RSR TB600W3 User manual

3.1Channel Dolby Atmos
Soundbar
Instruction Manual
www.richsound.com
For more indepthinformation, go to our Web site•••••• ••••••••

third prong is provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11 Only use attachments/accessories specied by
the manufacturer.
12 Use only with the cart, stand, tripod,
bracket or table specified by the
manufacturer, or sold with the
apparatus. When a cart or rack is
used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
13 Unplug the apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the unit has been exposed to rain
or moisture, does not operate normally, or has
been dropped.
15 This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not require
a safety connection to electrical earth.
16 The apparatus shall not be exposed to
dripping or splashing. No objects filled with
liquids, such as vases, shall be placed on the
apparatus.
17 Minimum distance around the apparatus for
sucient ventilation is 5cm.
18 The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers,table-cloths, curtains,
etc…
19 No naked flame sources, such as lighted
candles, should be placed on the apparatus.
20 Batteries should be recycled or disposed of as
per state and local guidelines.
21 The use of apparatus in moderate or tropical
climates.
Important Safety Instructions
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude as to constitute a
risk of electric shock to persons.
T h e e x c l a m a t i o n p o i n t w i t h i n a n
equilateral triangle is inten ded to
al er t th e us er t o th e pr e s e n c e of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
Safety
1 Read these instructions – All the safety and
operating instructions should be read before
this product is operated.
2 Keep these instructions – The safety and
operating instructions should be retained for
future reference.
3 Heed all warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
4 Follow all instructions – All operating and
usage instructions should be followed.
5 Do not use this apparatus near water – The
appliance should not be used near water or
moisture – for example, in a wet basement or
near a swimming pool and the like.
6 Clean only with a dry cloth.
7Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8 Do not install near any heat sources such as
radiators, heaters, stoves, or other apparatus
(including ampliers) that produce heat.
9 Do not defeat the safety purpose of the
polarized or grounding plug. A polarized
plug has two blades with one wider than the
other. A grounding plug has two blades and a
third grounding prong. The wide blade or the
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ELECTRIQUE NE PAS PUVRIR

Caution:
- Use of controls or adjustments or performance
of procedures other than those described
herein, may result in hazardous radiation
exposure or other unsafe operation.
- To reduce the risk of re or electric shock, do
not expose this apparatus to rain or moisture.
The apparatus must not be exposed to
dripping or splashing and objects lled with
liquids, such as vases, must not be placed on
apparatus.
- The mains plug/appliance coupler is used as
the disconnect device, the disconnect device
must remain readily operable.
- 4IJFMEFEDBCMFTNVTUCFVTFEXJUIUIJTVOJUUPFOTVSFDPNQMJBODFXJUIUIF$MBTT#'$$MJNJUTDanger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
Warning
• The battery (batteries or battery pack) shall not
be exposed to excessive heat such as sunshine,
re or the like.
• Before operating this system, check the
voltage of this system to see if it is identical to
the voltage of your local power supply.
• Do not place this unit close to strong magnetic
elds.
• Do not place this unit on the amplier or
receiver.
• If any solid object or liquid falls into the
system, unplug the system and have it checked
by qualied personnel before operating it any
further.
• Do not attempt to clean the unit with chemical
solvents as this may damage the nish. Use a
clean, dry or slightly damp cloth.
• When removing the power plug from the wall
outlet, always pull directly on the plug, never
yank on the cord.
• Changes or modications to this unit not
expressly approved by the party responsible
for compliance will void the user’s authority to
operate the equipment.
• The rating label is pasted on the bottom or
back of the equipment.
Battery usage CAUTION
To prevent battery leakage which may result in
bodily injury, property damage, or damage to the
apparatus:
- Install all batteries correctly, + and - as marked
on the apparatus.
- Do not mix old and new batteries.
- Do not mix alkaline, standard (Carbon-Zinc) or
rechargeable (Ni-Cd, Ni- MH, etc.) batteries.
- Remove batteries when the unit is not used for
a long time.
Correct Disposal of this product. This
marking indicates that this product
should not be disposed with other
household wastes throughout the EU.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the product
was purchased. They can take this product for
environmental safe recycling.
We hereby declares that this product
is in compliance with the essential
requirements and other relevant
provisions of Directive 2014/53/EU.

