Ryobi RY40030 User manual

OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
RY40030
EDGER ATTACHMENT
FOR USE WITH RY24001 24 V
OR RY40001B 40 V POWER HEAD
COUPE-BORDURES RY40030 À UTILISER AVEC
LE BLOC-MOTEUR DE 24 V RY24001 OU DE 40 V RY40001B
ADITAMENTO PARA BORDEADORA RY40030
PARA USAR CON CABEZAL MOTOR DE 24 V RY24001
O DE 40 V RY40001B
ALL VERSIONS
TOUTES LES VERSIONS/TODAS LAS VERSIONES
Le coupe-bordures a été conçue et fabriquée conformément à
nos strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation.Correctemententretenue,ellevousdonnerades années
de fonctionnement robuste et sans problème.
AVERTISSEMENT : Pour réduire les risques de
blessures, l’utilisateur doit lire et veiller à bien comprendre le
manuel d’utilisation avant d’employer ce produit.
Merci de votre achat.
Your edger has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using
this product.
Thank you for your purchase.
Su recortar de bordes ha sido diseñada y fabricada de conformidad
con las estrictas normas para brindar fiabilidad, facilidad de
uso y seguridad para el operador. Con el debido cuidado, le
brindará muchos años de sólido y eficiente funcionamiento.
ADVERTENCIA: Para reducir el riesgo de lesiones,
el usuario debe leer y comprender el manual del operador antes
de usar este producto.
Le agradecemos su compra.
BATTERIES AND CHARGERS SOLD SEPARATELY
PILES ET CHARGEUR VENDUS SÉPARÉMENT
LAS BATERÍAS Y EL CARGADOR SE VENDEN POR SEPARADO
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
SAVE THIS MANUAL FOR FUTURE REFERENCE

ii
See this fold-out section for all the figures
referenced in the operator’s manual.
Voir que cette section d’encart pour toutes les figures a
adressé dans le manuel d’utilisation.
Vea esta sección de la página desplegable para todas las
figuras mencionó en el manual del operador.

iii
Fig. 1
A - Edger attachment shaft (arbre de l’accessoire
coupe-bordures, eje del accesorio para cortar
bordes)
B - Blade guard (garde de lame, protección de la
cuchilla)
C - Gear head (carter d’engrenages, cabezal de
engranajes)
A
D
B
C
D- Blade (lame, cuchilla)
E - Guide wheel (roulette de guidage, rueda
guía)
F - Depth adjusting lever (levier de réglage
de la profondeur, palanca de ajuste de
profundidad)
G - Coupler (coupleur, acoplador)
H - Front handle (poignée avant, mango
delantero)
I - Lock-out (verrouillage, seguro)
J - Switch trigger (gâchette., gatillo del
interruptor)
K - 24 V battery (24 v bloc-pile, batería 24 v)
L - 40 V battery (40 v bloc-pile, batería 40 v)
G
F
H
JK
I
E
A
D
B
C
G
F
H
J
L
I
E
EDGER ATTACHMENT WITH 24 V POWER HEAD
COUPE-BORDURES AVEC LE BLOC-MOTEUR DE 24 V
ADITAMENTO PARA BORDEADORA CON CABEZAL
MOTOR DE 24 V
EDGER ATTACHMENT WITH 40 V POWER HEAD
COUPE-BORDURES AVEC LE BLOC-MOTEUR DE 40 V
ADITAMENTO PARA BORDEADORA CON CABEZAL
MOTOR DE 40 V

iv
A - 24 V power head (24 V bloc moteur, 24 V
cabezal motor)
B - 40 V power head (40 V bloc moteur, 40 V
cabezal motor)
C - Lock-out (verrouillage, seguro)
D - Switch trigger (gâchette, gatillo del
interruptor)
A - Knob (bouton, perilla)
A
Fig. 4
Fig. 5
C
D
Fig. 6
Fig. 2
Fig. 3
C
A
A - Coupler (coupleur, acoplador)
B - Base (base, base)
C - Arrow (flèche, flecha)
B
A - 24 V battery (24 V battery, 24 V battery)
B - 40 V battery (40 V battery, 40 V battery)
C - Latch(es) (loquet[s], pestillo[s])
C
D
PROPER EDGING OPERATING POSITION
POSITION D’UTILISATION CORRECTE
POUR COUPE-BORDURES
POSICIÓN CORRECTA PARA EL MANEJO
DE LA CORTAR BORDES
A
B
C
C
B
A

v
E
A
Fig. 9
A - Indicator hole (trou de l’indicateur, orificio
indicador)
B - Slots (fentes, ranuras)
C - Flange washer (rondelle bombée, arandela
cóncava)
D - Gear case (carter d’engrenages, caja de
engranajes)
E - Holding pin inserted into aligned slots
(broche de retenue insérée dans les fentes
alignées, sujetando el pasador introducido
en las ranuras alineadas)
F - Wrench (clé, llave)
G - Blade nut (écrou de lame, tuerca de la
cuchilla)
B
A
B
A
C
D
Fig. 7
A - To increase depth (pour augmenter la
profondeur, para aumentar la profundidad)
B - Depth adjusting lever (levier de réglage de la
profondeur, palanca de ajuste de profundidad)
C - Wheel arm (bras de roulette, brazo de la
rueda)
D - To decrease depth (pour réduirela profondeur,
para disminuir la profundidad)
Fig. 8
A - To blade depth (profondeur de coupe,
profundidad de la cuchilla)
B - Blade (lame, cuchilla)
C
D
E
G
C
D
BF
Fig. 10
A - Flange washer (rondelle à épaulement,
arandela de brida)
B - Gear case ring (anneau de carter
d’engrenages, anillo de caja de engranajes)
C - Blade (lame, hoja)
D - Cupped washer (rondelle bombée, arandela
cóncava)
E - Blade nut (écrou de lame, tuerca de la
cuchilla)
F - Motor shaft (écrou de lame, tuerca de la
cuchilla)
A
B
F

2 — English
Introduction ...................................................................................................................................................................... 2
Introduction / Introducción
Important Safety Instructions ........................................................................................................................................3-4
Instructions importantes concernant la sécurité / Instrucciones de seguidad importantes
Specific Safety Instructions.............................................................................................................................................. 5
Règles de sécurité particulières/ Reglas de seguridad espicifícas
Symbols.........................................................................................................................................................................6-7
Symboles / Símbolos
Features............................................................................................................................................................................ 8
Caractéristiques / Características
Assembly.....................................................................................................................................................................9-10
Assemblage / Armado
Operation...................................................................................................................................................................10-11
Utilisation / Funcionamiento
Maintenance................................................................................................................................................................... 11
Entretien / Mantenimiento
Troubleshooting.............................................................................................................................................................. 12
Dépannage / Corrección de problemas
Warranty ......................................................................................................................................................................... 13
Garantie / Garantía
Parts Ordering and Service ...............................................................................................................................Back Page
Commande de pièces et réparation / Pedidos de piezas y servicio ......................................................... Page arrière / Pág. posterior
TABLE OF CONTENTS
TABLE DES MATIÈRES / ÍNDICE DE CONTENIDO
INTRODUCTION
INTRODUCTION / INTRODUCCIÓN
This product has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability
have been given top priority in the design of this product making it easy to maintain and operate.
* * *
Ce produit offre de nombreuses fonctions destinées à rendre son utilisation plus plaisante et satisfaisante. Lors de la
conception de ce produit, l’accent a été mis sur la sécurité, les performances et la fiabilité, afin d’en faire un outil facile à
utiliser et à entretenir.
* * *
Este producto ofrece numerosas características para hacer más agradable y placentero su uso. En el diseño de este producto
se ha conferido prioridad a la seguridad, el desempeño y la fiabilidad, por lo cual se facilita su manejo y mantenimiento.

3 — English
WARNING :
When using electric gardening appliances, basic safety
precautions should always be followed to reduce the risk
of fire, electric shock and personal injury.
READ ALL INSTRUCTIONS
For safe operation, read and understand all instructions
before using this product. Follow all safety instructions.
Failure to follow all safety instructions listed below, can
result in serious personal injury.
Do not allow children or untrained individuals to use this
unit.
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the machine.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Following this rule will reduce
the risk of serious personal injury.
Use Safety Glasses – Always use face or dust mask if
operation is dusty.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Following this rule will reduce the risk
of serious personal injury.
Dress Properly – Use rubber gloves and substantial
footwear is recommended when working outdoors. Wear
heavy, long pants, long sleeves, boots, and gloves. Do
not wear loose fitting clothing or jewelry or anything that
can be caught in moving parts. Secure long hair above
shoulder level to prevent entanglement in moving parts.
Do not wear loose fitting clothing, short pants, sandals,
or go barefoot.
Do not wear loose fitting clothing, short pants, sandals,
or go barefoot.
Keep children away – Keep all bystanders, children, and
pets at least 50 ft. away.
Stay alert –Watch what you are doing. Use commonsense.
Do not operate this unit when you are tired, ill, upset, or
under the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Keep all parts of your body away from any moving part.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases, or
dust. Power tools create sparks which may ignite the
dust or fumes.
Avoid body contact with grounded surfaces such as
pipes, radiators, ranges, and refrigerators. There is an
increased risk of electric shock if your body is grounded.
Do not, under any circumstance, use any attachment or
accessory on this product, which was not provided with
the product, or identified as appropriate for use with this
product in the operator’s manual.
IMPORTANT SAFETY INSTRUCTIONS
Avoid Dangerous Environments – Don’t expose appliance
to rain or wet conditions. Water entering an appliance will
increase the risk of electric shock.
Use Right Appliance – Do not use appliance for any job
except that for which it is intended. Do not force tool.
Use the correct tool for your application. The correct tool
will do the job better and safer at the rate for which it is
designed.
Don’t Force Appliance – It will do the job better and with
less likelihood of a risk of injury at the rate for which it
was designed.
Do not operate the equipment while barefoot or when
wearing sandals or similar lightweight footwear. Wear
protective footwear that will protect your feet and improve
your footing on slippery surfaces.
Do not overreach – Keep firm footing and balance.
Overreaching can result in loss of balance.
Avoid accidental starting – Be sure switch trigger is in
the locked or off position before inserting battery pack.
Carrying tools with your finger on the switch trigger or
inserting the battery pack into a tool with the switch on
invites accidents.
Do not use tool if switch trigger does not turn it on or off.
Any tool that cannot be controlled with the switch trigger
is dangerous and must be repaired.
Disconnect edger – Disconnect battery pack from the
appliance before storing, servicing, or changing blade or
when not in use. Such preventive safety measures reduce
the risk of starting the tool accidentally.
Use only identical manufacturer’s replacement parts and
accessories. Use of any other parts may create a hazard
or cause product damage.
Check Damaged Parts – Before further use of the appli-
ance, a guard or other part that is damaged should be
carefullychecked to determinethatit will operate properly
and perform its function. Check for alignment of moving
parts, binding of moving parts, breakage of parts, mount-
ing and any other condition that may effect its operation.
A guard or other part that is damaged should be properly
repaired or replaced by an authorized service center un-
less indicated elsewhere in this manual.
Keep hands and feet away from cutting area.
Make sure all guards, straps, deflectors and handles are
properly and securely attached.
Store idle appliances indoors - When not in use, edger
should be stored indoors in a dry, locked place out of the
reach of children.
Inspect area to be cut. Remove objects (rocks, broken
glass, nails, wire, string, etc.) which can be thrown or
become entangled in cutting head.
Keep the air vents clean and free of debris to avoid
overheating the motor. Clean after each use.

