SAD DL08128 User manual

SAD Day Light
Unit Description
1. Switch
2. Cover
3. Plug
4. Mounting hole
5. Fold-out Stand
6. Lamp tube clip
7. 45W lamp tube
Product Code: DL08128
NOTE: Plug power lead into mains.

Technical specification
FAQ
Dimensions (WHD)
Weight
Fuse
Power
Failure
No light
Solutions
Turn on the switch
Re-install the light tube
The appliance is not correctly
connected to your power
Light intensity
Mains connection
Operating Environment
Storage Environment
Transport Environment
Product Classification
Lighting elements
Nominal data for replacement lighting elements
(provided by light tube supplier)
270 x 207 x 80 mm
0.8 kg
T3.15AH250V
45 watts
Possible causes
Main Power Off
Loose Light tube
No Power
> 10,000 lux in 15cm
220 V ~240V, 50 Hz
+50 to +77 oF/ +10 to +25 oC, and relative
humidity from 30% to 90%.
Atmospheric pressure: 700-1060hPa
-4 to +122oF/ -20 to +50 oC, and relative humidity
of max. 90%.
Atmospheric pressure: 700-1060hPa
-4 to +122oF/ -20 to +50 oC, and relative humidity
of max. 90%.
Atmospheric pressure: 700-1060hPa
1. Class II equipment
2. No applied part
3. Protection against ingress of water: IP20
4. Not category AP / APG equipment
5. Mode of operation: Continuous operation.
45W tubes, Daylight (full spectrum)
Service Life: 8000 hours
MP45 3U

1. About the SAD Day Light
Instructions for Use:
Congratulations on the purchase of your new SAD Daylight. The product will offer many years of reliable usage
if handled correctly. Please keep your receipt, these instructions and the original packaging safe in case of future
requirement.
Please read the instructions carefully to gain the most benefit from your new SAD Daylight, although the usage
guidelines in this document do not replace the advice of your qualified medical advisor.
Intended Use:
Medical intended use of this appliance is to treat SAD (Seasonal Affective Disorder) or winter depression.
“Mini Daylight” is intended to boost peoples energy levels, to adjust circadian rhythms and make people feel
more awake. “Mini Daylight” is safe and medically proven to relieve the winter blues.
How does the SAD Daylight work?
In autumn and winter, the seasons with the least sunlight because of shorter days, the lack of sunlight and a
problem with certain brain chemicals stops the hypothalamus working properly. The lack of light is thought to
affect the production of the hormone melatonin (that makes you sleepy).
SAD Daylight uses very bright lights to simulate the sunlight during the darker autumn and winter months, whilst
eliminating the dangerous UV rays contained in sunlight. The additional light helps your brain to reduce
heo production of melatonin to help the symptoms of SAD or winter depression.
Seasonal Affective Disorder:
Seasonal Affective Disorder (SAD) as known as winter depression or winter blues. It may cause people:
• Feel low, listless and fatigued
• Need for more sleep
• Have trouble concentrating
• Less active than normal
• Lacking in energy
NOTE: Symptoms occur during the same season each year. Most people with SAD start to have symptom in winter and
feel better in summer.
Please consult your doctor prior to using this product if you have:
• Suffer(ed) from severe depression
• Had recent eye surgery or a diagnosed eye condition which your doctor advised you to avoid bright light on
specific medication (i.e. certain antidepressants, psychotropic drugs or malaria tablets);
• Have high blood pressure
• Have skin sensitivity to light, such as systemic lupus emphysematous.
Possible side effects:
• Headaches
• Eyestrain
Measures to avoid, minimize or alleviate these side effects:
• Increase the treatment distance
• Avoid using the appliance during the late evening or before sleep
• Stop using the appliance for a few days to make the side effects disappear and then try again.
• Sleeping problems
• Nausea

4. Preparing the appliance for use
5. Operation
Setup :
• Remove the appliance from the packaging.
• Place the appliance on a solid surface, such as a table, and adjust the folding tripod.
• It is recommended that you keep your face 15 - 35 cm away from the light during use.
Fastening of SAD Daylight on the wall:
There is a mounting hole on the back side of the appliance. At this mounting hole the appliance can be fixed on
the wall with screw. Depending on the type of wall, an appropriate screw must be used.
NOTE:
• Ensure that there is a socket near the place where the appliance will stand.
• Lay the mains cable in such a way that no one can trip over it.
IMPORTANT: If the mounting hole or back housing is cracked or damaged. Do not fix the appliance on the wall.
Please contact customer service or the dealer for assistance.
1. Switching on the appliance:
Press the ON/OFF button of the appliance to switch on the light.
NOTE: The brightness of the tube may be visibly different when switched on. The tube develops it full luminosity
after a couple of minutes.
2. Safety and performance standards
3. Unpacking and Inspecting
This appliance has been designed and manufactured to conform to the highest standards of safety and
performance including electromagnetic compatibility (EMC). This appliance conforms to the applicable
requirements of the following of Medical Device Directive 93/42/EEC for medical appliances.
Every attempt is made to ensure your order is accurate and complete. However, to be sure that your order is
correct, verify the contents of the box against your packing slip.
The appliance is designed for simplicity of operation and set-up and requires minimal assembly.
The following items are included your box:
1 x SAD Daylight
1 x Operator’s Manual
Carefully inspect each item as it is unpacked for any signs of damage which may have occurred during shipment.
• Check the components according to the packing list.
• Check for any damage or defects. Do not attempt to setup the appliance if anything is damaged or defective.
Contact your supplier immediately if anything is found to be damaged or defective.

