Runco VideoWall VW-100HD User manual

VideoWall™ VW-100HD
CineWall™ CW-95HD
Full HD, In-Wall Display
INSTALLER/INTEGRATOR MANUAL

To register your Runco product and obtain information about warranty and service offerings, please visit
http://www.runco.com/info.html.
© Copyright 2008 Runco International, LLC (“Runco”). This document contains proprietary information protected by copyright,
trademark and other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written permission of Runco.
The trademarks reproduced in this Runco Owner’s Manual and used on the Runco Products are either owned by Runco or are
licensed by Runco. You may not reproduce or use the trademarks without the prior written consent of Runco.
Runco Products are manufactured under one or more of the following patents: US. Patent 6755540 and Other Patents
Pending.
Online Product Registration and Warranty
COPYRIGHT AND TRADEMARKS:

VideoWall™/CineWall™ Installer/Integrator Manual iii
PRELIMINARY
Thank you for your purchase of this quality Runco video product! It has been designed to provide you with the quality of video
that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the
menus and operation.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for the replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point
where they exit from the apparatus.
11. Only use the attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Keep the packing material in case the equipment should ever need to be shipped.
16. The lamp becomes extremely hot during operation. Allow the display to cool down for approximately 45 minutes prior to
removing the lamp assembly for replacement.
17. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond rated life could cause them to
explode in rare occasions.
18. Never look directly into the lens when the lamp is on.
Important Safety Instructions
WARNING
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.

iv VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Manufacturer’s Name: Runco International, LLC
Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992
hereby declares that the Products’ Model Numbers:
VideoWall™ VW-100HD and CineWall™ CW-95HD
conform with the provisions of:
Council Directive 2004/108/EC on Electromagnetic Compatibility;
EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment”
1998;
EN 55024 “Limits and methods of measurements of immunity characteristics of information technology equipment” 1998;
Including:
• EN 61000-4-2 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 2:
Electrostatic discharge immunity test”
• EN 61000-4-3 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 3: Radiated,
Radio-Frequency, Electromagnetic Field Immunity Test”
• EN 61000-4-4 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 4: Electrical
fast transient/burst immunity test”
• EN 61000-4-5 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 5: Surge
immunity test”
• EN 61000-4-6 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 6: Conducted
disturbances induced by radio-frequency fields immunity test”
• EN 61000-4-8 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 8: Conducted
disturbances induced by power frequency magnetic fields immunity test”
• EN 61000-4-11 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 11: Voltage
dips, short interruptions and voltage variations immunity tests”
Compliance Information
DECLARATION OF CONFORMITY:
During high-voltage spikes in AC power, this product's surge protection circuit may require
re-starting the unit. This behavior is normal.
Note

VideoWall™/CineWall™ Installer/Integrator Manual v
PRELIMINARY
And:
• EN 61000-3-2 “Electromagnetic compatibility (EMC) Part 3, Section 2: Limits for harmonic current emissions (equipment
input current up to and including 16 A per phase)” 2000;
• EN 61000-3-3 “Electromagnetic compatibility (EMC) Part 3, Section 3: Limitations of voltage changes, voltage
fluctuations and flicker in public low-voltage supply systems, for equipment with rated current up to and including 16 A
and not subject to conditional connection” 1995;
Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety;
EN 60950 “Safety of information technology equipment, including electrical business equipment”
The Technical Construction file required by this Directive is maintained at the corporate headquarters of Runco International,
LLC, located at 1195 NW Compton Drive, Beaverton, OR 97006-1992.
Date of Declaration: October 2008
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
FCC PART 15:
INDUSTRY CANADA (ICES-003):

vi VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
The Product contains small amounts of tin, lead and/or mercury. Disposal of these materials may be regulated due to
environmental considerations.
Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can be
hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws.
For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.
For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.
This symbol found on your product or on its packaging, indicates that this product should not be treated as
household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection
point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences to the environment and human health, which could
otherwise be caused by inappropriate disposal of this product. The recycling of materials will help to conserve
natural resources. This symbol is only valid in the European Union. If you wish to discard this product, please
contact your local authorities or dealer and ask for the correct method of disposal.
PRODUCT DISPOSAL:
IMPORTANT RECYCLE INSTRUCTIONS
DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (Applicable throughout the European
Union and other European countries with separate collection programs)

VideoWall™/CineWall™ Installer/Integrator Manual vii
1Table of Contents
Important Safety Instructions........................................................................................ iii
Compliance Information ................................................................................................ iv
1. Introduction ...............................................................................................................1
About This Manual .......................................................................................................1
Target Audience .....................................................................................................1
If You Have Comments About This Manual... ..........................................................1
Textual and Graphic Conventions ...........................................................................1
Using This Manual ........................................................................................................2
Description, Features and Benefits ...............................................................................3
Key Features and Benefits ......................................................................................4
Parts List ................................................................................................................4
Required Personnel, Tools and Materials ......................................................................4
VideoWall/CineWall System Components .....................................................................5
Chassis Assembly...................................................................................................5
Input Connectors and LEDs....................................................................................6
Remote Control ......................................................................................................7
Screen Assembly ....................................................................................................8
Chassis Installation Brackets...................................................................................8
Other System Components ....................................................................................9
2. Installation Preparation ..........................................................................................11
Site Requirements ......................................................................................................11
Infrastructure ........................................................................................................11
Power Requirements ............................................................................................12
Site Access...........................................................................................................12
Environmental Considerations...............................................................................13
Unpacking and Inspecting ..........................................................................................14
Site Preparation ..........................................................................................................16
3. Installation ...............................................................................................................21
Overview ....................................................................................................................21
Mounting the VideoWall/CineWall Chassis ..................................................................22
Install Top Flange and Bottom Brackets on Chassis Assembly .............................22
Install Chassis Assembly into Wall.........................................................................23
Secure Chassis to Wall .........................................................................................23

Table of Contents
viii VideoWall™/CineWall™ Installer/Integrator Manual
Connections to the VideoWall/CineWall ......................................................................26
Connecting Source Components to the VideoWall/CineWall .................................26
RS-232 Controller Connection ..............................................................................28
Connecting to AC Power ......................................................................................29
Installing the Screen ...................................................................................................29
Installing Batteries in the Remote Control ...................................................................32
Notes on Remote Control Operation.....................................................................32
Turning on the Power .................................................................................................32
Aligning the Image ......................................................................................................33
Color Balancing the VideoWall/CineWall .....................................................................34
Picture Adjustments ...................................................................................................35
Selecting a Source................................................................................................36
Input Levels – Analog RGB Sources .....................................................................37
Input Levels – HDMI, Digital, Component, Composite or S-Video Sources............40
Adjusting Image Position.......................................................................................43
Saving Your Work and Recalling a Memory...........................................................44
Memory: What is Saved and Where ......................................................................47
4. Maintenance and Troubleshooting ........................................................................49
Cleaning .....................................................................................................................49
Cleaning the Screen, Mirrors and Lens .................................................................49
Where is the dirt?..................................................................................................50
Lamp Replacement ....................................................................................................51
Removing the Old Lamp .......................................................................................51
Installing the New Lamp........................................................................................52
Resetting Lamp Hours ..........................................................................................52
How to Maintain Lamp Life ...................................................................................52
Filter Replacement .....................................................................................................52
Determining a Changing Schedule ........................................................................52
Removing the Air Filter ..........................................................................................52
Troubleshooting Tips ..................................................................................................53
On-Screen Codes.................................................................................................53
Status LEDs..........................................................................................................55
Isolating Faulty Parts.............................................................................................56
5. Serial Communications..........................................................................................57
RS-232 Connection and Port Configuration ...............................................................57
How to Form Commands ...........................................................................................57
Types of Commands ..................................................................................................58

Table of Contents
VideoWall™/CineWall™ Installer/Integrator Manual ix
Key Commands....................................................................................................58
Operation Commands ..........................................................................................58
String Commands.................................................................................................58
Addresses in Commands ...........................................................................................58
Direct Addressing .................................................................................................58
Command Structure ...................................................................................................59
Using the Operation Commands Table .......................................................................61
Operations and Operation Numbers .....................................................................61
Target...................................................................................................................61
Command Types Allowed.....................................................................................61
Values...................................................................................................................62
Reading the Response..........................................................................................62
Using Key Commands ...............................................................................................64
Command Word Key Commands .........................................................................64
Numeric Equivalent Commands............................................................................65
Examples of Operation Commands ............................................................................66
Recalling Memories...............................................................................................66
Asking (Get) and Telling (Set) ................................................................................68
Types of Responses .............................................................................................68
Operation Commands ................................................................................................71
6. Reference .................................................................................................................91
On-Screen Display (OSD) Menus ................................................................................91
Main Menu............................................................................................................93
Picture .................................................................................................................. 93
Size & Position......................................................................................................96
Aspect Ratio .......................................................................................................100
ISF Memories......................................................................................................105
Memory ..............................................................................................................106
Diagnostics.........................................................................................................108
Advanced Options ..............................................................................................111
Program Information ...........................................................................................115
VideoWall/CineWall Specifications ............................................................................116
Dimensions ..............................................................................................................117
Supported Timings ...................................................................................................119

Table of Contents
xVideoWall™/CineWall™ Installer/Integrator Manual
Notes:

VideoWall™/CineWall™ Installer/Integrator Manual xi
1List of Figures
PRELIMINARY
1-1. Chassis Installation Brackets (Model CW-95HD shown)................................................8
3-1. Installing the Top Flange and Bottom Brackets...........................................................22
3-2. HDMI/DVI Source Connections ..................................................................................26
3-3. VGA Connections.......................................................................................................27
3-4. Component Video Connections..................................................................................27
3-5. Composite and S-Video Connections.........................................................................28
3-6. RS-232 Control System Connection...........................................................................28
3-7. VideoWall/CineWall Screen Assembly – Rear View .....................................................29
3-8. Typical PLUGE Pattern for Adjusting Brightness .........................................................40
3-9. Typical Gray Bar Pattern for Adjusting Contrast ..........................................................41
3-10. Typical Color Bar Pattern for Adjusting Color Saturation and Hue .............................41
5-1. Remote Control Button Names Used in Serial Commands .........................................64
5-2. Remote Control Button Numeric Equivalents..............................................................65
6-1. VideoWall/CineWall OSD Menu Structure ...................................................................92
6-2. Typical Test Pattern for Adjusting Sharpness..............................................................95
6-3. VideoWall VW-100HD Dimensions ...........................................................................117
6-4. CineWall CW-95HD Dimensions...............................................................................118

xii VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Notes:

VideoWall™/CineWall™ Installer/Integrator Manual 1
PRELIMINARY
1.1
About This Manual
This Owner’s Manual describes how to install, set up and operate a Runco
VideoWall/CineWall™ Full HD, In-Wall Display.
Throughout this manual, the Runco VideoWall/CineWall™ Full HD, In-Wall Display is
referred to as the “VideoWall/CineWall.”
Target AudienceRunco has prepared this manual to help home theater installer/integrators safely install
and optimize the performance of the VideoWall/CineWall.
Runco has made every effort to ensure that this manual is accurate as of the date it was
printed. However, because of ongoing product improvements and customer feedback, it
may require updating from time to time. You can always find the latest version of this and
other Runco product manuals on-line, at www.Runco.com.
If You Have Comments
About This Manual...
Runco welcomes your comments about this manual. Send them to [e-mail].
Textual and Graphic
Conventions
Text Conventions: The following conventions are used in this manual, in order to clarify
the information and instructions provided:
• Remote and built-in keypad button identifiers are set in upper-case bold type; for
example, “Press PREV to return to the previous menu.”
• Computer input (commands you type) and output (responses that appear on-screen) is
shown in monospace (fixed-width) type; for example: “To switch to the Component
input, type op 00 select.source = 2 <Enter>.”
• All keys with functional names are initial-capped, set in bold type and enclosed in angle
brackets. These keys are the following: <Enter>, <Spacebar>, <Control>,
<Esc> and <Tab>.
•<Enter> indicates that you may press either the RETURN or ENTER key on your
keyboard if it has both keys.
In addition to these conventions, underlining, boldface and/or italics are occasionally used
to highlight important information, as in this example:
1. Introduction
A carriage return must be used after each command or string.
Note

Introduction
2 VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Graphic Conventions: These symbols appear in numerous places throughout the
manual, to emphasize points that you must keep in mind to avoid problems with your
equipment or injury:
1.2
Using This Manual
Use the following table to locate the specific information you need in this manual.
TIPS highlight time-saving short cuts and helpful guidelines for using
certain features.
NOTES emphasize text with unusual importance or special
significance. They also provide supplemental information.
CAUTIONS alert users that a given action or omitted action can
degrade performance or cause a malfunction.
WARNINGS appear when a given action or omitted action can result
in damage to the equipment, or possible non-fatal injury to the user.
DANGER appears when a given action can cause severe injury or
death.
Tip
Note
Caution
WARNING
DANGER!
If you need... ... Turn to page:
General information about the VideoWall/CineWall™ Full HD,
In-Wall Display
3
Installation preparation guidelines 11
Installation instructions 21
First-time configuration instructions 33
Maintenance and troubleshooting and information 49
Information on using serial commands 57
Instructions for using the on-screen menus 91
Specifications for the VideoWall/CineWall™ Full HD, In-Wall Dis-
plays
116

Introduction
VideoWall™/CineWall™ Installer/Integrator Manual 3
PRELIMINARY
1.3
Description, Features
and Benefits
Runco, the leading brand in luxury video solutions, proudly announces its new
VideoWall™ VW-100HD and CineWall™ CW-95HD in-wall video displays, which offer
custom home theater design and installation professionals new levels of installation
versatility and convenience while achieving full-HD imagery perfection.
Combining the best of front projection’s exceptional image with the aesthetic of a giant
flat-screen display, the VideoWall/CineWall provides a high-performance, in-wall display
solution for rooms of distinction where high ambient lighting conditions exist, but nothing
less than an exceptional Runco cinema experience will suffice.
The VideoWall/CineWall combines an advanced, high-contrast ambient light-rejecting
screen with cinema-grade optics and a powerful display engine in a single, self-contained
system. It is designed for quick and easy installation into a dedicated, framed wall with a
large opening.
The VideoWall/CineWall display engine provides a “Full-HD” (up to 1920 x 1080p) image
with stunning color fidelity, vivid whites, deep blacks and unmatched uniformity.
The VideoWall/CineWall features Runco’s SuperOnyx™ DMD™ chipset with
ConstantContrast™ frame-by-frame contrast correction to provide stellar black levels and
rich color saturation even in bright ambient light viewing. Runco’s exclusive CinOptx™
lens system incorporates O-Path™ light path enhancement for sharp-looking video, while
Vivix II™ internal processing ensures the best video performance.
Two VideoWall/CineWall models are available:
•TheModel VW-100HD features a 100-inch diagonal measure, 16:9 screen
(approximately 88.75 inches wide by 50.5 inches high).
•TheModel CW-95HD features a 95-inch diagonal measure, 2.35:1 screen
(approximately 88.75 inches wide by 37.88 inches high). The CW-95HD provides
uncompromising widescreen reproduction of movies originally filmed in the “scope”
(2.35:1) format, with no black bars above or below the picture.
In addition to wider viewing angles with increased brightness and colorimetry
consistencies, the VideoWall/CineWall provides significant technology and video quality
enhancements when compared to like-sized plasma or LCD products. The system’s
passive cooling allows for virtually silent operation and uses 80 per cent less energy than
comparably-sized flat panels.
The VideoWall/CineWall has been engineered to comply with Imaging Science
Foundation™ (ISF) standards for maximum home theater image quality. Runco's
sophisticated parameters for white balance and color gamut control have also been
implemented for precise balance of gray scale and color. The VideoWall/CineWall
incorporates Runco-proprietary de-interlacing technology that provides exceptional
scaling and film-to-video (3:2 pulldown) conversion for the most artifact-free images
possible.
Discrete IR and RS-232 control make custom installation seamless, while discrete source
and aspect ratio selection accommodate any automation control system.

