Rt TR3200 User manual

Hygiene Equipment
Designed for People
1
Registered at Medical Products
Agency, Sweden as a MDR Class 1
product according to MDR 2017/745.
TR reserves the right to make design
changes and/or improvements without
notice.
Always study this manual carefully before operat
ing
the shower trolley.
The operator/user must always have access to the
operating manual.
The shower trolley is intended for professional use
only where the patient will be under supervision of
trained personnel.
Operating instructions and recommended
maintenance procedures are explained in the
following pages.
If you have any questions regarding the operation or
maintenance of your shower trolley and cannot find
the answer in this manual, please contact us.
The shower trolley is designed for years of trouble-
free operation, with proper use and maintenance.
Operating manual
Version
2021
-
01
-
01
TR
3200
Shower Trolley
Mandatory to read the manual before using the
equipment

Hygiene Equipment
Designed for People
2
Table of contents
Manufacturer
3
Introduction
4
Unpacking
5
Intended use
6
Safety instructions
7
-
Safety instructions
7
-
In case of accident
9
Features and controls
10
Product description
12
-
TR3200
1
2
-
TR3200
-
R
1
3
Technical specifications
1
4
-
Technical specifications
1
4
-
Dimensions
1
5
User instructions
1
6
-
Before first use
1
6
-
Height adjustment
1
7
-
Tilt adjustment
1
7
-
Audible tones
TR3200
1
8
-
Audible tones TR3200
-
R
1
8
-
Calibration/Initialization
TR3200
19
-
Calibration/Initialization
TR3200
-
R
19
-
Charging instructions
TR3200
2
0
-
Charging instructions
TR3200
-
R
2
1
-
Side rails
2
2
-
Drainage
2
3
-
Castors with brake
2
3
-
Straight steering castors
2
4
-
Patient handling
2
5
-
Introdu
c
tion
2
5
-
Transfer f
rom sling
lift onto shower trolley
2
6
-
Transfer from
w
heelchair onto
s
hower trolley
2
7
-
Transfer from
b
ed onto
shower t
rolley
2
8
-
Showering the patient
29
Labels & Symbols
3
0
Routine maintenance
3
2
-
Before every use
3
2
-
Daily maintenance
3
2
-
Monthly
maintenance
3
2
-
Annual maintenance
3
3
-
Maintenance every 3 years
3
4
-
Maintenance every 5 years
3
4
-
Maintenance every 10 years
3
4
Recycling
3
5
Cleaning instructions
3
6
Training record
39
Maintenance record
4
0

Hygiene Equipment
Designed for People
3
Manufacturer
TR Equipment AB
Rundelgatan 2
SE-573 35 Tranås
Sverige
Phone: [phone]
www.trequipment.com
[e-mail]
Group subsidiaries:
USA
TR Group Inc. Phone: [phone]
www.trequipment.com
[e-mail]
United Kingdom:
TR Equipment Ltd Phone: [phone]
www.trequipment.com
[email protected].uk
Germany:
TranspoRehamed GmbH Phone: [phone]
www.transporehamed.de
[email protected]

Hygiene Equipment
Designed for People
4
Introduction
Dear Customer,
Thank you for choosing one of our quality products. We hope you enjoy the TR3200 shower trolley.
This manual shall, in conjunction with staff training, ensure that the operator/user is always using
and/or operating the TR3200 correctly.
New users must be trained by qualified and experienced staff.
TR Equipment AB requires that each user has read and understands the entire operating manual
and that they can apply the instructions as specified. This applies to anyone who was not present at
the in-service training.
This instruction manual should generally be kept easily accessible for every user. Copying the whole
manual is encouraged since its sole purpose is to improve the standard of training and safety.
Please order another copy from us if the instruction manual is lost or unusable, or if it has become
illegible over time.
If you need further information, do not hesitate to contact TR Equipment AB or one of our qualified
partners.
Mandatory to read the manual before using the
equipment

Hygiene Equipment
Designed for People
5
Unpacking
TR3200-L/-LR shower trolley is delivered on a pallet with a wooden crate around it.
TR3200 shower trolley is delivered on a pallet with a cardboard box around it.
Unpack the TR 3200-L/ -LR bariatric shower trolley by carefully cut and remove the plastic that surrounds the
wooden crate. DO NOT use any sharp tools that may scratch the shower trolley. Remove the crate by
unscrewing and remove the screws attached to the wooden pallet. Lift the over the TR 3200-L/ -LR (2 people
required).
Unpack the TR3200/ -R bariatric shower trolley by removing the lower cardboard staples with a pliers. If the
cardboard box is wrapped in plastic, carefully cut, and remove the plastic. DO NOT use any sharp tools that
may scratch the shower trolley. Lift the cardboard box over the TR 3200/ -R (2 people required).
Carefully remove the shower trolley from the pallet.
TR3200
-
L/
-
LR
TR3200/
-
R
When
moving the Shower trolley from
the pallet, two people are required.

