Ryobi RED1850Li40 User manual

ORIGINAL INSTRUCTIONS
Cordless Edger
RED1850Li40
RED1850Li20
RED1850Li15
OED1850

Important!
It is essential that you read the instructions in this manual before assembling,
operating and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your cordless edger.
INTENDED USE
The cordless edger is intended for edging along sidewalks,
driveway, ower beds, and similar areas.
The product should not be used for cutting or chopping
hedges, shrubs, bushes, owers and compost.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
■Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/or
the battery pack from the power tool before making
any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce
the risk of starting the power tool accidentally.
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.

2
■Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
■Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
EDGER SAFETY WARNINGS
WARNING
When using the product, the safety rules must be
followed. For your own safety and that of bystanders,
please read these instructions before operating the
product. Please keep the instruction safe for later use.
WARNING
The product is not intended to be used by children or
persons with reduced physical, mental, or sensory
capabilities. Children should be adequately supervised
to ensure they do not play with the product.
■Never use the edger while people, especially children,
or pets are nearby.
■While edging, always wear eye and ear protection,
substantial footwear, and long trousers.
■Always be sure of your footing on slopes.
■Use extreme caution when reversing or pulling the
edger toward you.
■Some regions have regulations that restrict the use of
the product to some operations. Check with your local
authority for advice.
■Avoid using the product in bad weather especially if
there is a risk of lightning.
■Use the product in daylight or with good artificial light.
■Avoid using the product on wet grass.
■Keep proper footing and balance at all times.
■Do not walk backwards when using the product.
■Walk, never run.
■Keep the head attachment below waist level.
■Do not cut on surfaces other than grass on ground.
■Never use the product with damaged guards or without
guards in place.
■Keep hands and feet away from the cutting means at
all times and especially when switching on the motor.
■Beware of objects thrown by the cutting blade.
■Turn off the product and remove the battery pack. Make
sure that all moving parts have come to a complete
stop:
●before servicing
●before leaving the product unattended
●before clearing a blockage
●before checking, cleaning, and working on the
product
●before changing accessories
●after striking a foreign object
●whenever performing maintenance
●whenever the product starts to vibrate abnormally
■Wear protective glasses or goggles.
■Always ensure that ventilation openings are kept clear
of debris.
■Do not operate the product while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and
improve your footing on slippery surfaces.
■Do not use the product if the lock-out trigger does not
turn it on or off. Any product that cannot be controlled
with the lock-out trigger is dangerous and must be
repaired.
■Do not grasp the exposed cutting edges when picking
up or holding the product.
■Replace a dull or worn blade. Do not attempt to sharpen
the blade.
■Do not use the edger on or near gravel surfaces.
■Make yourself familiar with the area you are edging. Be
aware of uneven sidewalks and holes in the terrain as
well as other similar hazardous conditions.
■Do not attempt to remove cut material or hold material
to be cut when the motor is running or when the cutting
blade is moving.
■A coasting blade can cause injury while it continues to
spin after the motor is stopped or the throttle trigger is
released. Maintain proper control until the blade has
completely stopped rotating.

3
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
OVERLOAD PROTECTION
RYOBI 18 V lithium-ion batteries are designed with features
that protect the lithium-ion cells and maximise battery life.
If the product stops during use, the following may be the
causes:
■The maximum current draw of the battery pack has
been exceeded, causing it to automatically stop
powering the product. Release the trigger to reset the
product and pull the trigger to resume operation.
■Excessive temperatures will cause the battery pack to
stop powering the product. Feel the battery pack; if it is
too warm, allow it to cool down.
TRANSPORTATION AND STORAGE
■Stop the product, remove the battery pack, and allow
the product to cool down before storing or transporting.
■Clean all foreign material from the product.
■Do not store or transport the product with the battery
packs fitted. Remove and secure the battery packs
separately. Store the product in a cool, dry, and well-
ventilated place that is inaccessible to children. Keep
the product away from corrosive agents, such as
garden chemicals and de-icing salts. Do not store the
product outdoors.
■For transportation in vehicles, secure the product
against movement or falling to prevent injury to persons
or damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery pack in accordance with local and
national provisions and regulations. Follow all special
requirements on packaging and labelling when transporting
batteries by a third party.
Ensure that no batteries can come in contact with other
batteries or conductive materials while in transport by
protecting exposed connectors with insulating, non-
conductive caps or tape. Do not transport batteries that are
cracked or leaking. Check with the forwarding company for
further advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can cause
possible injury, can contribute to poor performance, and
may void your warranty.
WARNING
Servicing requires extreme care and knowledge
and should be performed only by a qualied service
technician. Have the product serviced by an authorised
service centre only. When servicing, use only original
replacement parts.
WARNING
To avoid serious personal injury, always remove
the battery pack from the product when cleaning or
performing any maintenance.
■Turn off and remove the battery pack before conducting
any maintenance or cleaning work.
■You may make adjustments and repairs described in
this manual. For other repairs, contact an authorised
service agent.
■After each use, clean the product with a soft, dry brush.
Any part that is damaged should be properly repaired or
replaced by an authorised service centre.
■Check all nuts, bolts, and screws at frequent intervals
for proper tightness to ensure that the product is in safe
working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service
centre.
■Bring the product to an authorised service centre to
replace damaged or unreadable labels.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use a clean cloth to remove dirt, dust, oil, grease, etc.
WARNING
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic, which may result in serious personal
injury.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All the other parts
should be replaced at an authorised service centre.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise during use, and
the operator should pay special attention to avoid the
following:
■injury caused by vibration
–Hold the product by designated handles and restrict
working time and exposure.
■injury caused by exposure to noise
–Wear hearing protection and limit exposure.
■injury caused by flying debris.
–Wear eye protection at all times.

