Rowley AUTOMATION RTMWCR1C User manual

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 1
R-TEC Smart Controls - Cut-In Wall Mount Switches
Wall Box Mount Switches in cut-in configuration provide a sensible control
option for individual room and whole home window treatment control.
Available in 1, 2, or 15 channel models, wall switches are compatible with all
ARC motors.
Cut-In Wall Mount Switches feature a contemporary design and
a wirefree deployment, making them retrofit ready for any location.
Require RTMSMB/W for installation.
FEATURES - 1 CHANNEL
2-Way RF
Communication
Retrofit
Ready
FEATURES - 2 CHANNEL
Multi Channel
Selectable
Retrofit
Ready
Group
Control
2-Way RF
Communication
Hide Unused
Channels
FEATURES - 15 CHANNEL
Multi Channel
Selectable
Retrofit
Ready
Group
Control
2-Way RF
Communication
Hide Unused
Channels
RTMWCR1C, RTMWCR2C, RTMWSR15C

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 2
Technical Data / Pack Contents 3
Safety 4
Installation 5
Install Switch Batteries
Mount Switch
Functional Overview 6 - 8
Buttons
Selecting a Channel
Group Control using CH "0"
Hide Unused Channels
Lock Limit Setting
Programming 9
Using Motor P1 Button
Using a Pre-Existing Controller
Troubleshooting 10
TABLE OF CONTENTS

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 3
Parameters Value
COMPLIANCE STATEMENT
TECHNICAL DATA / PACK CONTENTS
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference that may cause undesired operation.
PRODUCT SPECIFICATIONS
Voltage 3 V DC
Battery 2 x AAA
Radio Frequency 433.92 MHz
Transmitting Power 10 milliwatt
Transmission Range 65'
Temperature Working Range 14º F - 122º F (-10º C - 50º C)
PACK CONTENTS
1. Cut-In Wall Mount Switch, 1, 2 or 15 Channel
2. Wall Fixing Screws (2) and Anchors (2)
3. Instruction Manual
4. 1.5 V AAA Batteries (2)
SOLD SEPARATELY: RTMSMB/W
Surface Mount Wall Back Box for Cut-In Style Remotes with Mounting Screws (2)

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 4
SAFETY
Any changes or modifications to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment. Incorrect installation can lead to serious injury and will void
manufacturer’s liability and warranty.
WARNING
Do no dispose of in general waste.
Please recycle batteries and damaged electrical
products appropriately.
CAUTION
• Do not expose to moisture or extreme temperatures.
• Do not allow children to play with this device.
• Use or modification outside the scope of this instruction manual will void warranty.
• Installation and programming to be performed by a suitably qualified installer.
• Use only R-TEC Automation®hardware.
• Keep clear when in operation.
• Replace battery with correctly specified type.
IMPORTANT SAFETY INSTRUCTIONS TO BE READ PRIOR
TO OPERATION
• It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future reference.
• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
should not be allowed to use this product.
• Frequently inspect for improper operation. Do not use if repair or adjustment is necessary.
• Keep away from children.

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 5
INSTALLATION
INSTALL SWITCH BATTERIES
Open rear battery cover by pressing
gently in, then sliding down.
Install 2 x AAA batteries with
negative (-) side facing springs.
MOUNT SWITCH
Use supplied fasteners and anchors
as needed to attach base.
Replace cover by sliding into place.

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 6
BUTTONS
SELECTING A CHANNEL
FUNCTIONAL OVERVIEW
UP
STOP
DOWN
LCD Screen
+ CHANNEL P2 Button- CHANNEL
Use LEFT and RIGHT arrows
to change channels.
Use RIGHT arrow to
increase channel.
Response
LCD screen will indicate selected channel
Please refer to the relevant documentation of your motor model for instructions on adjusting motor settings.
IMPORTANT

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 7
GROUP CONTROL USING CH "0"
Channel "0" is preset to control ALL window treatments paired within your multi channel switch.
To create a customized group channel, reference page 9.
HIDE UNUSED CHANNELS
Your multi channel switch can be configured to have anywhere between 1 or 15 visible channels.
Inactive channels will not be visible when scrolling through the < > selections.
Response
LCD screen displays "C",
then changes to "15"
Response
LCD screen displays the
selected number of channels
Response
LCD screen displays "o" to indicate
the channel number has been set
Press and hold LEFT
and RIGHT arrows
for 3 seconds.
Press RIGHT arrow
to hide channels.
Press the
STOP button.

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 8
LOCK LIMIT SETTING
The 15 channel switch uses the LCD screen to notify the user when the lock feature has been activated.
Response
LCD flashes "U" x 2
Press STOP and
hold for 15 seconds.
Release STOP button.
Unlocked limit settings.
Response
LCD flashes "L" x 2
Release STOP button.
Locked limit settings.
Press STOP and
hold for 15 seconds.

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 9
A = Existing switch or channel (to keep). B = Switch or channel to add or remove.
USING PRE-EXISTING CONTROLLER
Press P2 on
existing switch.
Press P2 a second time on
existing switch.
Press P2 on new switch
or remote controller.
Motor ResponseMotor ResponseMotor Response
PROGRAMMING
• Confirm that motor limits and favorite position are already set for each individual motor.
• Ensure that each motor you want to group is also assigned to another channel by itself.
USING MOTOR P1 BUTTON
Multiple motors can be grouped onto shared channels for coordinated control.
IMPORTANT
Select a channel
on switch using the
side arrow buttons.
Hold STOP
on switch.
Approx.
Motor Response
or
Hold P1 button on motor head.
Motor Response
Approx.
* Internal Tubular
pictured. Refer to “P1
Locations” for specific
devices to the right.
P1 LOCATIONS
Drapery
Large Tubular

© 2023 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 10
Any Questions?
Contact our R-TEC Automation®in-house experts at 866.985.3423. Email us at RTECAutomation@RowleyCompany.com.
TROUBLESHOOTING
Problem Cause Remedy
Motor is not responding
Switch battery is discharged Replace battery.
Battery is inserted incorrectly Check battery polarity.
Radio interference / Shielding
Ensure switch is positioned away from metal objects and
that aerial on motor or receiver is kept straight and away
from metal.
Receiver distance is too far
from switch Move switch to a closer position.
Power failure Check power supply to motor is connected and active.
Incorrect wiring Check wiring is connected correctly (refer to motor
installation instructions).
Cannot set limits on a single
motor (multiple motors
respond)
Using “Group” channels to
adjust motor limits
Red LED is solid
Always reserve an individual channel for programming
functions.
SYSTEM BEST PRACTICE - Provide an extra 15 channel
switch in your multi motor projects, that provides individual
control for each motor for programming purposes.
