Russell Hobbs RHHS2202 User manual

Model Number: RHHS2202
22.2V Turbo Lite Ultra
Cordless Handheld Vacuum
For Customer Services & Spare Parts please call0345 2097461
Opening times: Monday -Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE

Page(s)
Safety instructions
3-6
Turbo
Lite Ultra feature diagram 7
Turbo
Lite Ultra assembly 8-10
Charging your Turbo
Lite Ultra 11
Using your
Turbo Lite Ultra 12
Cleaning and care
13-15
Problem solving
16
Guarantee and customer services
17
Spare
parts 18
Notes
19
Disposal information
20
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Thank you for purchasing your 22.2V Turbo Lite Ultra 4 in 1 Cordless Cleaner.
To get the best from your new cleaner, take a few moments to read these
instructions and keep them in a safe place for future reference.
Should you require any further assistance, our friendly Product Care team will
be happy to help.

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•It is hazardous for anyone other than a competent
person to carry out any service or repair operation that
involves the removal of a cover which gives protection
against exposure to electrical parts.
•This product is intended for household use only. Do not
use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children unless they are older than
8 and supervised. Keep the appliance and its cord out of
reach of children less than 8 years.
•Only use the charger provided with the product. Using
another charger may damage the product and battery.
•Do not immerse in water or other liquids for cleaning.
•Do not store or charge the unit outdoors
•Do not use outdoors or on wet surfaces
•Use only as described in this manual

4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not attempt to use the charger with any other
product nor attempt to charge this product with another
charger
•Do not abuse the charger cord; never carry the charger or
base by the cord or pull cord to disconnect from an
outlet; grasp the charger and pull to disconnect from an
outlet.
•Keep hair, clothing, fingers, and all parts of the body
clear of moving parts.
•Do not pick up anything that is flammable, burning or
smoking.
•Use extra care when cleaning on the stairs.
•Never remove parts from the appliance such as the feet,
screws and so on.
•Only use the accessories supplied by the manufacturer.
•Do not operate this appliance for anything other than its
intended use.
•Never put any objects into the openings on the outer
case.
•This appliance is authorized for household/residential
use only
•Do not allow to be used as a toy. Close attention is
necessary when used by or near children.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Use only as described and for the uses described in this
manual
•Do not use the charger if power cord or plug has been
damaged.
•Do not use cordless vacuum cleaner or charger if it has
been dropped, damaged, left outdoors, or dropped in
water. Contact customer services for advice.
•Do not run over charger cord with vacuum cleaner.
Always unplug charger from vacuum cleaner before use.
•Keep charger cord away from heated surfaces(e.g.,
cooking surfaces).
•Do not handle charger cord or vacuum cleaner with wet
hands or while barefoot.
•Do not put any objects into openings. Do not use with
any opening blocked, keep free of dust, lint, hair and
anything that may reduce particle flow into the dust
container.
•Do not use the vacuum cleaner without dust container in
place.

6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
•Do not attempt to empty dust container while unit is
running, always turn off the appliance and unplug
before emptying/replacing the dust container.
•Turn off vacuum cleaner before clearing debris from
tools
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

7
TURBO LITE ULTRA FEATURE DIAGRAM
1Handheld Unit 5Short Extension Tube
2Nozzle 6Large Brush Tool
3Dust Container 7Connecting Joint
42 in 1 Crevice/Brush Tool 8Mattress Tool
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
1.
2.
5.
6.
3.
7.
8.
4.

8
TURBO LITE ULTRA ASSEMBLY
Before using your cleaner
Remove all packaging and lay out the separate components.
Check the unit after unpacking for any visual damage such as:
•Misaligned or damaged parts
•Damage to the main body and separate components
•Damage to the plug or cable.
If you can see any damage do not use the cleaner and contact
customer services.
Charge your Turbo Lite Ultra before first use.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

Attaching the tools
1. The connecting joint must be attached to use all tools. Line up the
connecting joint ensuring that the pins are aligned and push into the
nozzle of the hand held unit until it clicks into place.
2. Then, push the desired tool into the connecting joint.
2 in 1 Crevice/Brush Tool
The crevice tool is for narrow gaps and hard to reach places and the
brush tool can be used for dusting and cleaning delicate surfaces.
To use the 2 in 1 Crevice/Brush tool, first attach the connecting joint
to the handheld unit. Then, push the 2 in 1 attachment into the
connecting joint (as shown below).
To use the brush tool, slide the brush to the end of the tool until it
clicks into place.
To use the crevice tool, push the button on the end of the brush tool
and slide the brush back to expose the crevice tool until the brush
clicks in to place.
9
TURBO LITE ULTRA ASSEMBLY

10
Attaching the tools
Mattress Tool
The mattress tool is to help clean mattresses, bedding and other
upholstery.
To use the mattress tool, attach the connecting joint to the nozzle of
the main unit then push the mattress tool into the connecting joint.
Large Brush Tool
The large brush tool can be used for high reach cleaning such as
shelving and furniture tops.
To use the large brush tool, attach the connecting joint to the nozzle
of the main unit then push the large brush tool into the connecting
joint.
Short Extension Tube
The short extension tube can be used along with any of the cleaning
tools to increase cleaning distance.
To use the short extension tool, attach the connecting joint to the
nozzle of the main unit. Then, add the desired cleaning tool to the
end of the short extension tube and push the other end into the
connecting joint.
To remove the tools, simply pull out of the connecting joint. To
remove the connecting joint from the handheld unit, press the
release button on the top and pull away from the unit.
TURBO LITE ULTRA ASSEMBLY

11
CHARGING YOUR TURBO LITE ULTRA
Before using for the first time you will need to charge the cleaner.
1. Before charging ensure the cleaner is switched off.
2. Plug the charging cable into the adaptor socket on the side of the
handheld unit. Insert the plug into a suitable 13 Amp mains socket,
pressing the switch on.
3. The charging indicator light on the vacuum cleaner will illuminate
red, flashing in 2 second intervals to show that the unit is charging.
A full first time charge should be given 5 hours.
Once charged, the indicator light will illuminate solid red.
Note:
•The body may become warm during charging and this is
completely normal.
•Make sure the battery is charged when the product will not be
used for prolonged periods of time.