Hygiene Equipment
Designed for People
6
Intended use
Shower trolley TR3200
- The TR 3200 shower trolley is a battery-operated shower trolley.
- The TR 3200 shower trolley is intended to ease transferring and caring of the patient.
Typical situations where the TR 3200 shower trolley is used includes:
- Transporting the patient to and from a showering area.
- Showering and cleaning the patient.
- Dressing the patient.
- Changing diapers.
- The TR 3200 is NOT intended to be used with patients that exceed a weight of 200kg.
- The patient is typically a person who is unable to take care of their own personal hygiene.
- The TR 3200 is only intended to be used for short term use <60min when in contact with breached or
compromised skin.
- The TR 3200 is intended to be used indoors in all types of care facilities and private homes, including
hygiene areas.
- The user is any adult person who is capable of reading and understands the operating manual and is
qualified to care for dependent persons/patients.
- Before using the TR 3200, the user must read and understand the operating manual.
Important
Mandatory to read the Operating manual before using the shower trolley.
Important
Make sure you have read, understood, and applied the information on the following pages
before using the shower trolley.
Warning
Never leave the patient unattended.

Hygiene Equipment
Designed for People
7
Safety instructions
If you have a question regarding the operation or maintenance of your Shower Trolley and cannot find the
answer in this manual, please contact TR Equipment or your local TR representative.
- Always physically check water temperature before and during showering.
- The patient must be positioned comfortably on the stretcher mattress, with side rails securely locked.
- The bodyweight of the patient and/or body parts should never lean or be supported against the
stretcher side rails.
- Make sure that all parts that comes in contact with the patient are intact and without sharp edges.
- Ensure that the Trolley can be moved, raised, or lowered safely to avoid any pinch injuries to patient.
- Castor brakes must be securely locked on the TR3200 before transferring a patient and once in
position over a drain.
- Operate the Trolley carefully when transporting patients through narrow corridors or over irregular
uneven surfaces.
- Wipe under the Stretcher to prevent water dripping on the floor.
- The TR3200 must be cleaned after each use. Always read and follow detergent supplier instructions.
- Avoid skin or eye contact with detergent, which can be highly corrosive. If contact is made, rinse
immediately with excess water. If irritation occurs, consult a medical doctor. Always read and follow
detergent supplier instructions.
- Battery chargers supplied by TR Equipment are the only ones approved for charging the trolley.
- Do not use battery charger in wet or damp areas – Potential shock hazard.
- It is recommended that the Trolley batteries are charged daily or whenever Trolley is not in use.
- Batteries cannot be overcharged.

Hygiene Equipment
Designed for People
8
Safety instructions
- Check that castor brakes and straight steering are clean and free from damage.
- Check that side rails are locked in place and free from damage.
- Check that all screws are tightened.
- Mattress and pillow must be kept well maintained in place.
- Trolley must be inspected visually for sign or wear.
- Trolley should not be used if defects are noted. Prompt service is required.
If you have questions regarding operation or maintenance of your TR3200 Shower trolley and cannot find the
answer in this manual, please contact TR Equipment or your local TR Equipment representative.
Warning
Never leave the patient unattended.
Warning
Never let the patient sit on the short ends of the stretcher.
Warning
NEVER use the TR3200 shower trolley in any way that varies from the safety precautions and
operating procedures detailed in this manual. The TR3200 shower trolley must not be
operated by anyone until the user has read and understands the instructions in this manual.
Important
Mandatory to read the Operating manual before using the shower trolley.
Important
Only qualified staff, who understand all Operating and Safety procedures may operate the
equipment.

