Russell Hobbs Vario Max RHBCV2502 User manual

Model Number: RHBCV2502
220-240V~, 50/60Hz, 700W
Vario Max
Bagged Cylinder Vacuum Cleaner
For Customer Services & Spare Parts please call0345 2097461
Opening times: Monday -Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE

Page(s)
Safety instructions
3-6
Energy
performance label 7
Technical data
8
Vacuum
feature diagram 9
Vacuum cleaner
assembly 10-11
Using your vacuum
cleaner 12-15
Cleaning and care
16-18
Problem solving
19
Guarantee and customer services
20
Spare
parts 21
Connection to the mains supply
22
Disposal information
24
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Thank you for purchasing your Russell Hobbs Vario Max Bagged Cylinder
Vacuum Cleaner.
To get the best from your new cleaner, take a few moments to read these
instructions and keep them in a safe place for future reference.
Should you require any further assistance, our friendly Product Care team will
be happy to help.

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to electrical parts.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•This product is intended for household use only.
Do not use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
•Do not operate this appliance for anything other than its
intended use. This product is intended for household use
only. Do not use outdoors.
•Do not immerse in water or other liquids for cleaning.

4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
•Do not direct at people, animals, electrical outlets, or
equipment containing electrical components.
•Unplug from outlet when not in use. Do not leave the
cleaner unattended while plugged in.
•Do not use with damaged cord or plug.
•Do not use vacuum cleaner if it has been dropped,
damaged, left outdoors or dropped into water.
•Keep the vacuum cleaner away from water; do not allow
it to get wet. If unit is wet, do not plug unit into wall
socket or turn unit on.
•Do not handle the vacuum cleaner with wet hands.
•Do not pull or carry by cord, use cord as a handle, close
door on cord, pull cord around sharp corners or edges, or
expose cord to heated surfaces.
•Do not unplug by pulling on cord.
•To protect against electrical shock do not immerse cord,
plug, or appliance in water or other liquid.
•Unplug from the mains outlet when not in use, before
putting on and taking off parts, and before cleaning.
•The use of accessory attachments not recommended by
the appliance manufacturer may cause fire, electric shock
or injury. Only use the accessories supplied by the
manufacturer.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not let the cord hang over the edge of the worktop, or
touch hot surfaces.
•Do not use this vacuum to pick up water or any other
liquids, combustible substances or hot/burning objects.
•Only use the unit when fully assembled.
•Never place your fingers or other objects into any part of
the cleaner. Be aware that loose clothing or hair may
become trapped in the cleaner if improperly used.
•Before use, ensure that all of the air vents of the cleaner
are clear and there is no restriction of air flow.
•When cleaning stairs, ensure the cleaner is on a step
below you. NEVER place the cleaner above.
•Caution: Exhaust air discharged from the rear of the
cleaner may extinguish a gas fire, pilot light, or disturb
ashes in an open fire. Always avoid directing the cleaner
toward naked flames.

6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
•Important: This cleaner has a thermal safety device which
automatically cuts off the power supply in case of over
heating. If the safety device has switched the cleaner off,
unplug from the mains, allow the cleaner to cool down
and check for any blockages. Once the cleaner has cooled
it can be plugged back in to the mains and used as
normal.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

7
ENERGY PERFORMANCE LABEL
The purpose of the energy label is to help you understand a
vacuum cleaner’s energy efficiency performance.
1. Energy rating –
based primarily on
energy consumption
and pick-up.
2. Annual energy
usage –the amount of
energy used over a
year.
3. Emissions –the
amount of dust in the
air emitted from the
machine’s exhaust.
4. Noise –the noise
level produced by the
machine, measured in
decibels.
5. Pick up (carpets) –
the rating of how much
dust the machine picks
up from carpets.
6. Pick-up (hard
floors/crevices) –the
rating of how much
dust the machine picks
up from hard floors and
crevices.
1
3
2
4
56

8
TECHNICAL DATA(PRODUCT FISCHE)
Trade mark
Russell Hobbs
Model
RHBCV2502
Energy
efficiency class
A
Annual energy consumption
(kWh/year)
27
Carpet cleaning performance class
D
Hard floor cleaning
performance
class
A
Dust re
-emission class
A
Sound power
level
78db
Rated
input power
7
00

9
VACUUM FEATURE DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
1
2
3
4
5
6
7
1Hose suction control 7Floor head 13 Carry handle
2Hose connector 8Hose entry point 14 Top cover release latch
3Extension lock 9Bag full indicator 15 HEPA Filter Cover
4Extension tube 10 Power button 16 2 in 1 Crevice/brush
5Hose 11 Variable power dial
6Floor surface selector 12 Cord rewind button
13
10
11
12
9
15 (Not Shown)
16
8
14

10
VACUUM CLEANER ASSEMBLY
Before using your vacuum cleaner
Remove all packaging and lay out the separate components.
Check the unit after unpacking for any visual damage such as:
•Misaligned or damaged parts
•Damage to the main body and separate components
•Damage to the plug or cable.
If you can see any damage do not use the vacuum cleaner and
contact customer services.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

11
VACUUM CLEANER ASSEMBLY
Ensure the unit is unplugged before assembling.
1. Ensure there is a dust bag correctly inserted in the vacuum
cleaner.
With the vacuum cleaner stood upright, release the top cover by
pulling the latch towards you.
The cardboard collar of the dust bag should slide into the dust bag
holder with the arrow facing upwards.
2. Insert the ribbed end of the hose into the hose inlet, aligning the
shoulders on the end of the hose with the inserts in the hose inlet.
Twist the hose in a clockwise direction to secure.
3. Insert the opposite end of the hose into the extension tube and
push together.
4. Insert the other end of the extension tube into the floor head and
rotate if necessary.
1 2
3
4

