Royal Enfield Continental GT User manual

1
Foreword
The Royal Enfield Continental GT is our lightest, fastest, and most powerful motorcycle in production. It’s a machine
with a story, a nod to motorcycling’s finest hour, the best expression yet of a cultural phenomenon that has simply
refused to fade away - the cafe racer.
And now you have one of your own. Congratulations!
Your meticulously re-engineered Continental GT debuts a twin downtube cradle frame chassis developed by the
renowned Harris Performance from UK. A new engine displaces 535cc and dollops of torque, when you need it. W ith
gas-charged rear shock absorbers from Paoli and Brembo disc brakes, you stay in charge. W ith an aerodynamic
seating position, Pirelli Sports Demon tyres and a remapped ECU, the new Continental GT is part homage, part
engineering tour-de-force.
This manual will help you to operate your motorcycle and guide you to wholly maintain it. W e have also provided tips
on safe riding and on minor adjustments for the care of your motorcycle. Please avail the four free services at the
nearest Authorised Service Point at the appropriate time to maintain your motorcycle in top riding condition. We
request you to carefully read the terms and conditions of warranty and other useful information given in this manual
before starting to use your Continental GT. Log on to the exciting world of Royal Enfield on www.royalenfield.com to
get to know more about the company, its products and news from time to time.
Welcome to the world of the Rockers, and enjoy your burn-ups atop this spectacular machine.

2
All information in this manual is based on the latest product information available at the time of publication. Due to
continuous improvements or other changes, there may be discrepancies between information in this manual and your
vehicle. Royal Enfield reserves the right to make production changes at any time without prior notice and without
incurring any obligation to make same or similar changes to vehicles previously built or sold.
All images shown are for reference to explain and need not to be exactly the same on the model you own. Technical
specifications are subject to change without prior notice.
© Copyright 2014 Royal Enfield (A unit of Eicher Motors Ltd.). All Rights Reserved. No part of this manual shall be copied,
distributed or otherwise dealt without the express permission in writing from Royal Enfield.
Notice
Part No. 585441/A / Revision 1.0 / Qty. 500 / Apr. 2014
Disclaimer
This model fitted with “tubeless tyre” is provided with
an inner tube.
Failure to use an inner tube in a spoked wheel will
c a us e de f l at i o n o f th e ty r e r e s u l ti n g i n l o s s of
motorcycle control.
The approved tyres m ar ked wi th “TUBELESS” are
suitable for use with inner tube.

3
PERSONAL & VEHICLE INFORMATION ....... 6
FREE SERVICE RECORD ........................... 7
SAFETY DEFINITIONS ............................ 8
TECHNICAL SPECIFICATIONS .................... 9
Engine ................................................ 9
Ignition System ................................... 10
Transmission ...................................... 10
Electricals ........................................... 11
Chassis .............................................. 12
Dimensions ......................................... 13
Weights .............................................. 13
SAFE RIDING TIPS/GUIDELINES ................ 14
SAFE & HAPPY RIDING ............................ 18
RULES OF THE ROAD ............................... 19
VEHICLE IDENTI. NUMBER-DETAILS .......... 21
KEY PARTS LOCATION ............................. 22
Right Side View .................................. 22
Left Side View.................................... 23
Top View ............................................ 24
OPERATION OF CONTROLS ................... 25
Ignition Switc h .................................... 25
Steering Lock ..................................... 26
Steering Unlock .................................. 26
Fuel Tank Cap...................................... 27
Side Panel LH / Battery Cover ............ 27
Utility Box .......................................... 27
Side PANEL RH ................................. 27
Alpha-Numeric display unit.................. 28
Head Lamp Switch............................... 30
Head Lamp Day Flash.......................... 30
Dip Switch ......................................... 30
Engine Start Switch ............................ 31
Engine Stop Switch ............................ 31
Turn Signal Switch ............................. 31
Horn .................................................. 32
Contents

4
Contents
Manual Bi Starter (choke) ................... 32
PRE OPERATIONAL CHECKS .................... 33
RUNNING IN PERIOD.................................. 34
ELECTRONIC FUELINJECTION (EFI) ......... 35
EFI .................................................... 35
The Advantages of EFI ....................... 35
Malfunction Indicator Lamp (MIL) ......... 35
ROLL OVER SENSOR ............................... 36
STARTING ................................................ 37
GEAR SHIFTING ....................................... 40
PARKING .................................................. 41
Center Stand ...................................... 41
Side Stand ......................................... 41
TOOLS & FIRST AID KIT............................... 42
RECOMMENDED LUBRICANTS ................... 43
PERIODICAL MAINTENANCE ..................... 44
MINOR MAINTENANCE TIPS ...................... 48
Control Cables, Hand lever,
Center / Side Stand Pivots .................. 48
Oil Level Inspection ............................ 48
Engine oil change ............................... 49
Spark Plug ......................................... 50
Brake fluid (Front & Rear) ................... 51
Inspection of tyres and wheels .......... 51
Tyre pressure ..................................... 52
Front W heel removal .......................... 52
Front W heel reassembly ..................... 53
Rear wheel removal ........................... 54
Rear wheel reassembly ...................... 55
Adjustments-Clutch lever free play .... 57
Rear brake light switch adjustment...... 57
Drive Chain free play .......................... 58
Chain lock fitment ............................... 59
Adj. of gas filled shockabsorber ......... 60
Removal of Battery from the Vehicle..... 61