Hygiene Equipment
Designed for People
9
Safety instructions
In case of accident
Note:
In case of a serious incident when using the TR3200 shower trolley, this should be reported
to the manufacturer and to the local authorities where you are established.
TR Equipment AB
Rundelgatan 2
SE-573 35 Tranås
Sweden
www.trequipment.com
[email protected]
Phone: [phone]
Group subsidiaries:
USA
TR Group Inc. Phone: [phone]
www.trequipment.com
[e-mail]
United Kingdom:
TR Equipment Ltd Phone: [phone]
www.trequipment.com
[e-mail]
Germany:
TranspoRehamed GmbH Phone: [phone]
www.transporehamed.de
[e-mail]

Hygiene Equipment
Designed for People
10
Features and controls
TR3200/-L
1
Lifting columns
(2
pcs
)
2
Mattress
3
Pillow
4
Stretcher
5
Castor with barke
6
Straight steering castor
7
Hand control
8
Side rails
9
Side rail lock
10
Drainage
11
Drainage hose 1M
1
2
Drainage plug
1
3
Holder for drainage hose
1
4
Grey or Blue
Wedge pillow
15°
(option)
1
5
Grey or Blue
Wedge pillow
30°
(option)
16
Battery box
with Emergency stop
15
2
4
5
16
7
8
9
14
10, 12
3
1
10, 12
11, 13

Hygiene Equipment
Designed for People
11
Features and controls
TR3200-R/-LR
1
L
ifting columns
2
Mattress
3
Pillow
4
Stretcher
5
Castor with brake
6
Straight steering castor
7
Hand control
8
Side rails
9
Side rail lock
10
Drainage
11
Drainage hose
1M
1
2
Drainage plug
1
3
Holder for drainage hose
1
4
Grey or Blue
Wedge pillow
15°
(option)
1
5
Grey or Blue
Wedge pillow
30°
(option)
16
Removable battery
3
1
2
4
5
6
7
8
9
10, 12
10, 12
11, 13
14
15
16

Hygiene Equipment
Designed for People
12
Product description
TR3200/-L Onboard batteries
Battery operated and height adjustable shower trolley including:
Castors with brake (2 pcs), Straight steering castors (2pcs), Lifting columns (2pcs), Hand control, Battery,
Battery charger, Blue mattress, Blue pillow, Drainages 2pcs, Drainage plugs (2pcs) and Drainage hose 1M.
TR3200 are available in two different sizes:
TR3200
TR3200-L
Accessories/options:
Drainage hose 2,5M
Wedge pillow 15° (Grey or Blue)
Wedge pillow 30° (Grey or Blue)
4pcs castors with brake (-4B)
IV Pole

Hygiene Equipment
Designed for People
13
Product description
TR 3200R/-LR Removable batteries
Battery operated and height adjustable shower trolley including:
Castors with brake (2 pcs), Straight steering castors (2pcs), Lifting columns (2pcs), Hand control,
Removable battery, Battery charger, Blue mattress, Blue pillow, Drainages 2pcs, Drainage plugs (2pcs)
and Drainage hose 1M.
TR3200-R are available in two different sizes
TR3200-R
TR3200-LR
Accessories/options:
Drainage hose 2,5M
Wedge pillow 15° (Grey or Blue)
Wedge pillow 30° (Grey or Blue)
4pcs castors with brake (-4B)
IV Pole

Hygiene Equipment
Designed for People
14
Technical specifications
TR3200/TR3200-R
TR3200/TR3200-R
TR3200L/TR3200-LR
Technical life span
Technical life
span
of the equipment
10 years if the
product
is serviced and maintained
according to instructions in this manual.
Maximum working load
200kg
/ 440lb
Control
Hand control
Operating height range
5
00
–
900
mm
/ 19,7”
–
35,4”
Lifting speed
12mm/s
Mattress and pillow
PVC
IP Class
IP X
5
Floor clearance
160mm
/ 6,3”
Battery
TR3200/
-
L
24VDC 7Ah
(Lead
-
acid, rechargeable)
B
attery
TR3200
-
R/
-
LR
24VDC 4Ah (Li
-
ion rechargeable)
Battery charger input
100
-
240VAC 50/60Hz
Battery charger out put
24VDC
Length
1950mm
/ 76
,8”
Width
695mm
/ 27,4”
Weight
85kg
/ 187Ibs
Length
21
50mm
/ 84,6”
Width
7
95mm
/ 31,3”
Weight
93
kg
/ 205Ibs
Ambient t
emperature
-
20°C
-
+70°C
-
4°F
-
+158°F
Transport and storage

Hygiene Equipment
Designed for People
15
Technical specifications
TR3200/TR3200-R
TR3200L/TR3200-LR
Drawing mm
Drawing Inch

Hygiene Equipment
Designed for People
16
User instructions
Before first use
TR3200 Onboard batteries
- Clean mattress and pillow.
- Make sure the Emergency stop is released.
- Charge the battery for 24hours. See instructions in table of contents.
- Calibrate/initialize the lifting columns. See instructions in table of contents.
TR3200-R Removable battery
- Clean mattress and pillow.
- Charge the battery for 24hours. See instructions in table of contents.
- Calibrate/initialize the lifting columns. See instructions in table of contents.

Hygiene Equipment
Designed for People
17
User instructions
TR3200/TR3200
-
R
–
Height
and tilt
adjustment
Always make sure that the patient is comfortably positioned on the stretcher mattress, with side rails
securely locked before raising, lowering, or tilting the shower trolley.
- Use the hand control to raise and lower the stretcher to desired height.
- Use the hand control to tilt the stretcher to desired angle.
DOWN
UP
TILT
TILT
UP DOWN
TILT TILT
TR3200
TR3200
-
R
Warning
If the patient needs “Trendelenburg” position, only qualified staff who understands the
procedures may operate the Shower trolley.
Important
Maximum working load = 200Kg / 440lbs

Hygiene Equipment
Designed for People
18
User instructions
TR3200 – Audible tones
One short tone
When the stretcher reaches the horizontal position after being tilted a short audible tone will be heard.
One long and one short tone
When the batteries need to be charged, one long and two short tones will be heard.
Connect the battery charger to the shower trolley and charge the batteries for at least 8 hours.
One long and two short tones
When one long and two short tones are heard the lifting columns needs to be calibrated/initialized.
See instructions below.
TR3200-R – Audible tones
One short audible tone + a flashing orange light
The removable battery needs to be charged/replaced.
Connect the battery to the battery charger and charge the
battery for at least 8 hours.
If you have an extra battery on charge, replace the battery and
put the fully charged battery onto the shower trolley.
Put the removed battery on charge for at least 8 hours.
LED light

Hygiene Equipment
Designed for People
19
User instructions
TR3200 – Calibration/Initialization
Use the hand control to calibrate/initialize the lifting columns.
- Press the DOWN button and run the lifting columns
to the lowest position.
- When the lifting columns are in the lowest position
press the DOWN button again.
- Press the DOWN button once more and two short tones
will be heard.
When you hear the two short tones the lifting columns
are calibrated/initialized and the shower trolley is ready
to be used again.
TR3200-R Calibration/initialization
Use the hand control to calibrate/initialize the lifting columns.
Press the UP and DOWN button at the same time and keep the buttons
Pressed during the calibration/initialization. After 5-10 seconds the lifting
Columns will go down. Release the buttons when the lifting columns are in
the lowest position.
The lifting columns are now calibrated/initialized, and the shower trolley is
ready to be used again.
DOWN

Hygiene Equipment
Designed for People
20
User instructions
TR3200
–
Charging instruction
onboard batteries
Charge the battery daily for at least 8 hours or when the low battery audible tone sounds, when using the
hand control. The batteries cannot be overcharged. The battery charger is equipped with a magnetic
connector to avoid damages on the charger if the shower trolley will be moved during charging.
- Use only the battery charger supplied by TR Equipment.
- Connect the charger to the charging connector on the shower trolley before connecting the charger
to the mains supply.
- When the battery charger is properly connected the charging indicator on the charger will be lit. If
not, make sure the plug on the charger is properly connected.
- The charging indicator shows the charging cycles. Yellow while charging and Green when the
batteries are fully charged.
- Minimum charging time is 8 hours. The batteries cannot be overcharged.
- When the charging is completed, disconnect the charger from the mains, before you disconnect
the charger from the lift.
- A flat fuse (15A) is connected between the batteries. The batteries are placed in the battery box
under the mattress.
- Do not use battery charger i wet or damp areas – Potential shock hazard
Shower trolley
charging connector
Charging indicator
Battery charger
charging connector
