Ryobi RPS100 User manual

ORIGINAL INSTRUCTIONS
Palm Sander
RPS100

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

Safety, performance, and dependability have been given
top priority in the design of your palm sander.
INTENDED USE
The palm sander is intended for sanding and nishing
metal, wood, plastic or similar materials using the abrasive
pads or sheets provided. The palm sander is intended to
be used by adult operators who have read the instruction
manual and understand the risks and hazards. The palm
sander should only be used in well ventilated areas. The
palm sander is designed for dry sanding only.
The palm sander is intended only for consumer use.
Do not use the product in any way other than those stated
in Intended Use. Use of the product for operations different
from intended could result in a hazardous situation.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool’’ in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1. WORK AREA SAFETY
a. Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. ELECTRICAL SAFETY
a. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adaptor plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
f. If operating power tools in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. PERSONAL SAFETY
a. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
b. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
e. Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. POWER TOOL USE AND CARE
a. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the rate
for which it was designed.
b. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.
c. Disconnect the plug from the power source and/
or the battery pack from the power tool before
making any adjustments, changing accessories,
or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool
accidentally.
d. Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are dangerous
in the hands of untrained users.
1

e. Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits
etc., in accordance with these instructions,
taking into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
5. SERVICE
a. Have your power tool serviced by a qualified
repairpersonusingonlyidenticalmanufacturer’s
replacement parts. This will ensure that the safety
of the power tool is maintained.
SANDER SAFETY WARNINGS
■Always wear safety goggles and a dust mask when
sanding, especially sanding over-head.
■The machine is not suitable for wet sanding.
■Do not use sanding paper larger than needed. Extra
paper extending beyond the sanding pad can also
cause serious lacerations.
■The dust collection box shall be equipped with the
tool. It should be emptied frequently. To connect dust
collection box, insert the adapter of dust box to the dust-
collection opening on the rear end of the sander.
■It is recommended that the product be always supplied
via a residual current device with a rated residual
current of 30mA or less.
WARNING
Do not throw sanding dust into an open fire because
materials in fine particle form may be explosive.
WARNING
A suitable breathing respirator must be worn while
sanding lead paint, some woods and metal to avoid
breathing the harmful/toxic dust or air.
WARNING
Dust from certain paints, coatings, and materials may
cause irritation or allergic reactions. Dust from wood,
such as oak, beech, MDF, and others are carcinogenic.
Materials containing asbestos should only be worked on
or processed by qualied specialist operators.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise and the operator
should pay special attention to avoid the following:
■Injury caused by dust
–Using the product will produce considerable amount
of dust and fine particles. Use the dust collection
device or connect a dust extraction vacuum when
operating the product. Wear dust masks containing
filters appropriate to the materials being worked on.
Ensure adequate workplace ventilation. Do not eat,
drink, or smoke in the work area.
■Injury caused by noise and vibration
–Wear ear protection during the sanding operation.
Do not operate the product for long periods of time.
See “Risk reduction”.
RISK REDUCTION
It has been reported that vibrations from handheld tools
may contribute to a condition called Raynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness and blanching of the ngers, usually apparent
upon exposure to cold. Hereditary factors, exposure to
cold and dampness, diet, smoking and work practices
are all thought to contribute to the development of these
symptoms. There are measures that can be taken by the
operator to possibly reduce the effects of vibration:
■Keep your body warm in cold weather. When operating
the unit wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor about
these symptoms.
WARNING
Injuries may be caused or aggravated by prolonged use
of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
SANDPAPER SELECTION
Selecting the correct size, grit and type of sand paper is an
extremely important step in achieving a high quality sanded
nish. Aluminum oxide, silicon carbide, and other synthetic
abrasives are best for power sanding. Natural abrasives,
such as int and garnet are too soft for economical use in
power sanding.
In general, coarse grit will remove the most material
and ner grit will produce the best nish in all sanding
operations. The condition of the surface to be sanded will
determine which grit will do the job. If the surface is rough,
start with a coarse grit and sand until the surface is uniform.
Medium grit may then be used to remove scratches left
by the coarser grit and ner grit used for nishing of the
surface. Always continue sanding with each grit until
surface is uniform.
2

