Rozone ROWASHER User manual

Rozone Ltd Queen Street, Darlaston, Wednesbury, West Midlands United Kingdom WS10 8JF
Tel:- [phone] E-mail: [e-mail]
www.rozone.co.uk
ROWASHER
OPERATING MANUAL

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
Thank you for purchasing the Rozone ROwasher
The Rowasher is designed to safely and
This operating manual has been designed to give you all the information on the
Rozone ROwasher.
Please read carefully before using the machine. Familiarise yourself with this
unit`s operation, its particular features and limitations.
Should you require any further information please call our Rozone Support
Team on 0121 526 8181
The ROwasher is designed to safely and effectively
remove oil and grease from industrial and automotive
parts. It employs a clever technology called
bioremediation to dramatically reduce waste fluid
generation, reducing the expense of hazardous waste
removal and bringing significant savings to the user.
The ROwasher system comprises three distinct parts: The
ROwasher machine, the ROwash Cleaning Solution and
the ROwasher Microbe Filter Mat. The Filter Mat
contains millions of micro-organisms. It releases these
microbes into the ROwasher system to break down or
“eat” the oil and grease that has been washed off dirty
parts into the ROwash Cleaning Solution. The microbes
turn it all into harmless carbon dioxide and water,
leaving the ROwash Solution clean and strong for every
use, effectively recycling the fluid and reducing the need
for hazardous waste disposal. The ROwash Cleaning
Solution is pH neutral, non-caustic, non-flammable and a
biodegradable degreasing solution bringing health and
safety benefits to the user and assisting compliance with
latest workplace legislation.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
ORIGINAL OPERATING INSTRUCTIONS
CONTENTS
1. Safety Instructions
2. Power Connection
3. Proper Use
4. Function
5. Machine Diagram and Parts
6. Setting Up
7. Operation
8. Energy Saving Mode
9. Control Box Diagram –Normal Operation
10.Maintenance and Care
11.Shutting Down
12.Restarting
13.Moving or Transporting
14.Maintenance and Repair
15.Trouble Shooting Guide
16.Accessories and Spare Parts
17.Warranty
18.Disposal Information
19.Environmental Protection
20.CE Declaration and P.A.T. Testing
21.Electrical Box Diagram

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
1. SAFETY INSTRUCTIONS
Every person who works with this machine must be familiar with the content of the
operating instructions prior to use. These instructions are part of the unit and must
be available to operating staff at all times. Please read the operating instructions for
your ROwasher before using it.
In these operating instructions, the designation “the ROwasher” always refers to the
ROw500.
The unit should only be operated by those authorised to do so. Warning information
on the machine provides important directions for safe operation. Misuse of the
ROwasher will affect the safe operation of the machine.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
In addition to the information contained in the operating instructions, all statutory
safety and accident prevention regulations must be observed.
The operating noise level of this machine is below 70dB(A).
Key to Safety Instructions
2. POWER CONNECTION
The voltage indicated on the machine base control box label must correspond to the
voltage of the electrical source.
Safety class 1 –Appliances may only be connected to sockets with proper earthing.
Warning Symbol - You will find this symbol next to all safety instructions
relating to damage prevention. Take caution to avoid personal injury or
material damage.
Prohibition Symbol –You will find this symbol next to all prohibition
instructions where failure to comply could result in direct personal injury
and damage to material. It is mandatory to comply with these instructions