4 — English
Do not open or mutilate the batteries. Released electrolyte
is corrosive and may cause damage to the eyes or skin.
It may be toxic if swallowed.
Do not place battery tools or their batteries near fire or
heat. This will reduce the risk of explosion and possibly
injury.
Batteries can explode in the presence of a source
of ignition, such as a pilot light. To reduce the risk of
serious personal injury, never use any cordless product
in the presence of open flame. An exploded battery can
propel debris and chemicals. If exposed, flush with water
immediately.
Do not crush, drop or damage battery pack. Do not
use a battery pack or charger that has been dropped or
received a sharp blow. A damaged battery is subject to
explosion. Properly dispose of a dropped or damaged
battery immediately.
Exercise care in handling batteries in order not to short the
battery with conducting materials such as rings, bracelets,
and keys. The battery or conductor may overheat and
cause burns.
For best results, your battery tool should be charged in
a location where the temperature is more than 50°F but
less than 100°F. To reduce the risk of serious personal
injury, do not store outside or in vehicles.
Under extreme usage or temperature conditions,
battery leakage may occur. If liquid comes in contact
with your skin, wash immediately with soap and water,
then neutralize with lemon juice or vinegar. If liquid gets
into your eyes, flush them with clean water for at least
10 minutes, then seek immediate medical attention.
Following this rule will reduce the risk of serious personal
injury.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this power tool.
If you loan someone this power tool, loan them these
instructions also.
Stop the unit and disconnect the power source when not
in use. Carry the unit with the motor stopped.
Don’t grasp the exposed cutting edges when picking up
or holding the appliance.”
Maintain Appliance With Care - Keep cutting edge sharp
and clean for best performance and to reduce the risk
of injury. Follow instructions for lubricating and changing
accessories. Inspect appliance cord periodically, and
if damaged, have it repaired by an authorized service
facility. Inspect extension cords periodically and replace
if damaged. Keep handles dry, clean, and free from oil
and grease.
Store out of the reach of children.
Do not hang unit so that the switch trigger is depressed.
Battery tools do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition.
Be aware of possible hazards when not using your battery
tool or when changing accessories. Following this rule will
reduce the risk of electric shock, fire, or serious personal
injury.
Do not charge battery tool in rain, or damp or wet location.
Following this rule will reduce the risk of electric shock.
Do not use battery-operated appliance in rain.
Remove or disconnect battery before servicing, cleaning
or removing material from the gardening appliance.
Use only with battery and charger listed.
• When using with 24 V power head, use 24 V lithium-
ion battery packs. See Tool/Appliance/Battery Pack/
Charger Correlation Supplement 988000-446.
• When using with 40 V power head, use 40 V lithium-
ion battery packs. See Tool/Appliance/Battery Pack/
Charger Correlation Supplement 988000-842.
Store idle appliances - When not in use, edger should be
stored indoors in a dry, locked place out of the reach of
children.
Do not dispose of the batteries in a fire. The cell may
explode. Check with local codes for possible special
disposal instructions.
IMPORTANT SAFETY INSTRUCTIONS

5 — English
SPECIFIC SAFETY RULES
Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string which
can be thrown or become entangled in the edger blade.
Be sure all guards are properly and securely attached.
Replace dull or worn blade; do not attempt to sharpen.
Use this edger for edging along sidewalks, driveways,
flower beds, and similar areas. Do not use for any other
purpose.
Be thoroughly familiar with the controls. Know how to
stop the unit and disengage the controls quickly.
Do not use the edger on or near graveled surfaces.
Make yourself familiar with the area you are edging. Be
aware of uneven sidewalks and holes in the terrain as well
as other similar hazardous conditions (example: wire or
wire rope which can break off and become a dangerous
projectile). Always push the edger attachment slowly over
rough ground.
Do not attempt to remove cut material nor hold material
to be cut when the motor is running or when the cutting
blade is moving.
Keep hands and feet away from the cutting area.
Always keep your right hand on the rear handle and your
left hand on the front handle when the blade is rotating.
A coasting blade can cause injury while it continues to
spin after the motor is stopped or throttle trigger released.
Maintain proper control until the blade has completely
stopped rotating.
Check blade nut for tightness before operating the
attachment.
Improper assembly can create a dangerous situation.
Never stand or have any part of your body in line with the
path of the edger blade.
If the edger strikes any type of foreign object:
a) Stop the edger and remove the spark plug wire or
disconnect from the power supply.
b) Inspect for damage to the edger attachment.
c) Correct damage before using the edger attachment.
Failure to do so can cause serious injury.
Always stop motor and remove the battery before attempt-
ing to remove any obstruction caught or jammed in the
blade, installing attachment, or making any adjustments.
Store Idle Appliance Indoors — When not in use, product
should be stored indoors in a dry and high or locked up
place—out of the reach of children.
Save these instructions. Refer to them frequently and use
them to instruct others who may use this product. If you
loan someone this product, loan them these instructions
also to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS

6 — English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s
Manual
To reduce the risk of injury, user must read and understand operator’s
manual before using this product.
Eye Protection Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
Wet Conditions Alert Do not expose to rain or use in damp locations.
Cutting Hazard Keep feet and hands away from rotating blade.
Keep Bystanders
Away Keep all bystanders at least 50 ft. away.
Ricochet Thrown objects can ricochet and result in personal injury or property
damage.
Thrown Objects Thrown objects hazard; keep all bystanders at least 50 ft. or 15
meters away.
Blade Rotation Direction of Blade Rotation
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result
in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
NOTICE: (Without Safety Alert Symbol) Indicates important information not related to an
injury hazard, such as a situation that may result in property damage.

7 — English
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Recycle Symbol
This product uses lithium-ion (Li-ion) batteries. Local, state, or federal
laws may prohibit disposal of batteries in ordinary trash. Consult your
local waste authority for information regarding available recycling and/
or disposal options.
Direct Current Type or a characteristic of current
n
o
No Load Speed Rotational speed, at no load
.../min Per Minute Revolutions, strokes, surface speed, orbits etc., per minute
V Volts Voltage
Hz Hertz Frequency (cycles per second)
min Minutes Time
SYMBOLS

8 — English
PACKING LIST
Edger Attachment
Holding Pin
Wrench
Operator’s Manual
Some models may also include Ryobi 24 V or 40 V Power Head
WARNING:
If any parts are damaged or missing do not operate this
product until the parts are replaced. Use of this product
with damaged or missing parts could result in serious
personal injury.
WARNING:
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible serious
personal injury.
FEATURES
KNOW YOUR PRODUCT
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
EDGER WHEEL
The edger wheel allows for more stable cutting performance
while edging.
DEPTH ADJUSTMENT LEVER
The depth adjustment lever allows user to control
depth of cut.
IF PURCHASED WITH A RYOBI 24 V OR 40 V POWER
HEAD, YOUR UNIT ALSO FEATURES:
ADJUSTABLE FRONT HANDLE
The front handle assembly can be adjusted for ease of
operation and to help prevent loss of control, and can be
positioned above or below the coupler.
HANDLE OVERMOLD
Handle overmold provides added user comfort.
LOCK-OUT
The lock-out prevents accidental starting.
VARIABLE SPEED SWITCH TRIGGER
This tool has a variable speed switch that delivers higher
speed with increased trigger pressure. Speed is controlled
by the amount of switch trigger depression.
ASSEMBLY
UNPACKING
This product requires assembly.
Carefully remove the product and any accessories from
the box. Make sure that all items listed in the packing list
are included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have carefully
inspected and satisfactorily operated the product.
If any parts are damaged or missing, please call
1-800-860-4050 for assistance.
PRODUCT SPECIFICATIONS
Blade Length ................................................................ 9 in.
Edging Depth................ Adjustable from 1/4 in. to 1-1/2 in.
Weight ........................................................................ 4 lbs.
Compatible With...............Ryobi 24V and 40V Power Head
If purchased with 24 V power head:
Motor ............................................................ 24 Volts DC
If purchased with 40 V power head:
Motor ............................................................ 40 Volts DC

9 — English
ASSEMBLY
WARNING:
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from the
product when assembling parts.
CONNECTING THE POWER HEAD TO THE
EDGER ATTACHMENT
See Figure 2.
WARNING:
Never install, remove, or adjust any attachment while
power head is running or with the battery pack installed.
Failure to stop the motor or remove the battery pack can
result in serious personal injury.
The attachment connects to the power head by means of
a coupler device.
Remove the battery pack if installed.
Align the arrows on the edger attachment and the power
head. Then, insert the plug on the attachment into the
opening on the coupler. Make sure the plug is fully seated.
Slide the threaded coupler on the power head onto the
threaded base on the attachment and turn the coupler
clockwise. Tighten securely.
NOTE: Once assembled correctly, the edger attachment
and power head should not separate when pulled. Repeat
above steps if pieces can be separated.
WARNING:
Failure to secure the edger attachment and power head
as instructed above could result in serious personal injury.
REMOVING THE EDGER ATTACHMENT FROM
THE POWER HEAD
Remove the battery pack.
Turn the coupler counterclockwise to unlock. Then
remove the edger shaft from the power head.
OPERATION
WARNING:
Do not allow familiarity with products to make you
careless. Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING:
Never use flailing devices, wire, or rope on this product.
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
Depending on the power head you are using, this product
will accept either Ryobi 24 V or Ryobi 40 V battery packs.
For complete charging instructions, refer to the Operator’s
Manuals for your Ryobi battery pack and charger models.
TO INSTALL BATTERY PACK
See Figure 3.
WARNING:
Always remove battery pack from your tool when you are
assembling parts, making adjustments, cleaning, or when
not in use. Removing battery pack will prevent accidental
starting that could cause serious personal injury.
Insert the battery pack into the product as shown.
WARNING:
Make sure the latches (or latches) on the battery pack
snap in place and the battery pack is fully seated and
secure in the power head battery port before beginning
operation. Failure to securely seat the battery pack could
cause the battery pack to fall out, resulting in serious
personal injury.

10 — English
OPERATION

The edger will edge along sidewalks, driveways, flower
beds, curbs, and similar areas.

Cut at a steady pace. If the blade begins to bog down,
you are edging too fast; slow your pace. Do not force the
blade into ground.

Light contact of the blade against the sidewalk edge,
curb, etc., is acceptable and will not damage the edger.

Best appearance is obtained when grass is dry. Avoid
edging in wet soil or wet grass areas or the blade guard
might clog and result in an uneven edge. If the blade guard
becomes clogged, stop the edger, remove the battery,
and remove debris from the blade guard.
WARNING:
Always hold the edger away from the body keeping
clearance between the body and the edger. Any contact
with the edger cutting head while operating can result in
serious personal injury.
ADJUSTING DEPTH OF CUT
See Figures 7 - 8.

Remove the battery pack.

Loosen the depth adjusting lever and move the wheel arm
up to increase the depth or down to decrease the depth.

Lever locks into one of four positions.

