RovyVan Aurora A7 User manual

Ready to go with what you can rely on!
Aurora A7 User Manual
RovyVon V1
Momentary ON
Press and hold for momentary on (High), release to turn off.
Turn On / Off
Power On
Mode 1. Long press enter high mode, release turn off.
Mode 2. Double click turn on the main light (Low mode)
Mode 3. Triple click to turn on the sidelight (White reading light)
Power Off
Mode 1. Press and hold for 0.5 second at any mode
Mode 2. Click the button to turn off after the light stays at any mode for
over 60 seconds.
Light source mode changing
1. Primary Light
Click to cycle through: Low - Med - High – Strobe
2. Side Light
Click to cycle through;
⚫White: White reading light- White Flash
UV will be activated by quick 4 clicks
NOTE:
When the light is working over 2 minutes at High mode, the output will step
down to 65 lumens due to the heat the high mode produced, and the output
will be adjusted real time by the temperature controller.
Lumens Test Curve (High mode)
Product Illustration
Primary Features
⚫Semi-transparent glowing body (GITD Blue)
⚫CREE XP-G3 LED, max output 550 lumens
⚫UV and white reading sidelights
⚫Built-in Micro USB charging port with charging indicator
⚫130mAh Li-polymer rechargeable battery
⚫Quick charge in 45 minutes
⚫Side switch prevents accidental activation
⚫Ergonomic design for better grip and one-handed operation
⚫Built-in temperature controller
⚫Two-way clip included and tail paracord hole
⚫IP65 water resistance
Note: The UV light’s purpose is mainly for feeding the GITD case to make it glow brighter, faster, and last longer
than shined by external light sources.
Dimensions
Length: 54.8 mm
Diameter: 14.5mm
Weight: 11.7g (Battery included)
Accessories: Lanyard, user manual, stainless steel clip, USB cable, extra USB cover
Battery
Product Parameters
Note: The parameters mentioned above are approximate and may
vary between flashlight and environment.
Lithium polymer
battery
Dimensions
Standard
voltage
Capacity
Rechargeable
501030
4.2 V
130 mAh
Mode/
Specification
LED
Low
Med
High
Strobe
Primary light
CREE
XP-G3
15 Lm
230Lm
550 Lm
550
180 min
55 min
38min
/
1160 cd
80m
1.5m
IP65 weather resistance
Side Light
White
White flash
UV
4Lm
4Lm
365nm
10h
30h
1h
Micro USB Port
Torch body
On / Off
Paracord Hole
Clip slot
Items Time Lm
Front View
Back View
Torch head

Ready to go with what you can rely on!
Aurora A7 User Manual
RovyVon V1
Charging
Open the Micro USB cover and connect a cable to charge as shown
in the diagram below
Charging indicator: Red is charging, Blue is fully charged
Charging time: 45 minutes (350 mA / 5V)
When the battery voltage is lower than 2.6V, the indicator will be
constantly on reminding to charge the light
When the battery voltage is lower than 2.4V the light will stop working
How to open the Micro USB cover
Battery Replacement
The battery can only be replaced by a professional technician.
Warning!
Do not look directly into the light when it is switched on.
Do not point the light at human or animal eyes.
Do not permit children to use the flashlight unsupervised.
Warranty Service
Two year international warranty.
After the free maintenance period has expired, the maintenance service will
charge for material expense only, free of labor expenses.
RUNFREE EQUIPMENT TECHNOLOGY (HONG KONG) CO., LTD
Website: www.rovyvon.com
E-mail: [e-mail]
Address: UNIT 04, 7/F, BRIGHT WAY TOWER, NO.33 MONG KOK ROAD,
KOWLOON, HONG KONG.
A. Backward slot
A. Backward slot
B. Forward clip slot
B. Forward clip slot
B
A
3. Pull it up and the USB
cover will easily pop out.
1. Look on the edge of the
metal body where it looks
like a rubber hinge.
2. Grab the edge of that
little rubber tip with your
nail.
Clip installation instruction
The clip could be attached in the forward or backward position as
your preference
