RS PRO RSPS Series User manual

Quick Start Guide
RSPS Series
Stock number: 2010441 RSPS-6-200 2010442 RSPS-12.5-120
2010443 RSPS-20-76 2010444 RSPS-40-38
2010445 RSPS-60-25
EN
rspro.com

2 rspro.com
Limited Warranty
This product is warranted to the original purchaser against defects in
material and workmanship for 3 years from the date of purchase. During this
warranty period, RS PRO will, at its option, replace or repair the defective
unit, subject to verification of the defect or malfunction. This warranty does
not cover fuses, disposable batteries, or damage from abuse, neglect,
accident, unauthorized repair, alteration, contamination, or abnormal
conditions of operation or handling. Any implied warranties arising out of the
sale of this product, including but not limited to implied warranties of
merchantability and fitness for a particular purpose, are limited to the above.
RS PRO shall not be liable for loss of use of the instrument or other
incidental or consequential damages, expenses, or economic loss, or for any
claim or claims for such damage, expense or economic loss. Some states or
countries laws vary, so the above limitations or exclusions may not apply to
you. For full terms and conditions, refer to the RS PRO website.
This quick start guide contains proprietary information, which is protected by
copyright.All rights are reserved. No part of this quick start guide may be
photocopied, reproduced or translated to another language without prior
written consent.
The information in this quick start guide was correct at the time of printing.
However we continue to improve our products and therefore reserve the
right to change the specifications, equipment, and maintenance procedures
at any time without notice.

3
SAFETY INSTRUCTIONS
This section contains the basic safety symbols that may appear on the
accompanying User Manual CD or on the instrument. For detailed safety
instructions and precautions, please see the Safety Instructions chapter in
the user manual CD.
Safety Symbols
These safety symbols may appear in the user manual or on the instrument.
Warning
Warning: Identifies conditions or practices that could result
in injury or loss of life.
Caution
Caution: Identifies conditions or practices that could result
in damage to the instrument or to other properties.
DANGER High Voltage
Attention Refer to the Manual
Do not dispose electronic equipment as unsorted municipal
waste. Please use a separate collection facility or contact
the supplier from which this instrument was purchased.

4 rspro.com
Power Cord for the United Kingdom
When using the instrument in the United Kingdom, make sure the power
cord meets the following safety instructions.
NOTE: This lead/appliance must only be wired by competent persons.
WARNING: THIS APPLIANCE MUST BE EARTHED IMPORTANT:
The wires in this lead are coloured in accordance with the following code:
Green/ Yellow:
Earth
Blue:
Neutral
Brown:
Live (Phase)
As the colours of the wires in main leads may not correspond with the coloured marking
identified in your plug/appliance, proceed as follows:
The wire which is coloured Green & Yellow must be connected to the Earth terminal
marked with either the letter E, the earth symbol or coloured Green/Green &
Yellow.
The wire which is coloured Blue must be connected to the terminal which is marked
with the letter N or coloured Blue or Black.
The wire which is coloured Brown must be connected to the terminal marked with the
letter L or P or coloured Brown or Red.
If in doubt, consult the instructions provided with the equipment or contact the supplier.
This cable/appliance should be protected by a suitably rated and approved HBC mains
fuse: refer to the rating information on the equipment and/or user instructions for details.
As a guide, a cable of 0.75mm2should be protected by a 3A or 5A fuse. Larger
conductors would normally require 13A types, depending on the connection method
used.
Any exposed wiring from a cable, plug or connection that is engaged in a live socket is
extremely hazardous. If a cable or plug is deemed hazardous, turn off the mains power
and remove the cable, any fuses and fuse assemblies. All hazardous wiring must be
immediately destroyed and replaced in accordance to the above standard.

5
GETTING STARTED
Main Features
Performance
•High power density: 1500W in 1U
•Universal input voltage 85~265Vac, continuous operation.
•Output voltage up to 60V, current up to 200A.
Features
•Active power factor correction.
•Parallel master/slave operation with active current sharing.
•Remote sensing to compensate for voltage drop in load
leads.
•19" rack mounted ATE applications.
•A built-in Web server.
•OVP, OCP and OHP protection.
•Preset memory function.
•Adjustable voltage and current slew rates.
•Bleeder circuit ON/OFF setting.
•CV, CC priority start function. (Prevents overshoot with
output ON)
•Supports test scripts.
Interface
•Built-in RS-232/485, LAN and USB interface.
•Analog output programming and monitoring.
•Optional interfaces: GPIB, Isolated Voltage (0-5V/0-10V)
and Isolated Current (4-20mA) programming and
monitoring interface. (Factory options)

