Sac Turbo-max 6100 series Programming manual

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

MON600191 REV V 4/13/22

OPERATORS/PARTS MANUAL

TURBO-MAX

6100 SERIES TRAILER

Page # 2

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

REV DATE BILL OF MATERIALS DESCRIPTION

J2/21/14 MON600191 UPDATE MANUAL WITH NEW LOGO

GRAPHICS.

K 7/11/14 MON900703 UPDATED BOM & CHECKED ALL GRAPHICS &

BOM’S

L 8/11/14 MON900703

ADDED MON900980 UPDATED BOM AND GRAPHICS

M 12/30/14 MON900709 DELETED KEY38X2

N 12/11/15 MON901332, MON901333

REVIEWED ALL TEXT AND

ASSEMBLY PRINTS

ADDED UPDATED REEL AND PADDLE

UPDATED ALL BOM’S AND GRAPHICS

O 2/24/17 REVIEWED ALL ASSEMBLY PRINTS UPDATED ALL ASSEMBLY PRINTS AS NEEDED.

Q 2/28/20 DECAL LOCATION ADD DEC785 QTY 1, DEC786 QTY1, DEC787 QTY 1

R 8/28/20 MON900703 CHANGE BOLTS , WASHERS AND NUTS TO SHOULDER

BOLTS AND NUTS ON IDLER ARMS

S 11/19/20 MON900703 REPLACE TURNBUCKLE WITH ADJ TENSION ROD

T 12/21/20 DECAL LOCATION ADD DEC795

U 3/28/22 TRAILER SUBFRAME ASSEMBLY REPLACE LH AND RH BOGIE WITH SYMETRICAL BOGIE

V 4/13/22 BASE ASSEMBLY MON900703 CHANGE IDLER TENSIONERS TO ADJ THRD’D ROD

Page # 3

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

Never overload wagon. Follow rating of gear or rating of tires, whichever is less.

Ensure that anybody present is clear before applying power to any machinery used in conjunc-

tion with wagon box or when moving box.

Never allow anyone in, near, or on mixing chamber during mixing, transporting, or unloading

of feed.

Do not exceed 20 miles per hour when towing wagon.

GENERAL INFORMATION

1. Unless otherwise specied, high-strength (grade5) (3 radi-

al-line head markings) hex head bolts are used throughout

assembly of this piece of equipment.

2. Whenever terms“LEFT”and“RIGHT”areusedinthismanual

it means from a position behind the wagon box and facing

forward.

3. When placing a parts order, refer to this manual for

proper part numbers and place order by PART NO. and

DESCRIPTION.

4. Read assembly instructions carefully. Study

assemblyproceduresandallillustrationsbeforeyoubegin

assembly.Notewhichpartsareused ineachstep.Thisunit

must be assembled in proper sequence or complications

will result.

WARNING: TO AVOID PERSONAL INJURY OR DEATH, OBSERVE FOLLOWING

INSTRUCTIONS:

Thank you for purchasing aTurbo-Max 6100 series reel mixer. We feel you have made a wise choice and hope you are

completely satised with your new piece of equipment. Your new 6100 series Turbo-Max is a durable, ecient, and

easy to use unit. Proper care and use will result in many years of service.

Table of Contents

General Information.....................................................................................................................................................................................................3

Model and Serial Number Identication..............................................................................................................................................................4

Safety, Signal Words.....................................................................................................................................................................................................6

Equipment Safety Guidelines...................................................................................................................................................................................7

Lighting and Marking..................................................................................................................................................................................................7

Safety Sign Care.............................................................................................................................................................................................................7

Tire Safety ........................................................................................................................................................................................................................8

Before Operation...........................................................................................................................................................................................................8

During Operation.......................................................................................................................................................................................................9-10

Following Operation...................................................................................................................................................................................................10

Highway and Transport Operations.................................................................................................................................................................. 10-11

Performing Maintenance ..........................................................................................................................................................................................11

Bolt Torque .....................................................................................................................................................................................................................12

PTO Horsepower Requirements .............................................................................................................................................................................13

Drawbar Attaching System.......................................................................................................................................................................................13

Hydraulic System..........................................................................................................................................................................................................13

Mixer Setup....................................................................................................................................................................................................................13

Mixer Operation........................................................................................................................................................................................................ 14-15

Maintenance-Inspection and Adjustment..........................................................................................................................................................16

Electronic Scales...........................................................................................................................................................................................................16

Lubrication .....................................................................................................................................................................................................................17

Decal Location ..............................................................................................................................................................................................................18

Base Assembly........................................................................................................................................................................................................... 20-25

Reel Assemblies........................................................................................................................................................................................................ 26-30

Paddle Assemblies.................................................................................................................................................................................................... 31-32

Bearing Assembly ........................................................................................................................................................................................................33

Chain Idler Assembly .................................................................................................................................................................................................34

Auger Assemblies .................................................................................................................................................................................................... 35-38

Trailer Base Assembly ............................................................................................................................................................................................. 39-40

Subframe Assemblies............................................................................................................................................................................................. 41-44

Bogie Assembly ........................................................................................................................................................................................................... 45

Hub & Spindle Assemblies .......................................................................................................................................................................................46

Final Assembly ..............................................................................................................................................................................................................47

Slide Tray Breakdown..................................................................................................................................................................................................48

Power Discharge Breakdown............................................................................................................................................................................... 49-50

Hydraulics Breakdown ........................................................................................................................................................................................... 51-55

Control Box Breakdown ............................................................................................................................................................................................56

Driveline Assemblies .............................................................................................................................................................................................. 57-58

Lighting Breakdown....................................................................................................................................................................................................59

Loadcell Retainer Kit ..................................................................................................................................................................................................62

Trailer Specications ..................................................................................................................................................................................................63

Warranty...................................................................................................................................................................................................................... 64-65

Page # 4

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

Your model and serial numbers can be located on the front left hand side of the mixer. Please copy this information and write them

down inside of this manual. This will allow easy reference if the ordering of parts should become necessary.

MODEL AND SERIAL NUMBER IDENTIFICATION

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

_______________________________________________________________________________________________________

NOTES

Page # 5

Page # 6

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS

MANUAL IS USED TO CALL YOUR ATTENTION TO INSTRUCTIONS INVOLVING

YOUR PERSONAL SAFETY AND SAFETY OF OTHERS. FAILURE TO FOLLOW THESE

INSTRUCTIONS CAN RESULT IN INJURY OR DEATH!

THIS SYMBOL MEANS

ATTENTION

BECOME ALERT

YOUR SAFETY IS INVOLVED!

SIGNAL WORDS

Note: use of following signal words DANGER, WARNING,

and CAUTION with safety messages. Appropriate signal

word for each has been selected using following guidelines:

DANGER:

Indicates an imminently hazardous situation that, if not

avoided, will result in serious injury or death. This signal

word is to be limited to most extreme situations typically

for machine components which, for functional purposes,

cannot be guarded.

WARNING:

Indicates a potentially hazardous situation that, if not

avoided, could result in serious injury or death, and includes

hazards that are exposed when guards are removed. It may

also be used to alert against unsafe practices.

CAUTION:

Indicates a potentially hazardous situation that, if not

avoided, may result in minor or moderate injury. It may

also be used to alert against unsafe practices.

If you have questions not answered in this manual , require additional copies, or if your manual is damaged, please contact

your dealer or Sioux Automation Center Inc., 877 1st Ave NW, Sioux Center, IA 51250, ph: (712) 722-1488 or

Toll Free: 1-866-722-1488, Fax: (712) 722-1487 http://www.siouxautomation.com

SAFETY: YOU CAN LIVE WITH IT!

Page # 7

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

SAFETY...YOU CAN LIVE WITH IT

EQUIPMENT SAFETY GUIDELINES

Every year many accidents occur which could have been avoided by a few seconds of thought and a more careful

approach to handling equipment.You, the operator, can avoid many accidents by observing the following precautions

in this section. To avoid personal injury, study the following precautions and insist those working with you, and you

yourself, follow them.

In order to provide a better view, certain illustrations in this manual may show an assembly with a safety shield

removed. However, equipment should never be operated in this condition. Keep all shields in place. If shield removal

becomes necessary for repairs, replace shield prior to use.

Replace any CAUTION, WARNING, DANGER or instruction safety decal that is not readable or is missing. Location of

such decals is indicated in this manual. The part numbers for the decals are located in the lower right hand corner of

the decal, and listed in this manual on the following pages.

Do not attempt to operate this equipment under the inuence of alcohol or drugs.

Review safety instructions with all users annually.

Operator should be a responsible adult. DO NOT ALLOW PERSONSTO OPERATE OR ASSEMBLETHIS UNIT UNTILTHEY

HAVE READTHIS MANUAL AND HAVE DEVELOPED ATHOROUGH UNDERSTANDING OFTHE SAFETY PRECAUTIONS

AND PROPER OPERATIONAL PROCEDURES.

Do not paint over, remove, or deface any safety signs or warning decals on your equipment. Observe all safety signs

and practice the instructions on them.

Never exceed limits of a piece of machinery. If its ability to do a job, or to do so safely is in question DON’T TRY IT.

LIGHTING AND MARKING

It is the responsibility of customer to know lighting and marking requirements of the local highway authorities and to

install and maintain the equipment to provide compliance with the regulations. Add extra lights when transporting

at night or during periods of limited visibility. Lighting kits are available from your dealer or from manufacturer.

SAFETY SIGN CARE

• Keepsafetysignscleanandlegibleatalltimes.

• Replacesafetysignsthataremissingorhavebecomeillegible.

• Replacedpartsthatdisplayedsafetysignsshouldalsodisplaycurrentsafetysign.

• Safetysignsareavailablefromyourdistributor,dealerpartsdepartment,orthefactory.

How to install safety signs:

• Besurethatinstallationareaiscleananddry.

• Decideonexactpositionbeforeyouremovebackingpaper.

• Removesmallestportionofsplitbackingpaper.

• Aligndecaloverspeciedareaandcarefullypresssmallportionwithexposedstickybackinginplace.

• Slowlypeelbackremainingpaperandcarefullysmoothremainingportionofdecalintoplace.

• Smallairpocketscanbepiercedwithapinandsmoothedoutusingpieceofdecalbackingpaper.

SAFETY

Page # 8

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

TIRE SAFETY

• Failuretofollowproperprocedureswhenmountingatireonarimcanproduceanexplosionwhichmay 

result in a serious injury or death.

• Donotattempttomountatireunlessyouhaveproperequipmentandexperiencetodothejob.

• Inatingorservicingtirescanbedangerous.Wheneverpossible,trainedpersonnelshouldbecalledto 

service and/or mount tires.

• Alwaysorderandinstalltiresandwheelswithappropriatetypeandloadcapacitytomeetorexceed

anticipated weight to be placed on the equipment.

REMEMBER

Your best assurance against accidents is a careful and responsible operator. If there is any portion of this

manual or function you do not understand, contact your local authorized dealer or manufacturer.

BEFORE OPERATION:

• Carefullystudyandunderstandthismanual.

• Donotwearloose-ttingclothingwhichmaycatchinmovingparts.

• Alwayswearprotectiveclothingandsubstantialshoes.

• Itisrecommendedthatsuitablehearingandeyeprotectionbeworn.

• Operatormaycomeincontactwithcertainmaterialswhichmayrequirespecicsafetyequipment

relative to handling of such materials.

• Keepwheelandlugnutstightenedtospeciedtorque.

• Assurethatagriculturalimplmenttiresareinatedevenly.

• Giveunitavisualinspectionforanyloosebolts,wornpartsorcrackedwelds,andmakenecessary

repairs. Follow the maintenance safety instructions included in this manual.

• Besuretherearenotoolslyingonorinequipment.

• Donotuseunituntilyouaresurethatareaisclear,especiallyaroundchildrenandanimals.

• Don’thurrythelearningprocessortaketheunitforgranted.Easeintoitandbecomefamiliar

with your new equipment.

• Practiceoperationofyourequipmentanditsattachments.Completelyfamiliarizeyourselfandother

operators with its operation before using.

• UseatractorequippedwithRollOverProtectionSystem(ROPS)andfastenyourseatbeltpriorto

starting the engine.

• ManufacturerdoesnotrecommendusageofatractorwiththeROPSremoved.

• Makesurethatbrakesareevenlyadjusted.

• Movetractorwheelstowidestrecommendedsettingstoincreasestability.

• Donotallowanyonetostandbetweentongueorhitchandtowingvehiclewhenbackinguptoequipment.

• NEVERloadmixerwithoutrstattachingatractorofatleast2/3thegrosstrailerweight.

SAFETY

Page # 9

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

DURING OPERATION

• Beawareofbystanders,PARTICULARLYCHILDREN!Alwayslookaroundtomakesurethatitissafeto

start the engine or to move the unit. This is particularly important with higher noise levels and quiet cabs, as

you may not hear people shouting.

• NO PASSENGERS ALLOWED-Donotallowanyonetorideonorinsidethemixeratanytime!

• Keephandsandclothingclearofmovingparts.

• Donotclean,lubricate,oradjustyourequipmentwhileitismoving.

• Whenhaltingoperation,evenperiodically,setparkingbrakes,disengagePTO,shuto

engine, and remove ignition key.

• Beespeciallyobservantoftheoperatingareaandterrain.Watchforholes,rocks,orotherhiddenhazards.

Always inspect area prior to operation.

 -DONOToperatenearedgeofdrop-osorbanks.

- DO NOT operate on steep slopes as overturn may result.

- Operate up and down (not across) intermediate slopes. Avoid sudden starts and stops.

• Pickthemostlevelpossibleroutewhentransportingacrosselds.Avoidedgesofditches,gullies,andsteep

hillsides.

• Beextracarefulwhenworkingoninclines.

• Maneuvertractorortowingvehicleatsafespeeds.

• Avoidoverheadwiresorotherobstacles.Contactwithoverheadlinescouldcauseseriousinjuryordeath.

• Avoidloosegravel,rocks,andholes;theycanbedangerousforequipmentoperationormovement.

• Allowforunitlengthwhenmakingturns.

• Donotwalkorworkunderraisedcomponentsorattachmentsunlesssecurelypositionedandblocked.

• Keepallbystanders,pets,andlivestockclearofworkarea.

• Operatetowingvehiclefromoperatorsseatonly.

• Neverstandalongsideofunitwithenginerunningorattempttostartengineand/oroperatemachinewhile

standing alongside of unit.

• Neverleaverunningequipmentunattended.

• Asaprecaution,alwaysrecheckhardwareonequipmentfollowingevery100hoursofoperation.Correctall

problems. Follow maintenance safety procedures.

• Neverhandfeedmaterialsintomixerwhileitisrunning.Rotatingaugersinsidemixermaynotbevisiblefrom

the loading point, and may cut or grab hands, clothing, or material being loaded, causing severe injury.

Always stop tractor engine before hand loading materials.

• Donotallowoperationofthisunitbyinexperiencedorunqualiedpeople.Keepallunqualifedpeopleaway

from the mixer during operation. Operators of this unit must be alert and use good judgement at all

times. Operator should not climb on ladder or any part of the mixer when loading, mixing, or unloading material.

SAFETY

Page # 10

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

• Besuretheinsideofthemixerisclearofanyobstructionbeforeoperating.

• Usecautionwhenworkingaroundthedischargearea.Stayclearofpowerchute&slidetray.Theseare

controlled from the cab and could operate without warning, creating pinch points which could cause severe

injury or death. Always stop tractor engine and remove PTO driveline & hydraulic hoses before working

near the discharge area.

• Neverattempttoreleasejammedmaterialsorcleanmaterialsfromanyareaofthemixerordischarge

chute without stopping engine and removing driveline rst. Moving parts can be hidden by materials, and

stopped parts can start unexpectedly, causing severe injury. Always stop tractor engine and remove the PTO

driveline so that the mixer cannot be accidentaly turned on before attempting to remove jammed material or to clean.

• Neverputarmsorfeetinsideunit,powerchute,orneardischargedooropening,norclimbonorinthemixer

while it is running. NEVER allow anyone to position themselves over or near the top of the mixer while it is

running. Rotating augers and sprockets can grab clothing or create pinch points which can cause severe

injury or death to the operator or bystanders. Always stop tractor engine and remove the PTO driveline so

that the mixer cannot be accidentally turned on while inspecting, servicing, repairing, or cleaning.

• Followingoperation,orwhenunhitching,stoptractorortowingvehicle,setbrakes,shutoengineand

remove the ignition key.

• Storeunitinanareaawayfromhumanactivity.

• Donotparkequipmentwhereitwillbeexposedtolivestockforlongperiodsoftime.Damageand

livestock injury could result.

• Donotpermitchildrentoplayonoraroundstoredunit.

• Makesureallparkedmachinesareonahard,levelsurfaceandengageallsafetydevices.

• Wheelchocksmaybeneededtopreventunitfromrolling.

FOLLOWING OPERATION

HIGHWAY AND TRANSPORT OPERATIONS

• SAFETY CHAINS: If equipment is going to be transported on a public highway, always follow state and

local regulations regarding safety chains and auxiliary lighting. Be sure to check with local law enforcement

agencies for your own particular regulations. If required, safety chains should be obtained and installed

Only safety chains (not elastic or nylon/plastic tow straps) should be used to retain connection between

towing and towed machines in the event of separation of primary attaching system. Use a high strength,

appropriately sized hitch pin with a mechanical retainer and attach safety chains. Criss cross chains under

tongue and secure to draw bar cage, mounting loops, or bumper frame.

• Adoptsafedrivingpractices:

- Keep brake pedals latched together at all times. NEVER USE INDEPENDENT BRAKING WITH

MACHINE IN TOW, LOSS OF CONTROL AND/OR UPSET OF UNIT CAN RESULT.

- Always drive at a safe speed relative to local conditions, ensure that your speed is low enough for an

emergency stop. Keep speed to a minimum.

- Reduce speed prior to turns to avoid risk of overturning.

- Always keep tractor or towing vehicle in gear to provide engine braking when going downhill.

Do not coast.

- Do not drink and drive!

SAFETY

Page # 11

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

• Comply with state and local laws governing highway safety and movement of farm machinery on public roads.

• Use approved accessory lighting, ags and necessary warning devices to protect operators of other vehicles on

highway during transport. Various safety lights and devices are available from your dealer.

• Use of ashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws

should be checked for all highway lighting and marking requirements.

• When driving tractor and equipment on road under 20 m.p.h. (40 kph) at night or during day, use ashing amber

warning lights and a slow moving vehicle (SMV) identication emblem.

• Plan your route to avoid heavy trac.

• Be a safe and courteous driver. Always yield to oncoming trac in all situations, including narrow bridges, inter-

sections, etc.

• Be observant of bridge load ratings. Do not cross bridges rated lower than gross weight at which you are operating.

• Watch for obstructions overhead and side to side while transporting.

• Always operate equipment in a position to provide maximum visibility. Make allowances for increased length and

weight of equipment when making turns, stopping unit, etc.

SAFETY

HIGHWAY AND TRANSPORT OPERATIONS

• Good maintenance is your responsibility. Poor maintenance is an invitation for trouble.

• Make sure there is plenty of ventilation. Never operate engine in a closed building. Exhaust fumes may cause

asphyxiation.

• Beforeworkingonthismachine,stoptowingvehicle,setbrakes,shutoengineandremove ignition key.

• Always use safety support and block wheels. Never use a jack to support machine.

• Always use proper tools or equipment for job at hand.

• Use extreme caution when making adjustments.

• Follow torque chart in this manual when tightening bolts and nuts.

• Never use your hands to locate a hydraulic leak on attachments. Use a small piece of cardboard or wood. Hydraulic

uid escaping under pressure can penetrate skin.

• Openings in skin and minor cuts are susceptible to infection from hydraulic uid. Without immediate medical

treatment, serious infection and reactions can occur.

• Whendisconnectinghydrauliclines,shutohydraulicsupplyandrelieveallhydraulicpressure.

• Replace all shields and guards after servicing and before moving equipment.

• After servicing, be sure all tools, parts, and service equipment are removed.

• Do not allow grease or oil to build up on any step or platform.

• When replacing bolts, refer to owner’s manual.

• Refer to bolt torque chart for head identication marking.

• Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement parts

must be used to restore your equipment to original specications. Manufacturer will not claim responsibility for

use of unapproved parts or accessories and other damages as a result of their use.

• If equipment has been altered in any way from original design, manufacturer does not accept any liability for injury

or warranty.

• A re extinguisher and rst aid kit should be kept readily accessible while performing maintenance on this equipment.

PERFORMING MAINTENANCE

Page # 12

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

TORQUE DATA FOR STANDARD NUTS, BOLTS, AND CAP SCREWS.

Tighten all bolts to torques specied in chart unless otherwise noted. Check tightness of bolts periodically, using bolt

chart as guide. Replace hardware with same grade bolt.

NOTE: Unless otherwise specied, high-strength Grade 5 hex bolts are used throughout assembly of equipment.

Bolt Torque for Standard bolts *

GRADE 2 GRADE 5 GRADE 8

“A” lb-ft (N.m) lb-ft (N.m) lb-ft (N.m)

1/4” 6 (8) 9 (12) 12 (16)

5/16” 10 (13) 18 (25) 25 (35)

3/8” 20 (27) 30 (40) 45 (60)

7/16” 30 (40) 50 (70) 80 (110)

1/2” 45 (60) 75 (100) 115 (155)

9/16” 70 (95) 115 (155) 165 (220)

5/8” 95 (130) 150 (200) 225 (300)

3/4” 165 (225) 290 (390) 400 (540)

7/8” 170 (230) 420 (570) 650 (880)

1” 225 (300) 630 (850) 970 (1310)

Torque gures indicated are valid for non-greased

or non-oiled threads and heads unless otherwise

specfied. Therefore, do not grease or oil bolts

or capscrews unless otherwise specied in this

manual. When using locking

elements, increase torque values

by 5%.

* GRADE or CLASS value for bolts and capscrews

are identied by their head markings.

