Routline V10 User manual

OPERATING MANUAL
V10 / V15
Point-source kit for all purposes

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
2
CONTENTS
1. SAFETY REGULATIONS ..................................................................................................... 3
1.1. DISPOSAL OF WASTE MATERIALS...............................................................................................................3
1.2. CONFORMITY AND WARRANTY ...................................................................................................................3
2. SYSTEMS’ DESCRIPTION .................................................................................................. 4
2.1. VEGAS 10 AND VEGAS 15 .............................................................................................................................5
2.2. SUB 118 - SP12/SP23 ...................................................................................................................................6
3. WIRING ............................................................................................................................. 7
3.1. CONNECTORS SPECIFICATIONS .................................................................................................................8
3.2. CABLES AND PICTURES ..............................................................................................................................9
4. AMPLIFICATION ................................................................................................................ 10
4.1. DSP AND CONTROL THROUGH PC .............................................................................................................11
5. PRESETS AND USES ......................................................................................................... 13
6. ADDITIONAL ELEMENTS................................................................................................... 16
7. PERIODIC CONTROLS ....................................................................................................... 19
7.1. FUNCTIONAL CHECKS.................................................................................................................................19
7.2. PERIODIC CHECKS .......................................................................................................................................19
8. SPARE PARTS ................................................................................................................... 20
9. TECHNICAL SPECIFICATIONS........................................................................................... 22
9.1. VEGAS 10 ......................................................................................................................................................22
9.2. VEGAS 15 ......................................................................................................................................................24
9.3. SUB118 SP ...................................................................................................................................................26
APPENDIX: PERIODIC CHECKS ............................................................................................... 27

