Russell Hobbs RHSV1801 User manual

Model Number: RHSV1801
Turbo Vac Pro
18V 2 in 1 Cordless Cleaner
For Customer Services & Spare Parts please call0345 2097461
Opening times: Monday -Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE

Page(s)
Safety instructions
3-6
Turbo Vac feature diagram
7
Turbo Vac assembly
8-9
Charging your Turbo Vac
10
Using your
Turbo Vac 11-13
Cleaning and care
14 & 16
Wall
mounting your Turbo Vac 15
Problem solving
17
Guarantee and customer services
18
Spare
parts 19
Connection to the mains supply
20-21
Disposal information
24
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Thank you for purchasing your Turbo Vac Pro 18V 2 in 1 Cordless Cleaner.
To get the best from your new cleaner, take a few moments to read these
instructions and keep them in a safe place for future reference.
Should you require any further assistance, our friendly Product Care team will
be happy to help.

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to electrical parts.
•This product is intended for household use only. Do not
use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than
8 and supervised. Keep the appliance and its cord out of
reach of children less than 8 years.
•Only use the charger provided with the product. Using
another charger may damage the product and battery.
•Do not immerse in water or other liquids for cleaning.
•Do not store or charge the unit outdoors
•Do not use outdoors or on wet surfaces
•Do not handle the charger or appliance with wet hands
•Use only as described in this manual

4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not attempt to use the charger with any other
product nor attempt to charge this product with another
charger
•Do not abuse the charger cord; never carry the charger or
base by the cord or pull cord to disconnect from an
outlet; grasp the charger and pull to disconnect from an
outlet.
•Keep hair, clothing, fingers, and all parts of the body
clear of moving parts.
•Do not pick up anything that is flammable, burning or
smoking.
•Use extra care when cleaning on the stairs.
•Never remove parts from the appliance such as the feet,
screws and so on.
•Only use the accessories supplied by the manufacturer.
•Do not operate this appliance for anything other than its
intended use.
•Never put any objects into the openings on the outer
case.
•This appliance is authorized for household/residential
use only
•Do not allow to be used as a toy. Close attention is
necessary when used by or near children.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Children should be supervised to ensure they don’t play
with the appliance.
•Use only as described and for the uses described in this
manual
•Do not use the charger if power cord or plug has been
damaged.
•Do not use cordless sweeper or charger if it has been
dropped, damaged, left outdoors, or dropped in water.
Contact customer services for advice.
•Do not run over charger cord with sweeper. Always
unplug charger from sweeper before use.
•Never carry the charger by the cord, or yank to
disconnect from an outlet, to unplug, always grasp the
plug to remove from outlet, don not pull on cord.
•Keep charger cord away from heated surfaces(e.g.,
cooking surfaces).
•Do not handle charger cord or sweeper with wet hands
or while barefoot.
•Do not put any objects into openings. Do not use with
any opening blocked, keep free of dust, lint, hair and
anything that may reduce particle flow into the dust
container.
•Do not use the sweeper without dust container in place.

6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
•Do not attempt to empty dust container while unit is
running, always turn off the appliance and unplug
before emptying/replacing the dust container.
•Turn off sweeper before clearing debris from floor brush
assembly
•Do not run the vacuum cleaner over any cables - as this
will result in damaging the cable.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

7
TURBO VAC FEATURE DIAGRAM
1Main unit power switch 7Floor head release
button
13 Wall mounting screws
2Handle release button 8Floor head 14 Wall plugs
3Handheld vac release
button
9Main handle 15 Crevice tool
4Handheld vac power switch 10 Handheld handle 16 Brush tool
5Charging indicator light 11 Handheld vacuum 17 Charging cable
6Dust container release
button
12 Charging stand
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
13
14
15
16
17

8
TURBO VAC ASSEMBLY
Before using your cleaner
Remove all packaging and lay out the separate components.
Check the unit after unpacking for any visual damage such as:
•Misaligned or damaged parts
•Damage to the main body and separate components
•Damage to the plug or cable.
If you can see any damage do not use the cleaner and contact
customer services.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

9
TURBO VAC ASSEMBLY
Ensure the power is switched off before assembling.
1. Insert the assembled handheld vacuum unit into the main frame
as shown in the diagram - suction inlet first then pushing the unit
forward to lock into place.
2. Align the bottom of the frame with the connector on the ball joint
of the floor head, inserting the connector until it ‘clicks’ into place
and secures. Tilt the cleaner forward so it stands up independently.
3. Lift the main handle up in an anticlockwise direction until it ‘clicks’
into place. Note: Take care not to trap skin or hair.
4. The main vacuum unit is now ready to be used as a floor cleaner,
once you have given it a charge.
1 2
3 4

