Saber Compact SC17 User manual

Read these instructions before using the machine
MODELS: SC17
Operating Instructions
98861 11/25/03
P
WALK BEHIND SCRUBBER
IPX4

MACHINE DATA LOG/OVERVIEW
SC17 98861 05/15/01
2
For the name and address of your dealer contact: Windsor Industries
YOUR DEALER
Name: __________________________________________________________________________________________________
Address: _______________________________________________________________________________________________
Phone Number: _________________________________________________________________________________________
OVERVIEW
The Saber Compact is a battery powered, hard floor scrubber intended for commercial use.
The appliance applies a cleaning solution onto a hard floor, scrubs the floor with a brush or
pad, and then vacuums the soiled water back into the recovery tank.
MODEL _______________________________________
DATE OF PURCHASE __________________________
SERIAL NUMBER ______________________________
SALES REPRESENTATIVE # _____________________
DEALER NAME ________________________________
OPERATIONS GUIDE NUMBER ___________________
PUBLISHED __________________________________________
Copyright 1995 Windsor Industries, Printed in USA

TABLE OF CONTENTS
SC17 98861 11/25/03
3
Machine Data Log/Overview..........................2
Table of Contents...........................................3
HOW TO USE THIS MANUAL
How to use this Manual. ................................1-1
SAFETY
Important Safety Instructions.........................2-1
Hazard Intensity Level...................................2-2
Safety Label Location. ...................................2-3
OPERATIONS
Technical Specifications................................3-1
How the Machine Works................................3-3
Components...................................................3-4
Controls..........................................................3-5
Machine Operation....................................... 3-7
Pre-Run Machine Inspection.................... 3-7
Starting Machine....................................... 3-7
Emergency Stop Procedures.................... 3-7
Filling the Solution Tank........................... 3-7
Scrubbing.................................................. 3-7
Emptying & Cleaning Tanks..................... 3-8
MAINTENANCE
Batteries.........................................................4-1
Battery Maintenance...................................4-1
Checking Battery Specific Gravity..............4-2
Charging the Batteries................................4-3
Changing Batteries.....................................4-3
Battery Connections....................................4-3
Scrub Brushes................................................4-4
Types...........................................................4-4
Replacing or Removing Scrub Brushes.....4-5
Installing Scrub Brushes.............................4-5
Squeegee Blades...........................................4-5
Replace Squeegee Blade...........................4-5
Remove Squeegee Assembly....................4-5
Service Schedule...........................................4-6
Machine Troubleshooting ..............................4-7
GROUP PARTS LIST
Decal Group.................................................5-1
Electrical Panel Group.................................5-3
Hour Meter...................................................5-5
Handle Group...............................................5-7
Recovery Tank Group..................................5-9
Scrub Brush/Pad Driver Group....................5-11
Scrub Motor/Lift Group.................................5-13
Solution Tank Group....................................5-15
Squeegee Group..........................................5-17
Squeegee Lift Group....................................5-19
VacuumGroup.............................................5-21
Wheel & Frame Group.................................5-23
Wiring Group –Battery Cables....................5-25
Wiring Group –Main Harness.....................5-27
Wiring Group -Schematic............................5-29
Suggested Spare Parts................................5-30
EC Declaration of Conformity......................5-31
Warranty.......................................................5-32

