Ryonet Riley Hopkins PRTB-JNR4X1 User manual

Jr. 4-Color, 1-Station
Assembly Instructions

1
Tools Required:
What’s in the box
• Two 9/16” wrenches
• One Phillipps screwdriver
Tag
11 per unitMain Press core assembly
Print head assembly with clamp
Mounting feet
16” x 16” MDF platens with neck
Hardware kit
4 per unit
2 per unit
1 per unit
1 per unit
2
3
4
5
Item Q.
1
2
3
4
5

2
1
2
3
4
Tag
14
8
4
1
PRHD-HC3/8NC1GR5ZC
PRHD-LNYN3/8NCGR5ZC
PRCO-JR41MTGHDWKIT
3/8-16 X 1 Hex Cap Screw Grade 5 Zinc
3/8 PFC9 Yellow Zinc USS Flat Washer
3/8-16 Lowpro Nyloc Zinc
Mounting Hardware pack perforated bag (qty. 4
screws)
PRHD-WA3/8USSPFC9ZY
2
3
4
Name/ID Description Q.
PRCO-JRFTMTHDWPK
Riley Junior Foot Mounting Hardware Kit

3
1
2
3
4
5
6
Tag
18
4
4
8
1
4
PRSA-SPRINGKIT
PRHD-HC3/8NF3GR5ZC
PRHD-WA3/8SAE-SS
PRCO-9/16ENDWRENCH
PRHD-LNYN3/8NFGR5ZC
Riley Hopkins Press Mesh Covered Spring
Air Hose for Riley Junior bump stops 2” long
3/8-24 x 3” Hex Cap Screw grade 5 Zinc
3/8 Flat washer
9/16” End wrench (off-contact adjustment)
3/8-24 Lowpro nyloc nut
PRCO-BMPRBLTCVRBLU
2
3
5
6
4
Name/ID Description Q.
PRCO-JRSTOPHDWPK
Riley Junior Bump stop Hardware Kit

4
1
2
3
1
Tag
14
8
4
PRHD-HC3/8NF3GR5ZC
PRHD-LNYN3/8NFGR5ZC
3/8-24 x 3” Hex Cap Screw grade 5 Zinc
3/8 Flat washer
3/8-24 Low pro Nyloc Nut
PRHD-WA3/8SAE-SS
2
3
Name/ID Description Q.
PRCO-JRHNGHDWPK
Riley Junior print head hinge hardware kit

5
4
3
2
1
Step 1
Install the Mounting feet (4) to the main press core with the supplied
hardware. Two 9/16” wrenches are required for this step.
Note: Refer to Page 2 for hardware detail.

6
Step 2
Install the Print head assemblies with the supplied hardware. Two 9/16”
wrenches are required for this step. Repeat this step for the remaining
print head assemblies.
Note: Refer to Page 4 for hardware detail.
1
4
3
2

7
Step 3
Install the spring assemblies with the hooks facing upward. Lower the
Print head assemblies until they rest on the lower stop bolt. Repeat this
step for the remaining print head assemblies.
Note: Refer to Page 3 for hardware detail.
1
Hooks must be
facing upward
Lower Stop

8
Step 4
Install the upper stop bolts and rubber sleeves. Two 9/16” wrenches
are required for this step. DO NOT OVERTIGHTEN THE BOLTS. This will
cause resistance in the print head hinge point. Repeat this step for the
remaining print head assemblies.
Note: Refer to Page 3 for hardware detail.
1
2
3
5
1
4

9
2
1
Step 5
Mount the press base to a sturdy table top (2) with supplied mounting
screws (1). Press is shown mounted on a Riley Hopkins 1-station press
cart (sold separately). A Phillips screwdriver is required for this step.
Note: Refer to Page 2 for hardware detail.

10
1
3
2
Step 6
Install the platen assembly (1) onto the tubular arm of the press. When
platen is in desired location, first lock down the side knob (2). Lastly,
tighten down the lower locking knobs (3). The platen can be adjusted
front-to-back to help position the image onto the desired location of
the substrate.

11
Step 7
O-contact and tilt adjustments. First lock the screen in place with the
screen clamping knobs (1).
Next, loosen the o-contact nuts (2) with a 9/16” wrench. Set the
desired o-contact position and retighten the nuts.
Lastly, set the tilt angle of the screen by loosening the tilt locking nuts
(3). Make sure to fully lock down the tilt hardware to avoid movement
during printing.
1
2
3

12
3
2
1
76
5
4
Tag
1PRSA-PLWD-WIN16X16N-LOW
SPRINGKIT
PRCO-KNBFLT3/8NC4ML
PRSA-SPRINGKIT
PRHD-HC3/8NC1-1/2NYBLK
MFPD-JR1X1MTGFT
PRSA-JR1STNPNTHED
Riley Junior Press Platen assy. w/Lowpro
Riley Junior Press Clamping Head assy.
Riley Hopkins Screen Clamp Head Knob
Riley Hopkins Press Mesh Covered Spring
3/8”-16 x 1-1/2 Nylon bolt Black
Mounting Foot for Riley Junior 1 Station-Matte Black
1-station Junior Series Printhead, No Micro
PRSA-JRCLAMP
2
3
5
6
7
4
Name/ID Description
PRTB-JNR4X1
Riley Hopkins Junior 4 color, 1 station screen printing press

13
NOTE: This print head assembly applies to the PRTB-JNR4X1MICRO.
Tag
12
2
1
2
3
3
1
3
PRCO-KNBFLT3/8NCFML
MFPD-JRCLRARMSPG
PRHD-SCRWCVR3/8
PRCO-KNBKNL5/16NF2-3/4ML
PRCO-RDED5/16RHFMLS
MFZC-TILTCHNL
PRCO-RDED5/16RHML
2-3/8”Fluted KNOBS 3/8-16 female insert
SINTERED BRZ BUSHING (SBB FL38 08)
Junior series-Color arm spring plate
Screw cover Black rubber 3/8
1-3/4” Knurled KNOBS 5/16-24 x 2-3/4” Stud
5/16”-24 Right Hand Tread Female Rod End-
Long Shank
Riley Junior Off-Contact Channel-Zinc Plated
5/16”-24 Right Hand Tread Male Rod End
PRCO-BRNZB3/8ID1/2LG
2
3
5
6
7
8
4
Name/ID Description Q.
PRSA-JRPNTHED
Riley Hopkins Junior Micro print head assembly
1
8
7 6
5
4
3
2

14
1
23
4
5
6
7
8
9
Tag
12
2
4
2
2
2
1
1
2
PRCO-KNBFLT3/8NC4ML
PRHD-HN3/8NCGR5ZC
PRHD-BTN3/8NC1BLK
PRHD-LNYN3/8NCGR5ZC
PRHD-WA3/8SAE-SS
MFMS-JRCPHEADM
MFMS-CLMPBR1/2X1
PRHD-WA3/8USSPFC9ZY
Riley Hopkins Replacement Clamp Head Knob
3/8-16 Hex Finish Jam Nut
3/8-16 Hex Finish Nut
3/8-16 x 1 Button Head Allen Bolt Black Oxide
3/8-16 Lowpro Nyloc Zinc
3/8 SAE Flat Washer Stainless Steel
Machined universal Clamping head, Riley Junior
Universal clamping bar for Riley clamp heads
3/8 PFC9 Yellow Zinc USS Flat Washer
PRHD-JN3/8NCGR5ZC
2
3
5
6
7
8
9
4
Name/ID Description Q.
PRSA-JRCLAMP
Riley Hopkins Junior Screen Clamp assembly

15
NOTES:
