OCZ OCZ550FTY - MECHANICAL DRAWING User manual

1 6 .0
6 4 .0
1 3 8 .0
8 6 .0
6 .0 11 4 .0 6 .0
1 5 0 .0
8 0 .0
1 6 0 .0
ALL CASE MEASUREMENTS ARE IN mm
5.9" X 3.4" X 6.3” (W X H X D)
ALL WIRE LENGTHS ARE IN INCHES
4 X 6-32
MECHANICAL DRAWING: OCZ550FTY
Orange (+3.3V)
Blue (-12V)
Black (GND)
Green (PS-ON)
Black (GND)
Black (GND)
Black (GND)
Not Used
Red (+5V)
Red (+5V)
Red (+5V)
Black (GND)
(+3.3V) Orange
(+3.3V) Orange
(GND) Black
(+5V) Red
(GND) Black
(+5V) Red
(GND) Black
(PG) Gray
(+5VSB) Violet
(+12V1) Yellow
(+12V1) Yellow
(+3.3V) Orange
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
18” from case 20/24 Motherboard Power
Power Supply’s Modular Connectors
Yellow (+12V1)
Yellow (+12V1)
(GND) Black
(GND) Black
1
2
3
4
18” from case
Yellow (+12V1)
Yellow (+12V1)
Yellow (+12V1)
Yellow (+12V1)
(GND) Black
(GND) Black
(GND) Black
(GND) Black
1
2
3
4
5
6
7
8
18” from case CPU Power
M/B or CPU Power
Serial ATA Peripheral/Floppy
(+12V2) Yellow
(+12V2) Yellow
(+12V2) Yellow
(GND) Black
Black (GND)
Black (GND)
Black (GND)
Black (GND)
1 2 3 4
5 6 7 8
Yellow (+12V2)
Black (GND)
Black (GND)
Red (+5V)
Yellow (+12V2)
Black (GND)
Black (GND)
Red (+5V)
YELLOW (+12V2)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
YELLOW (+12V2)
BLACK (GND)
RED (+5V)
BLACK (GND)
ORANGE (+3.3V)
18” 24” 30” from case 18” 24” 30” from case 18” 24” 30” from case 18” 24” 30” from case
(+12V2) Yellow
(+12V2) Yellow
(+12V2) Yellow
Black (GND)
Black (GND)
Black (GND)
1 2 3
4 5 6
PCI Express Video
19” from case 19” from case 6/8 PCI Express Video