12
USING YOUR TURBO LITE ULTRA
Once assembled and charged:
1. Unplug the charger and place the desired cleaning tool on the
area that you would like to clean.
2. Slide the power switch on the top of the unit (circled below) to
start the power.
3. Move the cleaning tool in a forwards and backwards motion over
the areas you would like to clean.
Note: Large items can get trapped in the cleaning tool which could
cause the unit to overheat. Make sure you pick up larger items that
could get trapped before vacuuming.
4. To turn off the power, slide the power switch on the top of the
unit.

13
Whilst holding over a bin or inside a bin bag, press down the
button on the dust container below the nozzle to open the
bottom and release the dust (2).
Important: You may wish to empty the dust container outdoors
as emptying may create a dust cloud.
Make sure to empty the
dust container before
the ‘MAX’ fill line is
reached. Press the
release button on the
top of the vacuum
cleaner (1), and lift the
dust container clear of
the base.
Once empty, close the bottom of the dust container then clip the
dust container back into the vacuum cleaner unit, ensuring the
bottom of the dust container is correctly located before the release
button clicks back into place.
(2)
(1)
CLEANING AND CARE:
EMPTYING THE DUST CONTAINER

14
CLEANING AND CARE:
CLEANING THE FILTER
Turn off and unplug the cleaner. Remove the dust container as per
instructions on page 13.
Remove the filter assembly by
unclipping the filter release
clips on both sides of the dust
container. (1)
(1)
Twist the lid of the dust container
assembly to the UNLOCK position
and remove (2).
Remove the sponge and HEPA
filters (3). To clean, remove excess
dust from the filter using a soft
brush. Wash in warm water and
allow to dry for 24 hours.
Replace the filters, then twist the lid of the dust container to the
LOCK position. Refit the dust container as per the instructions on
page 13.
(2)
(3)

15
CLEANING AND CARE
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Before you clean the appliance, make sure the power is switched off
and that the unit is not on the charging stand.
To clean the exterior of the device, use a damp, soft cloth and mild
detergent.
NEVER IMMERSE THE CLEANER IN WATER.
Wash non-electrical removable accessories in warm soapy water and
allow to dry thoroughly before next use.
If the cleaner is damaged, contact the customer service helpline
using the details at the bottom of this page.
Storage
Store in a clean and dry environment.

16
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
The cleaner won’t
turn
on
The cleaner
hasn’t had
enough charge
Make sure you have plugged in the cleaner to charge for 5
hours. The
light will flash when charging.
Charging cable is
damaged
Make sure there is no signs of damage to the charging
cable
. If there is damage, do not use. Contact Customer
Services.
The power button has
not been pressed
Make sure you have turned
on the power using
the switch
on the main unit.
The suction
is
decreasing and the
cleaner is not picking
up dirt
Dust container
Check if
the dust container is full, if so, empty it.
Filters are dirty
Clean the filters. After around 6 months of regular use the
filters may need replacing. Contact Customer Services
using the details at the bottom of this page.
Handheld/head
blockages
Check that there are no blockages in the handheld suction
inlet
or tubes. If so, clear these blockages.
Cleaner is over
heating
Filters are dirty
Check that the filters are not blocked,
if so, clean them
following the instructions in this booklet.
Dust is coming out of
the vacuum cleaner
Dust container fitting
The dust container has not been fitted correctly. Refit the
container following the instructions in this booklet.
The air coming out of
the vacuum cleaner
smells
Filters are dirty
Clean the filters
and dust container.
Filters are not dry
Ensure the filters have been left to dry for 24 hours before
refitting back into the vacuum cleaner and using.
We’re here should you need us.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

17
GUARANTEE AND CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday –Friday: 8am-8pm & Saturday: 9am –1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original
proof of purchase.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
•It must be used for domestic purposes only and for its intended
use.
•This warranty does not cover wear and tear, damage, misuse
or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

18
SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
HEPA Filter
Charging cable
Short Extension tube
Crevice/Brush tool
Connecting joint
Replacement battery
Large Brush Tool
Mattress tool

NOTES
19

20
Revision 1
Model: RHHS2202
This symbol is known as the 'Crossed-out wheelie bin Symbol'.
When this symbol is marked on a product/batteries, it means that
the product/batteries should not be disposed of with your general
household waste. Only discard electrical/electronic/battery items
in separate collection schemes, which cater for the recovery and
recycling of materials contained within. Your co-operation is vital
to ensure the success of these schemes and for the protection of
the environment. For your nearest disposal facility, visit
www.recycle-more.co.uk or ask in store for details.
We reserve the right, due to possible changes to design, to alter
the instruction manual without prior notice.
For Customer Services & Spare
Parts please call
0345 209 7461
Opening times: Monday - Friday
8am –8pm & Saturday 9am –1pm
Or visit us at
www.productcare.co.uk
Made by G2S Ltd under license
from Spectrum Brands (UK) Limited.
G2S Limited, Wigan, WN2 4AY.
Russell Hobbs is the registered trademark of
Spectrum Brands (UK) Ltd.
