Royal Enfield Super Meteor 650 User manual

Royal Eneld Support
1800 - 210 - 0007
1. Roadside Assistance
2. Product Update
3. Feedback
4. Dealer Locator
@royaleneld www.royaleneld.com Support@royaleneld.com
Download the ROYAL ENFIELD APP and explore more
To access dealer details scan the QR code

FOREWORD
Congratulations and welcome to the Royal Eneld family.
As the world’s oldest motorcycle marque in continuous production, Royal Eneld has remained true to its legacy of pure
motorcycling – and you are now part of that proud tradition.
Your Super Meteor 650 is the quintessential cruiser. With its proven air-oil-cooled 648cc parallel twin engine and a stylish
steel tubular spine frame developed at our UK Tech Centre, the Super Meteor represents the perfect balance of power
and grace. We hope you enjoy cruising to new frontiers on your motorcycle as much as we enjoyed building it for you.
This manual is your friend, philosopher, and guide when it comes to taking care of your motorcycle. In the pages that
follow, you will nd ways of looking after your machine so that it remains a reliable partner in your travels and exploration
for decades to come.
Please avail all scheduled services at your nearest Royal Eneld Authorised Service Centre, ensuring your ride gets the
best care always. Do read through the terms and conditions of warranty and other useful information given in this manual
before you ride.
For support and any other information, please call 18002100007, any time between 9 am and 9 pm, any day of the week.
-Enjoy the Cruise !

Royal Eneld Super Meteor 65002
All information in this manual is based on the latest product information available at the time of publication. Due to continuous
improvements, there may be dierences between the information provided in this manual and information related to your
motorcycle.
Always consult an authorized Royal Eneld dealer for the latest specications, features etc. Royal Eneld reserves the right to
make production changes at any time without prior notice and without incurring any obligation to make the same or similar
changes to a motorcycle previously built or sold. All images shown are for reference to explain and need not to be exactly the
same on the model you own. Accessories and features may not be part of standard equipment. Technical specications are
subject to change without prior notice at the sole discretion of Royal Eneld.
Please take care while disassembling and assembling the seats, and sheet metal parts, as any sharp edges will lead to injuries.
“© Copyright 2022 Royal Eneld (A unit of Eicher Motors Ltd.). All Rights Reserved. No part of this manual shall be copied,
distributed or otherwise dealt without the express permission in writing from Royal Eneld”.
DISCLAIMER
1. Do not polish matt nished paint surface in your motorcycle as it will increase the gloss level.
2. Wash the painted parts only with plain water and do not use any strong solvents cleaning agents or detergents.
3. Scratches, if happens on the matt nish parts cannot be touched up and corrected / removed.
4. Warranty is not applicable for any matt nished painted parts of the motorcycle.
NOTE
xThis motorcycle meets the BS VI emission norms. Part No.RAM00610/A / Qty. / November 2022
NOTICE

03
Royal Eneld Super Meteor 650
CONTENTS
Safety denitions ..................................................... 4
Personal and motorcycle information ..................... 5
Safe riding tips / Guidelines...................................... 6
Rules of the road ...................................................... 10
Accessories and luggage .......................................... 12
Technical specications ........................................... 14
Recommended lubricants........................................ 19
Motorcycle identication numbers.......................... 20
Location of key parts................................................ 21
Operation of controls............................................... 24
Warning indications and safety systems.................. 49
Pre - Operational checks .......................................... 53
Running in period..................................................... 54
Starting..................................................................... 55
Gear shifting, riding and stopping............................ 59
Parking ..................................................................... 61
Tools kit and rst aid kit............................................ 62
Owners manual storage location ............................. 63
Minor maintenance tips ........................................... 64
Long trip precautions............................................... 90
Rear suspension setting........................................... 91
Washing procedure.................................................. 93
Storage precautions................................................. 96
Troubleshooting ...................................................... 97
Environment care..................................................... 99
Periodical maintenance ........................................... 100
Warranty terms and conditions ............................... 105
Emission warranty ................................................... 108
Evaporative emission control system warranty ....... 113
Service / Maintenance record .................................. 115
Notes ....................................................................... 116
* Click to reach directly to your choice of topics

Royal Eneld Super Meteor 65004
SAFETY DEFINITIONS
The information given under the titles: Warning, Caution and Note are for your safety and for the care and safety to
your motorcycle and others. Please read these carefully and if disregarded may result in injury to yourself or others and
damages to the motorcycle.
Indicates a potentially hazardous situation. Disregarding this message may result in injury to rider or other persons.
WARNING
Indicates important and useful messages for better understanding.
NOTE
This message, if disregarded, may result in damage to the motorcycle.
CAUTION

05
Royal Eneld Super Meteor 650
Name
Door No. / Street
Locality / Town
City Country
Contact No. Res : O :
Mobile : Email :
Licence No. Valid till :
Model Color :
Engine No.
VIN. No.
Tyre make Front : Rear :
Tyre Nos. Front : Rear :
Battery make Battery No.
Sold by
Date of Sale
PERSONAL AND MOTOR CYCLE INFORMATION

Royal Eneld Super Meteor 65006
SAFE RIDING TIPS / GUIDELINES
ŶBefore operating your new motorcycle, we request
you to carefully read and follow the operating and
maintenance instructions detailed in this manual
for the safety of your own, your motorcycle and also
that of others.
ŶKnow and adhere to the rules of the road with
respect to your driving country.
ŶBefore starting the motorcycle, check for proper
operation of brakes, clutch, gear shifter, handle bar
controls, tyre pressures, fuel and oil levels, etc.
ŶUse only genuine Royal Eneld spare parts and
approved accessories. Use of other manufacturer’s
parts may aect the performance of your
motorcycle and render the motorcycle void of
warranty. Visit your Royal Eneld Authorised Service
Centre for details.
ŶWhenever refueling your motorcycle, please
exercise utmost caution and carefully observe the
following guidelines.
Refuel in a well ventilated area with the engine
turned OFF condition.
Open the fuel ller cap slowly.
Switch OFF mobile phones and other hand held
electronic devices.
DO NOT smoke and please ensure that there are
no open ames or sparks near the motorcycle,
when refueling or servicing the fuel system.
Please ll fuel till the bottom of anti splash plate,
so as to leave sucient air space in the fuel tank
to allow for fuel expansion.
WARNING
Royal Eneld cautions you against the use of certain
nonstandard parts such as aftermarket and custom
made extended front forks or suspensions, which may
adversely aect performance and handling. Removing or
altering original parts may adversely aect performance
and could result in accident.

07
Royal Eneld Super Meteor 650
SAFE RIDING TIPS / GUIDELINES
ŶA new motorcycle must be operated according to
the special running-in-procedure. See running-in-
procedure mentioned in respective section.
ŶOperate motorcycle only at moderate speeds and
out of trac until you have become thoroughly
familiar with its operation and handling
characteristics under all conditions.
ŶDO NOT exceed the legal speed limit or ride too fast
for existing conditions. Always reduce speed when
poor riding conditions exist. High speed increases
the inuence of any other condition aecting
stability and increases the possibility of loss of
control.
If you are an inexperienced rider we recommend that
you obtain formal training on correct motorcycle riding
techniques and become thoroughly familiar with the
operation of your motorcycle. New riders should gain
experience under various conditions while driving at
moderate speeds.
NOTE
Pay strict attention to road surfaces and wind conditions.
Any motorcycle may be subject to the following upsetting
forces:
Wind blasts from passing vehicles.
Rough or uneven road surfaces.
Slippery road surfaces.
These forces may aect the handling characteristics of
your motorcycle. If this happens, reduce speed of the
motorcycle to a controlled condition. Do not apply brake
abruptly.
ŶOperate your motorcycle defensively. Remember
that a motorcycle does not aord the same
protection as an automobile in an accident. One of
the most common accident situations occurs when
the rider / driver of the other motorcycle / vehicle
fails to see or recognise a motorcycle and turns into
the oncoming motorcyclist.

Royal Eneld Super Meteor 65008
SAFE RIDING TIPS / GUIDELINES
Regularly inspect shock absorbers and front forks and
look for leaks. Replace worn out parts. Worn out parts
can adversely aect stability and handling.
Exhaust gas contains poisonous carbon monoxide
and chemicals, known to cause cancer, birth defects
WARNING
ŶWear an approved helmet, clothing and footwear
suited for riding a motorcycle. Bright / light colours
are best for greater visibility in trac, especially at
night. Avoid loose, owing garments and scarves.
ŶWhen carrying a pillion rider, it is your responsibility to
instruct them on proper riding procedures.
ŶDo not allow other individuals, under any
circumstances, to operate your motorcycle unless you
know they are experienced, licensed riders and are
thoroughly familiar with the operating conditions of
your motorcycle.
or other reproductive defects, durability / longevity
operation of your motorcycle.
For your personal welfare, all the listed service and
maintenance recommendations should be performed.
Lack of regular maintenance at the suggested
intervals may aect the safe/durability/longevity
operation of your motorcycle.
Avoid any contact with the exhaust system when
hot. Wear clothing that will completely cover the legs
while riding. The exhaust system gets very hot when
the engine is running and remains too hot to touch,
even after the engine is turned OFF. Failure to wear
proper or protective clothing could result in serious
injury.
Motorcycle batteries contain lead, acids and
chemicals known to cause cancer, birth defects or
other reproductive harm. Exercise extreme caution
while handling a battery, wash hands thoroughly
whenever a battery is handled.

09
Royal Eneld Super Meteor 650
Consult your Royal Eneld Authorised Service Centre
regarding any questions or problems that occur in the
operation of your motorcycle. Failure to do so may
aggravate an initial problem, cause costly repairs and
jeopardize your personal safety.
DO NOT tow a motorcycle. The steering and handling
of the towed motorcycle will be impaired due to
the force of the towline. If a motorcycle must be
transported, use a truck or a trailer.
DO NOT pull a trailer behind a motorcycle. Towing
a trailer may cause reduced braking eciency, tyre
overloading and unstable handling, as it may cause
loss of control of the motorcycle in the front, leading
to an accident.
WARNING
SAFE RIDING TIPS / GUIDELINES

Royal Eneld Super Meteor 65010
RULES OF THE ROAD
ŶBe sure your number plate is installed in the position
specied by law and is clearly visible at all times.
ŶRide at a safe speed that is consistent with the type
of road surface you are on. Pay strict attention while
riding on the following surfaces :
Dusty
Oily
Icy
Wet
Sand
ŶWatch for loose debris, such as leaves, slippery
substances or gravel that can hamper the stability of
your motorcycle.
ŶKeep to the correct side of the road center line when
meeting oncoming vehicles.
ŶActuate your turn signals and exercise caution when
passing other vehicles going in the same direction.
Never try to pass another vehicle going in the same
direction at street intersections, on curves, or when
going up/or down a hill.
ŶAt street intersection give the
right-of-way to the motorcycle on
your left or right. Do not presume
you have the right-of-way.
ŶAdhere to the rules of the road
with respect to your country
when preparing to stop, turn or
pass. While turning either right
or left, watch for pedestrians,
animals, as well as other vehicles.
ŶAll trac signs, including manual controls at
intersections, should be obeyed promptly. SLOW
DOWN at trac signs near schools and CAUTION
signs at railroad crossings.
ŶWhen intending to turn, signal at least 100 feet
(30.5 meters) before reaching the turning. Be
close to the center line (unless local rules require
otherwise), slow down and then turn carefully.
Yellow
Green
Yellow
Red