HOW TO USE THIS MANUAL
SC17 98861 05/15/01
1-1
This manual contains the following sections:
-HOW TO USE THIS MANUAL
-SAFETY
-OPERATIONS
-MAINTENANCE
-PARTS LIST
The HOW TO USE THIS MANUAL section will
tell you how to find important information for
ordering correct repair parts.
Parts may be ordered from authorized Windsor
dealers.When placing an order for parts, the
machine model and machine serial number are
important. Refer to the MACHINE DATA box
which is filled out during the installation of your
machine. The MACHINE DATA box is located
on the inside of the front cover of this manual.
The model and serial number of your machine
is on the front of the electrical panel.
The SAFETY section contains important
information regarding hazard or unsafe
practices of the machine. Levels of hazards are
identified that could result in product or
personal injury, or severe injury resulting in
death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains
preventive maintenance to keep the machine
and its components in good working condition.
They are listed in this general order:
-Batteries
-Scrub Brushes
-Squeegee
-Service Schedule
-Machine Troubleshooting
The PARTS LIST section contains assembled
parts illustrations and corresponding parts list.
The parts lists include a number of columns of
information:
-REF – column refers to the reference
number on the parts illustration.
-PART NO. – column lists the part
number for the part.
-QTY – column lists the quantity of the
part used in that area of the machine.
-DESCRIPTION – column is a brief
description of the part.
-SERIAL NO. FROM – column
indicates the first machine the part
number is applicable to. When the
machine design has changed, this
column will indicate serial number of
applicable machine. The main
illustration shows the most current
design of the machine. The boxed
illustrations show older designs.
-NOTES – column for information not
noted by the other columns.
NOTE: If a service or option kit is installed on
your machine, be sure to keep the KIT
INSTRUCTIONS which came with the kit. It
contains replacement parts numbers needed for
ordering future parts.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
DEALER NAME ______________________________
OPERATIONS GUIDE NUMBER __________________
PUBLISHED ________________________________
Copyright1995WindsorIndustries,PrintedinUSA

SC17 98861 05/15/01 2-1
IMPORTANT SAFETY INSTRUCTIONS
When using a battery powered appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer’s recommended components and
attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into
water, return it to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce
airflow.
This machine is not suitable for picking up hazardous dust.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this
machine near flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals,
factories, shops and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
If foam or liquid comes out of machine, switch off immediately.
Disconnect battery before cleaning or servicing.
Before the machine is discarded, the batteries must be removed and properly disposed of.
Make sure all warning and caution labelsare legible and properly attached to the machine.
During operation, attention shall be paid to other persons, especially children.
Before use all covers and doors shall be put in the positions specified in the instructions.
When leaving unattended, secure against unintentional movement.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, switch off or lock the main power switch to prevent unauthorized use.
Only chemicals recommended by the manufacturer shall be used.
This appliance has been designedfor use with the brushes specified by the manufacturer. The fitting
of other brushes may affect its safety.
Do not use on surfaces having a gradient exceeding 2%.
SAVE THESE INSTRUCTIONS
!
WARNING:

HAZARD INTENSITY LEVEL
SC17 98861 05/15/01
2-2
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and
FOR SAFETY. The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or
property damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist.
Locate all safety devices on the machine. Please take the necessary steps to train the machine
operating personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on
the machine. Use Windsor approved replacement parts.
Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away.
Keep solution tank in raised position when charging. Keep sparks and flames away from the
batteries. Do not smoke around batteries.
Disconnect batteries before working on machine. Only qualified personnel should work inside
machine. Always wear eye protection and protective clothing when working on or near
batteries. Avoid skin contact with the acid contained in the batteries.
Never allow metal to lie across battery tops.
!WARNING
!CAUTION
!WARNING
!WARNING
!WARNING

SAFETY LABEL LOCATION
SC17 98861 05/15/01 2-3
NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels
become illegible, promptly replace them.
SAFETY DECAL 81505
BATTERY CAUTION 80885

TECHNICAL SPECIFICATIONS
SC17 98861 05/15/01
3-1
ITEM DIMENSION/CAPACITY
Rated Voltage 24 VDC
Rated Amperage 30 Amps
Batteries 2 x 12 Volt 105-130 AH
Scrub Brush Motor 0.75hp (0.56 kw)
Vacuum Motor 24 VDC 2 stage by pass
Mass (GVW) 319 lbs (144.7 kg)
Weight empty without batteries 142 lbs (64.4 kg)
Solution Control Gravity feed, fully variable
Solution tank capacity 8 Gal (30.3 l)
Recovery tank capacity 10 Gal (37.9 l)
Scrub brush diameter 17 in (43 cm)
Scrub brush pressure 33 lbs (15 kg)
Scrub brush speed 200 RPM
Wheels 2 x 6 in (15 cm) Thermoplastic
non marking
Casters 3.0 x 1.0 (7.5 cm)
Foundation Pressure 286 lbs/in² (1992.6 Kpa)
Coverage 6700 ft²/hr
Frame Construction Steel with epoxy powdercoat
finish
Minimum aisle u-turn width 44 in (111 cm)
Maximum rated climb and descent angle with empty tanks 2%
Maximum rated climb and descent angle with full tanks 2%

TECHNICAL SPECIFICATIONS
SC17 98861 05/15/01 3-2
ITEM MEASURE
Height 35 in (88.9 cm)
Length 42 in (106.7 cm)
Width without squeegee 20 in (50.8 cm)
Width of squeegee 31 in (78.7 cm)
Width of scrub path 17 in (43 cm)
Length
Height
Width
SPECIAL NOTES:
The A-weighted sound pressure level emitted by
the appliance was measured to be 74.1 dBA. This
is a space-averaged, broad-band measurement
determined according to IEC 704-I. This appliance
contains no possible source of impact noise.
The overall root-mean-squared
acceleration at the operator’s arms was
measured to be less than 1.0 m/s². This is
a tri-axial, broadband measurement made
during normal operation on a composite tile
floor.

HOW THE MACHINE WORKS
SC17 98861 05/15/01
3-3
The Saber Compact is a battery powered, hard
floor scrubber intended for commercial use.
The appliance applies a cleaning solution onto
a hard floor, scrubs the floor with a brush, and
then vacuums the soiled water back into the
recovery tank.
The machine's primary systems are the solution
system, scrub system and recovery system.
The function of the solution system is to store
cleaning solution and deliver it to the scrub
system. The solution system consists of the
solution tank, strainer, and valve. The solution
tank stores cleaning solution (water and
detergent) until it is delivered to the scrub
system. The strainer protects the valve from
debris. The machine has a ball-type valve
which controls the amount of cleaning solution
delivered to the scrub system. The solenoid
type valve controls the delivery of cleaning
solution to the scrub system. The valve
automatically prevents solution flow unless the
scrub brushes are turned on. The solution
control lever controls the amount of cleaning
solution delivered to the scrub system.
The function of the scrub system is to scrub the
floor. The scrub system consists of a rotary
type disk scrub brush, motor, and lift linkage.
The brush scrubs the floor and the motor drives
the brush. The brush lift lever raises and lowers
motor and brush.
The function of the recovery system is to
vacuum the soiled water back into the recovery
tank. The recovery system consists of the
squeegee, vacuum motor, screen, and recovery
tank. The squeegee wipes the dirty solution off
the floor as the machine moves forward. The
vacuum motor provides suction to draw the dirty
solution off the floor and into the recovery tank.
The screen protects the vacuum fan from
debris. The recovery tank stores the dirty
solution. The float ball in the tank activates
when the recovery tank is full.

COMPONENTS
SC17 98861 05/15/01 3-4
1. Control Panel
2. Control Handle
3. Recovery Tank
4. Recovery Tank Drain Hose
5. Recovery Tank Dome
6. Scrub Brush/Pad
7. Solution Tank
8. Solution Tank Cover
9. Solution Tank Drain Hose
10. Solution Strainer
11. Solution Tank Support Lanyard
12. Squeegee
13. Vacuum Motor
14. Solenoid Valve
8
13
11
614
7
4
12
5
1
2
10
9
3

CONTROLS
SC17 98861 05/15/01
3-5
1. Solution Control Lever
2. Brush Switch
3. Brush Lift Pedal
4. Vacuum Switch
5. Squeegee Lift Lever
6. Battery Charge Level Indicator
7. Hour Meter (Optional)
8. Circuit Breakers
9. Brush Reverse Switch
6 4 2
1
7
5
9
8
3

