2HP-D Main Amplifier Operator’s Manual
Special order stainless steel front panel shown.

PREFACE
CONGRATULATIONS. You have just acquired one of the most advanced audio components ever
developed.
Your SAE 2HP-D was designed to set new standards in virtually every performance category. Not only does the 2HP-D
utilize a dual-differential balanced design, to our knowledge, it is the world’s rst amplier to be balanced both electrically
and physically. Each circuit board in the active signal path is designed with mirror imaged traces with the ground-point, the
fulcrum of the design, positioned at its absolute center.
Other signicant advances in the amplier include:
1. Dual mono design with separate and independent power transformers, power switches and line cords;
2. High temperature (Class F rated) toroidal transformers each with 1930 VA;
3. Separate and independent transformer windings for the input and output stages;
4. Independent transformer windings for each half of the balanced ampliers;
5. Independent bridge rectiers for each half of the balanced ampliers;
6. Four layer circuit boards used throughout; each with separate power and ground planes;
7. Mirror imaged board layout with a perfectly centered ground point. The circuit is both electrically and physically balanced;
8. Solid copper bus bar;
9. Current feedback for improved amplier control and virtually unlimited slew rate;
10. Double transistor input stage;
11. Dual-DC Servos virtually eliminate any DC offset;
12. ThermalTrak output devices optimize bias in real-time;
13. All protection circuitry is optically coupled and outside the circuit path. It is self-resetting;
14. Built-in distortion limiter compares amplier input and output and supply voltage to output voltage before engaging.
When engaged, amplier clipping is eliminated and THD cannot exceed 1%;
15. User selectable forced air (fan) cooling may be engaged or disabled as necessary.
16. Virtual VU and Frequency Spectrum Display Meters. These meters uniquely show the ampliers instantaneous peak
power output and average power output simultaneously without the inertia that causes inaccuracies in mechanical meters.
i

The lightning ash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of signicant magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the product.
ii
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE
CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THE AC (POLARIZED) PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
Extension cords are not recommended for use with this product.

Amplier Identication Record
This information is for your records and for future identication of the 2HP-D. Please take a moment to ll out all pertinent
data now, and as upgrades and/or options are installed. Whenever upgrades, inquiries and/or changes are requested, the
serial number will be required.
SERIAL NUMBER
DATE PURCHASED
DEALER’S NAME
DEALER’S ADDRESS/PHONE
IMPORTANT
Save all packaging in a dry place away from re hazards. Your amplier is a precision electronic instrument and should be
properly packaged any time shipment is made. In the unlikely event that you have to return your 2HP-D to the factory or
dealer for service or updating, the original packaging will best protect the unit from shipping damage.
In order to achieve the fullest exibility and enjoyment from your SAE 2HP-D, we recommend that you read this manual in
full before connecting the unit to your audio system.
iii
Warning: Each channel of the 2HP-D is a balanced bridge amplier, thus the negative speaker terminal is NOT a
ground, and cannot be connected to a system ground or a loudspeaker system with a common ground. Consult your
speaker manufacturer to ensure that any speaker in your system that will be connected to the SAE 2HP-D does NOT
have internal circuitry with a common ground.
Note: It is imperative that your 2HP-D be operated in a well-ventilated environment and that the immediate external
temperature be maintained as specied. If you need to stack any equipment directly above or below the amplier,
please engage the cooling fan to protect it from overheating.

