to the interference of radio wave.
2
System Installation
A. Indoor Unit
1) Fasten the bracket of the video indoor unit on the wall with screws.
Adopt 4 x 40PM screws to install it on 86 box.
Adopt 4 x 30BA screws to install it on the wall.
2) Hang the unit on the bracket after finishing the connection. Plug the
enclosed adapter into the sockets of AC power and the unit.
1. To prevent damage, the adapter should be fastened on the wall according
to instruction.
2. Power plug as disconnecting device should be kept convenient to operate.
·Bracket x 1
·Adapter x 1 ·15m Cable x 1 ·Screw pack x 1
63mm 1 2
Bracket
·Indoor Unit x 1
·Outdoor Uni t x 1 ·Rain Shade / Ob l i que Base
(Eithe r - o r)
(Ob lique B ase )
(Ra in Shad e)

B. Outdoor Unit
1) Rain shade
14 0 -170mm
1
96mm
36mm 2-1 2-2
43
5
14 0 -170mm
1
12 9 m m
50 m m
2-1 2-2
43
5
5. Finally seal the screw holes with enclosed silicone caps.
3. Connect the wires according to the wiring diagram.
4. Fix the outdoor unit into the rain shade and fasten the bottom with screws.
(Screw size: 2.6x8BA)
2. Drill three holes in proper size in the wall and fasten the rain shade on
the wall with screws.(Screw size: 4x40FA)
1. Install the outdoor unit at the height of 1.4m~1.7m up from the ground
and avoid direct sunlight and rain.
2) Oblique base
1. Install the outdoor unit at the height of 1.4m~1.7m up from the ground
and prevent direct sunlight.
2. Drill two holes in proper size in the wall and fasten the oblique base on
the wall with screws.(Screw size: 4x40FA)
3. Connect the wires according to the wiring diagram.
4.Fix the outdoor unit into the oblique base and fasten the bottom with screws.
(Screw size: 3x10FM)
5. Finally seal the screw holes with enclosed silicone caps.
4
3
46°

6
5
Operation Instruction
Indoor Unit
C. Wiring Diagram
Cables:
1.Audio wire
2.Ground wire
3.Video wire
4.Power wire
Outdoor Unit
Electronic-lock
Indoor Unit
Gate Unlock
12
34
AC100-240V
50HZ/60HZ
DC12V
111 222
333444555666777888
Connect the electric lock with indoor unit
Cables:
1.Audio wire
2.Ground wire
3.Video wire
4.Power wire
Outdoor Unit
Electronic-lock
Connect the electric lock with indoor unit
12
34
AC100-240V
50HZ/60HZ
DC12V
111 222
333444555666777888
+ -
AC 10 0- 24 0V
50 HZ /6 0H Z
DC 12 V
Power
Gate Unlock
Wiring Requirement
1) Generally please use 15m cable to connect indoor unit with outdoor unit.
2
2) RVV4 x 0.5mm connecting wire can be chosen if you want to lengthen it
to 15~50m.
2
3) RVV4 x 0.75mm connecting wire can be chosen if you want to lengthen
it to 50~100m.
2
4) Use RVV2 x 1.0mm connecting wire for the electric-lock.Connect the
wiring terminal 1,2,3,4 of indoor unit with the wiring terminals 1,2,3,4 of
outdoor unit respectively. The wiring terminals 5 and 6 of indoor unit are
2
connected to electric-lock through RVV2x1.0mm wire. The wiring
terminals 7 and 8 of indoor unit are connected to gate lock through
2
RVV2x1.0mm wire.Please refer to the wiring diagram during
connection.
Please choose only one connecting method to do the connection. The
electric lock can be connected either with the indoor unit or with the
outdoor unit. Connecting the electric lock with both the indoor and
outdoor unit at the same time is prohibited.
Melody (L/M/H)
Melody Selection
Brightness
Chroma
Volume
Wiring
Terminal
Speaker
Monitor
Unolock
Microphone
Gate Unlock
Talk

7
Technical Specifications
Indoor Unit
8
Screen Size
Resolution
Effective Area
Outline Size
Adapter Input Voltage
Working Distance
Power Consumption
Operating Temperature
Talking Time
Ralative Humidity
Monitor time
Adapter Output Voltage
&Current
AC100-240V 50Hz/60Hz
DC12V 1100mA
800(H) x 3(RGB) x 480(V)
154.08mm(H) x 85.92mm(W)
215mm(W) x 152mm(H) x 18mm(D)
Static State<0.5W,
Working State<8W
10%～90%（RH）
120S±10%
2
50m(4×0.5mm )
-10℃～+40℃
7
40S±10%
1) Press CALL button of outdoor unit to call. The doorbell will ring and the
images of visitors will be shown on the indoor unit. Press TALK ( ) to
activate the intercom. Press TALK ( ) again to disconnect. Each talking
time lasts for about 120 seconds.
2) Press UNLOCK ( ) button to release the electric door lock.
3) Press GATE UNLOCK ( ) button to release the outdoor gate.
4) Press MONITOR ( ) button to monitor the outdoor. The monitoring time
is about 40s.
5) After you press the MONITOR ( ) button, you can press the TALK
( ) button to talk with the person at the gate while monitoring outdoor.
Then you can press the TALK ( ) button to end monitor and intercom.
6) Turn the adjust knobs ( ), ( ) and ( ) on the side of indoor unit to
adjust the brightness,chroma and talking volume.
Outdoor Unit
Microphone
Camera
LED Light
Call
Speaker
Rain shade

9
Trouble Shooting
Problem
No Picture/Signal
·Make sure all the connections are secure and
properly connected.
·Make sure your monitor is plugged into a power
source.
·Make sure there is nothing obstructing the view
o f t he c amera.
Solutions
No Picture,
but intercommunication
is normal
No audio when calling
The outdoor unit cannot
call the indoor one
Door Unlock not
Functioning
No one can hear me
outside but I can hear
them after calling
No one can hear me
outside but I can hear
them when monitoring
·Make sure all the connections are secure and
properly connected.
·Make sure there is nothing obstructing the view
of the camera.
·Make sure the volume noch on the indoor unit is
turned up.
·Make sure there is nothing interfering with
the speaker or microphone on the indoor unit
or the camera.
·Make sure all the connections are secure and
properly connected.
·Make sure all the connections are secure and
properly connected.
·Make sure the connections with the locks are
secure and properly connected.
·Make sure you have the lock wired to a power
source which is enough to make it operate.
·Press TALK key for two-way intercom.
·Make sure all the connections are secure and
properly connected.
·Press TALK key for two-way intercom Since
simple touch MONITOR allows you to see and
hear outside but prevents the outside from
hearing you
·Make sure all the connections are secure and
proper ly connected
10
Outdoor Unit
Effective Distance
Operating Temperature
Resolution
Viewing Angle
Outline Size
about 1M
-15℃～+50℃
about 700TV lines
46±1°
130(H)x51(W)x47(D) mm