12
USING YOUR VACUUM CLEANER
1
Once assembled:
1. The cord is stored inside the unit. Pull the power cord out of the
machine to as long as you require and stop when you see the yellow
tab. Do not over-extend. If the red tab is visible, then wind the cord
back until only the yellow tab is visible.
2. Plug the cable into a wall socket and press the switch on.
3. Press the power button to start vacuuming.
4. Move the vacuum cleaner floor head in a forwards and backwards
motion over the areas you would like to clean.
Note: Large items can get trapped in the brush/floor head which
could cause the unit to overheat. Make sure you pick up larger items
that could get trapped before vacuuming.
3
2

5. You can adjust the extension tube length to a comfortable cleaning
height. To alter the length of the telescopic handle,
a) Push and hold the extension lock in the direction indicated.
b) Slide the tube, up or down, to the correct length.
6. The suction of the vacuum cleaner can be adjusted by rotating the
power dial on the front of the unit. You may want to use reduced power
when cleaning furniture, upholstery or long pile rugs.
13
USING YOUR VACUUM CLEANER
a)
b)
5
6
7
7. You can also adjust the suction using the tab on the hose handle. To
use less suction power, move the suction control tab to the open
position in the direction indicated. For maximum suction power, close
the tab.

14
USING YOUR VACUUM CLEANER
8. When using the floor head you can adapt the brush
depending on floor type. Please refer to the diagram below:
Tool Selection
This vacuum cleaner is supplied with a 2 in 1 crevice and brush tool
designed for different cleaning tasks:
The tool attaches to either the extension tube or the hose in the same
manner as the floor head.
- The crevice tool is designed for narrow gaps and hard to reach places
- The brush tool can be used on delicate surfaces or for dusting.
To adapt the tool for use as a brush on delicate surfaces, rotate the
head of the tool in the direction indicated below:
Hard Floors Carpets

15
USING YOUR VACUUM CLEANER
Changing the dust bag
To maintain peak performance, we recommend replacing the dust
bag when it reaches no more than ¾ full.
There is a “bag full indicator” which will turn red when the dust bag is
full:
1. With the vacuum cleaner stood upright, release the top cover by
pulling the latch towards you.
2. Slide the dust bag collar downward to remove the dust bag.
3. Pull the cardboard tab to seal the dust bag.
Replace with a new dust bag by sliding the cardboard collar into the
dust bag holder with the arrow facing upwards.
3
2

16
CLEANING AND CARE:
CLEANING THE EXHAUST FILTER
Before you clean the appliance, disconnect the mains plug from the
wall socket.
1. Remove the filter cover on the back of the unit.
2. Pull out the HEPA filter and tap over a bin to remove any excess
dust. Wash in warm water and allow to dry for 24 hours.
3. Once dried, put the filter back in place and refit the filter cover
on the back of the unit.

17
CLEANING AND CARE:
CLEANING THE INTERNAL FILTER
Before you clean the appliance, disconnect the mains plug from the
wall socket.
1. With the vacuum cleaner stood upright, release the top cover by
pulling the latch towards you. The
The internal filter will be easier to access if you remove the dust
bag.
2. Slide the dust bag collar downward to remove the dust bag.
3. The internal filter is located below the black filter cover.
Slide the filter cover towards you to remove.
4. Remove the internal filter and tap over a bin to remove any
excess dust. Wash in warm water and allow to dry for 24 hours.
5. Once dried, put the filter back in place and slide the filter cover
back into place.
6. Replace the dust bag.
2

18
CLEANING AND CARE
Disassembly
To clean the exterior of the device, use a damp, soft cloth and mild detergent.
NEVER IMMERSE THE VACUUM IN WATER.
Wash non-electrical removable accessories in warm soapy water and allow to
dry thoroughly before next use.
If the vacuum is damaged, contact the customer service helpline using the
details at the bottom of this page.
Storage
Store in a clean and dry environment.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Before you clean the appliance, disconnect the mains plug
from the wall socket.
1. Press the cord rewind button to automatically bring the cord back inside
the unit for storage.
2. To remove the extension tube, pull it away from the hose.
3. To remove the floor head/accessory, pull the extension tube/hose away
from the head/accessory –you may need to ease it off.
4. To remove the hose from the vacuum cleaner unit, twist in an anti-
clockwise direction and remove.
1

19
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
The vacuum cleaner is
plugged in but does
not work
Power cord/plug damage
Check the
power cord and plug for signs of damage.
Fuse is damaged
Check and replace the fuse in the plug.
The suction
is
decreasing and the
vacuum is not picking
up dirt
Dust bag
Suction may decrease if the dust bag is more than ¾ full. If
so, replace with a new bag
Filters are dirty
Clean the filters.
Hose/head blockages
Check that there are no blockages in the hose or cleaning
head.
Vacuum cleaner is
over heating
Filters are dirty or dust
bag is full
Check that the filters are not blocked and
that the dust
bag is not full.
, if so, clean/replace them following the
instructions in this booklet.
Automatic power cord
rewind does not fully
rewind the power
cord
Pull the power cord fully out and press the rewind button
again.
The air coming out of
the vacuum cleaner
smells
Filter is dirty or dust bag
is full
Clean the filter and check the dust bag is not full. Also
clean the
hose and dust container
Filters are not dry
Ensure the filters have been left to dry for 24 hours before
refitting back into the vacuum cleaner and using.
We’re here should you need us.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

20
GUARANTEE AND CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday –Friday: 8am-8pm & Saturday: 9am –1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original
proof of purchase.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
•It must be used for domestic purposes only and for its intended
use.
•This warranty does not cover wear and tear, damage, misuse
or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
