XZone4
Streaming System
4 Stream, 4 Zone Audio System
The Next Generation of Streaming Audio
The XZone4 Four-Stream, Four-Zone Audio system is a complete
streaming media solution that gives Russound installers a single-box
package that is easy to install via a simple browser-based configuration,
using a smartphone, tablet or laptop.
Russound created the XZone4 to become the go-to solution for bringing
streaming media to whole-house audio customers. The XZone4 offers
four independent audio streams that support up to four rooms of audio in
a home or business, and can easily scale up to 16 total streaming audio
zones by linking up one or more of the XStream Series products.
Like all components in the XStream Series, the XZone4 works with the
MyRussound app for iOS/Android phones and tablets and the XTS
Touchscreen for unrivaled control of the listening experience.
The XZone4 can be mounted in 4 ways: 1U Rack Mount, Tabletop,
Under-cabinet, or Flat-mounted to a wall, offering unique flexibility for
any installation.
RUSSOUND
CERTIFIED
INSTALLER
Control with XTS In-Wall
Touchscreen or MyRussound
App for iOS or Android
Features
• Built-in AirPlay streaming with full metadata to iOS/
Android apps or XTS touchscreens
• Hi-Res audio streaming supports up to 24-bit/192 KHz
• Powerful 30 watts per channel to each connected zone
• Integrated fixed/variable stereo line-out connections for
additional amplification options
• Four mounting options available: table top, rack mount,
under cabinet or wall mount
• Easy configuration and set-up via smartphone, tablet or
laptop using Russound Web Config
• 4 independent streaming audio players
• 4 amplified zones, expandable to 16 streaming zones
using any combination of XStream Series products
• Controllable by the XTS in-wall touchscreen or the
MyRussound app
• XStream complement of streaming sources include
Spotify, Pandora, AirPlay and more
• Mix and match with other XStream Series components
for versatile system design

03.01.16 WP
Russound | 1 Forbes Road Newmarket, NH 03857 | 603.659.5170 | www.russound.com
©2016 Russound/FMP, Inc. All rights reserved. Russound and the Russound logo are registered trademarks of Russound/FMP, Inc. Building Sound Solutions is a trademark of Russound/FMP, Inc.
All other trademarks are the property of their respective owners. Russound reserves the right to change specifications without notice.
Specifications
Frequency Response 20Hz to 20KHz
Audio Output Fixed/Variable Stereo RCA, 2Vrms
Max
Digital Amplifier Power Output: 30 Watts per channel at 8 ohms
Communication ports 1 Ethernet RJ45, 10/100 Base T
Music File Formats
MP3 (CBR, VBR), WAV (8, 16-bit),OGG
Vorbis, FLAC (8, 16-bit). AAC, AAC+
(supports up to 24-bit/192 kHz)
Power Requirements Input: 100-240V~50/60Hz, 240W
Dimensions 17” W x 9”D x 1.7”H (43 x 22.8 x 4.3cm)
Weight 7.2 lbs. (3.3 kg)
Part Number 4500-536793 US, 4500-536908 Intl.
Shipping Dimensions 23.25”W x 13.5”D x 5.75”H
(59 x 34.2 x 14.6cm) single unit
Shipping Weight 10.6lbs (4.8kg)
Wall Mount
Attach the included rack mount ears to
both sides of the unit, with mounting holes
facing down as shown.
Installation Options
Rack Mount
Attach the included rack mount ears to
both sides of the unit as shown.
Under Cabinet Mount
Attach the included rack mount ears to
both sides of the unit, with mounting
holes facing up as shown.
Top of the unit
4 Non-marking
adhesive
rubber feet
Table Top Mount
Attach the four adhesive backed
feet to the bottom of the chassis