deux lames et une troisième broche pour
la masse. La lame plus large et la troisième
broche sont là pour votre sécurité. Si la prise
fournie ne rentre pas dans votre prise murale,
prenez contact avec un électricien pour le
remplacement de la prise.
10 Protégez le cordon d’alimentation de tout
piétinement et empêchez qu’il soit pincé, et
plus particulièrement au niveau des prises
de courant et de l’endroit où il est branché à
l’appareil.
11 Utilisez uniquement des fixations/accessoires
recommandées par le fabricant.
12 Utilisez uniquement un chariot,
socle, trépied, support ou table
spécifiés par le fabricant ou vendu
avec l’appareil. Lorsqu’un chariot ou
rack est utilisé, soyez prudent quand vous
déplacez l’ensemble chariot/appareil de
manière à éviter les blessures en cas de chute.
13 Débranchez l’appareil en cas d’orage ou
lorsqu’il est inutilisé pendant de longues
périodes.
14 Confiez toute réparation à un personnel
qualié. Une réparation est nécessaire lorsque
l’appareil a été endommagé d’une manière
ou d’une autre, tels que lorsque le cordon
d’alimentation ou la che sont endommagés,
du liquide a été renversé, des objets sont
tombés à l’intérieur, l’appareil a été exposé à la
pluie ou à l’humidité, qu’il ne fonctionne pas
correctement ou qu’il est tombé.
15 Cette unité est un appareil électrique à
double isolation de Classe II. Il a été conçu de
telle sorte qu'il ne nécessite pas une connexion
à la terre pour la sécurité électrique.
16 L’appareil ne doit pas être exposé à des
égouttements ou des éclaboussures. Aucun
objet rempli de liquide, tel qu’un vase, ne doit
être placé sur l’appareil.
17 La distance minimale autour de l’appareil pour
une ventilation susante est de 5 cm.
18 Ne pas entraver la ventilation en recouvrant les
ouvertures de ventilation avec des objets tels
que journaux, nappes de table, rideaux, etc.
19 Ne pas placer de sources de flammes nues,
comme des chandelles, sur le produit.
20 Les piles doivent être recyclées ou mises au
rebut conformément aux directives nationales
et locales.
21 Utiliser l’appareil dans des climats tempérés ou
tropicaux.
Consignes de sécurité
Le symbole éclair avec une èche dans un
triangle équilatéral est destiné à alerter
l’utilisateur de la présence d’une tension
dangereuse non isolée dans le capot
du produit qui peut être d’une ampleur
suffisante pour constituer un risque de
décharge électrique pour les personnes.
Le point d’exclamation dans un triangle
équilatéral est destiné à alerter l’utilisateur
de la présence d’instructions importantes
d’utilisation et de maintenance dans la
documentation accompagnant l’appareil.
Sécurité
1 Lisez ces instructions – Toutes les consignes
de sécurité et de fonctionnement doivent être
lues avant d’utiliser ce produit.
2 Conservez ces instructions – Les instructions
de sécurité et de fonctionnement doivent être
conservées pour référence ultérieure.
3 Respectez tous les avertissements - Tous
les avertissements sur cet appareil et dans
les instructions d’utilisation doivent être
respectées.
4 Suivez toutes les instructions – Toutes les
instructions et consignes d’utilisation doivent
être suivies.
5 N’utilisez pas cet appareil près de l’eau.
L’appareil ne doit jamais être utilisé près de
l’eau ou de l’humidité, tel que dans un sous-sol
humide ou près d’une piscine ou similaires.
6 Nettoyez l’appareil uniquement à l’aide d’un
chion sec.
7 Ne bloquez pas les ouvertures de ventilation.
Installez l’appareil en suivant les instructions
du fabricant.
8 Ne placez pas l’appareil près d’une source de
chaleur, tels que des radiateurs, des bouches
d’air chaud, des gazinières ou tout autre
appareil (y compris des amplificateurs) qui
produisent de la chaleur.
9 N’éliminez pas la fonction de sécurité de la
che polarisée ni de la prise de terre. Une prise
polarisée possède deux lames avec une plus
large que l’autre. Une prise avec terre possède
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ÉLECTRIQUE NE PAS PUVRIR

MISE EN GARDE relative aux piles
Pour éviter les fuites des piles qui pourraient entraîner
des blessures corporelles, des dommages matériels ou
endommager l’appareil :
- Installer toutes les piles correctement, + et -
comme indiqué sur l’appareil.
- Ne pas mélanger des piles usagées et neuves.
- Ne pas mélanger des piles alcalines, standard
(carbone-zinc) ou rechargeables (Ni-Cd, Ni-MH,
etc.).
- Retirer les piles lorsque l’appareil n’est pas utilisé
pendant une longue période.
Mise au rebut de ce produit. Ce
pictogramme indique que ce produit ne
doit pas être jeté avec les autres déchets
ménagers dans toute l’Europe. An de
prévenir toute nuisance possible à
l’environnement ou à la santé humaine causée par
une élimination incontrôlée des déchets, recyclez ce
produit de manière responsable pour promouvoir la
réutilisation durable des ressources matérielles. Pour
retourner votre appareil usagé, veuillez utiliser les
systèmes de reprise et de collecte ou contactez le
revendeur où vous avez acheté le produit. Le
revendeur peut emmener ce produit pour son
recyclage propre et sûr.
Nous déclarons par la présente que ce
produit est conforme aux exigences
essentielles et autres dispositions
pertinentes de la Directive 2014/53/UE.
Attention :
- L’utilisation de dispositifs de commande ou de
réglage ou l’exécution de procédures autres
que celles décrites dans le présent document
peut entraîner une exposition dangereuse aux
rayonnements ou toute autre opération non
sécuritaire.
- An de réduire le risque d’incendie ou
d’électrocution, ne pas exposer cet appareil à la
pluie ou à l’humidité. Cet appareil ne doit pas être
exposé à des égouttements ou éclaboussures, ni
des objets remplis de liquides, tels que des vases,
ne doivent être placés sur l’appareil.
- Si la che secteur ou le coupleur de l’appareil
est utilisé comme sectionneur, ce dispositif doit
toujours rester facilement accessible.
- Le fait de remplacer la pile par une autre pile qui
ne convient pas présente un risque d’explosion.
Remplacer uniquement par une pile de type
identique ou équivalent.
Avertissement
• La pile (piles ou un ensemble de piles) ne doit pas
être exposée à une chaleur excessive, tel que le
soleil, le feu ou similaire.
• Avant de faire fonctionner ce système, vérier que
sa tension est identique à celle de l’alimentation
électrique locale.
• Ne pas placer cet appareil à proximité de champs
magnétiques puissants.
• Ne pas placer cet appareil sur l’amplicateur ou le
récepteur.
• Si un objet solide ou du liquide tombe dans le
système, débrancher le système et le faire vérier
par un personnel qualié avant de le remettre en
marche.
• Ne pas tenter de nettoyer l’appareil avec
des solvants chimiques car cela pourrait en
endommager la surface. Utiliser un chion propre,
sec ou légèrement humide.
• Pour débrancher la che du cordon d’alimentation
de la prise murale, toujours tirer directement sur
la che, ne jamais tirer sur le cordon.
• Tout changement ou modication de cet appareil
non expressément approuvé par la partie
responsable de la conformité annulera le droit de
l’utilisateur d’utiliser l’appareil.
• L’étiquette des caractéristiques nominales est
collée sur la face inférieure ou arrière de l’appareil.

FCC INFORMATION：NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
connected.
• Consult the dealer or an experienced radio / TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
IC-Canada: CAN ICES-3(B)/NMB-3(B)
This device contains licence-exempt transmitter(s)/
receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two
conditions:
1) This device may not cause interference.
2) This device must accept any interference, including
interference that may cause undesired operation
of the device.
FCC & IC Warning:
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
- This equipment should be installed and operated
with minimum distance 20cm between the radiator
& your body.
Déclaration de la FCC :
Remarque: cet équipement a été soumis à des essais
et a été déclaré conforme aux limites stipulées pour
un appareil numérique de classe B, conformément
FCC. Ces limites ont pour but d’assurer une protection
raisonnable contre le brouillage nuisible dans une
installation résidentielle. Cet équipement produit,
utilise et peut émettre de l’énergie en radio fréquence
et, s’il n’est pas installé et utilisé conformément aux
directives, il peut causer un brouillage nuisible dans les
communications radio.
Cependant, il est impossible de garantir qu’aucun
brouillage ne se produira dans une installation
particulière. Si cet équipement cause un brouillage de la
réception de radio ou de télévision, ce qu’il est possible de
déterminer en éteignant puis en rallumant l’équipement,
l’utilisateur est prié d’essayer de corriger le brouillage au
moyen de l’une ou de plusieurs des mesures suivantes :
• Réorienter ou déplacer l’antenne de réception.
• Augmenter la distance entre l’appareil et le
récepteur.
• Brancher l’appareil à une prise sur un circuit
branché.
• Consulter le revendeur ou un technicien radio/TV
expérimenté.
Cet appareil est conforme à la partie 15 des règles
de la FCC. Son fonctionnement est soumis aux deux
conditions suivantes :
(1) ce dispositif ne peut pas causer d’interférences
nuisibles et
(2) cet appareil doit accepte r toute inter férence
reçue, y compris les interférences qui peuvent
causer un mauvais fonctionnement.
IC-Canada : CAN ICES-3(B)/NMB-3(B)
L’émetteur/récepteur exempt de licence contenu dans
le présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions
suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
FCC & IC Avertissement :
non expressément approuvées par la partie
responsable de la conformité pourraient annuler
l’autorisation de l’utilisateur à utiliser l’équipement.
- Pour rester en conformité avec les consignes
d’exposition aux RF, placez le produit à au moins 20
cm des personnes proches.