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
It is recommended that you connect this device to a socket that has a 30mA RCD
device guard against earth leakage faults.
Make sure the power cord is not damaged by running over, pinching, dragging or
similar. Protect the cable from heat, oil and sharp edges. If the power cord is
damaged do not use. Damaged supply cords increase the risk of electric shock. The
cable should only be replaced by an approved Rozone Ltd Service Expert
Never touch the mains plug with wet hands
3. PROPER USE
The ROwasher is designed for manually cleaning parts with a maximum weight of
150kg. Do not exceed this weight.
ROwash Cleaning Solution and ROwasher Microbe Filter Mat must be used for the
ROwasher system to function properly. The use of other detergents or cleaning fluids
can hamper or prevent the bioremediation of oil and greases and invalidate the
warranty.
Do not fill the tank with solvents, flammable or explosive liquids.
The ROwasher is not meant for the disposal of used oil. If large quantities of oil,
petrol, engine oil, anti-freeze agents or similar substances are added to the system
this can hamper the bioremediation of oil and grease by the microbes
Do not clean paint brushes or painting tools in the ROwasher or any materials
containing asbestos or other hazardous substances such as pesticides.
The machine should only be used by people who have been instructed in how to use
it properly.
The operator must use the machine as instructed in this manual. The operator must
pay attention to any surrounding hazards and consider those working around him
when using the ROwasher.
The machine must be checked prior to use to ensure that it is in proper working
order and is operating safely.
All electrical equipment in the working area must be protected against any spraying
cleaning solution.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
Please wear appropriate PPE when using the machine –such as safety goggles and
protective gloves.
If the cleaning solution comes into contact with the eyes, please rinse the eyes
thoroughly with water. If swallowed please consult a doctor immediately.
4. FUNCTION
The microbes are first introduced to the system in the ROwasher Microbe Filter Mat
and are then transported by the ROwash Cleaning Fluid through the filter mat into
the ROwasher tank
The cleaning fluid in the tank is heated by the element and transported by the pump
to the sink where it is dispensed through the nozzle and flo-thru brush. The cleaning
fluid must remain heated for the microbes to function properly.
Solid dirt particles washed off parts into the sink are captured in the filter basket in
the sink tray and in the underlying ROwash Microbe Filter Mat which traps large
particles of grease and oil along with any particulate matter larger than 50 microns.
Grease and oil is washed off parts into the ROwasher tank and then degraded by the
microbes into carbon dioxide and water.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
5. MACHINE DIAGRAM AND PARTS
1
8. ROWASHER Tank Base
Part No. 11090800
XL : 11090807
9. Control Box
Part No. 11090803
10. Fluid Sensor
Part No. 11090840
11. Pump
Part No. 11090878
12. Heater
Part No. 11090828
1. Sink Top
Part No. 11090802 XL : 11090804
2. Nozzle
Part No. 11090857
3. Brush
Part No. 11090855 XL : 11090856
4. Filter Support Grid
Part No. 11090826
5. ROWASHER Microbe Filter Mat
Part No.
6. Sink Tray
Part No. 11090805 XL : 11090806
7. Basket Filter Part No. 11090538
1
4
5
6
7
3
2
9
8
9
12
11
10
0

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
6. SETTING UP
After removing packaging, check the unit for transport
damage. If any defect is detected do not connect the
machine to the mains. Report damage to vendor.
Situate the ROwasher on flat stable ground. The floor
must be even to ensure safe operation.
Press the wheel brakes on the rear of the machine
Remove the black sink tray
Unpack the ROwash Microbe Filter Mat and place it
white side up on top of the filter support grid
Replace the black sink tray on top
Pour 80 litres of ROwash Cleaning Solution slowly into the sink
Do not overfill
WARNING –Adding any other cleaning solution or liquids such as solvents,
disinfectants and alkaline cleaners can deactivate the microbes and the bio-
remediation of grease and oil will be affected resulting in the ROwasher not working
properly.
Plug into the correct mains supply. To avoid damage, the machine must be plugged
into the power source stated on the machine control box label. Switch on electrical
supply
The ROwasher will begin to heat up the cleaning solution to its optimal working
temperature of 42°c. (This will take approx. 4 hours)

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
7. OPERATION
Cleaning is a manual operation using the flo-thru brush in the ROwasher sink top
Wear appropriate PPE such as safety goggles and protective gloves
Place the dirty parts in the sink tray (maximum weight 150kg must not be exceeded)
Press the green button to turn the pump on. Wet the sink, nozzle and brushes prior
to cleaning to prevent grease and dirt sticking to the surfaces. The pump will run for
5 minutes and then automatically switch off.
Open the tap of the desired tool –you can use both the nozzle and the flo-thru brush
at the same time for maximum cleaning if desired.
Note: Any parts susceptible to corrosion should not be left in sink after cleaning
As with all partswashers excess grease and oil should be disposed of prior to
washing. DO NOT USE THE ROWASHER AS A WASTE DUMP
Do not turn the ROwasher off unless it is for safety reasons, moving or servicing. The
optimum temperature for the activity of the microbes and therefore breakdown of
oil and grease is between 37°c and 42°c, therefore the ROwasher must always be left
switched on.
8. ENERGY SAVING MODE
After a 4 hour period of inactivity the ROwasher automatically switches to energy
saving mode (37°c) and remains at this temperature until the pump is restarted
when it will return to 42°c

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
9. OPERATIONAL GUIDE FOR CONTROL BOX
No:
Output
Description
Notes
LED 1
FLUID
LED 2
TEMP
Sound
1
Flashing
Yellow
Flashing
Yellow
Beep
Indication of successful
initialisation stage.
Initialisation sequence will start
immediately after machine is
powered on. At the end of
successful initialisation the Sounder
and two LEDs are activated and
should be observed for one second.
Any other colours or no sound at this
point is an indicator of a problem.
2
Solid Green
Solid Green
No
Normal Mode 42°c active.
Liquid level is OK.
Normal operation.
3
Solid Green
Solid Yellow
No
ECO Mode 37°c active.
Liquid level is OK.
Normal operation.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
10. MAINTENANCE AND CARE
DAILY
Check to see if the red “LOW FLUID” indicator light is flashing
If the red “LOW FLUID” light is flashing, pour 20 litres of ROwash Cleaning Solution
into the ROwasher sink
NOTE –Do not overfill the ROwasher.
If the red “LOW FLUID” indicator light is flashing the heater element in the base unit
will be switched off and the cleaning solution will begin to lose temperature.
Therefore it is important to top up the fluid as soon as possible to keep the microbes
at their optimum working temperature
MONTHLY - Change the Filter Mat
First remove the sink tray
Wring out the fluid from the old Filter Mat into the sink
Please dispose of used Filter Mat according to local authority regulations for waste
containing mineral oil (see “Instructions for Disposal”)
Place new ROwasher Microbe Filter Mat white side up onto the filter support grid
Replace the sink tray
YEARLY - Annual maintenance check on the Rowasher recommended
If a cleanout and change of fluid is required please follow correct procedure
Ensure the machine is switched off and unplugged from the mains
Lift off the sink top and disconnect hose pipes
Remove dirty solution from the base unit and dispose of waste according to local
authority regulations (see “Instructions for Disposal”)
Rinse / jetwash the base unit
Replace sink top checking that the hose pipes are all connected
Remove sink tray
Place new ROwasher Microbe Filter Mat white side up on the filter support grid

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
Replace sink tray
Pour 80 litres of new ROwash cleaning solution into the sink
11. SHUTTING DOWN
Switch the power off at the electrical socket.
NOTE –In order for the bioremediation process to occur the temperature of the
cleaning solution must be maintained at 42°c for the microbes to operate at their
optimal level. Therefore the ROwasher must remain plugged in at all times. The
power supply must not be switched off at night or at weekends.
12. RESTARTING
If there is a power failure or the machine is switched off for a considerable length of
time and the cleaning solution is allowed to go cold, new microbes will need to be
added to the cleaning solution.
Replace the Filter Mat (see section “Maintenance and Care/Monthly”)
13. MOVING OR TRANSPORTING
Unplug the ROwasher from the electrical socket ; roll up the power cord. Take off
brakes. Carefully wheel to desired location taking into account the influences of the
surrounding area and ground conditions to ensure the ROwasher does not tip over.
Do not expose the appliance to rain or snow and do not use it in damp or wet
conditions to ensure safe operation.
When finished wheel ROwasher to desired location and plug the power cord back
into the appropriate electrical socket to avoid deterioration of cleaning performance
(see section “Restarting”)
Do not abuse the supply cord and/or the hose. Never use the supply cord or hose
to carry or pull the appliance. Damaged supply cords increase the risk of electric
shock.
14. MAINTENANCE AND REPAIR
Switch off the ROwasher and unplug from mains socket before carrying out any
maintenance on the machine.
Please wear appropriate PPE such as safety goggles and gloves.
Repair work should only be carried out by an approved Rozone Ltd Service Expert.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
15. TROUBLESHOOTING GUIDE
No
:
Output
Description
Notes
LED1
LED2
Sound
Problem Indicators
Solution
4
Flashing Red
every
second
Solid Green
or Yellow
Beep
Liquid level is too low.
Application stopped, heater
and pump are disabled.
a) Check fluid level.
b) Check level sensor position.
c) Replace sensor unit.
5
Both Flashing Red for 3
seconds then 2 seconds
OFF
Beep
Liquid level is too high.
Application stopped, heater
and pump are disabled.
a) Remove some fluid down to
allowed level.
b) Check level sensor position.
c) Replace sensor unit.
6
Both Flashing Red for 4
seconds then 2 seconds
OFF
Beep
No response from sensor.
Application stopped, heater
and pump are disabled.
a) Check sensor connection.
b) Replace sensor unit.
7
Both Flashing Red for 5
seconds then 2 seconds
OFF
Beep
No temperature rise has
been detected.
Application stopped, heater
and pump are disabled.
a) More liquid added while device
was active?
b) Restart unit.
Check fuses.
c) Replace sensor unit.
Heater element requires
replacement.
8
Both Flashing Red for 6
seconds then 2 seconds
OFF
Beep
Critical liquid temperature -
above 48C.
a) Initial liquid temperature was
too high.
b) Faulty heater relay.
c) Restart unit.
Check fuses.
d) Replace sensor unit.
Heater element requires
replacement.
9
Solid Green
Solid Red or
Yellow
No
Pump is not working after
button was pressed.
a) Check pump connection.
b) Check pump fuse.
10
OFF
OFF
No
No signs of activity when
unit is powered on for more
than a minute.
a) Check power connection.
b) Check PSU fuse.
c) Control unit requires
replacement.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
16. ACCESSORIES AND SPARE PARTS
Only use accessories and spare parts which have been approved by Rozone Ltd. This
ensures that the ROwasher operates correctly and safely.
17. WARRANTY
We will repair all machine appliance failures within the warranty period free of
charge, provided that the failure is caused by faulty parts or defects in fabrication.
In the event of a warranty claim please contact your dealer
18. DISPOSAL INFORMATION
Dispose of waste according to local authority regulations. The following EC waste
codes are applicable to the ROwasher Microbe Filter Mats and ROwash Cleaning
Solution
ROWASHER PRODUCT
EU WASTE CODE
FILTER MAT
130899 Oil Waste a.n.g.
ROWASH CLEANING SOLUTION
070601 Watery Wash Liquids
19. ENVIRONMENTAL PROTECTION
The packaging material can be
recycled. Please do not place the
packaging into the ordinary bin
for disposal, arrange for proper
recycling
Old appliances contain valuable
materials that can be recycled.
Please arrange for the proper
recycling of old appliances.
Batteries, oil and similar
substances must not enter the
environment. Please dispose of
your old appliances using
appropriate collection systems.
WEE Producer Registration Number –WEE/JG0549ZR/PRO

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
20. CE DECLARATION
We hereby declare that the machines stated below comply with the relevant basic
health and safety requirements of the EU Directive, both in their basic design and
construction and in the version put into circulation by us. This declaration shall cease
to be valid if the machine is modified in any way without prior approval.
PRODUCT
Machine designed for parts cleaning
using water based cleaning solutions
Type
ROwasher
Relevant EU Directives
2014/35/EU
2014/30/EU
Applied Harmonized Standards
EN61000-6-2:2005
EN61000-6-4:2007
EN60335-1:2012
EN61000-3-2:2014
EN61000-2-3:2013
+A11:2014
A13:2017
IP65
P.A.T. TESTING
The ROwasher machine is of a CLASS 1 construction and due to the weight of the
machine when full should be classed as stationary. We recommend a minimum time
of 12 months for combined testing and inspection and monthly for the formal visual
inspection
EARTH CONTINUITY
Lift the sink and place out of the way allowing access to the heater element. Place
the earth clamp of the P.A.T. tester onto the heater element and take readings as
normal (use the 25amp setting for this test). The heater effectively earths the fluid in
the base of the machine.
EARTH LEAKAGE
A 500v Insulation Test has been carried out on manufacturing of this machine.
If a machine fails the 500v Insulation Test whilst in service a second test may be
carried out with the setting reduced to 240v.

................................................................................
Change the ROWASHER Microbe Filter Mat EVERY MONTH
To Maintain Cleaning Performance
For Technical Support or to order more consumables
Tel: [phone] www.rozone.co.uk
21. ELECTRICAL BOX DIAGRAM