Introduction
4 VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Key Features and Benefits The VideoWall/CineWall offers these key features and benefits:
• Native Resolution: 1920 x 1080 (VW-100HD; 16:9 Native Aspect Ratio) or 1920 x 817
(CW-95HD; 2.35:1 Native Aspect Ratio)
• 156/180W UHP-type Lamp, 6000-hour median life
• ConstantContrast™ provides for infinitely variable adjustment of the light path through
the optics, enabling the perfect balance of black and white levels for any type of video
source material
Parts List Your VideoWall/CineWall is shipped with the following items. If any items are missing or
damaged, please contact your Runco dealer or Runco Customer Service at (800)
23-RUNCO.
• VideoWall/CineWall™ Full HD, In-Wall Display:
• Chassis Assembly
• Screen Assembly
• Remote Control Unit and two (2), AAA-size batteries
• AC Power Cord (North America), 1.83 meters (6.0 feet)
• VideoWall™/CineWall™ Installer/Integrator Manual (this document)
1.4
Required Personnel,
Tools and Materials
Installing the VideoWall/CineWall requires the following personnel, tools and materials:
• Two or more people familiar with complex mechanical installations. Only authorized,
Runco Academy-trained dealersshould install the VideoWall/CineWall.
• Circular saw
• Drill with ¼” bit
• Screwdrivers
• Socket and crescent wrenches (various sizes)
•Level
• Tape measure
•Studsensor
• Wood screws, bolts, nails, washers and other hardware, as dictated by the installation
method
•For color balancing the display, it is recommended that you use a computer-based
color analyzer (Sencore ColorPro 5000 software and ColorPro III sensor, or equivalent),
hand-held colorimeter or ISF optical comparator
• AVIA or Digital Video Essentials test DVD (or equivalent), for calibrating individual
inputs/sources
➤
➤

Introduction
VideoWall™/CineWall™ Installer/Integrator Manual 5
PRELIMINARY
1.5
VideoWall/CineWall
System Components
This section briefly describes the various VideoWall/CineWall system components.
Chassis AssemblyThe Chassis Assembly is a sheet metal assembly that contains all of the active
components of the VideoWall/CineWall, as shown below.
The lower middle section of the chassis assembly contains all of the active components
described below. A fold mirror mounted at the rear of the chassis reflects light from the
display engine. Several sets of handles are provided on the chassis to aid installation. The
outer handles are for carrying the unit to the installation wall; the inner handles are for
lifting the unit up and into the wall opening.
Display Engine: The display engine mounts directly to a shelf in the center bottom of the
chassis that makes up a plenum for intake air.

