DS-SABRE-L-2 PAGE 5
Advanced operation
The SABRE system comes with one transmitter, this is already SYNC’ed and will
operate the system out of the box.
To AUTO-SNYC a new transmitter
1. To SYNC a new SABRE handheld transmitter to the receiver box - simply press the SNYC button on the
SABRE receiver board. (see page 3 for button locations)
. The SABRE receiver will flash all of its relay output LEDs at a high rate to show that it is ready for
AUTO-SYNC.
3. Press ANY button on the transmitter handheld that you wish to SNYC to the receiver.
4. All flashing LEDs will go out, LED 8 will flash quickly for seconds then go out.
5. The SABRE receiver will then exit SYNC mode and return to normal operating mode - you may now use
the transmitter to switch the outputs.
MANUAL-SYNC individual transmitter buttons (advanced)
1. To SYNC a specific SABRE handheld transmitter button to a specific output on the SABRE receiver box -
press the SNYC button on the SABRE receiver board. (see page 3 for button locations).
. The SABRE receiver will flash all its relay output LEDs at a high rate to show that it is ready for SYNC.
3. Press the SYNC button again - the SABRE receiver will flash output LED 1 only - this is showing that out-
put 1 is selected. Pressing the SYNC button again will select output and so on to output 4.
4. Once you have selected the required output (that output LED only is flashing) press the SPECIFIC
button on the transmitter handheld that you wish to SNYC to the receiver.
5. The flashing LEDs will go out, LED 8 will flash quickly for seconds then go out.
NOTE: After a successful pairing the SABRE-RX will exit SYNC mode automatically.
You cannot perform and SYNC ALL and then MANUAL SYNC’s a single transmitter.
Erasing ALL transmitters:
1. Open the case and apply power
. Press and hold the ERASE button for 10 seconds
3. All relay LEDs flash together and then go out
4. Erase complete, you can now follow the pairing process to pair your transmitters to the receiver.
ERASE Individual Transmitters:
1. Open the case and apply power
. Press and release the ERASE button
3. The LED next to ERASE should remain lit and all relay LEDs will be flashing
4. Press any button on the transmitter to be erased
5. All output LEDs will go out to show that the transmitter has been erased
6. The SABRE will exit to normal operating mode
Erasing ALL Timers:
1. Open the case and apply power
. Press and hold the TIMER button for 10 seconds,
3. A single relay LED will be flashing
4. When all Relay LED flash together and then go out the timer erase process is complete.
5. All relays will operate as per their jumper settings.
NOTE: Setting a timer OVERIDES all momentary or Latching on board lin settings.
Continued overleaf...
