Ryobi RLM18X33H50F User manual

ORIGINAL INSTRUCTIONS
Cordless Lawn
Mower
RLM18X33H50F
RLM18X33H50
OLM1833H

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

Safety, performance, and dependability have
been given top priority in the design of your
cordless lawn mower.
INTENDED USE
The cordless lawn mower is only intended for
use outdoors.
The product is designed for domestic lawn
mowing. The cutting blade should rotate
approximately parallel to the ground over
which it is being wheeled. All four wheels
should touch the ground while mowing. It is
a pedestrian-controlled walk-behind mower
designed to be pushed by hand.
The mower should never be operated with
the wheels off the ground; it should not be
pulled or ridden on. It should not be used to
cut anything other than domestic grass lawns.
GENERAL SAFETY WARNINGS
WARNING
When using the product, the safety rules
must be followed. For your own safety
and that of bystanders, please read these
instructions before operating the product.
Please keep the instructions safe for later
use.
WARNING
The product should only be operated
with the battery pack. When using battery
operated product, basic safety precautions
should always be followed to reduce the risk
RI¿UHOHDNLQJEDWWHULHVDQGSHUVRQDOLQMXU\
PERSONAL SAFETY
ŶThe product is capable of amputating hands
DQG IHHW DQG WKURZLQJ REMHFWV )DLOXUH WR
observe all safety instructions could result
LQVHULRXVLQMXU\RUGHDWK
ŶRead and understand the instructions
and safety warnings. Be familiar with the
controls and the correct use of the product.
ŶNever allow children or people with reduced
physical, sensory or mental capabilities, or
people unfamiliar with these instructions,
to operate, clean or maintain the product.
Local regulations may restrict the age of the
operator. Children should be adequately
supervised to ensure they do not play with
the appliance.
ŶStay alert, watch what you are doing,
and use common sense when operating
the product. Do not operate the product
while tired or under the influence of
drugs, alcohol, or medication. A lapse in
concentration while operating the product
PD\UHVXOWLQVHULRXVSHUVRQDOLQMXU\
ŶWear heavy, long trousers, long sleeves,
sturdy anti-slip footwear. Do not wear short
trousers, sandals, or go barefoot. Avoid
wearing clothing that is loose fitting or that
has hanging cords or ties.
ŶAlways wear safety glasses with side
shields.
ŶAlways be sure of your footing. Keep firm
footing and balance. Walk, never run.
ŶAlways be sure of your footing on slopes.
ŶUse the product across the face of slopes,
never up and down. Exercise extreme
caution when changing direction on slopes.
ŶDo not use the product near drop-offs,
ditches, excessively steep slopes, or
embankments. Poor footing could cause a
slip and fall accident.
WORK AREA SAFETY
ŶNever use product while people, especially
children, or pets are within 15 m because
RI WKH GDQJHU RI REMHFWV EHLQJ WKURZQ E\
contact with the blade.
Ŷ2EMHFWV VWUXFN E\ WKH ODZQ PRZHU EODGH
FDQ FDXVH VHYHUH LQMXULHV WR SHUVRQV
Thoroughly inspect the area where the
product is to be used and remove all rocks,
sticks, metal, wire, bones, toys, or other
IRUHLJQ REMHFWV 5HPHPEHU VWULQJ RU ZLUH
may entangle with the cutting means.
ŶAlways use the product in the daylight or in
good artificial light.
ŶDo not operate the product in explosive
atmospheres, such as in the presence
of flammable liquids, gases or dust. The
product creates sparks which may ignite
the dust or fumes.
ŶDo not operate the product in wet grass or
in the rain.
ŶDo not use the lawn mower when there is a
risk of lightning.
ŶKeep in mind that the operator or user
is responsible for accidents or hazards
1

occurring to other people or their property.
ŶTragic accidents can occur if the operator
is not alert to the presence of children.
Children are often attracted to the product
and the mowing activity. Never assume
that children will remain where you last saw
them.
ŶKeep children out of the mowing area and
under the watchful care of a responsible
adult other than the operator, be alert and
turn the product off if a child enters the
area.
ŶUse extra care when approaching blind
FRUQHUV VKUXEV WUHHV RU RWKHU REMHFWV
including overhanging shrubs, etc., which
may block your view.
BATTERY TOOL USE AND CARE
ŶRead, understand, and always follow
the safety instructions which came with
your battery and charger. Failure to do
so may result in electric shock, fire or
other hazardous situations. Keep all the
instructions together in a safe place for
future reference.
ŶBattery-operated products do not have to be
plugged into an electrical outlet; therefore,
they are always in operating condition.
Remove the isolator key whenever you are
not operating the product.
ŶRemove the battery pack before making
DQ\ DGMXVWPHQWV FOHDQLQJ RU UHPRYLQJ
material from the product.
ŶEnsure the isolator key is removed before
inserting the battery pack.
ŶA battery pack must be recharged only with
the charger specified by the manufacturer.
Using a charger with an incompatible
battery pack may create a risk of fire. Use
the battery pack only with charger listed.
ŶUse only the battery pack intended
specifically for the product. Use of any
other battery packs may result in a risk of
ILUHHOHFWULFVKRFNRULQMXU\WRSHUVRQV
ŶWhen the battery pack is not in use, keep
LW DZD\ IURP RWKHU PHWDO REMHFWV OLNH
paper clips, coins, keys, nails, screws, or
RWKHUVPDOOPHWDOREMHFWVWKDWFDQPDNHD
connection from one terminal to another.
Shorting the battery pack terminals
together may cause sparks, burns, fire, or
explosion.
ŶDo not place battery products or their
batteries near fire or heat. This increases
WKHULVNRIH[SORVLRQDQGSRVVLEO\LQMXU\
ŶDo not open or mutilate the battery pack.
Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may
be toxic if swallowed.
ŶProtect the battery pack against moisture
and water. Do not charge the product in a
damp or wet location. Following this rule
will reduce the risk of electric shock.
ŶIn case of damage and improper use of the
battery, vapour may be emitted. Provide
for fresh air and seek medical help in case
of complaints. The vapour can irritate the
respiratory system.
ŶDo not leave the battery pack inside a
vehicle in hot or cold conditions.
ŶDo not incinerate the battery.
ŶUnder abusive conditions, liquid may be
HMHFWHG IURP WKH EDWWHU\ DYRLG FRQWDFW
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
VHHNPHGLFDOKHOS/LTXLGHMHFWHGIURPWKH
battery may cause irritation or burns.
LAWN MOWER SAFETY WARNINGS
ŶBefore using, always visually inspect to
ensure blades, blade bolts, and cutter
assembly are not worn or damaged.
ŶReplace worn or damaged blades and
bolts in sets to preserve balance.
ŶThe blade on this mower is sharp, use
extreme caution and wear heavy-duty
gloves when fitting, replacing, cleaning or
checking bolt security.
ŶBring the product to an authorised service
centre to replace damaged or unreadable
labels.
ŶCheck all nuts, bolts, and screws at
frequent intervals for proper tightness to
be sure the equipment is in safe working
condition.
ŶCheck the grass box frequently for wear,
holes, or deterioration.
ŶReplace worn or damaged parts before
operating the product.
ŶThe product must be started with the user
behind the handlebars in the operator
safety zone. Never start the product if:
Ɣall four wheels are not on the ground
2