CONTROLS
SC17 98861 05/15/01 3-6
1. SOLUTION CONTROL LEVER
Controls solution flow to scrub deck.
To increase flow push the knob forward to
the desired flow.
To decrease flow pull the knob back.
2. BRUSH SWITCH
Controls the scrub brush motor.
To turn scrub brush on, press the top of the
switch.
To turn scrub brush off, press the bottom of
the switch.
3. BRUSH LIFT PEDAL
Raises and lowers the brush.
To lower the brush, push down on pedal
and move to the left.
To raise the brush, lift the lever from its
lowered position.
4. VACUUM SWITCH
Controls the vacuum motor.
To start vacuum motor, press the top of the
switch.
To stop vacuum motor, press the bottom of
the switch.
5. SQUEEGEE LIFT LEVER
Raises and lowers the squeegee.
To lower the squeegee, lift and pull the lever
to the right and then lower.
To raise the squeegee, lift the lever and
push it to the left.
6. BATTERY CHARGE LEVEL INDICATOR
Indicates the charge level of the batteries.
The meter display is divided into 10 vertical
bars. Bars illuminated on the top indicate
full charge. Bars flashing near the bottom
indicate the batteries should be recharged.
Further operation of the machine could
damage the machine or the batteries.
When the machine is left overnight with less
than a full charge, the display may initially
indicate a full charge. It will also indicate a
full charge if the batteries are disconnected,
then reconnected. After a few minutes of
operation the meter will give the correct
charge level.
7. HOUR METER (OPTIONAL)
Records the number of hours the machine’s
brush has been in operation. This
information is useful in determining when to
service the machine.
8. CIRCUIT BREAKERS
Circuit breakers interrupt the flow of power
in the event of an electrical overload. When
a circuit breaker is tripped, reset it by
pressing the exposed button. If a circuit
breaker continues to trip, the cause of the
electrical overload should be found and
corrected.
25 Amp. Protects the scrub
brush motor.
25 Amp. Protects the vacuum
motor.
9. BRUSH REVERSE SWITCH
Reverses the scrub brush motor.
To activate, press the top of the switch.

MACHINE OPERATION
SC17 98861 05/15/01
3-7
PRE-RUN MACHINE INSPECTION
Do a pre-run inspection to find possible
problems that could cause poor performance or
lost time from breakdown. Follow the same
procedure each time to avoid missing steps.
NOTE: See maintenance section for pre-run
machine inspection checklist items.
FILLING SOLUTION TANK
FOR SAFETY: Before leaving or servicing
machine; stop on level surface, turn off
machine.
1. Turn the machine off.
2. Remove solution tank cover.
3. Fill the solution tank with clean water,
leaving enough room for the required
amount of cleaning solution. The solution
tank capacity is 8 gallons (30.3 liters). The
water must not be hotter than 140°F (60°C)
to prevent damage to the tank.
4. Measure the chemical into the solution
tank. Liquid chemicals should be added to
the solution tank after filling with water. Dry
chemicals should be thoroughly mixed
before being added into the solution tank.
Commercially available, high alkaline floor
cleaners are suitable for use in the solution
system.
NOTE: Read the chemical manufacturers
recommended proportion instructions.
5. Replace solution tank cover.
Flammable materials can cause an
explosion or fire. Do not use flammable
materials in the tanks.
NORMAL SCRUBBING
Plan the scrubbing pattern in advance. The
longest track is around the perimeter of the
area to be cleaned. For efficient operation, the
runs should be the longest possible without
turning, stopping, or raising and lowering scrub
brush/squeegee.
NOTE: In order to achieve the best possible
results, the area that is to be cleaned should be
swept before scrubbing. Large debris, strings &
wire must be removed to prevent being caught
in the brush or squeegee.
!WARNING

MACHINE OPERATION
SC17 98861 05/15/01 3-8
TO BEGIN SCRUBBING
When operating the machine around people,
pay close attention for unexpected
movement. Use extra caution around
children.
Flammable liquids and/or reactive metals
can cause explosions or fire! Do not pick
up.
1. Lower the squeegee.
2. Turn the vacuum on.
3. Lower the scrub brush to the floor.
4. Turn the scrub brush on.
5. Push machine forward to begin scrubbing.
NOTE: Shut machine off immediately if water
or foam is expelled from the machine.
6. Adjust the solution flow as necessary.
TO STOP SCRUBBING
1. Turn the scrub brush off.
2. Raise the scrub brush.
3. Raise the squeegee.
4. Turn the vacuum off.
DOUBLE SCRUB
For floors, which are heavily soiled or have
thick accumulations of floor finish the machine
may not clean sufficiently with one pass. In
these cases it will be necessary to double
scrub. To double scrub, make the first pass
over the surface being cleaned with the
squeegee up, vacuum off, the solution on, and
brush down and on. This allows the solution to
stay in contact with the soil while loosening the
surface accumulation with the brush. Allow time
for the first application to stay in contact with
the floor. The length of time between the first
and second pass depends on the amount of
accumulation and the type of chemical being
used. A second scrubbing with the squeegee
down, vacuum on and again with solution and
brush on will further
loosen the soil. The additional application of
solution will further assist the difficult cleaning
job.
FOR SAFETY: When using machine, go
slow on inclines and slippery services.
EMPTYING AND CLEANING TANKS
1. Park the machine next to a drain. Drain
hoses are on the rear of the machine.
2. Turn the machine off.
SOLUTION TANK
1. Pull the small drain hose from the retainer.
Lower the hose in the direction of the drain.
2. Remove the solution tank cover.
3. Flush the solution tank out with clean water
and run several gallons of clean water
through systems. Do not use water hotter
than 140°F (60°C) to clean the tank,
damage may occur.
NOTE: Never allow solution to remain in tank.
Damage to tank, seals and valves could occur.
4. Replace drain hose to retainer.
RECOVERY TANK
1. Unhook the large drain hose from the
retainer. Lower the hose in the direction of
the drain. Do not stand in front of the end of
the hose. Recovered solution will come out
with force. Slowly remove the plug from the
drain hose.
2. Flush the recovery tank out with clean
water. Do not use water hotter than 140°F
(60°C) to clean the tank, damage may
occur.
3. Clean off the float and check for free
movement of the float ball.
4. Replace the drain plug and secure the drain
hose in the retainer.
!
WARNING
!
CAUTION

MAINTENANCE
SC17 98861 05/15/01
4-1
BATTERIES
The batteries provide the power to operate the
machine. The batteries require regular
maintenance to keep them operating at peak
efficiency.
The machine batteries will hold their charge for
long periods of time, but they can only be
charged a certain number of times. To get the
greatest life from the batteries, charge them
when their charge level reaches 25% of a full
charge. Use a hydrometer to check the charge
level.
Do not allow the batteries to remain in a
discharged condition for any length of time.
Never expose a discharged battery to
temperatures below freezing. Discharged
batteries will freeze causing cracked cases. Do
not operate the machine if the batteries are in
poor condition or if they have a charge level
below 25% (specific gravity below 1.155).
Keep all metallic objects off the top of the
batteries, as they may cause a short circuit.
Replace worn or damaged cables and
terminals.
Check the electrolyte level in each battery cell
before and after charging the batteries. Never
add acid to the batteries, use distilled water.
Do not allow water level to fall below the battery
plates. Portions of plates exposed to air will be
destroyed. Do not overfill. Keep plugs firmly in
place at all times.
When servicing machine, avoid contact with
battery acid.
Batteries emit hydrogen gas. Explosion or
fire can result. Keep sparks and open flame
away. Keep covers open when charging.
Wear eye protection and protective clothing
when working with batteries.
Charge batteries in a well ventilated area.
BATTERY MAINTENANCE
1. When cleaning the batteries, use a solution
of baking soda and water. Do not allow the
cleaning fluid to enter the battery cells,
electrolyte will be neutralized.
2. Maintain the proper electrolyte level in each
battery cell. If a cell should accidentally
overflow, clean immediately.
3. Wipe off the top of the batteries at least
once a week.
4. Test battery condition with a hydrometer at
least once a week.
5. Ensure that all connections are tight and all
corrosion removed.
6. Every 4 to 6 months remove the batteries
from the machine and clean the battery
cases and battery compartment.
!
CAUTION
!
WARNING
!
WARNING
!
WARNING

