Russell Hobbs 23240 User manual

r
I www.russellhobbs.com
23240
Register online for an EXTRA year guarantee
Visit uk.russellhobbs.com/product-registration You must register within 28 days of purchase

2
h b
e
i
f
g
j
k
¬
f
m
h
1- 4
T

3
Read the instructions, keep them safe, pass them on if you pass the appliance on. Remove all
packaging before use.
IMPORTANT SAFEGUARDS
Follow basic safety precautions, including:
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been supervised/
instructed and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by children unless
they are older than 8 and supervised.
Keep the appliance and cable out of reach of children under 8 years.
Misuse of the appliance may cause injury.
h The surfaces of the appliance will get hot. Residual heat will keep
the surfaces hot after use.
l Don’t immerse the appliance in liquid.
If the cable is damaged, it must be replaced by the manufacturer, its
service agent, or someone similarly qualied, to avoid hazard.
• Sit the appliance on a stable, level, heat-resistant surface.
• Keep the appliance and cable away from the edges of worktops.
• Don’t use accessories or attachments other than those we supply.
• Don’t use the appliance for any purpose other than those described in these instructions.
• Don’t use the appliance if it’s damaged or malfunctions.
HOUSEHOLD USE ONLY
PARTS
1. Lid
2. Slot
3. Filter holder
4. Permanent lter
5. Carafe
6. Hotplate
¬Dishwasher - top rack
BEFORE USING FOR THE FIRST TIME
Fill the reservoir to the max mark, and run the appliance without coee.
FILLING
1. Remove the carafe from the hotplate.
2. Open the lid.
3. Fill the reservoir with the exact amount of water required. Note that the brewing process
will use all of the water that you put in the reservoir.

4
4. Make sure that the lter holder is pressed down all the way into position. It will click when
correctly installed.
5. The reservoir is calibrated to give 12 large cups (at 125ml per cup) and 18 small cups (at 83ml
per cup). For each large cup, add 6g of ground lter coee and for each small cup add 4g.
6. Close the lid.
7. Replace the carafe on the hotplate.
SET THE CLOCK
It isn’t neccessary to set the clock to use your coee maker but you will need to set it if you want
to use the timer functions.
1. Put the plug into the power socket.
2. Use the hand min buttons to set the correct time in 24 hour format.
• The clock will retain its settings until the coee maker is unplugged.
COFFEE STRENGTH
Pressing the 1-4 button will make the brewed coee slightly stronger. You can also use it if you
are only brewing a partial carafe of coee (i.e. not completely lling the reservoir). Your coee
maker will then alter the brewing process so your coee will have about the same strength as it
would if you had made a full carafe.
MAKING COFFEE
Note: If you want to use the coee strength feature press the 1-4 button before pressing the ]
button. The 1-4 button will light up.
1. Press the ]button – the 1icon will appear on the display. The ]button will light up.
2. Shortly afterwards, coee will start to drip into the carafe.
3. If you want to stop the coee maker while it’s brewing, press the ]button.
4. Once brewed, the hotplate will keep the carafe warm for up to 40 minutes.
USING THE TIMER
Note: Make sure the clock is set to the correct time. Use the hand min buttons.
1. Set the timer to the time you want to start brewing.
a) Press the Tbutton .
b) Use the hand min buttons to set the time you want brewing to start.
If you don’t press either the hor min buttons within 5 seconds, the coee maker will revert
to “normal”, and the current time will show. Press the Tbutton to start again.
2. When the time is programmed, press the ]button. The Tbutton will light up and the T
icon will appear on the display. Your coee maker is now set to make coee at the selected
time.
3. If you want to use the coee strength feature when using the timer, press the 1-4 button
now. The 1-4 button will light up.
• If you want to cancel the timer before brewing has started, press the ]button.
• If you want to stop the coee maker while it’s brewing, press the ]button.

5
KEEP WARM/AUTO SHUTOFF
1. Your coee maker will keep the coee warm for about 40 minutes.
2. 40 minutes after brewing your coee maker will shut down and the time of day will be
displayed.
3. To wake the appliance, press the min button.
A QUICK CUP
If you want a quick cup of coee before the brewing cycle has nished:
1. You can remove the carafe at any time. The non-drip valve will prevent coee dripping on
to the hotplate.
2. To prevent the lter holder overowing, replace the carafe on the hotplate within about 20
seconds.
3. When you replace the carafe on the hotplate the non-drip valve opens to let any remaining
coee through.
CARE AND MAINTENANCE
1. Unplug the appliance and let it cool.
2. Tip the contents of the lter holder into the bin.
3. Wipe all surfaces with a clean damp cloth.
4. Press the lever at the rear of the carafe lid, above the handle, to open the carafe lid.
5. Hand wash the carafe and lter holder.
6. Replace the lter holder. Make sure that the lter holder is pressed down all the way into
position. It will click when correctly installed.
7. Close the lid, and press down to lock it.
¬ You may wash these parts in the top rack of a dishwasher.
DESCALING
• After 60 brewing cycles, the display will show CL, to indicate that the appliance needs
descaling.
• To turn this function o, press the 1-4 and Tbuttons together, and hold them for 3
seconds.
• Use a proprietary brand of descaler suitable for use in plastic-bodied products. Follow the
instructions on the package of descaler.
• Products returned under guarantee with faults due to scale will be subject to a repair
charge.

6

7

8
RECYCLING
WTo avoid environmental and health problems due to hazardous substances,
appliances and rechargeable and non-rechargeable batteries marked with
one of these symbols must not be disposed of with unsorted municipal
waste. Always dispose of electrical and electronic products and, where
applicable, rechargeable and non-rechargeable batteries, at an appropriate
ocial recycling/collection point.
SERVICE
If you ring Customer Service, please have the Model Number to hand, as we won’t be able to
help you without it. It’s on the rating plate (usually underneath the product).
The product isn’t user-serviceable. If it’s not working, read the instructions, check the plug fuse
and main fuse/circuit breaker. If it’s still not working, consult your retailer.
If that doesn’t solve the problem – ring Customer Service – they may be able to oer technical
advice.
If they advise you to return the product to us, pack it carefully, include a note with your name,
address, day phone number, and what’s wrong. If under guarantee, say where and when
purchased, and include proof of purchase (till receipt). Send it to:
Customer Service
Spectrum Brands (UK) Ltd
Fir Street, Failsworth, Manchester M35 0HS
email: [e-mail]
telephone: [phone] (local rate number)
Please note: If you have purchased the product within the last 6 months, please contact the
retailer in the rst instance to deal with any matters relating to warranty.
GUARANTEE
Defects aecting product functionality appearing within the guarantee period will be corrected
by replacement or repair at our option provided the product is used and maintained in
accordance with the instructions. Your statutory rights are not aected.
This warranty shall not be valid where it is contrary to U.S. and other applicable laws, or where
the warranty would be prohibited under any economic sanctions, export control laws,
embargos, or other restrictive trade measures enforced by the United States or other applicable
jurisdictions. This includes, without limitation, any warranty claims implicating parties from, or
otherwise located in, Cuba, Iran, North Korea, Syria and the Crimea region.
Guarantee period = 2 years from rst retail purchase.
To claim an extra 1 year guarantee, register your product online within 28 days of purchase.
Register at: uk.russellhobbs.com/product-registration
Consumables are guaranteed only for their recommended lifecycle. Replacement/Spare parts*
are excluded and are only covered by a 1 year warranty.
* Examples include lters, removable grill plates, drip trays/crumb trays etc.
JONLINE
www.russellhobbs.com for more products
T22-9001683
