S.R.Smith RM-6000 Assembly instructions

www.srsmith.com
RM-6000 Remote Control System
INSTALLATION SHEET
This RM-6000 Automatic Operating
System package is specifically designed
Includes:
1) Transmitter
Antenna for the 6004 AND 6004-AS fiber optic
illuminators and should not be modified or
adapted in any way.This is an electric
component and should only be installed
1) Receiver module with antenna
by a qualified technician.
Please follow the instructions carefully.
RANGE IS APPROXIMATELY 75 FEET
DEPENDING ON CONDITIONS.
1
Locate the 6 Pin Connector
DANGER:TURN OFF ELECTRIC SERVICE TO THE ILLUMINATOR FIRST!
Remove the two screws securing the cover and remove the cover. Inside the Lifetime Illuminator
TM
chassis is a 6-pin plastic connector. Locate the connector and unplug it. This is where the RM-6000
will connect.
2
Slide the RM-6000 into the chassis and plug it in
Slide the RM-6000 into the two slots on the left side of the chassis with the wires
facing the FRONT.Plug together the 6-pin connectors (note that the connectors
only fit together one way). Secure the wires in the chassis so the fan and color
wheel are not blocked.Take the single antenna wire and attach it to the top of the
illuminator chassis with a small piece of electrical tape.
3
Change the toggle switches
Replace the cover on the illuminator. Look at the toggle switch
label on the rear of the illuminator and move the toggle switches
to their correct position-
Power - bottom position
Color - middle position
Turn the power back on and test the unit for proper operation by
pressing the ON button for power, and the START button for color
wheel rotation.
4
Transmitter
Replacement BatteryType: Std. 9V
PM 10140 Rev. J3
COLOR WHEEL
POWER
Lamp "Restrike"
When turning the system off and then turning it
immediately back on, it may take 1 to 3 minutes
before the lamp comes back on.
This process allows the lamp to cool down and then
restart.
This is a normal function of the Metal-Halide lamp
system that the SR Smith 6000 Series illuminators
use.
This unit is equipped with an automatic 4 hour shut off.
It must be turned on with the transmitter after shut off.
TOGGLE SWITCH POSITIONS
OPTIONAL RM-6000 CONTROL
For multiple AS units, use WPC-1 or WPC-2 control system (sold separately)

www.srsmith.com
Code Adjustments
If it is necessary to change the transmission code on the RM6000, an adjustment to the receiver AND the transmitter DIP
switches must be performed.
RECEIVER DIP SWITCHES- Remove the receiver from the illuminator by sliding the tray out and unplugging the two six-pin
connectors.Remove the four screws that attaches the bottom panel to the top cover.Removethetopcovertoexposereceiver
PCB and dip switch. Refer to FIG. C to locate the DIP switch panel.
TRANSMITTER DIP SWITCHES- Remove the 6 screws to expose the remote PCB.Refer to FIG.D to locate the DIP switch
panel. Do not discard the rubber gasket.
DIP SWITCH ADJUSTMENT- The four DIP switches have an ON and an OFF position. The default position is all four
OFF. Changing just one DIP switch to ON will change the code. MAKE SURE BOTH THE RECEIVER AND TRANSMITTER
HAVE THE SAME DIP SWITCH SETTINGS.
DIP SWITCH PANEL DIP SWITCH PANEL
FIG. C
RECEIVER
FIG. D
TRANSMITTER
FIG. E
DIP SWITCH PANEL