6 rspro.com
Appearance
Front Panel Overview
Lock/Local PROT Function Test Set Output
Unlock ALM_CLR M 1 M 2 M 3
Shift
: Long Push
VSR LAN RMT ERR DLY ALM ISR M 1 M2 M 3 RUN
C C
A
C V
V
VOLTAGE CURRENT
Voltage Current
2 3 4 51
116 7 8 9 10 12 13
Description
1. Power Switch
2. USB A Port
3. Air Inlet
4. Voltage Knob
5. Current Knob
6. Lock/Local Button
7. PROT Button(ALM_CLR Button)
8. Function Button(M1 Button)
9. Test Button(M2 Button)
10. Set Button(M3 Button)
11. Shift Button
12. Output Button
13. Output ON LED
Rear Panel Overview
S LS SLSNC
REMOTE SENSE
ANALOG PROGRAMMING RS485 / 232
OUT IN
LAN
DC OUTPUT
AC INPUT
L N
100 240V
2000VA MAX.
AC
47 63Hz
234 15678
9 10
87654321
0 - 5V / 0 -10V
ISOLATED PROGRAMMING
87654321
4 -20mA
ISOLATED PROGRAMMING
Description
1. AC Inlet
2. DC Output
3. USB Port
4. LAN Port
5. Remote-IN Port
6. Remote-OUT Port
7. Analog Control
8. Remote Sense
9. Option Slot
10. Ground Screw

7
Power up
1. Connect the power cord to the socket on the rear panel.
2. Turn on the power switch on the front panel.
3. The power supply will show the Power On settings (Pon) at start up. If
no Power On settings are configured, the RSPS will recover the state
right before the power was last turned OFF. If used for the first time, the
default settings will appear on the display.
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
V A
Note
You may also configure how the RSPS will behave on
startup by altering the Power On Configuration settings
Power down
To turn the RSPS power supply off, press the power switch again (0
position). It may take a few seconds for the power supply to fully turn off.
CAUTION
The power supply takes around 8 seconds to fully turn on
or shutdown.
Do not turn the power on and off quickly. Please wait for
the display to fully turn off.

8 rspro.com
How to Use the Instrument
Background
The RSPS power supplies use a novel method of
configuring parameter values only using the voltage or
current knobs. The knobs are used to quickly edit
parameter values at 0.01, 0.1 or 1 unit steps at a time.
When the user manual says to set a value or parameter,
use the steps below.
Example
Use the Voltage knob to set a voltage of 10.05 volts.
1. Repeatedly press the Voltage knob until the
least significant digit is highlighted. This will
allow the voltage to be edited in 0.01 volt
steps.
Voltage
2. Turn the Voltage knob till 0.05 volts is shown
on the voltage display
3.
Voltage
AV
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
3. Repeatedly press the Voltage knob until the most
significant digit is highlighted. This will allow the voltage
to be edited in 1 volt steps.
4. Turn the Voltage knob until 10.05 is shown.
AV
VOLTAGE CURRENT
VSR LAN RMT ERR DLY ALM ISR M 1 M 2 M 3 RUN
C V C C
Note
Notice the Set key becomes illuminated when setting the
current or voltage.
If the voltage or current knobs are unresponsive, press the
Set key first.

9
SPECIFICATIONS
The specifications apply when the RSPS is powered on for at least 30
minutes.
Output
Model
RSPS
6-200
12.5-12
0
20-76
40-38
60-25
Rated Output Voltage*1
V
6
12.5
20
40
60
Rated Output Current*2
A
200
120
76
38
25
Rated Output Power
W
1200
1500
1520
1520
1500
Constant Voltage Mode
Model
RSPS
6-20
0
12.5-120
20-76
40-38
60-25
Line regulation*3
mV
2.6
3.25
4
6
8
Load regulation*4
mV
2.6
3.25
4
6
8
Ripple and noise*5
p-p*6
mV
60
60
60
60
60
r.m.s.*7
mV
8
8
8
8
8
Temperature
coefficient
ppm/°C
100ppm/°C of rated output voltage,
after a 30 minute warm-up.
Remote sense
compensation
voltage (single wire)
V
1
1
1
2
3
Rise time*8
Rated load
ms
80
80
80
80
80
No load
ms
80
80
80
80
80
Fall time*9
Rated load
ms
10
50
50
80
80
No load
ms
500
700
800
1000
1100
Transient response
time*10
ms
1.5
1
1
1
1

10 rspro.com
Constant Current Mode
Model
RSPS
6-200
12.5-120
20-76
40-38
60-25
Line regulation*3
mA
22
14
9.6
5.8
4.5
Load regulation*11
mA
45
29
20.2
12.6
10
Ripple and noise*12
r.m.s.
mA
400
240
152
95
75
Temperature
coefficient
ppm/°C
100ppm/°C of rated output current, after a
30 minute warm-up.
Protection Function
Model
RSPS
6-200
12.5-120
20-76
40-38
60-25
Over voltage
protection
(OVP)
Setting range
V
0.6 - 6.6
1.25-
13.75
2 - 22
4 - 44
5 - 66
Setting
accuracy
V
0.06
0.125
0.2
0.4
0.6
Over current
protection
(OCP)
Setting range
A
5 - 220
5 - 132
5 -
83.6
3.8 -
41.8
2.5 -
27.5
Setting
accuracy
A
4
2.4
1.52
0.76
0.5
Under
voltage limit
(UVL)
Setting range
0 - 6.3
0 - 13.12
0 - 21
0 - 42
0 - 63
Model
RSPS All models
Over temperature
protection (OHP)
Operation
Turn the output off.
Incorrect sensing
connection
protection (SENSE)
Operation
Turn the output off.
Low AC input
protection(AC-FAIL)
Operation
Turn the output off.
Shutdown (SD)
Operation
Turn the output off.
Power limit
(POWER LIMIT)
Operation
Over power limit.
Value (fixed)
Approx. 105% of rated output power