5
Contents
Battery Maintenance ........................... 61
Reassembly of Battery on Vehicle ...... 62
CHANGING ELECTRICAL COMPONENTS .... 64
Head Lamp Bulb Replacement ............ 64
Tail Lamp bulb Replacement ................ 65
Trafficator bulb Replacement .............. 65
Fuse .................................................. 66
Blade fuse usage list .......................... 66
Air Filter Paper element......................... 67
WASHING PROCEDURE ............ ............... .. 68
Precautions ........................................ 68
Af ter washing..................................... 68
STORAGE PRECAUTION ........................... 70
Preparing the motorcycle for re-use ... 71
LONG TRIP PRECAUTIONS ....................... 72
COMPLETE W IRING DIAGRAM (Domestic) . 73
TROUBLE SHOOTING ............................... 74
Engine fails to start ............................ 74
Engine misfiring ................................. 75
Poor pickup ....................................... 75
White / Blue smoke ............................ 76
Engine overheating ............................ 76
Excessive fuel consumption................ 76
Brakes Poor ........................................ 77
Vehic le wobbles.................................. 77
Electricals .......................................... 77
Electronic Fuel Injection (EFI) .............. 78
WARRANTY ............................................. 79
EMISSION WARRANTY.............................. 81
FREE SERVICE COUPONS ......................... 86
PAID SERVICE/MAINTENANCE RECORD ..... 95
ALL INDIA ROAD SIGNS ........................... 103
LOG BOOK ............................................... 104
NOTES .................................................... 108

6
Name
Door No./St.
Locality
City State Pin
Contact Nos. Res: Off: Mobile: Email:
Engine No. Battery No.
Frame No. Battery make
Reg. No. Licence No.
Date of Sale Valid till dt.
Model Key No.
Tyre make Colour
Sold by Dealer Code
Vehicle Installation Form (VIF) No.
Personal & Vehicle Information

7
It is our endeavour to provide excellent service to your CONTINENTAL GT at all times. Towards this we provide 4 free
services at specific Intervals.
Please avail these services at the specified time, in any of the Royal Enfield Authorised Dealer / Service Point nearest to you
and as a token of satisfactory services, kindly return the free service coupon duly filled in and signed, to the service outlet.
Availing the free services in the specified time is a prerequisite for warranty consideration. The cost of fuel, oil, grease etc.
used for all free services are chargeable to the customer.
NOTE : Please ensure that the free service details are recorded in this sheet immediately after the service is carried out.
Date of Service
Kms Covered
Servicing ASP /
Dealer’s Name
Address
1st Service 4th Service2nd Service 3rd Service
Dealer / ASP
Rubber Stamp
Dealer / ASP
Rubber Stamp
Dealer / ASP
Rubber Stamp
Dealer / ASP
Rubber Stamp
Free Service Record

8
The information given under the titles: Warning, Caution and Note are for your safety and for the care and safety to
your motorcycle and others. Please read these carefully and if disregarded it may result in injury to yourself or others
and damages to the motorcycle
Statement in this manual preceded by the following words are with special significance.
Warning
Indicates a potentially hazardous situation, which if not avoided, could result in serious injury or damage.
CAUTION :
Indicates a potentially hazardous situation , if not avoided, may result in minor or moderate injury or damage.
NOTE :
Indicates important and useful messages for clear understanding.
Safety Definitions

9
Technical Specification
ENGINE
Engine ....................................................... 4 Stroke, air cooled, single cylinder, OHV, SI Engine
Capacity .................................................... 535 cc
Bore .......................................................... 87mm
Stroke ........................................................ 90 mm
Compression ratio ..................................... 8.5 : 1
Max. Power @ RPM ................................... 29.1 BHP (21.4 kw) @ 5100 rpm
Max. Torque @ RPM .................................. 44 Nm @ 4000 rpm
Air Filter Element ....................................... Paper Element Filter
Engine Oil Capacity (dry fill) ....................... 2.75 Litres.
Lubrication ................................................ Forced Lubrication, Wet Sump
Engine Oil Grade ........................................ Royal Enfield 15 W 50 API SL Grade Engine Oil (JASO MA)
Fuel System .............................................. Electronic Fuel Injection Programmed (PGM-EFI)
