Ryobi TS1340 Quick setup guide

RYOBI 10 in. (254 mm)
COMPOUND MITER SAW
MODEL NO. TS1340
REPAIR SHEET

2
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
FIGURE A
1
2
3
2
3
25
24
23
22
20
19
21 4
18
17 16
15
14
13
5
6
7
6
8
11 9
10
9
12

3
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
S58000500 BASE AND TABLE ASSEMBLY
1 580118000 FENCE............................................................................................ 1
2 A07103080457 * SOCKET HEAD CAP SCREW (M8 X 45 mm) ................................. 4
3 A36030814204 * SPRINGWASHER(M8) .................................................................. 4
4 A19003040093 * PANCROSS SCREW (M4 X 9 mm) ................................................. 2
5 518106300 TABLE SPINDLE............................................................................. 1
6 A35031025153 * FLATWASHER(M10) ..................................................................... 2
7 A36131020100 * SPRINGWASHER(M10) ................................................................ 1
8 A31703010008 * SELF-LOCKINGNUT(M10) ............................................................ 1
9 A36030612157 * SPRINGWASHER(M6) .................................................................. 2
10 A07003060257 * SOCKET HEAD CAP SCREW (M6 X 25 mm) ................................. 2
11 518104200 CONTROLARM .............................................................................. 1
12 518103100 LOCKHANDLE ............................................................................... 1
13 580114000 POINTER ........................................................................................ 1
14 A35030410018 * FLATWASHER(M4)....................................................................... 1
15 A10003040107 * PANCROSS SCREW (M4 X 10 mm) ............................................... 1
16 518105400 LOCKPLATE .................................................................................. 1
17 A49001020056 RIVET ............................................................................................. 3
18 580119000 MITER SCALE ................................................................................ 1
19 580117000 BASE .............................................................................................. 1
20 580120000 FIXED CAP ..................................................................................... 1
21 511104000 TABLEHOLDDOWN ...................................................................... 1
22 518A08130 VISE CLAMP ASSEMBLY .............................................................. 1
23 512106000 TABLE............................................................................................. 1
24 589027202 TABLE INSERT............................................................................... 1
25 A16003040083 * SCREW (M4 X 8 mm)...................................................................... 4
Themodelnumberwillbefoundonaplateattachedtothemotorhousing.Alwaysmentionthemodelnumber
in all correspondence regarding your Compound Miter Saw or when ordering repair parts.
PARTS LIST - FIGURE A
Key Part
No. Number Description Qty.
* Standard Hardware Item — May Be Purchased Locally

4
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
FIGURE B
1
23
4
56
7
8
9210
11 12 13 14
15
16
17
18
20
19
21 22 23
24 25
29
30 31 32
33
26
27
28
34 35 36
3738
39 40
41
42
43
44
45
46
47
60
50
48
49
51
52
53
54
55
56
57
58
59
59
78
79
80
77
69 70 71
73 74 75
76
64 61
62
63
65
66
67
68
72
81

5
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
Themodelnumberwillbefoundonaplateattachedtothemotorhousing.Alwaysmentionthemodelnumber
in all correspondence regarding your Compound Miter Saw or when ordering repair parts.
PARTS LIST - FIGURE B
Key Part
No. Number Description Qty.
* Standard Hardware Item — May Be Purchased Locally
S58000600 MOTOR ASSEMBLY
1 588004100 CORD HOLDER ............................................................................. 1
2 A19003050302 * PANCROSS SCREW (M5 X 30 mm) ............................................. 4
3 580309000 MOTOR HOUSING......................................................................... 1
4 A18003050054 * FIXED SCREW (M5 X 5 mm)......................................................... 2
5 A95001050060 * FIXED SCREW (M5 X 6 mm)......................................................... 2
6 528312100 BRUSH HOLDER ........................................................................... 2
7 588006100 CARBON BRUSH........................................................................... 2
8 528311004 BRUSH CAP................................................................................... 2
9 580317000 WARNING LABEL .......................................................................... 1
10 580302000 SWITCH.......................................................................................... 1
11 580316000 WARNING LABEL .......................................................................... 1
12 A10003040307 * PANCROSS SCREW (M4 X 30 mm) ............................................. 2
13 A10003040250 * PANCROSS SCREW (M4 X 25 mm) ............................................. 2
14 580318000 HANG TAG LABEL ........................................................................ 1
15 580311000 HANDLE COVER ........................................................................... 1
16 580313000 SPRING .......................................................................................... 1
17 580312000 SAFETY BUCKLE .......................................................................... 1
18 A30003004005 * HEX NUT (M4)................................................................................ 4
19 A90003040125 * PANCROSS SCREW (M4 X 12 mm) ............................................. 2
20 578313006 CORD CLAMP................................................................................ 1
21 9053N02000 FIELD ASSEMBLY......................................................................... 1
22 A90101050603 * PANCROSS SCREW (M5 X 60 mm) ............................................. 2
23 580314000 FAN CASING.................................................................................. 1
24 A50006080049 BEARING........................................................................................ 1
25 9053C01000 ARMATURE ASSEMBLY (INCLUDES KEY NOS. 24, 33, 34)...... 1
26 A17003060126 * CROSS SCREW (M6 X 12 mm)..................................................... 2
27 588025003 WASHER ........................................................................................ 2
28 588024007 CARRY HANDLE............................................................................ 1
29 A30003010007 * HEX NUT (M10).............................................................................. 1
30 A18003100206 * FIXED SCREW (M10 X 20 mm)..................................................... 1
31 A30003012194 * HEX NUT (M12).............................................................................. 2
32 A36031226023 * FLAT WASHER (M12).................................................................... 1
33 A46000150008 C-RING ........................................................................................... 1
34 A50060020056 BEARING........................................................................................ 1
35 A63020000320 O-RING........................................................................................... 1
36 586004800 ARM................................................................................................ 1
37 588026106 SPINDLE LOCK PIN ...................................................................... 1
38 A47000040006 E-RING .......................................................................................... 1
39 588027005 COMPRESSION SPRING.............................................................. 1
40 588A05043 ARBOR ASSEMBLY ...................................................................... 1
41 588031004 * SPECIAL SCREW (M5 X 10 mm) .................................................. 2