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
3
1. SAFETY REGULATIONS
Welcome to the Outline world! Congratulations on
choosing the Outline V10/V15 kit as your sound sy-
stem. We suggest you dedicate some time to rea-
ding this manual in order to get to know this product
in depth and ensure you make the most of its use.
It is important to remain at a suitable distance from
the sound reinforcement system, particularly when
it is used at high spl.
The V10 and V15 kits have been designed for me-
dium-small venues, but due to their high perfor-
mance, they could cause hearing damage.
The safety precautions to follow are:
• The installation of the kits requires that the per-
sons involved are aware of the safety procedures
to follow in this kind of situations;
• It is not recommended to use any material not
expressly provided for by Outline
• Protect the electrical parts dedicated to amplifi-
cation, especially in case of risk of contact with
rain or high humidity;
• Safeguard and protect the point-sources of the
kit in case of prolonged contact with rain or hu-
midity.
Outline declines any and all responsibility for da-
mage or faulty operation caused by using the kits
in a different way from that expressly foreseen and
specied:
• uncertified or unauthorized modification to any
part of the system can damage the system, com-
promising its real efficiency and safety
• always make sure to check the conformity and
good condition of the stands, tripods, supports,
support surfaces and everything concerning the
stability and safety of the system;
• it is advisable to carry out periodic inspections/
checks and any necessary maintenance of the
systems, cables and the amplifiers before using
them. In the event of wear or accidental damage
of the components, Outline will provide specific
support for their replacement;
• frequently check the conditions and correct ope-
ration of the tripods, wheelboards and other
fixing accessories.
Since the system is equipped with loudspeakers/
transducers that produce a static magnetic field, it is
strongly advisable to keep any electronic devices or
magnetic media of any type (computers, hard disks,
magnetic card, etc) at a suitable distance (approxi-
mately 1 metre) from the loudspeakers.
1.1. DISPOSAL OF WASTE MATERIALS
The product is designed and manufactured
with high quality materials and components,
which can be recycled and reused. When this
symbol of the crossed “wheelie” bin is atta-
ched to a product, it means that the product is cove-
red by the European Directive 2012/19/EU and sub-
sequent amendments. This means that the product
must NOT be disposed of with other household-type
waste.
Users are responsible for the disposal of their
electric and electronic equipment, consigning it to
an approved disposal facility. For further informa-
tion on where it is possible to send equipment for
recycling, contact your local distributor. Correct di-
sposal of the old product will help to prevent poten-
tial negative consequences for the environment and
people’s health.
1.2. CONFORMITY AND WARRANTY
All Outline electro-acoustic and electronic
devices are in conformity with the provisions
of EC/EU directives (as stated in our CE de-
claration of conformity).
The CE declaration of conformity is attached to the
product warranty certificate and is shipped with the
product.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
4
2. SYSTEMS’ DESCRIPTION
The V10 and V15 kits are the result of an in-depth
study made to obtain the most extensive and detailed
possible coverage, in full Outline style, maintaining
a compact, optimized, easy-to-use and to transport
system.
More specifically, these sound systems are cha-
racterized by an integrated and autonomous ampli-
fication system, implemented in the cabinet of the
subwoofer, with enclosed audio and power cables,
ready for use in the so-called “plug & play” formu-
la. The loudspeaker system includes three different
point-sources, all manufactured by Outline.
In detail:
Wheelboard-01
NL2FX/NL2FX
loudspeaker cable
Vegas10 Sub118-SP23 Vegas10
Powercon True1 IP65
power cord (EU)
The two kits are going to be illustrated and explained in full detail in this manual, by going into their compo-
nents’ properties and sound performance features. This information will be helpful to better understand the
appropriateness of the kits depending on their intended use.
• The
V10
kit contains two
Vegas 10
and one self-powered
Sub118 - SP23
, two audio speakON cables
NL2FX/
NL2FX
(10 m), one power cord
Powercon True1/Powercord
(EU) and one wheelboard;
Wheelboard-01
NL2FX/NL2FX
loudspeaker cable
Vegas15 Sub118-SP12 Sub118-SP12
Powercon True1 IP65
power cord (EU)
Vegas15
speaker
poles
• The
V15
kit contains two
Vegas 15
and two self-powered
Sub118 - SP12
, two audio speakON cables
NL2FX/
NL2FX
(2 m), two power cords
Powercon True1/Powercord
(EU), two speaker poles and two wheelboards.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
5
Two point source models are used as the systems’
satellites: Vegas 10 for the V10 kit and Vegas 15 for
the V15 kit.
These two-way loudspeaker systems from Outline
Vegas series differ in the dimensions of the mid-low
frequency woofer (10’’ or 15’’). Indeed, for the high
frequencies, they both mount the same 1.75’’ com-
pression driver loaded on a rotatable horn. This fea-
ture enables to use the enclosure both vertically and
horizontally depending on the needs.
The Baltic birch plywood cabinet, with two bass-
reflex ports of the same material, allows to achie-
ve an excellent performance by the speakers, free
from internal vibrations and resonance that could
compromise the final result. Its particular shape,
together with the rotatable horn mentioned above,
enables it to be also used on the ground as a stage
monitor.
The cabinet is painted with a layer of black polyurea
paint to protect the enclosure from wear over time.
The front grille, with sound-transparent foam, gua-
rantees protection against dust (and other external
agents) for the speakers and internal components.
The pole mount socket enables to use the enclosure
with poles and tripods. More info in chapter 9.
2.1. VEGAS 10 AND VEGAS 15
The internal passive crossover filter, manufactured
with very low resistance metallized polypropylene
capacitors, guarantees the best possible sound per-
formance.
The horizontal dispersion of 80/90° and the vertical
dispersion of 70° ensure an even and complete co-
verage (see chapter 5). The frequency response for
the two Vegas models ranges between the crossover
values chosen respect to the Sub118 SP and 20 kHz.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
6
2.2. SUB 118 - SP12/SP23
Sub118-SP12/SP23 is the self-powered subwoofer
for the reproduction of the low frequencies in the V10
and V15 kits. Its single 18’’ neodymium direct radia-
tion woofer with dedicated bass reflex ports ensures
a frequency response down to 35 Hz.
Its design and low overall weight (47 kg) allow easy
maneuverability. The Baltic Birch plywood cabinet in
fact, in addition to ensuring resistance and control
even at high vibration levels, has a number of hand-
les that can also be used to lock the subwoofer with
the wheelboard for transport.
The curved front grille guarantees additional pro-
tection of the woofer, without compromising in any
way its acoustic performance and without interefe-
ring with the ergonomics of the handles. Lastly, the
M20 threaded points allow the use of the subwoofer
with loudspeaker poles for Outline satellites such as
Vegas 10 or Vegas 15.
The difference between the two models of the Sub118
- SP12 and SP23 - regards the electronics part and
the connection panel of the dedicated amplifier mo-
dule (chapter 4). A passive version of the subwoofer
is also available.
Further information at
outline.it
CLIP/TEMP
SIGNAL
STATUS
FLAT
BASS BOOST
LOUDNESS
PRESENCE
PRESET
SELECT
+6
0
-∞
INPUT 1 INPUT 2
TO SATELLITE 1 (1+/1-) TO SATELLITE 2 (1+/1-)
OUTPUT 2
INPUT OUTPUT
MODEL
& S.N°
TESTED WEIGHT
www.outline.it
MODEL
& S.N°
TESTED WEIGHT
www.outline.it
Made in Italy
LOUDSPEAKERSYSTEM
CA UTION
Risk of electric shock. Do not open. To reduce
re or electric shock risks, do not expose this
equipment to rain or moisture.
AMPLIFIED SIGNAL OUTPUTS
MAINS
POWER
SPECIFIC.
50/60 Hz
115/120 V AC 230/240 V AC
50/60 Hz
CONSUMPTION
MAINS OUTPUT
AUTO SELECT 100/240 V~ 50-60 Hz
OUTPUT 1
3
2 1
X L R P O L A R I T Y
1= S H I E L D
2= H O T
3= C O L D
CONN.
SECT. LOAD
SIGNAL INPUTS & PROCESSING
CONN.
SECT. LOAD
1+ / 1- OUT 1 1 x VEGAS 10
1+ / 1- OUT 2 1 x VEGAS 10
www.outline.it
S.N°: KKKF T514
MODEL: O1ESUB118-SP23
TESTED
WEIGHT : XX kg (ZZ lb)
POWER
SPECIFIC.
50/60 Hz
115/120 V AC 230/240 V AC
50/60 Hz
CONSUMPTION
MAINS OUTPUT
6 A 3 A
10 A 10 A
www.outline.it
V10-KIT1
S.N°: WWW AB176
TESTED
MODEL: Y V10-KIT1
Sistema 12 kW composto da due Moduli da 2 elementi da 6 kW (order
(da abbinare ad un altro modulo per completare un sistema L + R)
Sistema L + R con gittata 25 mt, copertura 90°; due di questi sistemi possono coperire un’area di
CLIP/TEMP
SIGNAL
ST ATUS
FLAT
BASS BOOST
LOUDNESS
PRESENCE
PRESET
SELECT
+6
0
-∞
INPUT LINK
INPUT OUTPUT
MODEL
& S.N°
TESTED WEIGHT
www.outline.it
MODEL
& S.N°
TESTED WEIGHT
www.outline.it
Made in Italy
LOUDSPEAKERSYSTEM
MAINS
SIGNAL INPUT & PROCESSING
OUTPUT
AMPLIFIED SIGNAL OUTPUT
TO SATELLITE
1-
1+
CAUTION
Risk of electric shock. Do not open. To reduce
re or electric shock risks, do not expose this
equipment to rain or moisture.
POWER
SPECIFIC.
50/60 Hz
115/120 V AC 230/240 V AC
50/60 Hz
CONSUMPTION
MAINS OUTPUT
3
1 2
3
2 1
X L R P O L A R I T Y
1= S H I E L D
2= H O T
3= C O L D
CONN.
SECT. LOAD
AUTO SELECT 100/240 V~ 50-60 Hz
CONN.
SECT. LOAD
1+ / 1- OUT 1 x VEGAS 15
www.outline.it
SUB118 SP12
POWER
SPECIFIC.
50/60 Hz
115/120 V AC 230/240 V AC
50/60 Hz
CONSUMPTION
MAINS OUTPUT
6 A 3 A
10 A 10 A
S.N°: KKKF T515
MODEL: O1ESUB118-SP12
TESTED
WEIGHT : XX kg (ZZ lb)
www.outline.it
V15-KIT1
S.N°: WWW AB177
TESTED
MODEL: Y V15-KIT1
In particular, the SP12 model features a balanced
analog input (with the link to split the input signal)
and an output speakON NL4. The SP23 features
two analog inputs (L/R) and two corresponding NL4
outputs. Both have the same PowerCON True 1 stan-
dard input power connector.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
7
3. WIRING
After having analyzed the two different subwoofer panels and their relative input/output structures, here under
you will find the drawings of the cross over system and of the connection panel of the Vegas 10 and Vegas 15
enclosures which are the same for the two models:
1+
1-
2+
2-
1+
1-
2+
2-
NL4
NL4
INPUT / LINK
1+
1-
2+
2-
1+
1-
2+
2-
NL4
NL4
INPUT / LINK
The electro-acoustic features of the components are
therefore dimensioned according to the criteria de-
scribed above to obtain the best possible performan-
ce of the two elements in relation to the subwoofer in
conditions of extreme reliability and very low distor-
tion. Any configuration other than the provided one
will not be as performant and may, in some cases,
compromise the correct operation of the sound sy-
stem.
The wiring is very simple, as shown here under:
Output to Vegas
AC into amplifier
Analog signal