Torque Specications

CLASS 8.8 CLASS 9.8 CLASS 10.9

“A” lb-ft (N.m) lb-ft (N.m) lb-ft (N.m)

6 9 (13) 10 (14) 13 (17)

7 15 (21) 18 (24) 21 (29)

8 23 (31) 25 (34) 31 (42)

10 45 (61) 50 (68) 61 (83)

12 78 (106) 88 (118) 106 (144)

14 125 (169) 140 (189) 170 (230)

16 194 (263) 216 (293) 263 (357)

18 268 (363) -- -- 364 (493)

20 378 (513) -- -- 515 (689)

22 516 (699) -- -- 702 (952)

24 654 (886) -- -- 890 (1206)

Bolt Torque for Metric bolts *

GRADE-2 GRADE-5 GRADE-8

CLASS 8.8 CLASS 9.8 CLASS 10.9

8.8 10.9

9.8

BOLT TORQUE

Page # 13

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

PTO HORSEPOWER REQUIREMENTS

• PTO horsepower requirements are based on most normal dairy or beef rations. Horsepower requirements may vary

depending on the ration or material to be mixed.

• Refer to tractor weight requirements for these recommendations and transporting safety precautions for additional

tractor and towing requirements.

DRAWBAR ATTACHING SYSTEM

• Adjust tractor drawbar and/or the mixer clevis hitch so that the mixer is approximtely level. The top of the drawbar

should be 8”-12” below the tractor PTO shaft. Adjust the drawbar horizontally so that the hitch pin hole is 14”-16”

behind the tractor PTO and the drawbar is centered and locked into place.

• A hitch pin with a minumum of 1”diameter with a retainer pin is recommended.

HYDRAULIC SYSTEM

• Dual hydraulic outlets are required for operating the door and either the slide tray or the powerchute. If your tractor

has only a single set of ports, then either the 3 bank valve option or one of the 2 hose with manual selector valve

options should be ordered. On units with the power chute option, the chute hoses may be dicult to connect due

tothechuteweightontheliftcylinder.Liftweightochutecylindertoconnecthoses.Tractorhydraulicsystem

requirements are 6 GPM @ 1500 PSI when a slide tray is used, 15 GPM @2000 PSI when a 3-auger power chute is used.

MIXER SETUP

MIXER RUNIN

• To adjust the height of the power chute, change the length of the link chains on the sides of the chute. For best

performance,theunloadingheightshouldbesetatthelowestheightpossible.Thedischargetip-oonthepower

chute should be adjusted for correct magnet and discharge angle. Remove or loosen the upper bolts, pivot the tip

otothedesiredanglesandreinstallorretightenallbolts.

POWER CHUTE ADJUSTMENT OPTIONAL

To avoid personal injury: The hopper oor may be slippery and the auger can spin unexpectedly when stepped on.

Use caution when stepping or standing inside the unit, place a protective cover over the auger knives when work

inside the box is required.

MIXER SETUP

A. Before Starting:

  •Besureallshieldsareproperlyinplace.

  •Cycletheunloadingdoorandconveyorseveraltimestofullychargethehydraulicsystemwithoil.

  •Besurethattheaugersandreelcanturnfreely.

  •Checkfordebrisand/oranyotheritemsthatcouldblockoraectmachineoperation.

  •Besurethatdrainplugsareinstalledandthedoorisclosed.

B. Test run the mixer.

•Makesuremixerisempty,thenstartthemixer.

•RunforatleastveminutesatrecommendedRPM.

•Raiseandlowerthedoorandoperatetheconveyor/slidetrayseveraltimes.

•Disengagethemixerandturnothetractorengineandremovetheignitionkey.

  •Checkthemixerdrivecomponentstobesuretheyarenotabnormallyhot.

C. After operating for ½ hour:

  •Checkthatallboltsandfastenersarealltightenedproperly.(SeeTorqueSpec.)

  •Checkthatallwheelnutsaretight.

  •Checktheaugersandreel.Removeallstring,twine,orotherentangledmaterial.

  •Checkthatnohosesarepinched,rubbing,orbeingcrimped.Re-alignasrequired.

  •Checkforoilleaks.Stopleaksbeforecontinuing.

  •Lubricateallgreasettings.

D. After operating for 5 hours and 10 hours:

  •Re-torqueallwheelnuts,fasteners,andhardware.

  •Checktheaugersandreel.Removeallstring,twine,orotherentangledmaterial.

  •ProceedwithnormalservicingandmaintenancescheduleasdenedintheMaintenanceSection

If any of these items are not running as indicated, immediately repair or contact your service representative.

Page # 14

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

MIXER OPERATION

• Always use cured dry hay. Toughhaycancausewrapping,bindinganddamagetothemixerandcanadverselyeectthe

mixing performance. The following are some examples that contribute to tough hay conditions: high moisture content,

high grass content, high density bales,outdoor storage, use of hay preservatives, and excessive stem length.

HAY QUALITY

• Do not overload the mixer! Overloading causes excessive horepower requirements, increased strain on the

mixer driveline and poor mixer performance.

FILL LEVEL

MIXER OPERATION

Always refer to Equipment Safety Guidelines & Before Operation sections of this manual before operating this mixer.

• The Turbo-Max Mixer was designed for blending dairy and beef rations. Most commonly used ingredients, including

limited amounts of dry stem hay, can be mixed quickly and uniformly in this mixer. If you have questions regarding your

feed ration or have other applications, please contact Sioux Automation Center, Inc.

• Mixingperformancecanvarygreatlyaccordingto thedierencesin materials,loading sequence,mixing speed,and

unloading methods.

GENERAL

• When the mixer is in operation it has many moving parts which could cause severe injury or death to persons coming in

contact with these parts. To help avoid serious accidents, please read and understand this manual.

SAFETY

• Do not load hay without other dry commodities in the mixer rst to act as a carrier or “lubricant”.

• Do not overload hay content, Sioux Automation Center Inc. recommends up to 15%-20% of hay by weight in the load.

Exceeding this percentage can decrease mixing performance or could potentially damage mixer and cause premature

wear on driveline components.