4
RISK REDUCTION
It has been reported that vibrations from handheld tools
may contribute to a condition called Raynaud’s Syndrome.
Symptoms may include tingling, numbness, and blanching
of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet,
smoking, and work practices are all thought to contribute to
the development of these symptoms. There are measures
that can be taken by the operator to possibly reduce the
e󰀨ects of vibration:
■Keep your body warm in cold weather. When operating
the product, wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your physician.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
WHAT’S IN THE BOX
See pages 5–6.
■Power head x 1
■Edger attachment x1
■Combination wrench x 1
■Front handle x 1
■Operator’s manual
■Harness x 1
■Clamp x 1
■Locking pin x 1
SYMBOLS ON THE PRODUCT
Safety alert
Read and understand all instructions
before operating the product. Follow all
warnings and safety instructions.
Wear ear protection.
Wear eye protection.
Beware of thrown or ying objects. Keep
all bystanders at least 15 m away.
Keep feet away from the rotating blade.
Avoid using in wet or damp conditions.
Beware of thrown objects.
Direction of blade rotation
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
Regulatory Compliance Mark (RCM).
This product meets applicable regulatory
requirements.
95
Guaranteed sound power level
Remove the battery pack before starting
any work on the product.
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.
SYMBOLS IN THIS MANUAL
Parts or accessories sold separately
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Note
Warning

5
WHAT’S IN THE BOX
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
RED1850Li40
RED1850Li20
RED1850Li15

6
WHAT’S IN THE BOX
x 1
x 1
x 1 x 1
x 1 x 1
OED1850

7
Know your product
KNOW YOUR PRODUCT
1 2 3
4
5
6
7
10
11
8
9
12
13
1. Variable speed trigger
2. Lock-out trigger
3. Rear handle
4. Battery pack
5. Coupler
6. Battery charger
7. Depth adjustment lever
8. Guide wheel
9. Blade
10. Motor
11. Blade guard
12. Lower shaft
13. Front handle

8
GETTING STARTED
1
5
1
2
6
Always wear safety goggles or safety glasses with side shields
when operating the product. Wear non-slip, heavy-duty protective
gloves. Wear non-skid, protective footwear that will protect your
feet and improve your footing on slippery surfaces.
Push the lock-out trigger and squeeze the variable speed trigger
to operate the product.
Insert the battery pack until the latches click into place.
1
2
2
Install the lower shaft to the upper shaft. Tighten the coupler to
secure.

9
GETTING STARTED
1
2
3
4
Install the front handle. Re-insert and tighten the upper-shaft knob
to secure.
NOTE: The angle of the front handle can be adjusted 180°.
1
2
3
Loosen and remove the upper-shaft knob.

10
OVERVIEW
Operating the edger Adjusting the depth of cut
Replacing the blade Cleaning the edger Storing the edger
p.11
p.14 p.16 p.17
p.13

11
OPERATION
1
2
1
2
OPERATING THE EDGER
WARNING:Always use two hands to operate
the product. Hold the rear handle with the right
hand and the front handle with the left hand.
WARNING: Best appearance is obtained when
the grass is dry. Avoid using the edger in wet soil
or wet grass areas. The blade guard might clog
and result in an uneven edge. If the blade guard
becomes clogged, stop the edger, remove the
battery pack, and remove debris from the blade
guard.
1. Insert the battery pack until the latches click
into place.
2. Push the lock-out trigger, and squeeze
the variable speed trigger to operate the
product.

12
OPERATION
3
WARNING:Keep hands and feet away from the
blade at all times and especially when switching
on the motor.
3. Use the edger along sidewalks, driveways,
flower beds, curbs, and similar areas.
NOTE: Cut at a steady pace. If the blade
begins to bog down, you are edging too fast;
slow your pace. Do not force the blade into
the ground.

13
OPERATION
1
2
1
2
ADJUSTING THE DEPTH OF CUT
1. Remove the battery pack.
2. Move the depth adjustment lever up to
increase the depth of cut, or down to
decrease the depth of cut.
NOTE: The depth adjustment lever locks into
one of four positions.
NOTE: Adjust the blade depth from 15 mm (0.59
in.) to 45 mm (1.77 in.) deep initially. Make a
shallow cut to test the cutting depth. If the cutting
depth needs adjusting, do this progressively
until the preferred depth is reached.
NOTE: The angle in which the product is
positioned affects the exact depth of cut.

14
MAINTENANCE
1
2
1
2
1
2
3
1
3
2
4
REPLACING THE BLADE
1. Remove the battery pack.
2. Place the product on a level surface on the
ground. Position the product with the motor
side down and the blade guard side up.
3. Align the slot in the inner flange with the
slot in the motor ring. Insert the locking pin
through both slots to secure. Loosen and
remove the flange nut using the combination
wrench.
4. Remove the blade from the motor shaft.

15
MAINTENANCE
3
2
1
5
1
2
6
7
5. Center the new blade on the inner flange,
making sure that the blade sits flat.
NOTE: Install the outer ange properly. Only the
outer ring of the outer ange, not the inner ring
with the hole, must touch the blade.
6. Align the slot in the inner flange with the
slot in the motor ring. Insert the locking pin
through both slots to secure. Tighten the
flange nut into place using the combination
wrench.
7. Remove the locking pin from the inner
flange.

16
MAINTENANCE
1
2
1
2
CLEANING THE EDGER
1. Remove the battery pack.
2. Clean all foreign material from the product
with a soft, dry brush.
WARNING: Avoid using solvents when cleaning
plastic parts. Most plastics are susceptible
to damage from various types of commercial
solvents and may be damaged by their use.

17
STORAGE
1
2
20190619v1d2
2
1
1
2
STORING THE EDGER
NOTE: Clean the product before storing.
1. Remove the battery pack.
2. Loosen the coupler. Remove the lower shaft
from the upper shaft.
3. Store the product in a cool, dry, and well-
ventilated place that is inaccessible to
children and away from sources of ignition.
3

PRODUCT SPECIFICATIONS
Cordless Edger
Model RED1850Li40 /
RED1850Li20 /
RED1850Li15 /
OED1850
Voltage DC 18 Volts
Blade length 220 mm
No load speed 4,000 min-1
Cutting depth 15 mm up to 45 mm
Weight (without battery) 3.3 kg
A-weighted sound pressure level at the
operator position
LpA = 76.3 dB(A)
Uncertainty K = 2.5 dB
A-weighted sound power level LWA = 92.0 dB(A)
Uncertainty K = 2.5 dB
Vibration level
Front handle ah = 1.9 m/s²
Rear handle ah = 1.2 m/s²
Uncertainty K = 1.5 m/s²
BATTERY AND CHARGER
Model RED1850Li40 RED1850Li20 RED1850Li15 OED1850
Battery pack RB18L40A RB18L20 RB18L20 Not included
Charger RC18115 RC18115 RC18115 Not included
Compatible battery
packs
RB18L13, RB18L15, RB18L20, RB18L20A, RB18L25, RB18L26,
RB18L40, RB18L40A, RB18L50, RB18L60, RB18L90
Compatible
charger
RC18120, RC18150U, RC18627U, BCL1418IV, RC18115,
RC18150, BCL14181H, BCL14183H
REPLACEMENT PART
Blade RAC1104
VIBRATION LEVEL
The declared vibration value has been measured with a
standard test method and may be used to compare one
tool with another.
The declared vibration value may be used in a preliminary
assessment of exposure.
The vibration emission during actual use of power tool can
di󰀨er from the declared total value depending on the ways
in which the tool is used.
Identify safety measures to protect yourself based on an
estimation of exposure in the actual conditions of use,
taking account of all parts of the operating cycle such as the
times when the tool is switched o󰀨 and when it is running
idle in addition to the trigger time.