Replace the battery pack.
NOTE:Adjust the bladedepth from1/2 in.to 1 in.deepinitially.
Make a shallow cut to test the cutting depth. If the cutting
depth needs adjusting, this should be done progressively
until the desired depth is reached.
TO REMOVE BATTERY PACK
See Figure 3.
Depress the latch (or latches) on the battery pack.
Remove the battery pack.
WARNING:
To avoid serious personal injury, always remove the
battery pack and keep hands clear of the lock-out when
carrying or transporting the tool.
ADJUSTABLE FRONT HANDLE
See Figure 4.
The angle of the front handle can be adjusted 180°.
Remove the battery pack.
Set the edger on a flat surface and turn the knob
counterclockwise to loosen the handle.
For edging, adjust the handle downward.
Turn the knob clockwise until the handle is securely
tightened before reinstalling the battery pack
STARTING/STOPPING THE EDGER
See Figure 5.
To start:
Press and hold the lock-out.
Depress the switch trigger.
To stop:
Release the switch trigger to stop the edger.
Upon release of the switch trigger, the lock-out will
automatically reset to the locked position.
OPERATING THE EDGER
See Figure 6.

Hold the edger with your right hand on the rear handle
and your left hand on the front handle.

Keep a firm grip with both hands while in operation.

Edger should be held at a comfortable position with the
rear handle about hip height.

11 — English
MAINTENANCE
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts could create a hazard or cause
product damage.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING:
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or performing
any maintenance.
GENERAL MAINTENANCE
Before each use, inspect the entire product for damaged,
missing, or loose parts such as screws, nuts, bolts, caps, etc.
Tighten securely all fasteners and caps and do not operate
this product until all missing or damaged parts are replaced.
Please call 1-800-860-4050 or contact an authorized service
center for assistance.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which could result in serious personal injury.
Only the parts shown on the parts list are intended to be
repaired or replaced by the customer. All other parts should
be replaced at an Authorized Service Center.
REPLACING THE BLADE
See Figures 9 - 10.
Replace blades when worn down to indicator hole on blade.
Remove the battery pack.
Wear gloves when handling blade.
Align the slot in the flange washer with the slot in the
gear case ring; place the holding pin through both slots
to secure in place.
Using the wrench (included), turn the blade nut
counterclockwise to loosen.
Remove the old blade from the motor shaft.
Clean debris from the edger shaft, flange washer and
cupped washer.
Center the new blade on the flange washer, making sure
the blade sits flat.
Properly install the cupped washer with the raised center
area with the hole not touching the blade and the outer
ring of the cupped washer touching the blade.
Install the blade nut onto the motor shaft and reinsert the
holding pin into the slots as described above.
Using a wrench, turn the blade nut clockwise onto the
edger shaft and tighten securely.
This replacement part is available from the place of
purchase, or by calling 1-800-860-4050.
WARNING:
Always make sure the blade is correctly installed and
securely fastened before each use. Failure to properly
install the blade may result in serious personal injury.
STORING THE EDGER
Remove the battery pack from the power head before
storing.
Clean all foreign material from the edger.
Store it in a place that is inaccessible to children.
Keep away from corrosive agents such as garden
chemicals and de-icing salts.

12 — English
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
Motor fails to start when switch
trigger is depressed.
Battery is not secure.
Battery is not charged.
To secure the battery pack, make sure the latch
(or latches) snap into place.
Charge the battery pack according to the
instructions included with your model.
CALL US FIRST
For any questions about operating or maintaining your product,
call the Ryobi®Help Line!
Your product has been fully tested prior to shipment to ensure
your complete satisfaction.

13 — English
LIMITED WARRANTY STATEMENT
Techtronic Industries North America, Inc., warrants to the
original retail purchaser that this RYOBI®brand outdoor
product is free from defect in material and workmanship
and agrees to repair or replace, at Techtronic Industries
North America, Inc.’s, discretion, any defective product
free of charge within these time periods from the date of
purchase.
Three years if the product is used for personal, family
or household use;
90 days, if used for any other purpose, such as
commercial or rental.
This warranty extends to the original retail purchaser
only and commences on the date of the original retail
purchase.
Any part of this product found in the reasonable judgment
of Techtronic Industries North America, Inc. to be defective
in material or workmanship will be repaired or replaced
without charge for parts and labor by an authorized service
center for RYOBI®brand outdoor products (Authorized
Ryobi Service Center).
Theproduct,includingany defective part, mustbe returned
to an authorized Ryobi service center within the warranty
period.The expense of delivering the productto the service
center for warranty work and the expense of returning it
back to the owner after repair or replacement will be paid
by the owner. Techtronic Industries North America, Inc.’s,
responsibility in respect to claims is limited to making the
required repairs or replacements and no claim of breach of
warranty shall be cause for cancellation or rescission of the
contractof saleof anyRYOBI®brandoutdoor product.Proof
of purchase will be required by the dealer to substantiate
any warranty claim. All warranty work must be performed
by an authorized service dealer.
This warranty is limited to ninety (90) days from the date
of original retail purchase for any RYOBI®brand outdoor
product that is used for rental or commercial purposes, or
any other income-producing purpose.
This warranty does not cover any product that has been
subject to misuse, neglect, negligence, or accident, or that
has been operated in any way contrary to the operating
instructions as specified in this operator’s manual. This
warranty does not apply to any damage to the product that
is the result of improper maintenance or to any product
that has been altered or modified. The warranty does not
extend to repairs made necessary by normal wear or by the
use of parts or accessories which are either incompatible
with the RYOBI®brand outdoor product or adversely affect
its operation, performance, or durability. In addition, this
warranty does not cover:
A. Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B. Wear items – Bump Knobs, Outer Spools, Cutting
Lines, Inner Reels, Starter Pulleys, Starter Ropes, Drive
Belts, Tines, Felt Washers, Hitch Pins, Mulching Blades,
Blower Fans, Blower and Vacuum Tubes, Vacuum Bag
and Straps, Guide Bars, Saw Chains
Techtronic Industries North America, Inc., reserves the
right to change or improve the design of any RYOBI®brand
outdoorproductwithoutassuming any obligation tomodify
any product previously manufactured.
ALL IMPLIED WARRANTIES ARE LIMITED IN DURATION
TO THE STATED WARRANTY PERIOD. ACCORDINGLY,
ANY SUCH IMPLIED WARRANTIES INCLUDING
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, OR OTHERWISE, ARE DISCLAIMED
IN THEIR ENTIRETY AFTER THE EXPIRATION OF
THE APPROPRIATE THREE-YEAR OR NINETY-DAY
WARRANTY PERIOD. TECHTRONIC INDUSTRIES
NORTH AMERICA, INC.’S, OBLIGATION UNDER THIS
WARRANTYISSTRICTLYAND EXCLUSIVELY LIMITED TO
THE REPAIR OR REPLACEMENT OF DEFECTIVE PARTS
AND TECHTRONIC INDUSTRIES NORTH AMERICA,
INC., DOES NOT ASSUME OR AUTHORIZE ANYONE
TO ASSUME FOR THEM ANY OTHER OBLIGATION.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU. TECHTRONIC
INDUSTRIES NORTH AMERICA, INC., ASSUMES NO
RESPONSIBILITY FOR INCIDENTAL, CONSEQUENTIAL,
OR OTHER DAMAGES INCLUDING, BUT NOT LIMITED
TO, EXPENSE OF RETURNING THE PRODUCT TO AN
AUTHORIZED RYOBI SERVICE CENTER AND EXPENSE
OF DELIVERING IT BACK TO THE OWNER, MECHANIC’S
TRAVEL TIME, TELEPHONE OR TELEGRAM CHARGES,
RENTAL OF A LIKE PRODUCT DURING THE TIME
WARRANTY SERVICE IS BEING PERFORMED, TRAVEL,
LOSS OR DAMAGE TO PERSONAL PROPERTY, LOSS
OF REVENUE, LOSS OF USE OF THE PRODUCT, LOSS
OF TIME, OR INCONVENIENCE. SOME STATES DO NOT
ALLOWTHE EXCLUSIONOR LIMITATIONOFINCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies toall RYOBI®brand outdoor products
manufacturedbyor forTechtronicIndustriesNorth America,
Inc., and sold in the United States and Canada.
To locate your nearest Authorized Ryobi Service Center,
dial 1-800-860-4050.
WARRANTY