Introduction
6 VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Input Connectors and
LEDs
The VideoWall/CineWall interface board provides connections for up to six video sources,
as well as an RS-232 serial connection for personal computer (PC) or automation/control
system interface.
For a list of supported display modes on each input, refer to Supported Timings on
page 119.
1. RS-232
A female, RJ-45 connector for
interfacing with a PC or
automation/control system. For
more information, refer to Serial
Communications on page 57.
2. DIGITAL (DVI)
3. DIGITAL (HDMI)
Two (2), HDCP-compliant digital
video inputs for connecting a DVD
player, personal computer or HD
tuner with a DVI or HDMI output.
4. ANALOG(RGB)
A 15-pin VGA connection to a
personal computer. The
VideoWall/CineWall automatically
detects the signal resolution.
5. STATUSLEDs
These provide information about
the current state of various
VideoWall/CineWall system
components. For information on
how to interpret them, refer to
Status LEDs on page 55.
6. COMPONENT
Standard- or high-definition,
YPrPb component input from a
DVD player, gaming console or
other component video source.
7. S-VIDEO
Standard S-Video input for connecting a DVD player, satellite receiver or Super VHS
(S-VHS) VCR.
8. COMPOSITE
Standard composite video input for connecting a VCR, camcorder, laser disc player or
other composite video source.
➤
Fan - System
Fan - DMD
Fan - Lamp
Ballast Status
Engine Status
Lamp Saver
Serial Cmd
Serial Data
Remote IR
Lamp
Source
Ready
Option Key
DVI TO ENGINE
POWER +5V OUT IR SENSOR CUBE CONTROL
ICP AUX
RS-232
DIGITAL DVI
DIGITAL HDMI
ANALOG
COMPONENT
S-VIDEO
COMPOSITE
INPUT
RS-232
1
2
3
4
5
6
7
8

Introduction
VideoWall™/CineWall™ Installer/Integrator Manual 7
PRELIMINARY
Remote ControlThe VideoWall/CineWall remote control unit, shown below, allows you to perform the
following tasks:
1. ON
Press to turn the
VideoWall/CineWall on.
2. Source Select Buttons
Use these buttons to select a video
source (Analog, Digital DVI, Digital
HDMI, Component, S-Video or
Composite).
3. OFF
Press to turn the
VideoWall/CineWall off.
4. Aspect Ratio Selection Buttons
Use thee buttons to select an
aspect ratio (or “scale mode”)
directly.
5. MENU
Press this button to show or hide
the on-screen display (OSD) menus.
6. ENTER
Press to select a highlighted menu
item or confirm a changed setting.
7. PREV
Press this button to exit the current
menu and return to the previous
one.
8. UP
Use this button to move the menu
cursor up in the OSD.
9. ISF DAY
Press to recall the “ISF Day” memory slot.
10.RIGHT
Use this button to move the menu cursor to the right in the OSD.
11.LEFT
Use this button to move the menu cursor to the left in the OSD.
12.CUST 1-2
Press to recall the “Custom 1” or Custom 2” memory slot.
13.ISF NIGHT
Press to recall the “ISF Night” memory slot.
14.DOWN
Use this button to move the menu cursor down in the OSD.
ON
OFF
CPONENTANALOG
SVIDEO
PREVMENU ENTER
ISF DAY
ISF NIGHT CUST 1-2
HDMI DVI
CPOSITE
4:3 16:9 L BOX
CINEMA V CINE
V WIDE
1
3
5
7
14
9
2
4
6
8
11 10
13 12

Introduction
8 VideoWall™/CineWall™ Installer/Integrator Manual
PRELIMINARY
Screen Assembly The Screen Assembly comprises all of the components associated with the screen which
is attached on the outer side of the installation wall. The Screen Assembly is packaged
separately from the Chassis Assembly, to facilitate unpacking and installation.
Southco-type latches at the bottom of the screen secure the screen in the closed
position.
A hinge system is provided at the top of the screen assembly that interfaces to the top
flange of the chassis assembly. This hinge allows the screen assembly to be “hooked”
from the top during initial installation. Two, small retaining brackets attach to the top rear
of the screen frame. These prevent the screen from “hopping” out of the hinge hook and
thus secure the screen.
Chassis Installation
Brackets
To reduce the overall depth of the chassis assembly for shipping, the installation brackets
that secure the chassis and screen to the wall are packaged separately. These brackets
are installed at the customer site right before installing the chassis assembly into the wall
opening:
Figure 1-1. ChassisInstallation Brackets(Model CW-95HD shown)
➤
➤
Top Flange
Bottom Brackets (4)
Side Light
Block, Left
Bottom
Light
Blocks,
Left Side
(2)
Bottom Light
Blocks, Right
Side (2)
Side Light
Block,
Right