11
General Specifications
Model
RSPS All models
Weight
main unit only
kg
Less than 8.7kg
Dimensions
(W×H×D)
mm3
423×43.6×447.2
Cooling
Forced air cooling by internal fan.
EMC
Complies with the European EMC directive 2004/108/EC for ClassA
test and measurement products.
Safety
Complies with the European Low Voltage Directive 2006/95/EC and
carries the CE-marking.
Withstand
voltage
AC to Chassis: 1500Vac/1min
AC to Output terminal: 3000Vac/1min
Output terminal to Chassis:
Vout≤150V: 1000Vdc/1min
150V<Vout≤600V: 1500Vdc/1min
Insulation
resistance
Chassis and output terminal; chassis andAC input;AC input and
output terminal: 100MΩ or more (DC 1000V)

12 rspro.com
Notes:
*1 Minimum voltage is guaranteed to maximum 0.2% of the rated output voltage.
*2 Minimum current is guaranteed to maximum 0.4% of the rated output current.
*3 At 85 ~ 132Vac or 170 ~ 265Vac, constant load.
*4 From No-load to Full-load, constant input voltage. Measured at the sensing
point in Remote Sense.
*5 Measure with JEITA RC-9131B (1:1) probe
*6 Measurement frequency bandwidth is 10Hz to 20MHz.
*7 Measurement frequency bandwidth is 5Hz to 1MHz.
*8 From 10% to 90% of rated output voltage, with rated resistive load.
*9 From 90% to 10% of rated output voltage, with rated resistive load.
*10 Time for output voltage to recover within 0.5% of its rated output for a load
change from 10 to 90% of its rated output current. Voltage set point is from
10% to 100% of rated output.
*11 For load voltage change, equal to the unit voltage rating, constant input
voltage.
*12 For 6V model the ripple is measured at 2 ~ 6V output voltage and full output
current. For other models, the ripple is measured at 10 ~ 100% output voltage
and full output current.
For other detailed specification about RSPS series, please refer to the RSPS
user manual.

13
EC Declaration of Conformity
We declare that the below mentioned product
RSPS-6-200, RSPS-12.5-120, RSPS-20-76, RSPS-40-38, RSPS-60-25
satisfies all the technical relations application to the product within the
scope of council:
Directive: 2014/30/EU; 2014/35/EU; 2011/65/EU; 2012/19/EU. The above
product is in conformity with the following standards or other normative
documents:
◎EMC 
EN 61326-1 :
EN 61326-2-1:
Electrical equipment for measurement, control and
laboratory use –– EMC requirements (2013)
Conducted & Radiated Emission
EN 55011: 2009+A1: 2010
Electrical Fast Transients
EN 61000-4-4: 2012
Current Harmonics
EN 61000-3-2: 2014
Surge Immunity
EN 61000-4-5: 2014
Voltage Fluctuations
EN 61000-3-3: 2013
Conducted Susceptibility
EN 61000-4-6: 2014
Electrostatic Discharge
EN 61000-4-2: 2009
Power Frequency Magnetic Field
EN 61000-4-8: 2010
Radiated Immunity
EN 61000-4-3: 2006+A1: 2008
+A2: 2010
Voltage Dip/ Interruption
EN 61000-4-11: 2004
◎Safety
Low Voltage Equipment Directive 2014/35/EU
Safety Requirements
EN 61010-1: 2010 (Third Edition)
EN 61010-2-030: 2010 (First Edition)

14 rspro.com
Africa
RS Components SA
P.O. Box 12182, Vorna Valley 1686
20 Indianapolis Street, Kyalami Business Park
Kyalami, Midrand, South Africa
Asia
RS Components Ltd.
Suite 1601, Level 16, Tower 1, Kowloon Commerce Centre,
51 Kwai Cheong Road, Kwai Chung, Hong Kong
China
RS Components Ltd.
Suite 23 A-C, East Sea Business Centre Phase 2
NO. 618 Yan’an Eastern Road, Shanghai, 200001, China
Europe
RS Components Ltd.
PO Box 99, Corby, Northants NN17 9RS
United Kingdom
Japan
RS Components Ltd.
West Tower (12th Floor), Yokohama Business Park,
134 Godocho, Hodogaya, Yokohama,
Kanagawa 240-0005 Japan
North America
Allied Electronics
7151 Jack Newell Blvd. S. Fort Worth, Texas 76118
U.S.A.
South America
RS Componentes Electrónicos Limitada
Av. Pdte. Eduardo Frei M. 6001-71, Centro Empresas El Cortijo
Conchali, Santiago, Chile

15
