Rycom 8890 User manual

8890 & 8891
Passive Marker Locator
User Manual

8890 Controls and Indicators
ON/OFF Button
The unit will load settings from previous usage.
Note: Automatic shut off after 10 minute of no use.
FREQUENCY Button
Toggles through available EMS frequencies.
To change the Depth Measurement from English to Mertic, hold the Depth Key
for ten seconds.
MODE Button
Toggle through available mode (model specific) BROAD PEAK.
DEPTH Button
DEPTH function will first momentarily display the depth estimate.
GAIN Button (Up or Down)
Adjusts the gain up or down.
VOLUME (SHIFT Button + MODE Button)
Toggle volume through High, Medium, Low and Off.
BACKLIGHT (SHIFT Button + FREQUENCY Button)
Hold the SHIFT Key and press the FREQUENCY key to toggle on and off the back
light.
LOW BATTERY
The 8890 Locator will indicate low battery condition by displaying "LO BAT" in the
three digit Signal Strength Display at the top of the LCD screen.
DISPLAYS ABSOLUTE
SIGNAL STRENGTH
OR DEPTH
ADJUSTS GAIN UP OR
DOWN
ON/OFF BUTTON
MEASURES DEPTH RELATIVE SIGNAL
STRENGTH BAR GRAPH
(single bar shows gain
setting)
mA
cm
SON
DFF
ACC
kHz
FREQUENCY SELECTOR
(+ Shift Key
toggles on/off
backlight)
MODE SELECTOR
(+ Shift Key
toggles volume)
SHIFT KEY
Hold while select-
ing secondary key
functions
DISPLAYS SELECTED
FREQUENCY

Introduction Congratulations on the purchase of your new 8890/8891 Locator. The 889X Series
Locator is specially designed to detect passive electronic markers.
The ReceiveR detects the signal. You can locate the relative posi-
tion of the buried marker by locating the point of the highest signal.
Prepare for Use
Unpack your new 8890/8891 Locator . Make sure there is no shipping damage
and all the parts are included.
Locate the battery compartment on the back of the “head” of the ReceiveR.
Open the compartment using a phillips screwdriver. Install the six Duracell® “C”
batteries as marked.
Note: For longer battery life and reliable operation under adverse conditions,
use only Duracell® alkaline batteries.
Electric shock hazard:
• Tool is designed to detect electromagnetic eld emitted from buried metallic
utilities. There are buried cables, pipes, and utilities this instrument CANNOT
detect.
• LOCATING is not an exact science. The only certain way to be sure of the ex-
istence, location, or depth of buried utilities is to carefully expose (dig up) the
utility.
• De-energize any circuits in or around the work area.
• Do not expose tool to rain or moisture.
• Use tool only for intended purpose as described in this manual
Failure to observe these warnings could result in severe injury or death.
DISCLAIMER OF LIABILITY
RYCOM INSTRUMENTS, INC.® SHALL NOT BE LIABLE TO DISTRIBUTOR, RESELLER, OR
ANY OTHER PERSON FOR ANY INCIDENTAL, INDIRECT, SPECIAL, EXEMPLARY OR
CONSEQUENTIAL DAMAGES, OR INJURY OF ANY TYPE WHATSOEVER, AND CAUSED
DIRECTLY OR INDIRECTLY BY PRODUCTS SOLD OR SUPPLIED BY RYCOM INSTRUMENTS,
INC.®.
!WARNING
800.851.7347 www.rycominstruments.com
2

800.851.7347 www.rycominstruments.com
3
Locating
Locating A Passive Electronic Marker
It i s ideal t o have a general i dea o f where a marker may be buried. By first
locating the utility, the user has a path in witch the marker is buried.
Select desired gain setting. M ost markers may be located on lowest gain set-
ting. Use high gain if marker is known to be deep.
Move the RECEIVER at a medium speed side to side while walking a straight line.
Move slowly so a marker may not be missed. The RECEIVER will detect a marker
just a few feet away so a grid search may be needed to find a marker.
The RECEIVER will g ive a maximum signal when d irectly over t he m arker. GAIN
adjustment may be needed for optimum sensitivity.
NOTE: IT IS POSSIBLE TO DETECT AN ON-TARGET MARKER.

8890/8891 Locator Specifications
Transmitter
800.851.7347 www.rycominstruments.com
13

Factory Service
If your 8890 Locator is not working properly, first call RYCOM Instruments, Inc. Tech
Support at 800-851-7347 for assistance. If the locator is in need of repair, Tech
Support will provide instructions for sending your locator to the closest factory
approved service center. The instrument will be repaired and shipped back or
you will be advise if the instrument is unrepairable.
Note: There is a minimum charge for repair and handling.
Warranty
This insTRumenT is undeR waRRanTy foR one yeaR fRom The daTe of deliveRy
againsT defecTs in maTeRial and woRkmanship (EXCEPT BATTERIES). we
will RepaiR oR Replace pRoducTs ThaT pRove To be defecTive duRing waR-
RanTy peRiod.
This waRRanTy is void if, afTeR having Received The insTRumenT in good con-
diTion, iT is subjecTed To abuse, unauThoRized alTeRaTions oR casual RepaiR.
no oTheR waRRanTy is expRessed oR implied. The waRRanTy descRibed in This
paRagRaph shall be in lieu of any oTheR waRRanTy, including buT noT limiTed
To, any implied waRRanTy of meRchanTabiliTy oR fiTness foR a paRTiculaR
puRpose. we aRe noT liable foR consequenTial damages.
800.851.7347 www.rycominstruments.com
14
©2008 RYCOM Instruments, Inc. 1/08