Contents
2. What’s in the Box .............................................................................................................................. 5
3. Identifying the Parts ........................................................................................................................ 6
3.1 Main Unit ................................................................................................................................................................................................6
3.2 Wireless Subwoofer..............................................................................................................................................................................6
3.3 Remote Control .....................................................................................................................................................................................7
4. Preparations ..................................................................................................................................... 7
4.1 Prepare the Remote Control.............................................................................................................................................................7
4.2 Replace the Remote Control Battery .............................................................................................................................................7
5. Placement and Mounting ................................................................................................................ 8
5.1 Placement................................................................................................................................................................................................8
5.2 Wall Mounting (if using option-B)...................................................................................................................................................8
6. Connections...................................................................................................................................... 9
6.1 Dolby Atmos®.........................................................................................................................................................................................9
6.2 HDMI Connection .................................................................................................................................................................................9
6.3 Use the OPTICAL Socket.....................................................................................................................................................................9
6.4 Use the COAXIAL Socket ................................................................................................................................................................. 10
6.5 Use the AUX Socket........................................................................................................................................................................... 10
6.6 Connect Power ................................................................................................................................................................................... 10
7. Pairing the Wireless Subwoofer with the Main Unit.................................................................... 10
7.1 Automatic pairing.............................................................................................................................................................................. 10
7.2 Manual pairing.................................................................................................................................................................................... 10
8. Basic Operation .............................................................................................................................. 11
8.1 Standby/ON ......................................................................................................................................................................................... 11
8.2 Automatic Power O Function ..................................................................................................................................................... 11
8.3 Select Modes ....................................................................................................................................................................................... 11
8.4 Adjust the Bass/Treble Level.......................................................................................................................................................... 11
8.5 Turn the Surround Sound ON/OFF.............................................................................................................................................. 11
8.6 Select Equalizer (EQ) Eect............................................................................................................................................................. 11
8.7 Adjust the Volume............................................................................................................................................................................. 11
8.8 Adjust the Brightness....................................................................................................................................................................... 11
9. AUX / OPTICAL / COAXIAL / HDMI Operation ............................................................................... 12
10. Bluetooth Operation...................................................................................................................... 12
10.1 Pair Bluetooth-enabled Devices................................................................................................................................................... 12
10.2 Listen to Music from Bluetooth Device...................................................................................................................................... 13
11. USB Operation ................................................................................................................................ 13
12. Troubleshooting............................................................................................................................. 14
13. Specications.................................................................................................................................. 15

5
2. What’s in the Box
• Design and specications are subject to change without notice.
HDMI Cable
3.5mm to 3.5mm
Audio Cable
RCA to 3.5mm
Audio Cable
Main Unit Wireless Subwoofer
Wall Bracket Wall mounting Screw
Remote Control /
AAA Batteries x 2
AC Power Cord x 2

6
7 8 109 11 12 13
3
64
5
2
1
1 2 3
3. Identifying the Parts
3.1 Main Unit
1Remote Control Sensor
Receive signal from the remote control.
2 Display Window
Show the current status.
3Wall bracket screws
4(ON/OFF) button
Switch th e u nit bet ween ON and
Standby mode.
5 (SOURCE) button
Select the play function.
6 VOL+/VOL- buttons
Increase/decrease the volume level.
7AC~ Socket
8 COAXIAL Socket
9 OPTICAL Socket
10 USB Socket
Insert the USB device to play music.
11 AUX Socket
Connect to an external audio device.
12 HDMI OUT (eARC/ARC) Socket
Connect to a TV via HDMI cable.
13 HDMI IN (1/2) Sockets
Connect to a TV via HDMI cable.
3.2 Wireless Subwoofer
1 AC~ Socket Connect to power.
2 PAIR button
Press activate the pairing function
b e t w e e n t h e m a i n u n i t a n d t h e
subwoofer.
3 PAIR Indicator
Light up solidly when the pairing
succeed.