Ɣthe grass discharge chute is exposed
without being protected by the grass box
and grass discharge chute cover
Ɣhands and feet of all persons are not
clear of the cutting enclosure
ŶNever operate the product if the on/off
switch on the handlebar does not properly
start and stop the mower.
ŶNever attempt to lock the on/off switches in
the on position, this is extremely dangerous.
Ŷ'RQRWIRUFHWKHSURGXFW,WZLOOGRWKHMRE
better and safer at the speed for which it
was designed.
ŶStop the blade when crossing gravel
surfaces.
ŶDo not pull the product backward unless
absolutely necessary. If you must back the
product away from a wall or obstruction,
first look down and behind to avoid tripping
or pulling the product over your feet.
ŶStop the motor and allow the blade to stop if
the mower has to be tilted for transportation
when crossing surfaces other than grass,
and when transporting the product to and
from the area to be mowed.
ŶNever use the product with defective guards
or shields, or without safety devices, for
example, deflectors and/ or grass boxes,
in place.
ŶDo not tilt the lawn mower when switching
on the motor or while the motor is running.
This exposes the blade and increases the
SUREDELOLW\RIREMHFWVEHLQJWKURZQ
ŶSwitch on the motor carefully according
to instructions and keep hands and feet
away from cutting area. Keep clear of the
discharge opening at all times. Do not start
the product when standing in front of the
discharge opening.
ŶDo not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all time.
ŶNever pick up or carry the product while it
is running.
ŶStop the mower motor and remove isolator
key, make sure that all moving parts have
come to a complete stop for the below
cases:
Ɣwhenever you leave the product
unattended (including disposal of grass
clippings).
Ɣbefore cleaning a blockage or unclogging
discharge chute
Ɣbefore checking, cleaning or working on
the product
ƔDIWHU VWULNLQJ D IRUHLJQ REMHFW LQVSHFW
the product for damage and make
repairs as necessary before restarting
and operating the product)
Ɣbefore removing the grass box or
opening the grass discharge chute
cover.
ƔIf the product starts to vibrate abnormally
(check immediately)
–inspect for damage, particularly the
blades
–replace or repair any damaged parts
–check for and tighten any loose parts
ŶAvoid holes, ruts, bumps, rocks, property
VWDNHV RU RWKHU KLGGHQ REMHFWV 8QHYHQ
terrain could cause a slip and fall accident.
ŶAlways ensure the motor control cable
is never trapped, pinched or otherwise
damaged during assembly or when folding
the handle.
ADDITIONAL BATTERY SAFETY
WARNINGS
WARNING
7R UHGXFH WKH ULVN RI ¿UH SHUVRQDO LQMXU\
and product damage due to short circuit,
never immerse your tool, battery pack, or
FKDUJHULQÀXLGRUDOORZDÀXLGWRÀRZLQVLGH
WKHP &RUURVLYH RU FRQGXFWLYH ÀXLGV VXFK
as seawater, certain industrial chemicals,
and bleach or bleach-containing products,
etc., can cause a short circuit.
OVERLOAD AND OVERHEAT
PROTECTION
The product has an overload protection
device. When overloading is detected, the
product will automatically switch off. If the
overload protector is actuated, the on-off
button must be released. Press the on-off
button to restart the product.
The battery pack has overheat protection.
Excessive temperatures will cause the battery
to stop powering the product. Feel the battery
pack; if it is too warm, allow it to cool down
before resuming operation. If the product still
does not work, recharge the battery.
3