WARNING
Do not use sander without sandpaper; doing so will
damage the cushion.
Sheet/pad recommended use
80-grit sanding sheet Coarse sanding
120-grit sanding sheet Light sanding
150-grit sanding sheet Light sanding
MAINTENANCE
WARNING
The product should never be connected to a power
supply when assembling parts, making adjustments,
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product from the power
supply will prevent accidental starting that could cause
serious injury.
■When servicing, use only identical Ryobi replacement
parts. Use of any other parts may create a hazard or
cause product damage.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
■Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
■Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.
■If the power supply cord is damaged, it must be
replaced only by the manufacturer or by an authorized
service center to avoid risk. Contact authorized service
center.
■For greater safety and reliability, all repairs should be
performed by an Authorised Ryobi Service Centre.
WARNING
Electrical tools used on berglass material, wallboard,
spackling compounds, or plaster are subject to
accelerated wear and possible premature failure
because the berglass chips and grindings are highly
abrasive to bearings, brushes, commutators, etc. We do
not recommend using the product for extended work on
these types of materials..
WARNING
Do not use compressed air to blow dust from the product.
This practice is dangerous and can cause dirt and grit to
be blasted into someone’s eyes, causing injury.
LUBRICATION
All of the bearings in the product are lubricated with a
sufcient amount of high grade lubricant for the life span of
the product under normal operating conditions. Therefore,
no further lubrication is required.
CLEANING THE SCRUBBING PADS
To ensure longer life and optimum performance, periodically
clean all sanding residue and foreign materials from the
scrubbing pads. This can be done by rinsing the pad with
warm water until all foreign material has been washed
away. After cleaning, gently squeeze the pad to remove
excess water and allow pad to dry. Always store pads and
sanding sheets flat in a cool dry location.
CLEANING THE SANDING SHEETS
The sanding sheets that come with the product are made to
be re-used. Therefore, it is important that they be cleaned
periodically to remove sanding residue and foreign material
that can accumulate over time.
To clean sanding sheets, rub the sheets with a hard rubber
block. You can also use the clean rubber sole of a shoe.
WARNING
Always remove scrubbing or sanding pad from the
product before cleaning. Failure to do so could cause
serious personal injury.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories
and packaging should be sorted for
environment-friendly recycling.
SYMBOL
Safety Alert
VVolts
Hz Hertz
Alternating Current
WWatts
noNo-load speed
min־¹ Revolutions or reciprocations per minute
Orbital Diameter
Regulatory Compliance Mark (RCM). Product
meets applicable regulatory requirements.
Class II tool, double insulation
Wear ear protection
3

Wear eye protection
Please read the instructions carefully before
starting the machine.
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Connect to the power supply.
Disconnect from the power supply.
Parts or accessories sold separately
Lock
Unlock
Note
Off
On
Without force
With force
The following signal words and meanings are intended to
explain the levels of risk associated with this product:
DANGER
Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
(Without Safety Alert Symbol) Indicates a situation that
may result in property damage.
4

5

6
3
4
5
8
6
9
7
2
1
1. Switch off
2. Switch on
3. Cover
4. Finger pad
5. Lock
6. Dust collection box
7. Quick change hook-and-loop pad
8. Finger adhesive sandpaper
9. Delta adhesive sandpaper
KNOW YOUR PRODUCT

7
4
3
2
1 2
5
1
2
3 4
6

8

9
1
2
1
2
3
3
1
2
1
2a
b
3
3
4

10
2
3
1
1
2
5
6

1
2
3
1
2
12
3
4
20170310v1d4
11

PRODUCT SPECIFICATIONS
Palm sander
Model RPS100
Voltage 220 - 240 V 50 / 60Hz
Power 100 W
Orbital minute 12,000 min-1
Orbital diameter 1.6 mm
Pad size
Delta pad 168 x 100 mm
Finger pad 26 x 47 mm
Weight
(According to EPTA procedure 01/2003) 0.95 kg

20160919v1
20170310v1
Techtronic Industries (Australia) Pty. Ltd.
31 Gilby Road,
Mount Waverley VIC 3149, Australia
Techtronic Industries New Zealand Ltd.
2 Landing Drive, Mangere,
Auckland, New Zealand 2022
Imported by:
