RST OP-WH01 User manual

PRODUCT HANDBOOK
BIG DADDY HAMMOCK
Red Star Traders | www.redstartraders.com | [email protected]
Salt Lake City | Orange County, CA | Shenzhen, China
‘BIG DADDY’ WOOD ARC HAMMOCK SET
5 – Ply Cy ress Wood Frame| Deluxe Hammock Set
model: O -WH01
BIG DADDY HAMMOCK | Assembly Instructions
Please do not return this roduct to the store. Most likely, they do not
stock arts and cannot hel you. For questions, comments and
customer su ort lease email:
[email protected]

PRODUCT HANDBOOK
BIG DADDY HAMMOCK
Red Star Traders | www.redstartraders.com | [email protected]
Salt Lake City | Orange County, CA | Shenzhen, China
Thank you for purchasing the BIG DADDY HAMMOCK. Another great
product, brought to you by Red Star Traders. We hope you will get years of
enjoyment and relaxation from your new purchase. We appreciate your business.
Red Star Traders, LLC
!!!DISCLAIMER | WARNING!!!
Please do not leave children unattended around this
product. Maximum weight limit, 350lbs.
Not to be used by people unwilling or unable to take
responsibility for their actions.
This product requires good balance and coordination
during use. Improper use may result in serious injury.
User assumes all risk when using this product.
Do not use under the influence of drugs or alcohol.
!!!USE AT YOUR OWN RISK!!!
Warranty information
This product is fully warranted by the manufacturer to be free from defects in
materials and workmanship for ONE (1) year form the date of purchase. Red Star
Traders will replace any part or components that are found defective and not fit
for the intended purpose.
Please keep your proof of purchase and email
[email protected] for any warranty claims or after sales
support.
Before assembling your HAMMOCK, please familiarize your self with the
component and make sure you have everything listed below. If you are missing
any parts, please contact [e-mail], or call
[phone].

PRODUCT HANDBOOK
BIG DADDY HAMMOCK
Red Star Traders | www.redstartraders.com | [email protected]
Salt Lake City | Orange County, CA | Shenzhen, China
PARTS LIST
Item
Description
QTY
A
Bottom Support Arches
–
with 2 pre-drilled holes on top (that
attach to base) and 2 recessed holes on each end.
2
B
Base Stands
–
to support the entire hammock.
2
C
Top Support Arches
– with 2 side holes and 1 top end hole.
2
D
Hammock
Bed
1
E
9.5”
Hex
Head B
olt
- with 2 washers and lock nuts. Use to attach
top support to bottom support arches.
4
F
6” Hex Head B
olt
– with lock nut and washer. To attach Bottom
Support Arches to Base Stands
4
G
Chain with
Spring Loaded Carabineer Type H
ooks
2
H
Socket Wrench
with Leverage Bar
–
for assembly. Use to
tighten double treaded screws and hex bolts.
2
I
Eye
Bolt
s
–
used to attach the chain to the frame.
2

PRODUCT HANDBOOK
BIG DADDY HAMMOCK
Red Star Traders | www.redstartraders.com | [email protected]
Salt Lake City | Orange County, CA | Shenzhen, China
Assembly Instructions
You might find it helpful to get someone to help you assemble your Hammock.
Please read and understand all instructions before starting assembly.
Step 1:
Place the 2 base stands(B) about 42”
inches apart with the notched out
sides facing each other.
This will provide a stable base for
your hammock.
Step 2:
Using the 6” hex bolts, attach the
base support arch(A) to the base
stands(B).
Note - Make sure that the recessed
holes are facing out. This allows you
to recess the locking nuts later.
Step 2b:
Repeat Step 2 with the other base
support arch.
Again, note the recessed holes should
face out.

PRODUCT HANDBOOK
BIG DADDY HAMMOCK
Red Star Traders | www.redstartraders.com | [email protected]
Salt Lake City | Orange County, CA | Shenzhen, China
Step 3:
Attached the top support arch(C)
using the 9.5” hex head bolt(E).
Note – 1) It is easier to attach the top
holes first, 2) the dilled hole should be
on top with the recessed side in the
back.
Use the provided socket wrench to
tighten the locking bolts.
Step 3b:
Repeat step 3 on the other side to
form the arch.
Make sure to securely tighten all nuts
and screws before use!
Step 4:
Attach the eye bolts(I) using a
washer, lock nut and socket wrench.
Attach the chain(H) to the assembled
frame using the spring loaded
carabineer hook .
Attach the hammock bed(D) to the
chain(H) using the spring loaded
carabineer hook. Adjust to desired
tension and enjoy.
•Note – it may be necessary to
increase tension from time to time as
your Hammock stretches.