6
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
42 588023001 STOP PIN CAP ............................................................................... 1
43 A63000000051 O-RING............................................................................................ 1
44 588022300 STOP PIN ....................................................................................... 1
45 A90003040167 * PANCROSS SCREW (M4 X 16 mm) ............................................... 1
46 588021203 RUBBER SLEEVE .......................................................................... 1
47 A47000060002 E-RING ............................................................................................ 1
48 S58000700 LOWERGUARDASSEMBLY.......................................................... 1
49 S58000300 RETAININGSPRINGHOLDER ....................................................... 1
50 580407000 LOWERGUARD .............................................................................. 1
51 A35010616105 * FLATWASHER(M6) ....................................................................... 1
52 A31703006004 * SELF-LOCKINGNUT(M6) .............................................................. 1
53 976740-001 LABEL ............................................................................................. 1
54 589015108 SHOULDERSCREW ....................................................................... 1
55 538417000 RETAININGRING ........................................................................... 1
56 566407000 ROLLER .......................................................................................... 1
57 589021300 RETRACTSPRING ......................................................................... 1
58 580412000 HEXWASHERHEADSCREW........................................................ 1
59 588035105 FLANGE .......................................................................................... 2
60 580513000 BLADE ............................................................................................ 1
61 580315000 MOTORLABEL ............................................................................... 1
62 580411000 COVERLABEL ............................................................................... 1
63 A10003050106 * PANCROSS SCREW (M5 X 10 mm) ............................................... 4
64 A19001040091 * PANCROSS SCREW (M4 X 9 mm) ................................................. 1
65 580410000 LOGOPLATE.................................................................................. 1
66 S58000400 UPPERGUARD ASSEMBLY .......................................................... 1
67 A63020000428 O-RING............................................................................................ 1
68 595026002 ELBOW ........................................................................................... 1
69 A10003050105 * PANCROSS SCREW (M5 X 10 mm) ............................................... 1
70 589034005 DEFLECTOR ................................................................................... 1
71 A35030519105 * FLATWASHER(M5) ....................................................................... 1
72 A31703004006 * SELF-LOCKINGNUT(M4) .............................................................. 1
73 A31703005005 * SELF-LOCKINGNUT(M5) .............................................................. 1
74 589032207 STOPPER ....................................................................................... 1
75 A10003040152 * PANCROSS SCREW (M4 X 15 mm) ............................................... 1
76 581410003 SCREW ........................................................................................... 1
77 580514000 DUST BAG ...................................................................................... 1
78 A07910520000 * ALLENWRENCH(5mm) ................................................................ 1
79 A07810622000 * ALLENWRENCH(6mm) ................................................................ 1
80 A07910820000 * ALLENWRENCH(8mm) ................................................................ 1
81 580310000 CORDASSEMBLY.......................................................................... 1
Themodelnumberwillbefoundonaplateattachedtothemotorhousing.Alwaysmentionthemodelnumber
in all correspondence regarding your Compound Miter Saw or when ordering repair parts.
PARTS LIST - FIGURE B CONTINUED
Key Part
No. Number Description Qty.
* Standard Hardware Item — May Be Purchased Locally

7
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
FIGURE C
12
3
454
6
7
3
2
10 9
8
17
10
9
8
16 15
14
13
11
712

8
RYOBI 10 in. (254 mm) COMPOUND MITER SAW – MODEL NO. TS1340
Themodelnumberwillbefoundonaplateattachedtothemotorhousing.Alwaysmentionthemodelnumber
in all correspondence regarding your Compound Miter Saw or when ordering repair parts.
* Standard Hardware Item — May Be Purchased Locally
PARTS LIST - FIGURE C
Key Part
No. Number Description Qty.
1 511D04020 SUPPORT BRACKET ASSEMBLY ................................................. 1
2 A30003006003 * HEXNUT(M6)................................................................................. 2
3 578206000 * HEX BOLT (M6 X 16 mm) ............................................................... 2
4 A49001020056 RIVET ............................................................................................. 3
5 580202000 BEVEL SCALE................................................................................ 1
6 A07003100256 * SOCKET HEAD CAP SCREW (M10 X 25 mm) ............................... 2
7 A36031018255 * SPRINGWASHER(M10) ................................................................ 3
8 578203007 POINTER ........................................................................................ 2
9 A35030410018 * FLATWASHER(M4) ....................................................................... 2
10 A10003040107 * PANCROSS SCREW (M4 X 10 mm) ............................................... 2
11 578205106 PIVOTSUPPORT ........................................................................... 1
12 588058103 LOCKBOLT .................................................................................... 1
13 589011308 WASHER......................................................................................... 1
14 589010200 PIVOT SHAFT................................................................................. 1
15 A35031025153 * FLATWASHER(M10) ..................................................................... 1
16 589012100 HANDLE .......................................................................................... 1
17 580319000 TENSIONSPRING .......................................................................... 1
983000-248 OPERATOR'SMANUAL
983000-248R REPAIR SHEET
1-16-04