MAINTENANCE
SC17 98861 05/15/01 4-2
CHECKING BATTERY SPECIFIC GRAVITY
Use a hydrometer to check the battery specific
gravity.
CHECKING GRAVITY
A. Hydrometer
B. Battery
NOTE: Do not take readings immediately after
adding distilled water, if the water and acid are
not thoroughly mixed, the reading may not be
accurate.
Check the hydrometer readings against this
chart.
SPECIFIC
GRAVITY @ 80°F
(27°C)
BATTERY
CONDITION
1.265 100% CHARGED
1.225 75% CHARGED
1.190 50% CHARGED
1.155 25% CHARGED
1.120 DISCHARGED
NOTE: If the readings are taken when the
battery electrolyte is any temperature other than
80°F (27°C), the reading must be temperature
corrected.
To find the corrected specific gravity reading
when the temperature of the battery electrolyte
is other than 80°F (27°): Add (+) to the specific
gravity reading 0.004 (4 points), for each 10°F
(6°C) above 80° (27°C).
Subtract (-) from the specific reading 0.004 (4
points), for each 10°F (6°C) below 80°F (27°C).
Battery Check

MAINTENANCE
SC17 98861 05/15/01
4-3
TO CHARGE THE BATTERIES
When servicing machine, avoid contact with
battery acid.
Batteries emit hydrogen gas. Explosion or fire
can result. Keep sparks and open flame away.
Keep covers open when charging.
Wear eye protection and protective clothing
when working with batteries.
Charge batteries in a well ventilated area. Leave
the solution tank open.
Use a 24 volt, 12 amp maximum output, DC charger
which will automatically shut off when the batteries
are fully charged to charge the two battery pack.
1. Stop the machine in a clean, well ventilated area
next to the charger.
2. Turn the machine off.
FOR SAFETY: Before leaving or servicing
machine; stop on level surface, turn off machine.
3. Drain recovery tank and raise the recovery tank.
Batteries emit hydrogen gas. Explosion or fire
can result. Keep sparks and open flame away.
Keep covers open when charging.
4. Check the electrolyte level in each battery cell.
Before charging, add just enough distilled water
to cover the plates. After charging is complete,
add just enough distilled water to bring up the
level to the indicator ring. If the water level is
too high before charging, normal expansion rate
of the electrolyte may cause an overflow.
Resulting in a loss of battery acid balance and
damage the machine.
5. Replace the battery caps, and leave them in
place while charging.
6. Unplug the battery connector from the machine.
FOR SAFETY: When charging, connect the
charger to the batteries before connecting the
charger to the AC wall outlet. Never connect the
charger to the AC wall outlet first. Hazardous
sparks may result.
7. Plug the charger connector into the battery
connector. Connect the charger AC plug to a
wall outlet. The charger gauge should indicate
that the batteries are charging.
8. When the batteries are fully charged, disconnect
the charger from the AC wall outlet, then
disconnect the charger from the batteries.
9. Connect the batteries to the machine connector.
10. Check the electrolyte level. It should be up to
the indicator ring. If necessary, add distilled
water.
11. Lower the recovery tank.
CHANGING BATTERIES
Stop the machine in a clean area next to the
charger. Turn off machine.
FOR SAFETY: Before leaving or servicing the
machine; stop on level surface, turn off machine.
1. Drain recovery tank and raise the recovery tank.
2. Disconnect battery pack from machine.
3. Disconnect squeegee lift cable and vacuum
hose.
4. Prepare a suitable site to place the batteries.
5. Pull battery tray with batteries out of rear of
machine.
Batteries are a potential environmental hazard.
Consult your battery supplier for safe disposal
methods.
! WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
- blk + red
- blk+ red
!
CAUTION

MAINTENANCE
SC17 98861 05/15/01 4-4
SCRUB BRUSHES
NOTE: All original equipment brushes are
equipped with “Perform Alert”. This feature
will tell the operator when it is time to replace
the scrub brush. “Perform Alert” brushes
have pre-trimmed bright yellow tufts to indicate
the length of a worn out brush. When the tufts
in the scrub brush wear to a length equal to the
yellow tufts, the scrub brush should be
replaced.
There are three different types of brushes
available to cover applications from cleaning
heavily soiled floors to polishing. A pad driver
is also available to take advantage of the many
cleaning pads on the market and further add to
the flexibility of the Saber Compact. Please
refer to the following to assist in selecting the
proper brush or pad for the work at hand.
UNCOATED FLOORS
Mild Grit is a less aggressive silicone carbide
grit suitable for cleaning medium soil conditions.
Advantages are faster ground speed than nylon
bristles on light solid applications.
Polypropylene is a general-purpose scrub
brush with stiff bristles. Polypropylene works
well for maintaining concrete, wood and tile
floors.
FINISHED FLOORS
Nylon bristles are used in a variety of
applications on coated or uncoated surfaces.
White Pads (Polishing) are used for dry
polishing to achieve a high-gloss appearance,
or surface washing on highly polished or
burnished floors.
Red Pads (Buffing) are used for light-duty
scrubbing. When used with a mild detergent
they will provide surface cleaning without
removing the finish.
Blue Pads (Scrubbing) are used for heavy-duty
scrubbing and light stripping. The blue pads
remove less finish than brown stripping pads,
yet will remove black marks, stains and dirt.
Brown Pads (Stripping) are used for easy and
complete removal of old floor waxes/finishes.
They will quickly remove ground in dirt, black
heel marks, and spills. When used with the
proper stripper, this pad leaves the floor clean
and ready for finishing.
The scrub brush should be checked before
each days work for wire, string, wear and
damage. The scrub brush should be replaced if
brush bristles are missing or if yellow Perform
Alert indicates minimum brush length.

MAINTENANCE
SC17 98861 05/15/01
4-5
REPLACING OR REMOVING SCRUB
BRUSHES
1. Turn the machine off.
FOR SAFETY: Before leaving or servicing
the machine; stop on level surface, turn OFF
machine.
2. Raise the scrub deck up by pushing down
on the pedal.
3. Locate the brush reverse switch on the rear
of the panel. Press to activate the motor
then release to disconnect brush driver.
4. Tilt and pull machine back to expose brush
driver.
INSTALLING SCRUB BRUSHES
1. Turn the machine off.
FOR SAFETY: Before leaving or servicing
the machine; stop on level surface, turn OFF
machine.
2. Tilt and push machine over brush driver.
The brush centering bracket will position the
brush driver.
3. Lower the scrub deck by pushing the pedal
down and to the left.
4. Locate the brush switch and turn on.
SQUEEGEE BLADES
The front squeegee blade allows solution to
pass through channels in the blade into the
squeegee assembly while maintaining vacuum
to provide lift.
The rear blade wipes the floor to a near dry
condition. It is important the rear blade be in
good condition to properly do its job.
Check both the front and rear squeegee blades
for damage and wear each day in the pre-run
check. Change the front blade if it is torn or has
an uneven edge. Change the rear blade if it is
less than 1/2 the original thickness.
TO REMOVE SQUEEGEE ASSEMBLY
1. With the squeegee in the up position, turn
the machine power off.
2. Loosen both squeegee knobs and pull
squeegee assembly rearward from the
lifting carrier.
3. Inspect or repair as necessary and reinstall.
TO REPLACE SQUEEGEE BLADES
1. With the squeegee in the up position, turn
the machine power off.
FOR SAFETY: Before leaving or servicing
machine; stop on level surface, turn off
machine.
2. Remove the squeegee assembly from the
machine. Remove all screws and remove
blade retainer strap and remove squeegee
blade.
3. Replace squeegee blades as required.
4. Install squeegee blade.
5. Install squeegee retainer strap.
6. Install all screws starting from center and
working to ends.