11
Royal Eneld Super Meteor 650
RULES OF THE ROAD
ŶNever jump a trac light. When a change is imminent
from GO to STOP (or vice versa) at intersections, slow
down and wait for the light to change to green. Never run
through a yellow or red trac light.
ŶDo not leave the curb or parking area without signaling.
Be sure your way is clear to enter moving trac. A
moving line of trac always has the right-of-way.
ŶWhen parking the motorcycle, park on a rm and at
surface to prevent it from falling over.
ŶProtect your motorcycle against theft. After parking your
motorcycle, ensure that the steering head is locked and
then remove the ignition key.
SIDE VIEW MIRRORS
Your motorcycle is equipped with convex mirrors and have a
curved surface. This type of mirror is designed to give a much
wider view of the rear than a normal at mirror. However,
vehicles and other objects seen in this type of mirror will look
smaller and farther away than when seen in a at mirror.
To establish the relative distance of vehicles / objects
behind your motorcycle through the mirrors, adjust each
mirror in such a way, that a small portion of your shoulder
is visible and a large portion behind your motorcycle is
seen clearly with reference to your riding posture.
NOTE
Use care when judging the size or distance of vehicles /
objects seen in these mirrors. Use the tool available in tool
kit to loosen and adjust the side mirrors.

Royal Eneld Super Meteor 65012
ACCESSORIES AND LUGGAGE
Royal Eneld oers a range of Genuine Motorcycle
Accessories that have been fully approved and extensively
tested alongside the motorcycle.
Therefore, the rider must be responsible for safe operation
of the motorcycle when installing accessories or carrying
additional weight.
Please adhere to the following guidelines when carrying a
pillion, luggage or when tting any accessories.
ŶDo not exceed 110 km/h when riding solo, carrying
a pillion or payload on an accessory equipped
motorcycle.
ŶKeep luggage weight concentrated close to the
motorcycle and as low as possible; this minimizes
sudden shift in the motorcycle’s center of gravity.
ŶDistribute weight evenly on both sides of the
motorcycle.
ŶDo not load bulky items behind the rider or add
weight to the handlebars or front forks.
ŶRe-check the luggage periodically to ensure it is
secured and will not shift while riding. Accessories
mounted loosely may aect the riding of the
motorcycle and aect the handling and stability of
the motorcycle.
ŶLarge surfaces such as fairings, windshield, backrest
and luggage racks can adversely aect handling of the
motorcycle. Use Royal Eneld Genuine Motorcycle
Accessories which are model specic and follow
installation procedure.
Do not load weight or install accessories incorrectly
on the motorcycle. Doing so may aect the
motorcycle’s stability, handling characteristics and
safe operation and could result in an accident causing
serious injury or loss of life.
Royal Eneld oers a range of Genuine Motorcycle
Accessories that have been fully approved and
extensively tested alongside the motorcycle.
WARNING

13
Royal Eneld Super Meteor 650
ACCESSORIES AND LUGGAGE
Royal Eneld cautions you against use of nonstandard
parts such as aftermarket and custom made
extended front forks which may adversely aect
the performance and handling of the motorcycle.
Removing or altering original parts may adversely
aect the performance of the motorcycle, causing an
accident, which could result in serious injury or loss of
life.
Do not ignore model / design specications. Doing
so constitutes both motorcycle and accessories
misuse which may adversely aect the handling and
performance of the motorcycle causing an accident,
which could result in serious injury or loss of life.
WARNING LUGGAGE CATEGORIES (If fitted)
Do not exceed the below listed maximum weight in each
Royal Eneld Genuine motorcycle accessory.
1. Long haul panniers - 5 kg max each side
2. Soft panniers - 3 kg max each side
3. Top box - 3 kg

Royal Eneld Super Meteor 65014
TECHNICAL SPECIFICATIONS
E
ngine type ............. Parallel twin cylinder, 4 stroke,
SO
H
C
B
ore ......................... 78 m
m
Stroke ...................... 67.8 mm
Swe
p
t volume........... 647.95 cc
C
om
p
ression ratio.... 9.5:1
M
ax
p
ower ............... 34.6 kW (47 PS) @ 7250 r
p
m
M
ax to
rqu
e .............. 52.3 Nm
@
5650 r
pm
Idl
e R
PM.
...
...
...
...
...
...
.
120
0
r
100 r
p
m
Starting .................... Electric start
A
ir

lt
e
r
e
l
e
m
e
nt...... Pa
p
er elemen
t
Lub
ric
ati
on.
...
...
...
...
..
Forced lubrication, Wet sum
p
with
p
ump
d
riven oi
l
d
e
l
ive
ry
ENGINE
IGNITION SYSTEM
Ignition ..................................... Digital spark ignition
Ignition advanced...................... 11.25° BTDC
Spark plug.................................. BOSCH UR5CC
Spark plug gap............................ 0.7 mm to 0.8 mm
Fuel supply ............................ Fuel injection
Cooling ................................... Air cooling

