EGM
Electret Gooseneck Microphone
The EGM-8N 8” (20 cm), EGM-12N 12” (30.5 cm), and EGM-18N 18” (45.7 cm) electret cardioid microphones are ideally suited
for vocal sound reinforcement, and public address and intercom applications. The unidirectional cardioid response makes them
particularly benecial when background noise is a problem. Each microphone features a self-locking Neutricon connector for
panel mounting, specically selected for use with the previous DKP-8, DKP-12, and KP-12 models.
Utilizes a special, low-mass diaphragm for excellent frequen-
cy and transient response with low distortion.
Always available to the intercom system: no on-off switch.
May be powered from any 9-52 VDC external (phantom)
power source.
Rugged construction for long life.
Panel-mount seven-pin Neutricon connector.
Non-reective black nish.
Features
Line Drawing

EGM Specications
Microphone Element
Electret Condenser
Polar Pattern
Cardioid (unidirectional)
Frequency Response
20 to 20,000 Hz
Output Impedance
5,000
Output Level (Open Circuit at 1 kHz)
-57 dB
Dynamic Range
Greater than 110 dB
Maximum Input SPL (1 kHz, 1% THD)
130 dB
Signal to Noise Ratio
Greater than 67 dB at 1 kHz
Power Requirements
3 to 20 VDC at bias terminal
Connector
Neutricon, seven-pin, self-locking
Ordering Information
EGM-8N: 8” Electret Gooseneck Microphone:
Catalog Number: 90007355002
EGM-12N: 12” Electret Gooseneck Microphone:
Catalog Number: 90007355000
EGM-18N: 18” Electret Gooseneck Microphone:
Catalog Number: 90007355001
This specications information is preliminary and is subject to change without notication.
Brand names mentioned are the property of their respective companies.
Contact Information
Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, Minnesota 55337
Telephone: 877·863·4169
Fax: 800·955·6831
Form Number: LIT000045000
Date: April, 2006
