Sabre PS02074 User manual

PARTS LIST
LISTE DE PIÈCES
ONDERDELENLIJST
TEILELISTE
ELENCO DEI PEZZI
LISTA DE PIEZAS
GBGB
GBGB
GB
FF
FF
F
NLNL
NLNL
NL
II
II
I
EE
EE
E
DD
DD
D
P/N PS02074
e
P25
UT 01707 C, DUT 01707 C, D
UT 01707 C, DUT 01707 C, D
UT 01707 C, D

2
1•A 02097B ENGINE HOUSING & DECAL KIT 1
2 02264 GRIP-Starter 1
3 82541 SCREW-ThreadForm.(#10X1/2") 1
4 98791 BRACKET-Retaining 1
5 9789902 ROPE-Starter 1
6 98770A PULLEY-Starter 1
7 A 98773A SPRING & CONTAINER 1
No. Part No. Description Qty.
3 30-40 ............. 3.4-4.5
Torque Specs
Item In/Lbs Nm Required
No Loctite
6
3
4
5
7
2
STARTER
1
© 1999, JDCP, Inc.
04/12/99

3
ENGINE INTERNAL
04/12/99
9
3
2
6
5
4
1
1 •UP 00739 SHORT BLOCK 1
2 •UP 00016 PISTON & ROD 1
3 PS 01359 RING-Piston 1
4 •UP 07145 CYLINDER KIT 1
5 04388 B GASKET-Cylinder 1
6 06900 A GASKET-Heat Dam 1
7 08661 GASKET-Crankcase Cover 1
8 88084 1 SCREW, SEMS (12-24 x .750) 3
9 69250 KEY-Woodruff 1
10 88081 1 SCREW, SEMS (10-24 x .910) 4
11 • A 00858 CRANKCASE COVER 1
7 08661 GASKET-Crankcase Cover 1
12 82541 SCREW-Plastite (#10 X 1/2") 2
13 98792 BUMPER, Rubber 3
No.No.
No.No.
No. PP
PP
Part No.art No.
art No.art No.
art No. Description QtyDescription Qty
Description QtyDescription Qty
Description Qty Torque Specs
Item In/Lbs Nm Required
No Loctite
8 55-65 ............. 6.2-7.3
10 25-30 ............. 2.8-3.4
12 30-40 ............. 3.4-4.5
8
7
11
12
10
13

4
IGNITION
Torque Specs
Item In/Lbs Nm Required
No Loctite
1•A 04446 IGNITION KIT 1
2 A 33055 TERMINAL-HiTension 1
3 79252 SPARK PLUG (RDJ-7Y) 1
4 82540 SCREW-Thread Form.(8-32X1") 2
5 A 04158 S ROTOR & STARTER PAWL KIT 1
6 PS 84065 WASHER-Flat 1
7 02041 EXTENSION-Shaft 1
2
4
765
3 120-180 ......... 13.6-20.3
4 30-40 ............. 3.4-4.5
7 100-150 ......... 11.3-16.9 ...........Red 262
3
1
No. Part No. Description Qty.
4/12/99

5
1•A 07316 MUFFLER-Complete 1
2 88060 SCREW-Sems Hex Hd. (10-24 X 2 1/2") 2
3 06613 GASKET-Muffler 1
4•A 04707 A AIR FILTER BOX 1
5 00331 DECAL-Choke 1
6 98760 FILTER-Air 1
7 81208 NUT-LockingHex(10-24) 2
2 40-50 ............. 4.5-5.6
Torque Specs
Item In/Lbs Nm Required
No Loctite
MUFFLER & AIR FILTER
No. Part No. Description Qty.
04/12/99
35
6
7
1
4
2