15
Royal Eneld Super Meteor 650
TECHNICAL SPECIFICATIONS
Clutch....................... Wet multi plate
Primary drive............ Gear
Primary ratio ............ 2.05:1
Gear box................... 6 Speed constant mesh
Gear ratio ................ 1st 2.615:1
2
nd 1.813:1
3
rd 1.429:1
4
th 1.190:1
5
th 1.040:1
6
th 0.962:1
Secondary drive......... Sprockets and chain (5/8 Pitch)
Secondary ratio......... 2.667:1
TRANSMISSION
Frame ......................... Steel tubular spine frame
Suspension
Front ............... Upside down telescopic fork,
120 mm travel
Rear................. Twin shock, 81 mm travel
Brakes
Front disc ....... Single 320 mm disc, twin piston
oating caliper
Rear disc ......... Single 300 mm disc, twin piston
oating caliper
ABS ................ Dual channel
CHASSIS

Royal Eneld Super Meteor 65016
TECHNICAL SPECIFICATIONS
Type of Wheel Standard Type
Front
(Alloy wheel)
100/9019 M/C 57H CEAT
ZOOM CRUZ Z F TL
(Tubeless tyre)
Rear
(Alloy wheel)
150/80B16 M/C 71H CEAT
ZOOM CRUZ Z F TL
(Tubeless tyre)
Tyre
Pressure Solo With Pillion
Front 41 psi 41 psi
Rear 36 psi 41 psi
Steering lock............................... Ignition barrel (33 deg)
Fuel type .................................... Unleaded gasoline
Ethanol content ......................... E0
Minimum octane rating .............. 91 RON (Research
Octane Number) or
higher
Induction ................................... Fuel injected
Fuel tank capacity ...................... 15.7* L, useable
(14.5 L)
Low fuel warning ....................... 3.1* L, useable
(2.1 L)
Dead stock ................................ 1 L
* The above values are approximate and the actual
capacity will vary with each fuel tank.

17
Royal Eneld Super Meteor 650
TECHNICAL SPECIFICATIONS
System ................................... 12V - DC
Generation.............................. Alternator
Alternator output................... 156 W @ 1100 rpm
Battery.................................... 12V - 12 Ah VRLA
Head lamp............................... FPL 1.55 W LED,
low beam 12.12 W, high
beam + low beam 14.22 W
Brake lamp.............................. 4.5 W, LED
Tail lamp.................................. 2.5 W, LED
Turn signal............................... 12V, 10W
Instrument cluster................... Digital display with
analog speedometer
Horn......................................... 430 Hz high tone
Starter motor............................ 12V, 0.8 kW
Charger Port ............................ USB 2.0 Type A - 5 V 2 A
output
ELECTIRCALS
Using bulbs/electrical gadgets other than specied rating
will lead to overloading/erratic behaviour/premature
failure of electrical system.
Modications or tments which are not approved by
Royal Eneld, will seriously aect the performance of the
vehicle and will render the warranty void.
WARNING

Royal Eneld Super Meteor 65018
TECHNICAL SPECIFICATIONS
Rake/Head angle ................... 27.57 degrees
Front wheel rim size............... MT 2.5 ×19
Rear wheel rim size................. MT 3.5 ×16
Length.................................... 2260 mm
Width..................................... 890 mm (without mirrors)
Height ................................... 1155 mm
Wheel base............................ 1500 mm
Ground clearance
(At static sag)........................ 135 mm
DIMENSIONS WEIGHTS
Kerb weight (90% fuel and oil).............................. 241 kg
Gross vehicle weight ............................................. 429 kg
NOTE
ŶValues / dimensions given above only for your
guidance.
ŶIn view of continuous improvements being done on
our products, the specications could change without
prior notice.