10
CHARGING YOUR TURBO VAC
Before using for the first time you will need to charge the cleaner.
The charger can be used either fitted to the wall or mounted on its
floor support. Refer to page 15 for wall mounting instructions.
1. Make sure the charger dock is inserted into the charger floor
support.
2. Plug the charging cable into the adaptor socket on the side of the
charger dock and plug the socket into a suitable 13 Amp mains
socket, pressing the switch on.
3. Lift the assembled cleaner onto the charger dock, ensuring that
the lip on the back clips onto the charging dock and secures.
The charging indicator light on the handheld vacuum will illuminate
red to show that the unit is charging.
A full first time charge should be given, of 14-16 hours.
Once charged, the indicator light will turn blue.
Note:
•The body may become warm during charging and this is
completely normal.
•Make sure the battery is charged when the product will not be
used for prolonged periods of time.
1 2 3

11
USING YOUR TURBO VAC
12
34
Once assembled and charged:
1. Lift the vac off the charging dock and place on the floor.
2. Support the floor head with your foot and pull back the handle
3. Press the main unit power switch downwards to start the power.
This will illuminate the power indicator light on the floor head.
4. Move the cleaner floor head in a forwards and backwards motion
over the areas you would like to clean.
Note: Large items can get trapped in the brush/floor head which
could cause the unit to overheat. Make sure you pick up larger items
that could get trapped before vacuuming.
5. To turn off the power, pull the main unit power switch upwards.
The power indicator light will turn off.

12
USING YOUR TURBO VAC - HANDHELD
3 4
12
1. To convert from full sized vac to handheld cleaner, make sure the
unit is stood in the upright position and press in the handheld vac
release button. Ensure you are holding the handheld unit handle so
that it can be pulled out safely.
2. Attach the tool of choice by slotting it into the suction inlet of the
handheld unit, with the clear side facing upwards. To remove the
tool, pull away from the inlet to slide it out.
•The crevice tool can be attached for cleaning hard to reach
areas, such as sofas, cobwebs high up or down to skirting.
•The brush tool is ideal for cleaning upholstery and stairs.
3. To start cleaning, press down the handheld unit power switch.
4. Move the cleaner suction inlet over the areas you would like to
clean, avoiding any liquids and large or sharp objects.

13
USING YOUR TURBO VAC
1 2
3 4
Emptying the dust container
When the dust container starts to fill it will need to be emptied. This
will help it to maintain suction performance.
1. To remove the dust container, press the release button located just
above where the container is attached.
2. Pull the dust container away from the unit.
3. Over a bin, remove the whole filter and tap off the trapped dirt. Tip
the container upside down to empty the contents. You may need to
tap the sides to dispose of all of the dirt.
4. Place the filter back into the dust container in the direction
indicated by the diagram.
Important:
You may wish to empty the dust container outdoors as emptying may
create a dust cloud.
5. Place the assembled dust container back onto the unit, until it
secures into place.

14
CLEANING AND CARE:
CLEANING THE FILTER
It is necessary to clean the filters regularly with frequent use in
order to maintain suction performance and prolong the life span of
your cleaner.
1. Follow steps 1 to 3 on page 13.
2. Carefully wash the filter and dust bag in warm water and allow to
dry for 24 hours.
3. Once dried, place the filter back into the dust container in the
direction indicated by the diagram.
4. Place the assembled dust container back onto the unit, until it
clips into place.
After around 6 months of regular use the filters may need replacing.
Refer to page 19 and Contact Customer Services.
Floor head brush maintenance
If any threads or hair gets trapped in the brush you may need to
carry out maintenance.
For regular maintenance, pull out the waste from around the bar.
If you cannot manually rotate the brush, unscrew the cover and
remove the brush to clean it.
When reinserting, make sure the brush cover is securely fixed and
that the brush rotates properly.

15
WALL MOUNTING YOUR TURBO VAC
What you will need
Use the three wall mounting screws and three wall plugs provided
with the product (under the stand floor support.)
You will also require: a drill with an 6mm masonry drill bit, a sharp
pencil, a screw driver, a hammer and, ideally, a spirit level.
Take out your wall mounting template sheet provided in the Turbo
Vac gift box.
Note: The below measurements are a guide only and should be
adjusted according to your requirements.
Hard wall mounting
1. Using a spirit level and a pencil, draw a horizontal line of
approximately 5cm long at least 50cm from the floor.
2. Place the wall mounting template directly under the line you have
marked on the wall.
3. Using a sharp pencil, pierce a mark on each ‘+’ sign on the
template, making sure the template does not move.
4. Using an 6mm masonry drill bit, drill the three holes previously
marked out.
5. Insert the three wall plugs/fixings into the drilled holes and knock
in with a hammer to secure.
6. Insert the three screws into the fixings, so that the screws take to
the wall plug, leaving approximately 8-10mm of the screw to hang
the wall mounting bracket over.
7. Insert the wall bracket over the screws and let the bracket fall into
place.
8. Tighten all three screws securely, being careful not to over-tighten.
9. Place the cleaner unit onto the bracket.
Note: For partitioning walls, you will require plaster board fixings to
mount the wall bracket (not supplied.)

16
CLEANING AND CARE
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Before you clean the appliance, make sure the power is switched off
and that the unit is not on the charging stand.
It is recommended to store the appliance on the charging stand. Do
not leave plugged in for extended periods of time.
You can fold the handle by pressing in the handle release button and
folding backwards.
You can also remove the floor head by pressing in the floor head
release button and pulling the head away from the unit.
To clean the exterior of the device, use a damp, soft cloth and mild
detergent.
NEVER IMMERSE THE CLEANER IN WATER.
Wash non-electrical removable accessories in warm soapy water and
allow to dry thoroughly before next use.
If the cleaner is damaged, contact the customer service helpline
using the details at the bottom of this page.
Storage
Store in a clean and dry environment.

17
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
The cleaner won’t
turn
on
The cleaner
hasn’t had
enough charge
Make sure you have plugged in the cleaner to charge for
14
-16 hours. The light will illuminate when charging.
Charging cable is
damaged
Make sure there is no signs of damage to the charging
cable
.
The power switch has not
been pressed
Make sure you have turned on the power using either the
main unit power switch or the handheld power switch.
The suction
is
decreasing and the
cleaner is not picking
up dirt
Dust container
Check if
the dust container is full, if so, empty it.
Filters are dirty
Clean the filters. After around 6 months of regular use the
filters may need replacing. Contact Customer Services
using the details at the bottom of this page.
Handheld/head
blockages
Check that there are no blockages in the handheld suction
inlet or cleaning head. If so, clear these blockages.
Cleaner is over
heating
Filters are dirty
Check that the filters are not blocked,
if so, clean them
following the instructions in this booklet.
The charging stand is
not working
The
unit is not fitted
correctly on the stand or
the stand is not correctly
plugged in to the mains
Dust is coming out of
the vacuum cleaner
Dust container fitting
The dust container has not been fitted correctly. Refit the
container following the instructions in this booklet.
The air coming out of
the vacuum cleaner
smells
Filters are dirty
Clean the filters
and dust container.
Filters are not dry
Ensure the filters have been left to dry for 24 hours before
refitting back into the vacuum cleaner and using.
We’re here should you need us.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

18
GUARANTEE AND CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday –Friday: 8am-8pm & Saturday: 9am –1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original
proof of purchase.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
•It must be used for domestic purposes only and for its intended
use.
•This warranty does not cover wear and tear, damage, misuse
or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

19
SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
1
4
23
56
1
Dust container
4
Crevice tool
2
Dust container
filters
5
Brush tool
3
Charging stand
6
Charging cable

20
Revision 2.1
Model: RHSV1801
This symbol is known as the 'Crossed-out wheelie bin Symbol'.
When this symbol is marked on a product/batteries, it means that
the product/batteries should not be disposed of with your general
household waste. Only discard electrical/electronic/battery items
in separate collection schemes, which cater for the recovery and
recycling of materials contained within. Your co-operation is vital
to ensure the success of these schemes and for the protection of
the environment. For your nearest disposal facility, visit
www.recycle-more.co.uk or ask in store for details.
We reserve the right, due to possible changes to design, to alter
the instruction manual without prior notice.
For Customer Services & Spare
Parts please call
0345 209 7461
Opening times: Monday - Friday
8am –8pm & Saturday 9am –1pm
Or visit us at
www.productcare.co.uk
Produced for:
G2S Ltd,
Wigan,
WN2 4AY