LIMITATIONS

• Do not use tough hay (20%-60% moisture) Always used cured, dry hay. Wet hay, foreign objects or overloading may

cause binding and damage to the mixer.

• Keep in mind the overall size of the mixer to allow clearance through doorways.

WARNINGS

• The mixer can mix an average load in 3 to 5 minutes. Due to this short mixing time, there is normally no reason to run

the mixer during loading except to level the materials.

MIXING TIME

• When deciding when and how fast to operate the mixer, factors such as ingredients being used, the thoroughness of

the mix, and the time available to mix must be considered. Normal mixing speed is 3/4 to full PTO speed.

• Do not exceed rated PTO speed. When the mixer is operated faster than rated PTO speed the strain on the drive train and

mixer is greatly increased.

MIXING SPEED

• The design of the Turbo-Max Mixer requires that there be adequate space to allow the feed to move in and around

the reel chamber. If the reel is completely covered, it cannot eciently mix the materials. The reel cross tubes or

paddles should always be visible at the top of their rotation to allow this mixing space.

Page # 15

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

MIXER OPERATION

• ThefollowingfeedmaterialsrequirepreparationorprocessingtobemixedintheTurbo-MaxMixer:

• ALLLONGANDUNCUREDGRASSES

• ROUNDBALES,LARGESQUAREBALES

• SMALLSQUAREBALES

MATERIALS REQUIRING PREPARATION

• Priortoloading,checkmixerforforeignobjectsandbesurethedoorisfullyclosed.

•Loadallcommoditiesfromtheauger/dischargesideofthemixer.

1. Load Commodities

• Adding ingredients like corn, soybean meal, cottonseed, etc. will act as a carrier or “lubricant”if hay is included

in the ration.

• If there are few commodities in the ration, substituting corn silage or haylage is preferred.

• Fill mixer between 1/3-1/2 full by volume in commodities and forage before adding the hay to the ration. This

will allow enough room for the hay to expand and bring feed level up so the top auger can assist in processing.

2. Load Hay

• Load processed hay. With the mixer running at 3/4 to full PTO speed, proceed loading the small square bale pieces

or tub ground hay into the mixer. Do not exceed 15%-20% of hay by weight.

3. Finish Loading Commodities

• Finish loading any other ingredients to complete the ration in order of least binding ingredient to most binding.

Example: dry commodities rst, corn silage second, haylage last.

4. Finish Loading Wet Commodities

• Any other wet feeds may be added at this time.

5. Add Liquid Ingredients

  •Ifrationincludeswater,additlast.Addingwateratthebeginningwillcausethehaytobind.

LOADING AND MIXING

• ManydierentkindsofmaterialscanbemixedwiththeTurbo-MaxMixer,buteachkindofmaterialhasitsownunique

characteristics.

• FORAGES- Chopped hay, corn silage, and nely chopped crop residue can be mixed in the mixer. Wet and heavy forages

added in large volumes may require more power to mix.

• GRAINS- Ground, rolled, aked, and whole cereal grains, minerals, and concentrates, are all very easily mixed, and can

improve the mixing performance of the other materials.

• LIQUIDS- Supplements and liquid fat can be blended in the mixer. Some operators prefer adding liquids into the empty

mixer, and others add liquids on top of grains or roughage. Sticky liquids such as molasses tend to increase the power

requirements.

MATERIAL THAT CAN BE LOADED DIRECTLY INTO THE MIXER

• After the ration has been thoroughly mixed, open the mixer door to begin unloading. The combination of the dis-

charge door opening and the mixer speed determines the ow of feed from the mixer. The door must be opened far

enough to prevent separation of materials.

• The Turbo-Max Mixer is equipped with a slide tray to assist in the delivery of feed. The tray height is adjusted with

hydraulic cylinders.

UNLOADING

Page # 16

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

NORMAL SERVICE AND MAINTENANCE

IMPORTANT! READ BEFORE OPERATING MIXER.

• Roller Chain Tighteners so they apply sucient spring tension to keep roller chains running smoothly. The chain will

form grooves in the tightener blocks. These grooves help to keep the chains in proper alignment, and the blocks need

not be turned unless the roller portion of the chain has worn into the block.

• Roller Chains for wear, proper alignment and tension. Adjust or replace if necessary. Roller chain connector links which

pass over polyethylene tightener blocks must have the legs of the cotter pins trailing to the direction of rotation.

• Safety Decals for readability. If any safety decals are removed, obstructed, or otherwise not understandable, they should

be replaced immediately. Keep all decals clean and visible.

• Safety Shielding to be sure all shielding is in place and functions properly. Replace all damaged or missing shielding

immediately - see parts pages for more information.

• Bolts and Set Screws after a few hours of use and each month thereafter. Tighten if necessary.

• Reel Wipers plastic strips which help material clean out of the reel hopper. If the strips become bent back, they can be

unbolted and turned around or replaced to improve clean out.

• Upper Auger Knives (optional) can be turned over for use on a new cutting edge and should be periodically sharpened,

or replaced if they are no longer suciently breaking up material.

• Lower Auger Round Knives can be rotated several times before sharpening or replacement is required.

• Discharge Chute Augers (optional) to keep from rubbing on the chute body: There are shims behind each chute auger

bearing for alignment. Periodically check chute liners for wear, replace as necessary.

• Trailer Hitch for proper location, alignment and tightness of attaching bolts. If the upper clevis bar becomes excessively

worn the hitch assembly should be unbolted and replaced as necessary. Frequently check the clevis attaching bolts for

tightness, and that the clevis is secure. Worn or damaged bolts must be replaced.

INSPECT AND ADJUST

MAINTENANCE

• Wheel Bolts must be kept properly torqued. Damage to the rim may occur if wheel bolts are not checked frequently.

8-bolt rim: 170 ft lbs-Grade 8 Lug

10-bolt rim: 300 ft lbs-Grade 8 Lug

• Tire Wear and Pressure must be checked to ensure that there is no excessive wear, and that tires are inated to the rec-

ommended operating pressure for each given tire.

• Rain can accumulate in mixer if stored outside, always remove drain plugs on hopper ends to allow unit to drain com-

pletely and replace drain plugs before next use.

• Freezing Weather the PTO shield requires extra grease to prevent freezing. Snow can accumulate in mixer if stored

outside, always remove drain plugs on hopper ends to allow unit to drain completely and check hopper for snow or ice

buildup before operating unit. Thaw and remove any obstruction and replace drain plugs before next use.

• IMPORTANT: WHEN WELDING ON THIS UNIT: Do NOT allow the current to ow through the bearings, roller chains,

or scale weigh bars. Ground directly to the item being welded. ALWAYS disconnect weigh bar cords from scale indicator

before welding.

• Scale Indicator: Refer to the electronic scale operators manual for adjustment information. The operator’s manual

for the Electroic Scales should be kept with this manual. Additional scale manuals may be obtained through Sioux

Automation Center, Inc.

• Load Cells: Should be kept clean, dry,and lubricated to insure dependabiltiy.

• Normal Scale Activity: Some warm up scale “drift” may occur after the scale is turned on but should zero balance

within 10-15 minutes. Scale may zero shift over night due to temperature changes.

ELECTRONIC SCALES

Page # 17

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

3

27

4

33

6

5

1

IF APPLICABLE

• It is extremely important that the following lubrication schedule be followed: Bearings: use a good quality

multipurpose grease. Replace all damaged or missing grease zerks immediately. Always clean zerks before using

grease gun. Pump the grease in slowly until a slight bead forms around the bearing seals. Once a month check lines

and connections on grease banks for leaks.

• Oilbath Oil: Use a good high quality universal oil. Use an oil that meets or exceeds hydraulic oil grade. Fill to the top

lower oilbath roller chain. Change yearly or whenever contaminated.

• Before operating a new mixer, the roller chains should be liberally lubricated and then the unit operated under a

no-load condition. This break-in period will allow the roller chains to be thoroughly lubricated and thus minimize

heat-up during operation.

LUBRICATION

ITEM LUBRICATION

INTERVAL CAPACITY OIL TYPE LOCATION

1 8 HOURS

HIGH QUALITY MULTI PURPOSE GREASE

FRONT AUGER & REEL BEARINGS

2 8 HOURS REAR AUGER & REEL BEARINGS

3 8 HOURS DRIVELINE BEARINGS & UNIVERSAL JOINTS

4 ANNUALLY WHEEL BEARINGS (REPACK ANNUALLY)

520 HOURS DISCHARGE BEARINGS (IF APPLICABLE)

6 CHAIN LUBE OIL DISCHARGE CHAINS (IF APPLICABLE)

7 50 HOURS APPROX. 3.5 GALLONS GOOD QUALITY HYDRAULIC OIL OIL BATH OIL (CHECK LEVEL)

REPLACE ANNUALLY

Page # 18

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

17

6

5

1112

2

111

14

2

1

16

710

18

4

7

20

4

13

22

8

19

21

7 1

1

2

13

1

2

14 9 7

2

15 18

ITEM # 6150

QT Y.

6160

QT Y.

6170

QT Y.

PART # DESCRIPTION

1 9 9 10 DEC102 DECAL,GRS,GUN,PICTURE

2 5 5 5 DEC105 DECAL,DANGER,DRVLN,ROTATE

3 1 1 1 DEC106 DECAL,CAUTION,MAN,OWNER,5,6

4 1 1 1 DEC107 DECAL,WARNING,CHAIN,EXPOSED

5 1 1 1 DEC108 DECAL,WARNING,PART,MOVING,4,4

6 1 1 1 DEC109 DECAL,CAUTION,WLD,3,3

7 4 4 4 DEC111 DECAL,DANGER,AUGER,5,6

8 1 1 1 DEC626 DECAL,SAC,LOGO

9 1 1 1 DEC442 DECAL,TM,9,228,CS

10 1 1 1 DEC444 DECAL,TM,9,173.75,SS

11 1 1 1 DEC375 DECAL,MODEL,SERIAL,SAC,2.75,5

12 1 1 1 DEC393 DECAL,FEMA,1.5,2.5

13 2 2 2 DEC322 DECAL,WARNING,CHUTE,AREA

14

2 0 0 DEC422 DECAL,TURBOMAX,6150,WHITE

0 2 0 DEC423 DECAL,TURBOMAX,6160,WHITE

0 0 2 DEC424 DECAL,TURBOMAX,6170,WHITE

15 1 1 1 DEC785 DECAL,GREASE,BEARINGS,SHAFT/REEL

16 1 1 1 DEC786 DECAL,GREASE,BERAING,AUGER/JACKSHAFT

17 1 1 1 DEC787 DECAL,GREASE,BEARING,JACKSHAFT

18 2 2 2 DEC795 DECAL,NUT,LUG,CHECK

19 80 80 80 DECREFLECTAPE TAPE,RFLCTV,2”,RED,WHT

20 1 1 1 DECSMV DECAL,VEHICLE,SLOW,MOVE,VINYL

21 1 1 1 STI702174 REFLCTR,RECT,AMBER

22 1 1 1 STI702175 REFLCTR,RECT,RED

DECAL LOCATION

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

_______________________________________________________________________________________________________

NOTES

Page # 19

Page # 20

877 1st Ave. N.W. | Sioux Center, IA 51250 | Toll Free: 1.866.722.1488 | siouxautomation.com

OPERATION

REPLACEMENT PARTS

READ complete manual CAREFULLY

BEFORE attempting operation.

MON900703 BASE ASSEMBLY

ITEM

#

6150

STD

QTY

6160

STD

QTY

6170

STD

QTY

6150

TURBO

QTY

6160

TURBO

QTY

6170

TURBO

QTY

PART # DESCRIPTION

1 16 16 16 16 16 16 BLT1X312NC 1X3-1/2 BOLT

2 3 3 3 3 3 3 BLT12X4NC 1/2X4 BOLT

3 20 20 24 20 20 24 BLT12X112NC 1/2X1-1/2 BOLT

4 5 5 5 5 5 5 BLT12X114NC 1/2X1-1/4 BOLT

5 8 8 8 8 8 8 BLT34X2NC 3/4X2 BOLT

6 2 2 2 2 2 2 BLT34X2NF 3/4X2 BOLT G8 FINE THD

7 36 36 36 36 36 36 BLT34X3NC 3/4X3 BOLT

8 12 12 12 12 12 12 BLT34X2-1/2NC 3/4X2-1/2 BOLT

9 4 4 4 4 4 4 BLT38X1NC 3/8X1 BOLT

10 8 8 8 8 8 8 BLT38X12NC 3/8X1/2 BOLT

11 4 4 4 4 4 4 BLT58X3NC 5/8X3 BOLT

12 1 1 1 1 1 1 BLT58X5NC 5/8X5 BOLT

13 19 19 19 19 19 19 BLT58X212NC 5/8X2-1/2 BOLT

14 4 4 4 4 4 4 BLT78X3NC 7/8X3 BOLT

15 9 9 12 9 9 12 BLT516X114NC 5/16X1-1/4 BOLT

16 1 1 1 1 1 1 BRGFB22464H 4 FLANGE BEARING

17 1 1 1 1 1 1 BRGRCJ2 2 FLANGE BEARING

18 3 3 3 3 3 3 BRGRCJ2716 2.438 FLANGE BEARING

19 1 1 1 1 1 1 BRGYCJ2 2 FLANGE BEARING

20 1 1 1 1 1 1 BRGYCJ2716 2.438 FLANGE BEARING

21 2 2 2 2 2 2 BURN12000305 4.5 SPROCKET RETAINER DISK

22 2 2 2 2 2 2 HYD1404-2-2 UNION

23 1 1 1 1 1 1 HYD5502-2-2 90 DEG ELBOW

24 1 1 1 1 1 1 KN170445 3.5 FLANGE BEARIING

25 3 3 3 3 3 3 MON102032 5.5 X 3.56X14GA SHIMS

26 3 3 3 3 3 3 MON102037 6 X 4.06X14GA SHIMS

27 1 1 1 1 1 1 MON102584-1 SPROCKET (100B15)

28 1 1 1 1 1 1 MON102585 1.75 DRIVE SHAFT

29 1 1 1 1 1 1 MON102717 100-H ROLLER CHAIN

30 1 1 1 1 1 1 MON102718 120-H ROLLER CHAIN

31 1 1 1 1 1 1 MON102719 140-H ROLLER CHAIN

32 1 1 1 1 1 1 MON102720 160-H ROLLER CHAIN

33 2 2 2 2 2 2 MON102755 RETAINER SEAL

34 1 1 1 1 1 1 MON102917 BEARING SEAL

35 1 1 1 1 1 1 MON102918 BEARING SEAL

36 1 1 1 1 1 1 MON103434 SPACER

37 1 1 1 1 1 1 MON103455 SPACER

38 1 1 1 1 1 1 MON103460 SPACER

39 2 2 2 2 2 2 MON103461 SPACER

40 1 1 1 1 1 1 MON104349 KEY 1/2 X 1/2 X 1 3/4

41 1 1 1 1 1 1 MON104529 SHAFT 2.44 DIA. X 29.75

42 1 1 1 1 1 1 MON104541 KEY 5/8 X 5/8 X 4 7/8

43 1 1 1 1 1 1 MON104685 SUPPORT PLATE

44 1 1 1 1 1 1 MON104690 ACCESS COVER

45 2 2 2 2 2 2 MON104699 IDLER TIGHTENER ARM

46 1 1 1 1 1 1 MON104701 IDLER TIGHTENER ARM ELBOW

47 1 1 1 1 1 1 MON300014 PLASTIC BEARING (3-7/16)

48 20 20 24 20 20 24 MON300018 KNIFE BOTTOM AUGER (ROUND)

49 3 3 3 3 3 3 MON300026 PLASTIC TIGHTENER

50

1 0 0 1 0 0 MON701077-1 6150 BODY WELDMENT

0 1 0 0 1 0 MON701077-2 6160 BODY WELDMENT

0 0 1 0 0 1 MON701077-3 6170 BODY WELDMENT

51 1 1 1 1 1 1 MON701078 SPROCKET

52 1 1 1 1 1 1 MON701080 SPROCKET

53 1 1 1 1 1 1 MON701081 SPROCKET

54 1 1 1 1 1 1 MON701085 SPROCKET

55 1 1 1 1 1 1 MON701100 DISCHARGE DOOR WELDMENT

56 1 1 1 1 1 1 MON701105 DISCHARGE CYLINDER BRACKET

57 3 3 4 3 3 4 MON701118 BUSKET GUARD

58 2 2 2 2 2 2 MON701292 2.44 SHAFT FLANGE

59

1 0 0 1 0 0 MON701293 6150 TOP AUGER

0 1 0 0 1 0 MON701296 6160 TOP AUGER

0 0 1 0 0 1 MON701386 6170 TOP AUGER (SMOOTH)

SAC Turbo-Max 6100 Series Programming manual