7
1
4
2
6
5
!
"
#
$
3.3 Remote Control
1 Switch the unit between ON and
STANDBY mode.
2 SOURCE buttons Select the play function.
3 / Skip to previous/next track in
Bluetooth/USB mode.
• Play/pause/resume playback in
Bluetooth/USB mode.
Press and hold to activate the pairing
function in Bluetooth mode or
disconnect the existing paired
Bluetooth device.
4 BASS+/- Adjust bass level.
5 TREBLE +/- Adjust treble level.
6 (MUTE) Mute or resume the sound.
• +/- (vol) Increase/decrease the volume level.
7 VERTICAL/SURROUND Adjust the surround ON/OFF.
8 EQ buttons Select Equalizer (EQ) Eect.
9DIMMER Adjust display brightness.
4. Preparations
4.1 Prepare the Remote Control
The provided Remote Control allows the unit to
be operated from a distance.
• Even if the Remote Control is operated within
the effective range 19.7 feet (6m), remote
control operation may be impossible if there
are any obstacles between the unit and the
remote control.
• If the Remote Control is operated near other
products which generate infrared rays, or if
other remote control devices using infra-red
rays are used near the unit, it may operate
incorrectly. Conversely, the other products
may operate incorrectly.
4.2 Replace the Remote Control Battery
1 Press and slide the back cover to open the
battery compartment of the remote control.
2 Insert two AAA size batteries (included). Make
sure the (+) and (–) ends of the batteries match
the (+) and (–) ends indicated in the battery
compartment.
3 Close the battery compartment cover.
1 32
Precautions Concerning Batteries
• Be sure to insert the batteries with correct
positive “Q” and negative “R” polarities.
• Use batteries of the same type. Never use
dierent types of batteries together.
• Either rechargeable or non-rechargeable
b a t t e r i e s c a n b e u s e d. R e f e r t o t h e
precautions on their labels.
• Be aware of your ngernails when removing
the battery cover and the battery.
• Do not drop the remote control.
• Do not allow anything to impact the remote
control.
• Do not spill water or any liquid on the remote
control.
• Do not place the remote control on a wet
object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote control
when not in use for a long period of time,
as corrosion or battery leakage may occur
and result in physical injury, and/or property
damage, and/or re.
• Do not use any batteries other than those
specied.
• Do not mix new batteries with old ones.
• Never recharge a b atter y u nless it is
conrmed to be a rechargeable type.

8
4
870 mm
1
2
870 mm
Remove
the screws
Install the wall
mounting screws
3
4
5. Placement and Mounting
5.1 Placement
A If your TV is placed on a table, you can place
the unit on the table directly in front of the
TV stand, centered with the TV screen.
B If your TV is attached to a wall, you can
mount the unit on the wall directly below the
TV screen.
5.2 Wall Mounting (if using option-B)
- Installation must be carried out by qualied
personnel only. Incorrect assembly can
result in severe personal injury and property
damage (if you intend to install this product
yourself, you must check for installations
such as electrical wiring and plumbing
that may be buried inside the wall). It is the
installer’s responsibility to verify that the wall
will safely support the total load of the unit
and wall brackets.
- Additional tools (not included) are required
for the installation.
- Do not overtighten screws.
- Keep this instruction manual for future
reference.
- Use an electronic stud finder to check the
wall type before drilling and mounting.
1. Drill 4 parallel holes (Ø 5.5-6 mm each
according to wall type) in the wall. The
distance between the holes should be 870
mm.
2. Firmly x 1 dowel into each hole in the wall if
necessary. Tighten the wall mount brackets
on the wall with screws and screwdriver (not
included). Make sure that they are securely
installed.
3. Remove the screws at the back of the unit.
Install the wall mounting screws into the
back of the unit.
4. Lift the unit onto the wall mount brackets
and slot into place.
A B

9
6. Connections
6.1 Dolby Atmos®
Dolby Atmos gives you amazing experience you
have never before by overhead sound, and all the
richness, clarity, and power of Dolby sound.
For using Dolby Atmos®
Dolby Atmos® is available only in HDMI mode. For
the details of the connection, please refer to“HDMI
Connection”.
1. To use Dolby Atmos® in HDMI 1 / HDMI 2
/ HDMI ARC mode, your TV has to support
Dolby Atmos®.
2. Make sure that “No Encoding“ is selected
for bitstream in the audio output of the
connected external device (e.g. Blu-ray DVD
player, TV etc.).
3. While entering Dolby Atmos / Dolby Digital /
PCM format, the soundbar will show DOLBY
ATMOS / DOLBY AUDIO / PCM AUDIO.
6.2 HDMI Connection
Some 4K HDR TVs require the HDMI input or picture
settings to be set for HDR content reception. For
further setup details on HDR display, please refer to
the instruction manual of your TV.
Method 1: ARC (Audio Return Channel)
The ARC (Audio Return Channel) function allows
you to send audio from your ARC- compliant TV to
your sound bar through a single HDMI connection.
To enjoy the ARC function, please ensure your
TV is both HDMI-CEC and ARC compliant and set
up accordingly. When correctly set up, you can
use your TV remote control to adjust the volume
output (VOL +/- and MUTE) of the sound bar.
HDMI
eARC/ARC
HDMI OUT
(eARC/ARC)
56:/)'2)5'>/'2.KGJVNUTK
- Connect the HDMI cable from unit's HDMI OUT
(eARC/ARC) socket to the HDMI (ARC) socket on
your ARC compliant TV. Then press the remote
control to select HDMI (eARC/ARC) .
Tips:
• Your TV must support the HDMI-CEC and
ARC function. HDMI-CEC and ARC must be
set to On.
• The setting method of HDMI-CEC and ARC
may differ depending on the TV. For details
about ARC function, please refer to the
owner’s manual.
Method 2: Standard HDMI
- If your T V is not HDMI ARC-compliant,
connect your soundbar to the TV through a
standard HDMI connection.
HDMI IN 1 HDMI IN 2
HDMI OUT
. . .
HDMI IN
HDMI OUT
(eARC/ARC)
or
56:/)'2)5'>/'2.KGJVNUTK
1. Use an HDMI cable to connect the soundbar's
HDMI OUT (eARC/ARC) socket to the TV’s
HDMI IN socket.
2. Use an HDMI cable to connect the soundbar's
HDMI IN (1 or 2) socket to your external
devices (e.g. games consoles, DVD players
and blu ray).
6.3 Use the OPTICAL Socket
- Remove the protective cap of the OPTICAL
socket, then connect an OPTICAL cable (not
included) to the TV’s OPTICAL OUT socket
and the OPTICAL socket on the unit.
56:/)'2)5'>/'2
.KGJVNUTK

10
6.4 Use the COAXIAL Socket
• You also can use the COAXIAL cable (not
included) to connect the TV's COAXIAL OUT
socket and COAXIAL socket on the unit.
Tip: The unit may not be able to decode all
digital audio formats from the input source.
In this case, the unit will mute. This is NOT a
defect. Ensure that the audio setting of the
input source (e.g. TV, game console, DVD
player, etc.) is set to PCM or Dolby Digital
(Refer to the user manual of the input source
device for its audio setting details) with HDMI
/ OPTICAl / COAXIAL input.
6.5 Use the AUX Socket
A. Use a RCA to 3.5mm audio cable (included)
to connect the TV’s audio output sockets to
the AUX socket on the unit.
.KGJVNUTKAB
B. Use a 3.5mm to 3.5mm audio cable (included)
to connect the TV’s or external audio device
headphone socket to the AUX socket on the
unit.
6.6 Connect Power
• Risk of product damage! Ensure that
the power supply voltage corresponds to the
voltage printed on the back or the underside
of the unit.
• Before connecting the AC power cord, ensure
you have completed all other connections.
• Soundbar
Connect the mains cable to the AC~ Socket
of the main unit and then into a mains
socket.
• Subwoofer
Connect the mains cable to the AC~ Socket
of the Subwoofer and then into a mains
socket.
56:/)'2)5'>/'2.KGJVNUTK
7. Pairing the Wireless Subwoofer
with the Main Unit
7.1 Automatic pairing
The subwoofer and soundbar will automatically
pair when both units are plugged into the mains
sockets and turned on. No cable is needed for
connecting the two units.
• When the subwoofer is pairing with the main
unit, the Pair Indicator will ash fast.
• When the subwoofer is paired with the main
unit, the Pair Indicator will light up.
NOTE:
- Do not press the Pair button on the rear of
the subwoofer, except for manual pairing.
- If the automatic pairing fails, pair the
subwoofer with the main unit manually.
7.2 Manual pairing
1. Ensure that all the cables are well connected
and the main unit is in Standby mode.
2. Press and hold the Pair button on the rear
of the subwoofer for a few seconds. The
subwoofer will enter the pairing mode and
the Pair Indicator will blink quickly.
3. Press the button on the main unit or on the
remote control to switch the main unit on.
4. After the wireless connection succeeded, the
Pair Indicator will light up.
5. If the Pair indicator blinks, the wireless
connection has failed. Unplug the cable of the
subwoofer and then reconnect the main cable
after 4 minutes. Repeat step 1 ~ 4.

11
NOTE:
• If the wireless connection fails again, check if
there is conict or strong interference
(for example, interference from an electronic
device) around your location. Remove these
conflicts or strong interferences and repeat
the above procedures.
• The subwoofer should be within 6m (18 feet)
of the soundbar in an open area.
• If a TV or an external device is connected, the
main unit AUX model and the subwoofer will
switch on automatically when the TV or the
external device is switched on.
• If the main unit is not connected with the
subwoofer and it is in On mode, the POWER
Indicator will flash. Follow step 1 ~ 4 above
to pair the subwoofer to the main unit.
8. Basic Operation
8.1 Standby/ON
When you rst connect the main unit to the mains
socket, the main unit will be in Standby mode.
• Press the button on the unit or on the
remote control to switch the unit ON.
• Press the button again to switch the unit
back to STANDBY mode.
• Disconnect the mains plug from the mains
socket if you want to switch the unit OFF
completely.
- If a TV or an external device is connected, the
unit will switch on automatically when the
TV or the external device is switched on.
8.2 Automatic Power O Function
The unit automatically turns to Standby mode
after about 15 minutes if the TV or the external
unit is disconnected, switched o or the volume is
too close to mute.
• To switch the unit o completely, remove the
mains plug from the mains socket.
• Please turn the unit off completely to save
energy when not in use.
8.3 Select Modes
Press the (SOURCE) button on the unit or the
AUX, BT, OPT/COA, HDMI 1/2, HDMI eARC and
USB and buttons on the remote control to select
the desired mode. The selected mode will show
on the display.
8.4 Adjust the Bass/Treble Level
• Press the BASS +/- buttons on the remote
control to adjust bass level.
• Press the TREBLE +/- buttons on the remote
control to adjust bass level.
8.5 Turn the Surround Sound ON/OFF
• Press the VERTICAL/SURROUND button on
the remote control to turn on the surround
sound. Press this button again to turn o the
surround sound.
8.6 Select Equalizer (EQ) Eect
Press the VOICE / SPORT / MOVIE / MUSIC
buttons on the remote control to select your
desired preset equalizer eects.
8.7 Adjust the Volume
• Press the + / - (VOL) buttons on the unit or
on the remote control to adjust the volume.
• If you wish to turn the sound o, press the
(MUTE) button on the remote control.
Press the (MUTE) button again or press
the + / - (VOL) buttons on the unit or on the
remote control to resume normal listening.
8.8 Adjust the Brightness
- Press the DIMMER button on the remote
control to select brightness level.

12
9. AUX / OPTICAL / COAXIAL /
HDMI Operation
1 Ensure that the unit is connected to the TV or
audio device.
2 Press the button repeatedly on the unit or
the AUX, OPT/COA, HDMI 1/2, HDMI eARC
buttons on the remote control to select the
desired mode. The selected mode will show
on the display.
3 Operate your audio device directly for
playback features.
4 Press the VOL +/– button to adjust the
volume to your desired level.
Tip:
• The unit may not be able to decode all digital
audio formats from the input source. In this
case, the unit will mute. This is NOT a defect.
Ensure that the audio setting of the input
source (e.g. TV, game console, DVD player,
etc.) is set to PCM or Dolby Digital (Refer to
the user manual of the input source device
for its audio setting details) with HDMI 1 /
HDMI 2 / HDMI ARC / OPTICAl / COAXIAL
input.
• When the DOLBY DIGITAL audio format is
entered, the Soundbar display shows DOLBY
AUDIO.
• When the PCM audio format is entered, the
Soundbar display shows PCM AUDIO.
• When entering non-PCM or DOLBY DIGITAL
audio formats, if there’s no sound output
from the unit and the display show NO
SUPPORT.
• The full Dolby Atmos experience is only
available when the Soundbar is connected to
the source via a HDMI 2.0 cable.
• The Soundbar will still function when
connected via other methods (such as a
Digital Optical cable) but these are unable to
support all of the Dolby features. Given this,
our recommendation is to connect via HDMI,
in order to ensure full Dolby support.
10.Bluetooth Operation
10.1 Pair Bluetooth-enabled Devices
The rst time you connect your bluetooth device
to this player, you need to pair your device to this
player.
Note:
- The operational range between this player
and a Bluetooth device is approximately 8
meters (without any object between the
Bluetooth device and the unit).
- Before you connect a Bluetooth device
to this unit, ensure you know the device’s
capabilities.
- Compatibility with all Bluetooth devices is
not guaranteed.
- Any obstacle between this unit and a
Bluetooth device can reduce the operational
range.
- If the signal strength is weak, your Bluetooth
receiver may disconnect, but it will re-enter
pairing mode automatically.
1 During ON mode, press the button
repeatedly on the unit or SOURCE button on
the remote control to select Bluetooth mode.
“NO BT” will show on the display if the unit is
not paired to any Bluetooth device.
2 Activate your Bluetooth device and select the
search mode. “RSR TB600W3” will appear on
ZPVS#luetooth device list.
- If you cannot find the unit, press and hold
the or BT button on the remote control
to be searchable. The display will show“PAIR”
and you will hear "Pairing" from the unit.
3 Select “RSR TB600W3” in the pairing list.
"GUFSTuccessful pairing, you will hear
1BJSFEfrom the unit, and the display panel
TIPXT“BT”.
4 Play music from the connected Bluetooth
device.
To disconnect the Bluetooth function, you can :
- Switch to another function on the unit.
- Disable the function from your Bluetooth
de vi c e.Th e Bl u et o ot h dev ice w il l be
disconnected from the unit af ter the
“Disconnected” voice prompt.
- Press and hold the or BT buttonon the
remote control.

13
Tips:
• Enter "0000" for the password if necessary.
• If no other Bluetooth device pairs with this
player within two minutes, the player will
recover its previous connection.
• The player will also be disconnected when
your device is moved beyond the operational
range.
• If you want to reconnect your device to this
player, place it within the operational range.
• I f t h e d e v i c e i s m o v e d b e y o n d t h e
operational range, when it is brought back,
please check if the device is still connected to
the player.
• I f th e c on ne ct io n is l os t , fol lo w the
instructions above to pair your device to the
player again.
10.2 Listen to Music from Bluetooth Device
- If the connected Bluetooth device supports
Advanced Audio Distribution Prole (A2DP),
you can listen to the music stored on the
device through the player.
- If the device also supports Audio Video
Remote Control Prole (AVRCP), you can use
the player's remote control to play music
stored on the device.
1. Pair your device with the player.
2. Play music via your device (if it supports
A2DP).
3. Use supplied remote control to control play (if
it supports AVRCP).
- To pause/resume play, press the button
on the remote control.
- To skip to a track, press the / buttons
on the remote control.
11.USB Operation
1 Insert the USB device.
USB
2 Press the button repeatedly on the unit
or press the SOURCE button on the remote
control to select USB mode.
3 During playback:
- To pause or resume play, press the button
on the remote control.
- To skip to the previous/next le, press the
/ buttons on the remote control.
Tips:
• The unit can support USB devices with up to
32 GB of memory.
• This unit can play MP3 only.

14
12.Troubleshooting
To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using
this unit, check the following points before requesting service.
No power •Ensure that the AC cord of the apparatus is properly connected .
•Ensure that there is power at the AC outlet.
•Press (standby) button to turn the unit on.
Remote control does not
work
•Before you press any playback control button, rst select the correct
source.
•Reduce the distance between the remote control and the unit.
•Insert the battery with its polarities (+/-) aligned as indicated.
•Replace the battery.
•Aim the remote control directly at the sensor on the front of the unit.
No sound •Make sure that the unit is not muted. Press MUTE or VOL+/VOL– button
to resume normal listening.
•Press button on the unit or on the remote control to switch the
soundbar to standby mode. Then press the button again to switch the
soundbar on.
•Unplug both the soundbar and the subwoofer from the mains socket,
then plug them again. Switch on the soundbar.
•Ensure the audio setting of the input source (e.g. TV, game console, DVD
player, etc.) is set to PCM or Dolby Digital mode while using digital (e.g.
HDMI, OPTICAL, COAXIAL) connection.
•The subwoofer is out of range, please move the subwoofer closer to the
soundbar. Make sure the subwoofer is within 5 m of the soundbar (the
closer the better).
•The soundbar may have lost connection with the subwoofer. Re-pair
the units by following the steps on the section “Pairing the Wireless
Subwoofer with the Soundbar”.
•The unit may not be able to decode all digital audio formats from the
input source. In this case, the unit will mute. This is NOT a defect.device
is not muted.
TV has display problem
while viewing HDR content
from HDMI source.
•Some 4K HDR TVs require the HDMI input or picture settings to be set for
HDR content reception. For further setup details on HDR display, please
refer to the instruction manual of your TV.
I can’t nd the Bluetooth
name of this unit on my
Bluetooth device for
Bluetooth pairing
•Ensure the Bluetooth function is activated on your Bluetooth device.
•Ensure you have paired the unit with your Bluetooth device.
This is a 15 mins power o
function, one of the ERPII
standard requirement for
saving power
•When the unit's external input signal level is too low, the unit will be
turned o automatically in 15 minutes. Please increase the volume level
of your external device.
The subwoofer is idle or
the indicator of subwoofer
do not light up.
•Please unplug power cord from the mains sockect, and plug it in again
after 4 minutes to resent the subwoofer.

15
13.Specications
13.1 Soundbar
Power Supply AC100-240V~ 50/60Hz
Power Consumption 30 W / < W (Standby)
Speakers Impedance 8 Ω + 8 Ω + 4Ω
USB
5V 0.5A
Hi-Speed USB (2.0)
32G (max) , MP3
Audio input sensitivity 500mV
Frequency Response 120Hz - 20KHz
Dimension (WxHxD) 950 x 71 x 112
Net weight 2.85 kg
13.2 Bluetooth / Wireless specication
Bluetooth Version /proles V 4.2 (A2DP, AVRCP)

Bluetooth Frequency bands 2402 MHz ~ 2480 MHz
2.4G wireless frequency range 2400 MHz ~ 2483 MHz
13.3 Subwoofer
Power Supply AC100-240V~ 50/60Hz
Power ConsumptionW / < 0.5 W (Standby)
Impedance 3 Ω
Frequency Response 40Hz - 120Hz
Dimension (WxHxD) 240 x 420 x 240 mm
Net weight 5.5 kg
13.4 Amplier (RMS Output Power)
Total 240 W
Main Unit 30W + 30W + 60W
Subwoofer 120W
13.5 Remote Control
Distance/Angle 6m / 30°
Battery type AAA (1.5V x 2)