NOTE: The battery pack LED indicator will
not work if the battery protection feature has
caused the battery pack to stop powering the
product. Release the on-off button or remove
the battery pack from the product and the
battery pack LED indicator will resume normal
function.
RESIDUAL RISKS
Even when the product is used as prescribed,
it is still impossible to completely eliminate
certain residual risk factors. The following
hazards may arise in use and the operator
should pay special attention to avoid the
following:
Ŷ,QMXU\ FDXVHG E\ YLEUDWLRQ $OZD\V XVH
WKH ULJKW WRRO IRU WKH MRE 8VH GHVLJQDWHG
handles and restrict working time and
exposure.
Ŷ([SRVXUHWRQRLVHFDQFDXVHKHDULQJLQMXU\
Wear ear protection and limit exposure.
ŶContact with the blades.
Ŷ,QMXU\IURPWKURZQREMHFWV
TRANSPORTATION AND STORAGE
ŶStop the product, remove the isolator key
and the battery. Make sure that all moving
parts have come to a complete stop. Allow
the product to cool down before storing or
transporting.
ŶClean all foreign material from the product.
Store it in a cool, dry, and well-ventilated
place that is inaccessible to children. Keep
away from corrosive agents such as garden
chemicals and de-icing salts. Do not store
outdoors.
ŶFor transportation, remove isolator key,
secure the product against movement
RU IDOOLQJ WR SUHYHQW LQMXU\ WR SHUVRQV RU
damage to the product.
WARNING
Use extreme caution when lifting or tilting
the product for maintenance, cleaning,
storage, or transportation. The blade is
sharp. Keep all body parts away from the
blade while it is exposed.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local
and national provisions and regulations.
Follow all special requirements on packaging
and labelling when transporting batteries by a
third party. Ensure that no batteries can come
in contact with other batteries or conductive
materials while in transport by protecting
exposed connectors with insulating, non-
conductive caps or tape. Do not transport
batteries that are cracked or leaking. Check
with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s
replacement parts, accessories, and
attachments. Failure to do so can cause
LQMXU\SRRUSHUIRUPDQFHDQGPD\YRLG\RXU
warranty.
WARNING
Servicing requires extreme care and
knowledge and should be performed
RQO\ E\ D TXDOL¿HG VHUYLFH WHFKQLFLDQ )RU
service, we suggest you bring the product
to your nearest authorized service center
for repair. When servicing, use only original
replacement parts.
ŶRemove the isolator key and the battery
before any cleaning or maintenance task.
Ŷ<RX PD\ PDNH DGMXVWPHQWV DQG UHSDLUV
described here. For other repairs, contact
the authorized service agent.
ŶCheck the grass box frequently for wear or
deterioration.
ŶAfter each use, clean the product with a
soft dry cloth. Any part that is damaged
should be properly repaired or replaced by
an authorised service centre.
ŶCheck all nuts, bolts, and screws at frequent
intervals for proper tightness to ensure the
product is in safe working condition.
Ŷ%HFDUHIXOGXULQJDGMXVWPHQWRIWKHSURGXFW
to prevent entrapment of the fingers
between moving blades and fixed parts of
the product.
ŶWhen servicing the blades be aware that,
even though the power source is switched
off, the blades can still be moved.
ŶThe blade on the product is sharp. Use
4

extreme caution and wear heavy-duty
gloves when fitting, replacing, cleaning, or
checking bolt security.
ŶReplace damaged blades and bolts in sets
to preserve balance.
RISK REDUCTION
It has been reported that vibrations from
handheld tools may contribute to a condition
called Raynaud’s Syndrome. Symptoms may
include tingling, numbness, and blanching of
WKH ¿QJHUV XVXDOO\ DSSDUHQW XSRQ H[SRVXUH
to cold. Hereditary factors, exposure to cold
and dampness, diet, smoking, and work
practices are all thought to contribute to the
development of these symptoms. There are
measures that can be taken by the operator to
possibly reduce the effects of vibration:
ŶKeep your body warm in cold weather.
When operating the unit wear gloves to
keep the hands and wrists warm.
ŶAfter each period of operation, exercise to
increase blood circulation.
ŶTake frequent work breaks. Limit the
amount of exposure per day.
If you experience any of the symptoms of this
condition, immediately discontinue use and
see your doctor.
WARNING
,QMXULHVPD\ EHFDXVHG RUDJJUDYDWHG E\
prolonged use of a tool. When using any
tool for prolonged periods, ensure you take
regular breaks.
KNOW YOUR PRODUCT
See page 10.
Parts
1. On-off button
2. Handle
3. Motor control cable
4. Motor control cable retainer
5. Battery door
6. Grassbox full indicator
7. Grassbox
8. Rear wheel
9. +HLJKWDGMXVWPHQWOHYHU
10. Front wheel
11. Isolator key
12. Battery
13. Charger
14. Start button
SYMBOLS ON THE PRODUCT
Read and understand all
instructions before operating
the product, follow all warnings
and safety instructions.
Wear ear protection.
Wear eye protection.
Do not operate on inclines
greater than 15°. Mow across
the face of slopes, never up
and down.
Do not expose to rain or damp
condition.
Beware of sharp blades.
Blades continue to rotate after
the motor is switched off –
Remove isolator key before
maintenance
%HZDUHRIWKURZQRUÀ\LQJ
REMHFWV.HHSDOOE\VWDQGHUV
especially children and pets,
at least 15m away from the
operating area.
Press the Start button and
then the On-off button (A, B,
C or D) to start the product.
Release the Start button and
keep pressing the On-off button
to run the product. Release
the On-off button to stop the
product.
Please read the instructions
carefully before using the
product.
Waste electrical products
should not be disposed of
with household waste. Please
recycle where facilities exist.
Check with your local authority
or retailer for recycling advice.
Conforms to all regulatory
standards in the country in
the EU where the product is
purchased.
5

EurAsian Conformity Mark
Ukrainian mark of conformity
94
The guaranteed sound power
level is shown on this label by
94 dB.
The following signal words and meanings
are intended to explain the levels of risk
associated with the product:
DANGER
Indicates an imminently hazardous situation,
which, if not avoided, will result in death or
VHULRXVLQMXU\
WARNING
Indicates a potentially hazardous situation,
which, if not avoided, could result in death or
VHULRXVLQMXU\
CAUTION
Indicates a potentially hazardous situation,
which, if not avoided, may result in minor or
PRGHUDWHLQMXU\
CAUTION
(Without safety alert symbol) Indicates a
situation that may result in property damage.
SYMBOLS IN THIS MANUAL
Parts or accessories sold
separately
Keep hands away from blades
Note
Warning
Stop the product.
MOWING TIPS
The run time of the battery depends on the
condition, length, and density of the grass.
$GMXVW WKH FXWWLQJ KHLJKW RI WKH ODZQ PRZHU
to suit the current condition of the lawn to be
mowed.
Grass
conditions
Suggested height
adjustment
Coverage
(maximum)
First pass Succeeding
passes
4 Ah
battery
5 Ah
battery
Very thin / Dry 3 2 200 m2250 m2
Thin / Dry 4 ĺ 150 m2200 m2
Medium /
Dense 5ĺ 100 m2150 m2
ŶFor best performance, always cut off one-
third or less of the total height of the grass.
ŶWhen cutting long grass, reduce walking
speed to allow for more effective cutting
and a proper discharge of the clippings.
ŶDo not cut wet grass; it will stick to the
underside of the deck and prevent proper
collection or discharge of grass clippings.
ŶNew or thick grass may require a higher
cutting height.
ŶA higher cutting height will extend the run
time of the battery.
ŶEmpty the grass box regularly, otherwise
the discharge chute will become blocked
with grass cuttings.
ŶThe mower is designed to operate and cut
most effectively when moving forwards.
6

x 1 x 1
x 1 x 1
RLM18X33H50F
x 1
x 2
x 2
13mm
x 1 x 1
7

x 1 x 1
x 1 x 1
RLM18X33H50
x 1
x 2
x 2
13mm
x 1 x 1
8

OLM1833H
x 1
x 1
x 1
13mm
x 1
x 2
x 2
x 1
9

14
11 12 13
7
6
8
9
10
1
2
4
5
3
10

1
2
5
1
2
1
2
6 7
2
1
1
2
3
1 2
2
2
1
1
3
1
A
B
C
D
2
A
+/
B
/
C
/
D
A
B
C
D
8
3 4
1111

12

p.16
p.15
p.16
13

GO
STOP
p.21p.20
p.19p.15p.17
14

15
A
2
A
+/
B
/
C
/
D
A
B
C
D
1
B
C
D
Û0D[Û
1
2
3
4
2
1

16
1
2
1
2
3
4
5

17
2
1
4
3
1
2
3
2
1
4

18
1
2
5
6
7