3 — Français
AVERTISSEMENT :
Lors de l’utilisation d’outils de jardinage, toujours suivre
les consignes de sécurité de base pour éviter les risques
d’incendie, d’électrocution et de blessures.
LIRE TOUTES LES INSTRUCTIONS
Pour travailler en toute sécurité, lire et veiller à bien
comprendre toutes les instructions avant d’utiliser ce
produit. Respecter toutes les instructions de sécurité. Le
non respect des instructions de sécurité ci-dessous peut
entraîner des blessures graves.
Ne pas laisser des enfants ou personnes n’ayant pas reçu
une formation adéquate utiliser cet produit.
Déblayer la zone de travail avant chaque utilisation. La
débarrasser de tous les objets tels que cailloux, verre brisé,
clous, fils métalliques, cordes, etc. risquant d’être projetés
ou de se prendre dans la ligne de coupe ou la lame.
Toujours porter une protection oculaire avec écrans latéraux
certifiée conforme à la norme ANSI Z87.1. Le respect de
cette règle réduira les risques de blessures graves.
Utiliser les lunettes de sûreté – Toujours la visage d’usage
ou le masque de poussière si l’opération est poussiéreuse.
Protection respiratoire. Porter un masque facial ou un
masque antipoussière si le travail produit de la poussière. Le
respect de cette consigne réduira les risques de blessures
graves.
Vêtements adéquats – Le port de gants de caoutchouc et
de chaussures solides est recommandé pour le travail à
l’extérieur. Porter des pantalons et des manches longues
en tissu robuste, des chaussures de travail et des gants. Ne
pas porter de vêtements amples, des bijoux ou tout autre
article pouvant se coincer dans les pièces mobiles. Attacher
les cheveux longs pour les maintenir au-dessus des épaules
afin qu’ils ne se coincent pas dans les pièces mobiles.
Ne pas porter de vêtements amples, bijoux, shorts, sandales
et ne pas travailler pieds nus.
Tenir les enfants éloignés - Ranger les appareils qui ne sont
pas utilisés - Garder les badauds, enfants et animaux à une
distance de 15 m (50 pi) minimum.
Rester alerte –Se concentrer sur son travail. Faire preuve
de bon sens. Ne pas utiliser ce taille-bordures en état de
fatigue, si l’on est souffrant, si vous êtes bouleversé, ou sous
l’influence de l’alcool, de drogues ou de médicaments.
Ne pas travailler sous un éclairage insuffisant.
Garder toutes les parties du corps à l’écart des pièces en
mouvement.
Ne pas utiliser d’outils électriques dans des atmosphères
explosives, par exemple en présence de liquides, gaz ou
poussières inflammables. Les outils électriques produisent
des étincelles risquant d’enflammer les poussières ou
vapeurs.
Éviter tout contact du corps avec des surfaces mises
à la terre, telles que tuyaux, radiateurs, cuisinières et
réfrigérateurs. Le risque de choc électrique est accru lorsque
le corps est mis à la terre.
N’utiliser en aucun cas un accessoire non fourni avec le
produit, ou indiqué comme pouvant être utilisé sur l’outil
dans le manuel d’utilisation.
Éviter les environnements dangereux –Ne pas exposer le
appareil ou outil à la pluie ou l’humidité. La pénétration d’eau
dans ces outils accroît le risque de choc électrique.
Utiliser les appareils appropriés –Ne pas utiliser l’outil pour
une tâche pour laquelle il n’est pas conçu. Ne pas forcer
l’produit. Utiliser un produit approprié pour le travail. Un
produit approprié exécutera le travail mieux et de façon
moins dangereuse s’il fonctionne dans les limites prévues.
Ne pas forcer appareil – Un produit approprié exécutera le
travail mieux et de façon moins dangereuse s’il fonctionne
dans les limites prévues.
Ne pas faire fonctionner l’équipement pied-nu ou en portant
des sandales ou des chaussures légères similaires. Porter
des chaussures de protection qui protègent vos pieds et
améliorent votre équilibre sur des surfaces glissantes.
Ne pas exagérer en se courbant ou en s’étirant. Se tenir bien
campé et en équilibre. Cette façon de travailler pourrait vous
faire perdre l’équilibre.
Éviter les démarrages accidentels s’assurer que la gâchette
est verrouillée en position d’arrêt avant d’insérer le bloc piles.
Le transport d’outils avec le doigt sur le commutateur ou
l’insertion du bloc piles avec le commutateur en position de
marche est une invite aux accidents.
Ne pas utiliser l’produit si le commutateur ne permet pas
de le mettre en marche et de l’arrêter. Tout produit qui ne
peut pas être contrôlé par son commutateur est dangereux
et doit être réparé.
Débrachement du taille-bordures – Retirer le bloc-piles de
l’outil avant de le ranger, le réparer ou changer la lame. Ces
mesures de sécurité réduisent les risques de démarrage
accidentel de l’outil.
Utiliser exclusivement des pièces de rechange et accessoire
d’origine. L’usage de toute autre pièce pourrait créer une
situation dangereuse ou endommager l’produit.
Vérifier l’état des pièces – Avant d’utiliser l’appareil de
nouveauexaminer soigneusementles pièceset dispositifsde
protectionquisemblent endommagésafin dedéterminer s’ils
fonctionnent correctement et s’ils remplissent les fonctions
prévues. Vérifier l’alignement des pièces mobiles, s’assurer
qu’aucunepiècen’est bloquée oucassée,vérifier la fixationde
chaquepièce ets’assurerqu’aucun autreproblèmenerisque
d’affecter le bon fonctionnement de l’outil. La réparation
ou le remplacement du dispositif de protection ou de toute
autre pièce doivent être confiés à un centre de réparations
autorisé, sauf indication contraire dans le présent manuel.
Éloigner les mains et les pieds de la zone de coupe.
S’assurer que tous les dispositifs de protection, déflecteurs
d’herbe et poignées sont correctement installés et
solidement assujettis.
INSTRUCTIONS IMPORTANTES CONCERNANT LA SÉCURITÉ

