RUSPA CITIPRO Guide

EN 05/2020
CITIPRO SEAT WARRANTY AND INSTRUCTIONS
100% MADE IN ITALY

INDEX pg
1
PRODUCT DESCRIPTION
1
2
MODELS
2
3
MATERIALS
3
4
WARRANTY AND ASSISTANCE ASSEMBLY AND DISASSEMBLY
4
5
KIT SUPPLIED
4
6
ASSEMBLY AND DISASSEMBLY INSTRUCTIONS
5
7
CLEANING
7
8
GRAFFITI REMOVAL
7
9
SANITISING
7
10
POLISHING AND SCRATCH REMOVAL
8
11
WARNINGS
8
12
DISPOSAL
8
1. PRODUCT DESCRIPTION
The CITIPRO seat is a modular system consists of:
-Top profiles with or without handle in plastic or brushed, polished,
painted or anodised aluminium
-Interchangeable seat and back in plastic, glued fabric or padded fabric - Back
support in plastic or aluminium
-Right or left armrest in plastic
-Hip stopper in plastic or aluminium
-Plastic side cover
-USB socket and LED lights
(for maintenance of the USB socket and LED lights contact the manufacturer)
LED LIGHTS
1
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email [e-mail] - www.ruspa.com
STANCHION
HOLDER TOP PROFILE
WITH HANDLE
STRUCTURE BACKREST
HIP STOPPER
ARMREST
COVER
BOTTOM PROFILE
USB SOCKET
SEAT

2. MODELS
TYPES OF SEAT
STRUCTURE
TOP/BOTTOM PROFILE
SEAT/BACKREST
Standard
Aluminium: brushed,
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted
or anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 563
width 432
depth 513
PMR
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 640
width 440
depth 513
Junior
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
Anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 509
width 432
depth 513
Jumbo
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 509
width 624.5
depth 513
Tip up
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 665
width 449
depth
open 555
closed 234
Flip
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
height 494
width 432
depth
open 430
closed 113
Wood
Aluminium: brushed
polished, painted or
anodised
PA6
Aluminium: brushed
polished, painted or
anodised
Wood
height 563
width 432
depth 513
Multiseat
Aluminium: brushed
polished, painted
or anodised
PA6
Aluminium: brushed
polished, painted
or anodised
PA6
Polycarbonate
Polyethylene (PE)
Fabric
variable width
height 640
depth 513
2
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com

3. MATERIALS
PRODUCT
ALUMINIUM STAINLESS STEEL PA6 POLYCARBONATE
POLYETHYLENE WOOD FABRIC
FRAME
PLASTIC TOP AND BOTTOM PROFILE with or without handle
METAL TOP AND BOTTOM PROFILE with or without handle
SEATS AND BACKRESTS for all models
ARMRESTS right or left, upwards tilting
HIP STOPPER corridor side
PLASTIC STANCHION SUPPORT for plastic top profiles
METAL COLUMN SUPPORT for metal top profiles
COVER corridor side
BASES with wall fixing
ADAPTERS made to measure
3
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com

4. WARRANTY AND ASSISTANCE
Thank you for choosing and purchasing our product and for the trust you have placed in us.
This product has a 24-month warranty from the delivery date as displayed on a document
issued by the manufacturer (e.g. document or delivery note that came with the goods). The
warranty is valid for any production defects, quality of the materials used and in the technical
and aesthetic characteristics if they differ from that described in the manufacturer's
specifications.
In case of non-compliance of the ordered product, you have 60 days from receipt of goods to
report any discrepancies.
The aforementioned guarantee will become void if the product is used for any purposes
other than those for which it was designed.
This guarantee does not cover operations and/or repairs and/or any spare parts that are
defective due to:
-Failure to follow the use and maintenance instructions in the booklet supplied - Negligence
and improper use
-Incorrect installation
-Maintenance or repairs carried out by unauthorized personnel and/or use of non-original spare
parts - Damage caused during transport, unless Ruspa Officine S.p.A. carried this out or defects
caused by actions that are not attributable to product conformity defects.
Our Customer Helpline is available Monday to Friday from 08:00 to 17:00 on
+39/011-9234111.
5. KIT SUPPLIED
A maintenance kit is supplied together with the seat comprising:
- 1 magnetic pen for removing the screw covers that secure the top and bottom profiles
- 1 torx key for disassembling the fixing screws
- 2 round magnets
- 2 screw covers
At the end customer’s disposal we provide a complete maintenance kit consisting of:
- 1 magnetic pen for the extraction of the covers of the screws that fix the headers
- 1 Torx-key for removing the fixing screws
- 1 abrasive pad for the maintenance of brushed aluminum, also
suitable for the removal of small superficial scratches on the structure
- 2 anti-vibration adhesive strips
- 2 round magnets
- 2 screw covers
- 1 bottle of detergent
Code. 6759080
4
Image 1
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com

6. ASSEMBLY AND DISASSEMBLY INSTRUCTIONS
Remove the magnetic covers from the frame end with the supplied magnetic pen.
One end has a positive charge and the other negative. Turn the pen round to identify
which end has the correct magnetic charge. (Image 2)
Image 2
Unscrew the torx screws with the key provided and remove them completely. (Image 3)
Image 3
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com 5

6. ASSEMBLY AND DISASSEMBLY INSTRUCTIONS
Remove the top profile by pulling upwards.
If necessary, apply left and right alternating pressure by gently tapping with a non-
marking rubber mallet. (Image 4)
Image 4
Slide backrest or seat out from the metal structure. If the anti-vibration strips are damaged,
replace them with the spare ones supplied with the kit. (Image 5)
Image 5
To reassemble, repeat the above operations in reverse order.
6
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com

7. CLEANING
For cleaning metal, plastic, imitation leather or other parts:
-Use a standard soap-based cleaning product and water - It is always
advisable to carry out a test of the chosen product on less visible areas
before starting complete cleaning
-For deeper cleaning, we recommend a non-abrasive liquid detergent such
as Pulimax MA-FRA®
-Apply the product to a clean cloth or sponge and rub until stains are
eliminated
-Rinse and clean with a dry cloth
-The product has low toxicity. It is advisable to use adequate protection,
gloves and mask as indicated on the packaging.
8. GRAFFITI REMOVAL
-For more tenacious marks such as permanent markers or paint, we
recommend LOCTITE® SF 7063 cleaner spray
-Clean with a dry cloth
-The product has low toxicity. It is advisable to use adequate protection,
gloves and mask as indicated on the packaging.
(Image 6)
Image 6
9. SANITISING
All CITIPRO seats can be disinfected with normal ethyl alcohol, or with
disinfectant products such as those from the SANITIZED® range.
-It is always advisable to conduct a test on a less visible area before
commencing complete cleaning - It is advisable to use adequate
protection, gloves and mask as indicated on the packaging.
RUSPA OFFICINE S.p.A. - Via C. Colombo 2 10070 Robassomero (TURIN) ITALY - Ph. [phone] - Email in[email protected] - www.ruspa.com 7

8
10. POLISHING AND SCRATCH REMOVAL
If the aluminium structure is not painted or anodised, the original brushed finish can
be restored by rubbing with the special medium-grain Scotchbrite™ 3M abrasive
sponge to erase scratches and restore the original satin finish. Then clean with a
normal detergent.
Metal or plastic parts that are badly damaged or which cannot be restored can be
easily replaced, as described in the section describing maintenance and replacement
of parts. (Image 7)
Image 7
11. WARNINGS
-Use only original components and spare parts
-Use cleaning fluids and sanitisers recommended by the manufacturer
-The use of non-compliant materials or equipment, such as those described below, are
NOT recommended:
-Steam cleaners with temperatures above 100°
-Bleaches, acids, paint thinners
-Abrasive pastes or emery papersthat could seriously damage the seat surfaces.
Ruspa Officine S.p.A. declines all responsibility for any damage to persons or things caused
by non-compliance with these warnings and instructions.
In such cases, the guarantee will be invalidated.
12. DISPOSAL
The CITIPRO seat is modular and so can be easily disassembled.
It can be recycled as it is or after simple disassembly, as more than 90% of the
components are made of single materials.
Only those models with padded seats require additional work to separate them into
their constituent parts for recycling, as they are made of a mix of plastic, foam and
coverings.
