Runco Reflection VX-5c User manual

REFLECTION
™
SERIES DLP
™
PROJECTORS AND VHD
™
CONTROLLERS
R
EFLECTION
RE
VX-
5c
RUN
CO
INTERNATI
O
NA
L
DI
G
ITAL LI
G
HT PR
OC
E
SS
I
N
G
™
CUTTIN
G
ED
G
E DI
G
ITAL PR
O
JECTI
ON
REV
O
LUTI
O
NARY DI
G
ITAL PR
O
CE
SS
IN
G
F
O
R FIXED PIXEL DEVICE
S
VH
D
™
D
™
VIRTUAL
HI
G
H
DEFINITI
ON
™
©
©
2001
R
unco
I
n
t
erna
t
ona
l
.
All
r
ght
s reserve
d
.
R
e
fl
ec
t
on,
V
r
t
ua
l
Hgh
D
e
f
n
t
on an
d
VHD
are
t
ra
d
emar
k
s o
f
R
unco
I
n
t
erna
t
ona
l
.
Dgt
a
l
L ght
P
rocess n
g
an
d
DLP
are
t
ra
d
emar
k
s o
f
T
exas
I
ns
t
rumen
t
s
.
2001 R I t t
i
l All
i
ht d R fl t
i
V
i
tlH
i
hD f
ii
t
i
dVHD t d k fR I t t
i
lD
ii
tlL
i
ht P
i
dDLP t d k fT I t t
Th
e
W
o
rl
d
’
s Finest Home Theater Products
’
™
™
VX-101c VX-3c
™

Runco International®
2463 Tripaldi Way, Hayward CA 94545
Tel: [phone] • Fax: [phone]
www.runco.com
REFLECTION VX-5CDIGITAL LIGHT PROCESSING PROJECTOR
SPECIFICATIONS FOR THE PROJECTOR
Projector Type: 3-chip DLP™ system, using 0.9”
DMDs
Scan Frequency Range: 15 to 120 KHz Horizontal
24 to 120 Hz Vertical
Native Resolution: 1280 x 1024
Data Compatibility: 640 x 480 to 1600 x 1200
DTV Compatibility: 480p, 720p, 1080i; also 1080p at
24,25 and 30Hz vertical refresh
rates
Lenses: Option 1: 1.5 to 2.2 x width
Option 2: 2.2 to 4 x width
Option 3: 4 to 7 x width
Option 4: 0.8 x screen width
(additional charge; recommended
only for rear-screen applications)
Lamp: 700W Xenon Arc Lamp,
adjustable from 450W to 700W.
Lamp Life: Approx. 1500 Hours
Throw Distances: See ‘Lenses’
Light Output: 3000 ANSI Lumens
Inputs: (1) RGB/Component
Contrast Ratio: 400:1
Bandwidth: 120 MHz
Memories: 100 discrete memories
Power Requirements: 100-240VAC, 50/60 Hz, 1080W
Thermal Dissipation: 3700 BTU’s
Dimensions: Width: 28.9” (734 mm)
Depth: 31.6” (803 mm)
Height: 13”
Weight: 175 lbs
Safety Regulations: Complies with FCC class ‘B’, CE,
C-Tick
Operating environment: 41°-95° (5°-35° C), 20-85%
humidity (non-condensing)
Runco, always committed to
researching, developing, and
refining the latest advancements in
video display technologies, expands
its line-up of Reflection™ Series DLP
projectors with the introduction of
the new flagship VX-5c DLP™ pro-
jector. This ultra-bright projector
incorporates the latest advance-
ments in three-chip DLP™ technol-
ogy, featuring true SXGA native reso-
lution of 1280 x 1024 — ideal for
displaying both HDTV and high-res-
olution computer signals — both in
their native formats. The VX-5c
DLP™ projector utilizes a 700W
Xenon arc lamp that provides a
maximum brightness of 3000 ANSI
lumens. This highly specialized
lamp allows the user to adjust the
wattage range from 450W to
700W, according to the specific
brightness requirements of the
application/installation. Like the
Runco VX-3c DLP™ model, this
projector incorporates both horizon-
tal and vertical lens shift, as well as
keystone correction, for ease and
flexibility of placement. The projec-
tion lens of the VX-5c incorporates
a unique lens shift feature that
provides alignment of the lens to
the projection screen. And, as with
all Reflection™ Series DLP™ projec-
tors, the VX-5c is packaged with the
VHD Ultra Controller, which pro-
vides stunning 10-bit processing,
and an output matched pixel-for-
pixel with the native resolution of
the projector. The high-light output
and high-resolution three-chip
DLP™ optical engine, combined
with the VHD Ultra Controller’s
unparalleled processing, clearly
make the VX-5c the hands-down
favorite for the home-theater
enthusiast.
Inputs: (1) Composite, (1) S-Video,
(1) Component, (1) Pass-through
Input Standards: NTSC (PAL, NTSC export version)
Aspect Ratios: Anamorphic, Letterbox, 4:3
Output Signals: 1280 x 1024 (4:3 screens or 16:9
screens w/optional anamorphic
lens)
1280 x 720 (widescreens)
Power requirements: 100-120 VAC, 50/60 Hz, 15W (220
VAC export version)
Control Options: Infrared, RS-232, Front panel
Bandwidth: Video inputs: 5.5 MHz
Pass-through: 100 MHz
Operating Environment: 41°-95° (5°-35° C), 0-90% Humidity
(non-condensing)
Dimensions: Width: 17.45” (443.23 mm)
Depth: 16” (406.40 mm)
Height: 3.5” (88.90 mm)
Weight: 16lbs. (7.26kg)
Safety Regulations: Complies with FCC class ‘B’, CE,
C-Tick
Thermal Dissipation: 51 BTU’s
FEATURES
• Native SXGA (1280 x 1024) resolution
• 3000 ANSI Lumens; Great for larger screens (>10’ wide)
• Includes one of three standard lens (optional short-throw
lens (0.8 x width) available)
• Lamp current adjustable from 450W-700W
• Horizontal and Vertical lens shift
• Electronic keystone correction
• IR or RS-232 controllable
• Includes VHD™ Ultra Controller
SPECIFICATIONS FOR THE VHD ULTRA CONTROLLER:
THE WORLD’S FINEST
HOME THEATER PRODUCTS™
Call factory for more specific information on export specifications.
Specifications are subject to change without notice.
*Optional anamorphic lens kit available.
9/1/01