6. Replacing the lamp tubes
Distance
35cm
25cm
15cm
Duration of light therapy
Approx. 2 hours
Approx. 70 minutes
Approx. 30 minutes
1. Switching on the appliance:
2. Taking the light
Now sit down in front of the light or as close to it as comfortable, between 15 cm and 35 cm. You can go
about your normal activities while using it. You can read, write, make telephone calls, etc. When using the
appliance, try to maintain the recommended distance of 15 - 35 cm between your face and the appliance.
In effect, the closer you are to the source of light, the less time you need to use it.
Note:
• Do not look directly into the light continuously! Some eye pain or mild headaches may be experienced during initial
sessions but these should pass. If in doubt just lower your treatment times until comfortable again.
• Do not leave the appliance unattended
• Do not touch the appliance in the duration. Let the appliance cool down before reposition it.
• To ensure the product services life, you can use the appliance up to 2 hours, but do not use more than 4 hours in each
use. Let the appliance cool down for at least 15 minutes before reuse.
• Do not block vent holes in the duration.
3. Enjoying light over longer periods
During the darkest period of the year, repeat the treatment for at least 7 consecutive days, or longer, depending
on your individual requirements.
1. 2. 3.
In the event that the light is faulty, or when it comes to end of life, the light tube can be replaced.
Note: Do not replace the lamp tube which is not provided by the supplier. To do so, proceed as follows:
• Always unplug the appliance and let it cool off.
• For safety reasons, do not remove any components or screws other than those specified below.
1. Slacken the retaining screws on the back using a screwdriver, and remove the front cover.
2. Remove the tube transparent retaining clip using a screwdriver.
3. Carefully pull the tube out of the housing and replace a new tube.
4. When inserting the tube, following these instructions in reverse order.

7. Cleaning up a broken tube
The light tube contains a small amount of mercury sealed within the glass tubing, when a tube breaks in your
home, some of this mercury is released as mercury vapor. To minimize exposure to mercury vapor, we
recommend that users follow the cleanup and disposal steps as follows:
Before Cleanup:
• Have people and pets leave the room and air out the room for 5-10 minutes by opening a window or door to
the outdoor environment.
• Shut off the central forced air heating/ air-conditioning system, if you have one.
• Collect material needed to clean up broken tube: stiff paper or cardboard, sticky tape, damp paper towels or
disposable wet wipes.
During Cleanup:
• Vacuuming is not recommended unless broken glass remains after all other cleanup steps have been taken.
Vacuuming could spread mercury-containing powder or mercury vapor.
• Be thorough in collecting broken glass and visible powder.
• Place cleanup materials in a sealable container.
After Cleanup:
• Promptly place all bulb debris and cleanup materials outdoors in a trash container or protected area until
materials can be disposed of properly. Avoid leaving any bulb fragments or cleanup
materials indoors.
• If practical, continue to air out the room where the bulb was broken and leave the heating/air
conditioning system shut off for several hours.
8. Cleaning
9. Storage
10. Disposal
• Before you clean the appliance, always switch it off, unplug it and let it cool off.
• Do not touch the appliance with wet hands.
• Clean using a damp cloth, to which you can apply a little detergent if necessary.
• Do not let water run into the appliance or spill water onto the appliance.
• Cleaning can be done once per month.
When the appliance is not being used, it should be stored in a dry location out of reach of children. Do not keep
the appliance connected to a power source. The appliance is designed to be stored in the following
environmental conditions:
1. Ambient temperature from -20oC (-4oF) to 50oC (122 oF).
2. Relative humidity of max. 90%.
3. Atmospheric pressure: 700-1060hPa
Please note that this appliance is marked with the WEEE symbol on the left. This means that this appliance must
not be disposed of together with ordinary household waste, electrical and electronic waste must be disposed of
separately. If you have any questions, please contact your local authorities responsible for waste disposal.

11. Notes
Please read these instructions for use carefully and keep them for later use, be sure to make them accessible to
other users and observe the information they contain.
Safety Notes:
• Do not use in humid surroundings.
• Before use, ensure that all packaging materials are removed and that there is no visible damage to the
appliance.
• The appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Keep the cord away from hot objects and open flames.
• The mandatory minimum distance between the appliance and flammable objects is 1.0 meter.
• Connect the appliance only to the mains voltage listed on the type plate.
• Always remove the mains plug and let the appliance cool off before you touch it.
• Do not touch the appliance with wet hands while it is plugged in; do not allow any water to be sprayed onto
the appliance. The appliance must be operated only when it is completely dry.
• Protect the appliance from strong impacts.
• Avoid pulling the cord when removing the plug from the socket. Instead, hold the plug.
• If the cord or the housing is damaged, contact customer service or the dealer, since special tools are needed
to make repairs. Never try to repair the appliance yourself.
• Disconnection from the mains supply is only guaranteed if the mains plug has been removed from the socket.
• The appliance requires no calibration, preventive inspection and maintenance.
• The appliance is not repairable and contains no user serviceable parts.
• No modification of this appliance is allowed.
General notes:
• This appliance is not intended for commercial or clinical use, but only for individual, private household use.
• If you are taking medication such as pain relievers, antihypertensives or antidepressants, consult your doctor
before using the appliance.
• People with retinal diseases as well as diabetics need to be examined by an ophthalmologist before
beginning to use the appliance.
• Please do not use if you have an eye disease such as cataracts, glaucoma, diseases of the optic nerve in
general and inflammation of the vitreous humour.
• If you have health concerns of any kind, contact your general practitioner!
Repairs:
• Only open the appliance to replace the tube. Please do not attempt to repair the appliance yourself.
This could result in serious injuries. Failure to observe this regulation shall void the warranty.
• If this appliance is damaged in any way or it is not working, it should not be operated. Please try to fix the
problem according to FAQ table. If the problem still not resolved, please contact customer service dealer,
since special tools are needed to make repairs. Never try to repair the appliance yourself.