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
8
3.1. CONNECTORS SPECIFICATIONS
The cable used for cabling the point-source like Ve-
gas and the Sub118 SP is the speakON NL2FX cable
(four-pole chassis and 1+ / 1- contacts). Its standard
length of 10 m and 2 m is specifically designed for the
wiring for the two kits. It will however be possible to
use longer cables or, using a special cable adaptor, to
extend those already included with cables of the same
type. Its chassis is approved for wiring with NL4MP-2
input / output connectors like those found on the Ve-
gas and the Sub118 SP.
The cable used for the audio signal wiring from the
source to the subwoofer input panel (chapter 4), is
a classic audio cable with XLR 3-pole EIA-standard
connector:
1. Ground
2. Positive
3. Negative
Alternatively, the input panel (with Combo connector)
also accepts balanced 6.35 mm jack cables (TRS).
The cable used to connect to the amplifier DSP (chap-
ter 4) integrated in the Sub118 SP is the USB cable
with a type B connector.
For most users, the PC needs a USB type A connector
on the other end of the cable.
3
1 2
3
2 1
3
1 2
3
2 1
XLR male connector
Cable with NL2FX connectors
Jack 6,35 mm
TRS connector
USB type B USB type A

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
9
3.2. CABLES AND PICTURES
NL2FX /
NL2FX
PowerCON
True 1 /
Powercord
(EU)
Type A /
Type B
USB cable
XLR bal. -
jack 6,35 mm
TRS
10 m / 2 m speakON audio cables for satellites (1+ / 1- )
1.8 m professional power cable for the amplifier
Connection cable between the DSP of the kit
and the dedicated PC
(not included in the package)
Approved connectors for the SUB118 SP input panel to
use with external source signals
(not included in the package)
NAME / CODE DESCRIPTION

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
10
4. AMPLIFICATION
As already mentioned, the amplifiers are directly inte-
grated into the two Sub118 SP models. The amplifier
module is completely autonomous and designed to
be immediately ready for use (plug & play) once con-
nected to the power and wired to the Vegas satellites.
The Powercon True 1 connector guarantees stability
and security against any small infiltration of external
agents (IP 65) between power input and output.
The integrated DSP allows the management of the
input audio signal by routing it to the output channels
dedicated to the Vegas and Sub118. In fact, despite
the passive crossover of the Vegas, the two types of
satellites have a very precise and specifically studied
frequency cut, all managed by the DSP. Beyond the
flat setting, it will be possible to use other presets for
the whole system (chap 5).
Below you will find all the elements and the poten-
tial offered by the management panel:
Potentiometer and metering: the management of the system gain can be re-
gulated with the help of the dedicated potentiometer which can be set from -∞
to + 6 dB respect to the input signal. It is possible to monitor the ratio between
the input and output levels with the help of the metering LEDs. It is strongly
recommended not to reach the “clip/temp” status for long periods of time, even
though the DSP limiter is set to values for the best protection of the loudspea-
ker components.
USB input type B: USB port dedicated to DSP control through PC and
Armonía
Plus
software (chapter 4.1).
Preset selection: button for the selection of one of the four available presets
(chapter 5). It is possible to see the active preset with the help of the dedicated
LEDs.
Amplied signal output: speakON connector model NL4MP-2 dedicated to the
transmission of the amplified signal to the Vegas loudspeakers through the
dedicated speakON NL2FX audio cable.
Analog signal input: Combo type connector (XLR / TRS jack 6,35 mm) for ba-
lanced analog signal. The
Sub118-SP23
model will have two separate inputs
(stereo left / stereo right).
Input and output power: input with Powercon True 1 connector and IP65 degree
of protection, with an output to further power up to three kits in parallel at 220
V or two kits in parallel at 110 V (connection also valid to power the kits V10 and
V15 in parallel).
Analog signal link: analog output for splitting the input signal, to forward it to
another kit or any other system (
Sub118-SP12)
.
INPUT OUTPUT
MAINS
AUTO SELECT 100/240 V~ 50-60 Hz
Sistema 12 kW composto da due Moduli da 2 elementi da 6 kW (order
INPUT
LINK
CLIP/TEMP
SIGNAL
STATUS
+6
0
-∞
FLAT
BASS BOOST
LOUDNESS
PRESENCE
PRESET
SELECT
OUTPUT

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
11
4.1. DSP AND CONTROL THROUGH PC
The internal digital processor (DSP) integrated into
the Sub118 SP amplification system, allows control
and routing of the input signal to the relative output
channels, following precise frequency cuts between
Vegas and Sub118. As already mentioned, besides the
control of the amplifier gain through the relative po-
tentiometer, the DSP allows the choice of four diffe-
rent presets (chapter 5).
Moreover, for more expert users, it is possible to
obtain some further controls over the processing
system, by connecting directly to the DSP through a
special PC and USB cable (type B / type A) - if the
PC has more USB ports it will be possible to connect
two or more kits at the same time - as shown in the
previous chapters. Before making this connection,
you need to download and install the
ArmoníaPlus
software (download at armonia.powersoft.it).
This is the procedure to follow where, for some com-
puters, it will be necessary to install the VCP proto-
col (
www.silabs.com/products/development-tools/
software/usb-to-uart-bridge-vcp-drivers
):
It is also necessary to download and install the dedica-
ted Outline plug-in (download at
outline.it/download/
Software/ArmoniaOutlineModelsPluginSetup.zip
).
1. Installer 2. Installer 3. Installer
Armonia Plus Armonia Pro
Audio Suite
Armonia Plus
Outline plug-in
CP210x_Univer-
sal_Windows_Driver
Armonia Plus Armonia Pro
Audio Suite
Armonia Plus
Outline plug-in
CP210x_Univer-
sal_Windows_Driver
Armonia Plus Armonia Pro
Audio Suite
Armonia Plus
Outline plug-in
CP210x_Univer-
sal_Windows_Driver
Lastly, add the desired kit to the section “Add” > “Powered speaker” (Outline), in order to have the desired
control, once the system is connected to the PC (“Match”):

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
12
Afterwards, when clicking on it, a window appears where it is possible to modify the following parameters:
• Input EQ - it is possible to choose between different types of filters, for input signal equalization indepen-
dent from the selected preset, ideal for circumstances and venues with particularly complex acoustics;
• Overall gain - level regulation independent from the level regulation on the amplifier, can be useful in case
you want to set a digital “limit” of the final output volume;
• Delay and Polarity (up to 340ms) - delay and polarity change of the whole kit intended as a unique system
and therefore useful in case of allignment with another system or kit.
i
It will be possible to modify the mix between the two inputs for the V10 kit, by choosing between stereo
(default) and mono mix in the “Scheme” section.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
13
•
Flat (default)
- linear frequency response of the whole system, for a free
from coloration use; ideal for those who appreciate a uniform sound
through the whole spectrum or for those who make tailored EQs by me-
ans of a mixing desk.
•
Bass Boost
- frequency response to boost the low frequencies; ideal
for situations where particular “vibrations” are required, perfect also in
case of remarkable sound dispersion in free field.
•
Loudness
- a slight cut of the medium frequencies (with a consequent
emphasis of the high and low frequencies), suitable for lower volumes.
This EQ enables to maintain a good intelligibility level of the system even
in case of contained sound emission.
•
Presence
- filtered response in a given bandwidth, corresponding to the
frequency range of the human voice (medium frequencies). It is an ideal
preset for conference-style or speech contexts, ensuring the best intel-
ligibility of the voice throughout the listening area.
5. PRESETS AND USES
The great peculiarity of the two kits is that when you
have a power supply and an analog input signal, they
are immediately ready for use in plug & play mode.
Having analyzed the various controls available on the
amplifier and its DSP, it is important to underline that
the whole system is controllable and settable even
with minimum effort. In fact, depending on different
needs and tastes, but in the absence of necessary
time or sufficient skills for a personalized set-up,
Outline has made available four presets that are po-
tentially useful in any situation or venue. In detail:
It is always possible to combine the available presets with a custom input EQ through
ArmoníaPlus
, as
shown earlier.
i

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
14
The four default presets (shared by both kits), aim to
satisfy the needs of end users for different circum-
stances and venues.
It is however important to know the intended use for
each of the two kits, which changes depending on the
type and charachteristics of the venue (open or clo-
sed spaces, reverberation level, acoustic treatment,
parallel or slanting walls, etc.
Therefore the environmental and consequently acou-
stic variables are many and often not modifiable.
However, the user can pay proper attention to the
positioning and aiming at the venue of the satellite,
always taking into consideration their horizontal and
vertical dispersion (Fig. 1 and Fig. 2) and possible
comb filtering effects at their crossing point.
When placing the satellites close to each other, at-
tention must be paid to their aiming, in order to re-
spect their horizontal and vertical dispersion angles
as much as possible. If (Fig. 1) these are on the same
plane and side by side and equally oriented, the for-
mation of an area characterized by inhomogeneities
over the entire coverage area will be inevitable, fol-
lowing the succession of destructive sums and peaks
over the whole frequency spectrum (
comb filtering
).
You will obtain the same effect in case you place them
one upon the other (fig. 2), in this case in relation to
their vertical dispersion. Their behaviour will be diffe-
rent from that of line arrays, which have waveguides
and horn loadings and are made to be combined with
each other.
In case the two satellites are places on the same plane
and aimed according to their (nominal) horizontal
dispersion angle, the final result will be as
optimized as possible. It is however
necessary to take into account that
the omnidirectional dispersion of the
low frequencies may cause their sums
and cancellations. To have a precise idea
about the whole frequency spectrum behaviour
it is possible to make a simulation with Outline pro-
prietary software
Open Array 2.
Fig. 1 : incorrect horizontal positioning and aiming
fig. 3 : correct horizontal positioning
and aiming
Fig. 2 : incorrect vertical positioning and aiming

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
15
In the example above, with a V10 kit in a space of 15
m x 10 m, it is possible to see that the most even co-
verage through the whole venue can be obtained by
placing the two satellites at 1.7 metres from Sub118
SP23 and at 0.9 metres respect to the seated audien-
ce with an inclination of 15° respect to the central
point (Z axis).
OpenArray2
will offer a simulation that is as close to
reality as possible (in free-field).
Logically, the more distance there is between the sa-
tellites, the more the aiming should be made inwards.
On the contrary, when reducing this distance, the ai-
ming should be made outwards (see the two exam-
ples). In any case the two sources will cross at a cer-
tain point which mostly probably won’t feature any
evident or compromising cancellations.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
16
6. ADDITIONAL ELEMENTS
The aim of the V10 and V15 kits, designed as mobile
type systems, is to meet different types of needs (wi-
thin the limits of their extensive potential). Obviously
nothing excludes their use in a fixed installation. The
user has the possibility to perform different types of
installations depending on the space available.
Outline offers, separately from the elements included
in the two kits (therefore to be requested specifical-
ly to the local dealer or distributor), the possibility to
expand and set up the two systems in a different way
from the standard configuration.
Here are some additional elements:
• Additional
Vegas 10
(only for the V10 kit) - it will be
possible to link one Vegas 10 per side in addition to
the two satellites of the kit for the total of four, to get
a more extensive coverage. SUB118 SP-23 with the
Bass Boost
preset will deliver an excellent level of low
frequencies for the four satellites.
• Wall brackets and Two-speakers adaptor - a very
useful accessory, compared to the traditional speaker
poles (included in the V15 kit), is the wall bracket. The
wall brackets provided for the two Vegas models can
be very useful in fixed installations and can be an ideal
solution for indoor venues where, due to limited space,
it is necessary to place the loudspeakers on the wall
to ensure a more even coverage. For small venues it
is also possible to use one tripod with a two-speakers
adaptor (
suitable for Vegas 10 only
).
Wall bracket
ADJBV-E10/E15
#2 M8 FIXING POINT
#2 M8 FIXING POINT
#4 M6 FIXING POINT
•
Fixing Point
- Already included by default in all
Vegas models, these fixing points for the wall
brackets allow the mobility of the satellite in
order to point it in the horizontal or vertical po-
sition as designated by the project. Below you
will find some examples of wall brackets and
their related item codes, to purchase separa-
tely from your local dealer or distributor.

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
17
Two-speakers adaptor
STAND-ADAPT
Wall bracket
STAND-WALL1
#2 M8 FIXING POINT
#2 M8 FIXING POINT
#4 M6 FIXING POINT
Wall bracket
WHH100-B
Fixing points for vertical installation Fixing points for horizontal installation
Truss bracket
TH100-B
Horizontal wall
bracket
ADJBH-E10/E15
#3 M8 FIXING POINT

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
18
•
Speaker pole with base plate
- A much more elegant
alternative to the classic tripod. Ideal for conferences
and similar situations, where it is possible to place the
plate on a flat and stable surface. Easy to handle and
transport, thanks to the dedicated bag. Maximum load
25 kg (made by
gravitystands.com
).
•
Tripod pole
- classic and very versatile solution. Equip-
ped with “pneumatic” technology, it allows a regulated
descent of the stand, simplifying the disassembly pro-
cedures. Maximum load 50 kg (made by
gravitystands.
com
).

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
19
7. PERIODIC CONTROLS
All the components of the system (lodspeakers, am-
plifiers, cables, rigging hardware etc.) require a num-
ber of periodic controls to be performed at regular
time intervals to be decided by the persons in charge.
Some functional checks must be performed before
and after each use to confirm the working conditions
of each element.
In-depth controls must be performed ar regular time
intervals (for example, every 6 or 12 months), after
prolonged use (e.g. after a tour or a festival) or after
particular working conditions (incorrect use, wrong
rigging, drop etc.)
7.1. FUNCTIONAL CHECKS
It is strongly recommended to check the following
parameters of the electroacoustic components after
each use:
• general state of the satellites and subwoofers
(strongly recommended) ;
• integrated hardware (pole mount sockets and
threaded points as well as the stability of the
pole mounts);
• security of the power supplies (generators,
mains supply, electric panels, cables);
• system cabling to the integrated amplifier (noi-
se check of each single amplifier channel, ac-
curacy of the selected presets and connections,
souce connections etc.), to be performed both
through listening and, where possible, through
measurements;
• others.
The aim of these check is to guarantee the best possible performance and safety of the system from all points
of view. Any discrepancies found must be corrected. If these discrepancies compromise the safety of the sy-
stem, it must be immediately dismissed.
The in-depth checks are aimed to discover eventual
causes of possible problems that coud occur over
time and to check the parameters that are not mea-
surable during everyday use. These checks include: :
• cables, connectors’ conformity, pinouts, cuts,
tears, cables’ safety etc.;
• amplifiers and their electrical and thermic
safety (always verify the amplifier does not
overheat during prolonged use)
• frequency response check of the electroacou-
stic components (using a measurement mi-
crophone and software that can measure the
frequency response of the loudspeakers, in or-
der to compare them to the reference curves);
• control of other electroacoustic components
(absence of vibrations, integrity of the panels
and so on);
• integity check of all components, absence of
deformations, cracks and roundnesses, signs
of damage) ;
• check of all accessories (wheelboards, tripods,
poles etc.)
The aim of these checks is to have a ready-to-use
system at any time. The results of these checks must
be reported on a paper or electronic sheet like the
one at the end of this manual in the appendix.
In case of difformities it will be necessary to proceed
with reparation which must be done by skilled per-
sonnel only. In case of doubts it is mandatory to con-
tact an Outline’s representative, distributor or Oultine
headquarters directly.
7.2. PERIODIC CHECKS

OUTLINE S.R.L.
Via Leonardo da Vinci, 56
25020 Flero (Brescia) Italy
Tel. +39 030.3581341
Fax +39 030.3580431
www.outline.it
20
8. SPARE PARTS
As for all Outline products, there are spare parts available in case of component failures. For any other type
of reparation it is necessary to contact Outline directly. Below you will find the spare parts and their relative
item codes:
Sub118 SP 12/23
spares: woofer 18”, four rubber feet, amplifier module (with connection panel)
O S18B14ND40WP8
M V802
L AME3KV1SP12/23
This manual suits for next models
1
Table of contents
Other Routline Speakers System manuals