6
3 40-50 ............. 4.5-5.6 ...............Red262
5 30-40 ............. 3.4-4.5
Torque Specs
Item In/Lbs Nm Required
No Loctite
54
2
3
CARBURETOR & FUEL TANK
1
04/12/99
7
10
11
13 9
12
8
6
1•A 04331A CARBURETOR(Walbro) 1
2 98766A GASKET-Carburetor 1
3 093221 SCREW, SEMS (10-24 x 1.100) 2
4 98768A HEATDAM 1
5 04474 SCREW- Hex Hd. (10-24 X 2 1/2") 2
6 98765B GASKET-HeatDam 1
7•A 04447D FUELTANK 1
8 49422 FILTER-Fuel 1
9 0143932 TUBING-Rubber 2
10 A 00982B FUELCAP 1
11 98792 BUMPER-Rubber 3
12 9477232 TUBING-Rubber 1
13 98268 CLAMP-Wire 1
7•UP 00136 FUELTANK ASSY. 1
14 49422 FILTER-Fuel 1
15 0143918 TUBING-Rubber 1
16 0143910 TUBING-Rubber 1
17 9477213 TUBING-Rubber 1
18 UP 00106 FUELCAP 1
19 98792 BUMPER-Rubber 3
20 02067 FITTING-Inline 1
21 98268 CLAMP-Wire 1
No. Part No. Description Qty.
14 16
15
19
18
20
17
21
7
Beginning with Serial Number #HA1040001

7
11 HandTight
16 15-20 ............. 1.7-2.3
23 30-40 ............. 3.4-4.5
25 30-35 ............. 3.4-4.0 ...............Red 262
Torque Specs
Item In/Lbs Nm Required
No Loctite
1 02713 STRAINER (1") 1
2 49956 CLAMP 2
3 48461-01 HOSE (1") 1
4 A 02919 BARBEDCOUPLING 2
5 02728 ADAPTOR-GardenHose 1
6 02988 GASKET 1
7 02924 CAP w/O-RING 1
8•A 03055 PUMP BODY & DECALS 1
9 02715 DECAL-Operation 1
10 02714 DECAL-Warning 1
11 02926 IMPELLER 1
12 02931 SHIM-(.030")(Impeller) A/R
13 02932 SHIM-(.015")(Impeller) A/R
14 02933 SHIM-(.030")(Seal) A/R
15 02927 SEAL 1
16 82571 SCREW-Pan Hd. (10-24 X 1") 4
17 02732 ADAPTER(EnginetoPump) 1
18 02930 NUT (M5) 3
19 02928 O-RING 1
20 02925 CAP w/O-RING 1
PUMP
No. Part No. Description Qty.
04/12/99
11 1214
8
15
19
17
16
21
18
24
25
22
23
23
7
5
6
10
4
2
6
20
9
4
2
3
2
1
13
21 02730 HANDLE-EngineMtg. 1
22 02731-A BASE PLATE 1
23 82563 SCREW-ThreadForm.(10-14X3/4") 3
24 02929 WASHER-Flat(M5) 3
25 82549 SCREW-ThreadForm.(10-24X1") 4
No. Part No. Description Qty.

04/12/99
U.S.A.: 704-588-3200 FAX: [phone]
EUROPE: 31-2526-87342 FAX: [phone]
AUSTRALIA: 61-03-878-6155 FAX: [phone]
FRANCE: 33 (1) 34.21.89.70 FAX: [phone]
P.O. BOX 7047
CHARLOTTE, N.C. 28241
U.S.A.
Pump Accessories
Test Equipment/Tools
Part # Description
48461 01 Spiral PVC Suction/discharge hose
1" x 12.5' (No couplings)
A48467 1" x 25' (Nylon couplings)
02713 1" Strainer
48572 1" Puddle Sucker
48387 1" Male Coupling NPT x 1"
Male Barbed Shank (Nylon)
48814 1" Male Coupling NPT x 1"
Male Barbed Shank (Brass)
Part # Description
18043 Repair Tag & Wire
18774 Visual Fuel Mix Tester
JA 31316 4 Spark Tester
94194 Compression Tester
94197 Carb/Crankcase Pressure Tester
18416 Digital Tachometer
24982 03 Torx Bit T-25
18566 01 Torx Bit T-27
PS 24306 Module Gap Shim