4 — Français
INSTRUCTIONS IMPORTANTES CONCERNANT LA SÉCURITÉ
Entreposer les outils à l’intérieur - Quand pas dans l’usage,
tondeuse à fouet devrait être emmagasiné à la maison dans
un sec, fermé à clef la remiser dans un endroit inaccessible
aux enfants.
Examiner la surface à tondre. Retirer tous les objets (roches,
verre brisé, clous, câble, corde etc.) qui peuvent être projetés
dans les airs ou qui peuvent s’emmêler dans la tête de
coupe.
S’assurer que les évents d’aération sont propres et exempts
de débris afin d’éviter que le moteur ne surchauffe. Les
nettoyer après chaque utilisation.
Arrêter l’produit et le débrancher de la source d’alimentation
lorsqu’il n’est pas utilisé. Attendre l’arrêt complet du moteur
avant de déplacer l’produit.
Ne pas tenir les bords coupants lorsque l’on ramasse ou
que l’on tient l’outil.
Realice un mantenimiento cuidadoso del artefacto -
mantenga los bordes de corte afilados y limpios para
optimizar el rendimiento y reducir el riesgo de lesiones. Siga
las instrucciones referentes al cambio y la lubricación de
accesorios. Inspeccione periódicamente el cable del artefacto
y, si está dañado, llévelo a reparar a un establecimiento
de servicio autorizado. Revise periódicamente los
prolongadores y reemplácelos si están dañados.
Mantenga los mangos secos, limpios y sin aceite ni grasa.
Ranger l’produit en s’assurant qu’il est débranché et qu’il
est hors de la portée des enfants.
Ne pas suspendre l’produit d’une façon qui enclencherait la
gâchette.
Les outils fonctionnant sur piles n’ayant pas besoin d’être
branchés sur une prise de courant, ils sont toujours en état
de fonctionnement. Tenir compte des dangers possibles
lorsque l’produit n’est pas en usage et lors du remplacement
des piles. Le respect de cette consigne réduira les risques
d’incendie, de choc électrique et de blessures graves.
Ne pas recharger un produit fonctionnant sur piles dans un
endroit la pluie ou humide ou mouillé. Le respect de cette
règle réduira les risques de choc électrique.
Ne pas utiliser un appareil alimenté par pile sous la pluie.
Retirer ou débrancher la pile avant l’entretien ou le nettoyage
de l’produit de jardin ou avant d’en retirer des matériaux.
Utiliser seulement la pile et le chargeur indiqués.
• Utiliser les blocs-piles de 24 V au lithium-ion lors
de l’utilisation du bloc-moteur de 24 V. Consulter la
documentation de correspondance 988000-446 de l’outil,
de l’appareil, du bloc-piles et du chargeur.
• Utiliser les blocs-piles de 40 V au lithium-ion lors
de l’utilisation du bloc-moteur de 40 V. Consulter la
documentation de correspondance 988000-842 de l’outil,
de l’appareil, du bloc-piles et du chargeur.
Ranger les appareils qui ne sont pas utilisés – lorsque le
coupe-bordure n’est pas utilisé, le ranger à l’intérieur dans
un endroit sec et verrouillé hors de la portée des enfants.
Ne pas jeter les piles au feu. La cellule peut exploser. Vérifier
les codes locaux pour connaître toute instruction spéciale
relative à l’élimination des piles.
Ne pas altérer le bloc piles. L’électrolyte est un produit
corrosif pouvant causer des lésions cutanées ou oculaires.
Il peut être toxique en cas d’ingestion.
Ne pas placer les outils électriques sans fil ou leurs piles
à proximité de flammes ou d’une source de chaleur. Ceci
réduira les risques d’explosion et de blessures.
Les piles peuvent exploser en présence d’une source
d’allumage, telle qu’une veilleuse. Pour réduire les risques de
blessures graves, ne jamais utiliser un appareil sans fil, quel
qu’il soit, en présence d’une flamme vive. En explosant, une
pile peut projeter des débris et des produits chimiques. En
cas d’exposition, rincer immédiatement les parties atteintes
avec de l’eau.
Ne pas écraser, faire tomber ou endommager le bloc piles.
Ne jamais utiliser un bloc piles ou un chargeur qui est tombé,
a été écrasé, a reçu un choc violent ou a été endommagé
de quelque façon que ce soit. Une pile endommagée risque
d’exploser. Éliminer immédiatement toute pile endommagée,
selon une méthode appropriée.
Manipuler les piles avec soin pour éviter des courts circuits
avec des objets conducteurs comme des anneaux, des
bracelets et des clés. La pile ou l’objet conducteur peuvent
surchauffer et causer des brûlures.
Pou un résultat optimal, les piles de l’produit doivent être
rechargées dans un local où la température est de 10 à 38 °C
(50 à 100 °F). Ne pas ranger l’produit à l’extérieur ou dans
un véhicule.
Si l’produit est utilisé de façon intensive ou sous des
températures extrêmes, des fuites de pile peuvent se
produire. En cas de contact du liquide avec la peau,
rincez immédiatement la partie atteinte avec de l’eau
savonneuse, puis neutralisez avec du jus de citron ou du
vinaigre. En cas d’éclaboussure dans les yeux, rincez-les à
l’eau fraîche pendant au moins 10 minutes, puis contactez
immédiatement un médecin. Le respect de cette consigne
réduira les risques de blessures graves.
Conserver ces instructions. Les consulter fréquemment et
les utiliser pour instruire les autres utilisateurs éventuels.
Si cet produit est prêté, il doit être accompagné de ces
instructions.

5 — Français
RÈGLES DE SÉCURITÉ PARTICULIÈRES
Déblayer la zone de travail avant chaque utilisation. La
débarrasserde tous les objets telsquecailloux, verebrisé,
clous,fils métalliques,cordes,etc., risquant d’êtreprojetés
ou de se prendre dans la lame du coupe- bordures.
S’assurer que tous les dispositifs de protection sont cor-
rectement et solidement fixés.
Remplacer les lames émoussées ou usées; ne pas tenter
de les affûter.
Ce coupe-bordures permet d’effectuer la finition des
trottoirs, allées et massifs de fleurs. Ne pas l’utiliser pour
d’autres applications.
Bien se familiariser avec les commandes. Savoir arrêter
l’appareil et débrayer rapidement l’entraînement.
Ne pas utiliser le coupe-bordures sur ou à proximité de
surfaces gravillonnées.
Se familiariser avec le terrain sur lequel sont effectuées
les finitions. Faire attention aux trottoirs irréguliers et aux
trousdansleterrain ainsi qu’auxautressituationsprésent-
ant un danger semblable (exemple : ne jamais utiliser de
fil ou câble métallique qui pourrait se briser et devenir
un projectile dangereux).Toujours pousser lentement
l’accessoire coupe-border sur les terrains irréguliers.
Ne pas essayer de retirer de l’herbe coupée de l’outil ou
de tenir l’herbe à couper lorsque le moteur tourne ou la
lame est en rotation.
Garder la lame tournante loin des mains et des pieds.
Lorsque la lame est en rotation, toujours tenir l’outil avec
la main droite sur la poignée arrière et la main gauche sur
la poignée avant.
Une lame continuant de tourner au débrayé une fois que
le moteur est arrêté et la gâchette relâchée peut causer
des blessures. Garder le contrôle de l’outil jusqu’à ce que
la lame soit complètement immobilisée.
S’assurer que l’écrou de lame est serré solidement avant
d’utiliser l’accessoire.
Un assemblage inadéquat peut entraîner une situation
dangereuse.
Ne jamais se tenir vis-à-vis du chemin de coupe et garder
toutes les parties du corps à l’écart de celui-ci.
Si le coupe-bordures cogne un objet quelconque :
a) Arrêter le coupe-bordure et débrancher le fil de la
bougie ou débrancher de la prise secteur.
b) Inspecter le coupe-bordures pour voir s’il est endom-
magé.
c) Effectuer les corrections requises avant d’utiliser
l’accessoire coupe-bordures. Ne pas prendre cette pré-
caution peut entraîner des risques de blessures graves.
Toujours éteindre le moteur et retirer le bloc de piles avant
d’essayer de retirer des objets pris dans la lame ou la
bloquant, avant d’installer la lame ou avant d’effectuer
tout réglage.
Entreposer ce outil à l’intérieur – Quand l’outil n’est pas
utilisé, il devrait être entreposé à l’intérieur, dans un en-
droit sec ou haut c’est sécuritaire – hors de la portée des
enfants.
Conserver ces instructions. Les consulter fréquemment
et les utiliser pour instruire les autres utilisateurs
éventuels. Si cet outil est prêté, il doit être accompagné
de ces instructions, afin d’éviter un usage incorrect et
d’éventuelles blessures.
CONSERVER CES INSTRUCTIONS