SAFETY PRECAUTIONS
Please carefully read each item of the operating instructions and safety precautions before installing and using this product.
Use extra care to follow the warnings written on the product itself and/or in the operating instructions. Keep the operating
instructions and safety precautions for future reference.
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE ANY OF THE COVER PANELS.
NO USER-SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT ALLOW LIQUIDS TO SPILL OR OBJECTS TO FALL INTO ANY
OPENINGS OF THE PRODUCT.
THIS UNIT IS SUPPLIED WITH TWO 3-PIN GROUNDED AC PLUGS. ALWAYS INSERT THE AC PLUG INTO A GROUNDED
OUTLET. DO NOT REMOVE THE GROUND PIN OR DISABLE THE GROUND FOR ANY PURPOSE.
BEFORE MAKING ANY CONNECTIONS TO THE 2HP-D, FIRST TURN OFF THE POWER AND THEN DISCONNECT
THE AC POWER CORD.
WHEN INSTALLING THE 2HP-D IN YOUR SYSTEM, MAKE CERTAIN TO ALLOW A MINIMUM OF 6 INCHES OF VENTILATION
ON TOP AND ON EACH SIDE OF THE UNIT. IMPROPER VENTILATION OF THE UNIT MAY CAUSE OVERHEATING, WHICH
MAY DAMAGE THE UNIT AND CAUSE A FIRE. PLACE THE UNIT ON A SOLID SURFACE ONLY. I.E. NOT ON CARPET, ETC.
DO NOT PLACE THE 2HP-D NEAR HEAT SOURCES SUCH AS DIRECT SUNLIGHT, STOVES, HEAT REGISTERS,
RADIATORS OR OTHER HEAT PRODUCING EQUIPMENT.
TO PREVENT DAMAGE TO THE ANALOG OUTPUT CIRCUITRY, BE CERTAIN TO NEVER SHORT THE OUTPUT
SIGNAL TO GROUND. ENSURE THAT YOUR AUDIO OUTPUT CABLES DO NOT HAVE ANY INTERNAL SHORTS
BEFORE CONNECTING THEM TO THE 2HP-D.
IF REPLACEMENT OF THE AC LINE FUSE AND/OR ANY INTERNAL/EXTERNAL FUSE BECOMES NECESSARY,
REPLACE ONLY WITH SAME VALUE AND TYPE OF FUSE. NEVER BYPASS THE FUSE.
IF THE AC CORD BECOMES DAMAGED, DO NOT USE IT. IMMEDIATELY REPLACE IT WITH A NEW ONE OF THE
SAME OR BETTER RATING.
IT IS IMPERATIVE THAT 2HP-D BE OPERATED IN A WELL VENTILATED ENVIRONMENT AND THE IMMEDIATE
EXTERNAL TEMPERATURE BE MAINTAINED AS SPECIFIED. DO NOT STACK ANY EQUIPMENT DIRECTLY ABOVE,
BELOW OR TO THE IMMEDIATE SIDES OF THE 2HP-D AS TO PROTECT IT FROM OVERHEATING, AS WELL AS THE
CONTINUED FUNCTIONALITY OF ANY EQUIPMENT NEAR AND AROUND IT.
EACH CHANNEL OF THE 2HP-D IS A BALANCED BRIDGE AMPLIFIER, THUS THE NEGATIVE SPEAKER TERMINAL
IS NOT A GROUND AND CANNOT BE CONNECTED TO A SYSTEM GROUND OR A LOUDSPEAKER SYSTEM WITH
A COMMON GROUND. PLEASE CONSULT YOUR SPEAKER MANUFACTURER TO ENSURE THAT ANY SPEAKER
IN YOUR SYSTEM THAT WILL BE CONNECTED TO THE SAE 2HP-D DOES NOT HAVE INTERNAL CIRCUITRY WITH
A COMMON GROUND.
AFTER MARKET and THIRD PARTY MODIFICATIONS
PLEASE NOTE THAT ANY AFTER MARKET AND/OR THIRD PARTY MODIFICATION WILL VOID THE WARRANTY.
iv

v
Table of Contents
PREFACE ...........................................................................................................................................................................i
WARNING .......................................................................................................................................................................ii
SAE 2HP-D Identication Record .................................................................................................................................. iii
SAFETY PRECAUTIONS ..............................................................................................................................................iv
INTRODUCTION ..............................................................................................................................................................1
Getting to know your amplier .........................................................................................................................................1
Burn-In/Break-In Time......................................................................................................................................................1
Reference Manual Conventions.......................................................................................................................................1
IMPORTANT NOTICE......................................................................................................................................................1
Front Panel Layout...........................................................................................................................................................2
Virtual VU/Spectrum Display Meters................................................................................................................................3
Rear Panel Layout ...........................................................................................................................................................4
OPERATION ......................................................................................................................................................................5
Connecting the 2HP-D .....................................................................................................................................................5
Setup and Operation........................................................................................................................................................5
Remote Triggers ..............................................................................................................................................................5
Appendix A Troubleshooting Guide..................................................................................................................................6
Appendix B Specications ...............................................................................................................................................7
Warranty...........................................................................................................................................................................8

vi
INTRODUCTION
Getting to know your SAE 2HP-D
This SAE 2HP-D amplier has been put through a rigorous and unique testing procedure that ensures that it will last for
many years with minimal service requirements. This procedure includes the following:
• All assembled circuit boards are given a thorough visual inspection and are then tested in a bench-reference amplier.
•The tested, assembled circuit boards are then installed in a new 2HP-D and the whole unit is tested for every function
and parameter.
•The unit is put on a burn-in torture rack to test for any possible component failures.
• The amplier then undergoes a critical listening and functional test.
•The unit has all remaining chassis components installed and then undergoes a complete visual inspection, which
assures that all SAE ampliers meet visual specications.
Burn-In/Break-In Time
This unit has a break in period of about 1 week during which continuous improvement in sound quality will be observed. It is
recommended that music be played continuously through the unit during this time to expedite the break in period.
Reference Manual Conventions
For clarity purposes, references to buttons and LED’s will be shown in bold capital letters.

1
IMPORTANT NOTICE
I. It is imperative that the SAE 2HP-D be connected to a ground via its three wire AC power cord. It is important that the
AC power outlet, which the amplier is plugged into, is actually grounded. Failure to do so will severely compromise the
performance, reliability and safety of use of the SAE 2HP-D.
II. Ventilation is an important issue when placing the SAE 2HP-D in a system. If the amplier is intended for passive (convection)
cooling, please make certain that it is placed in a well-ventilated area or rack unit. If the amplier will operated with fan
cooling, please allow space at the rear for heat to be discharged and cool air must be allowed to enter the amplier.
III. Please take note that powerline conditioners are not generally recommended for use with the SAE 2HP-D. If it is your
intention is to plug the 2HP-D into a line conditioner, check with your dealer to make certain that the particular conditioner
that is intended for use DOES NOT DEFEAT THE AC GROUND on its AC outlets and that it is capable of 20A operation.
Otherwise, the amplier’s power output may be compromised.
IV. DO NOT remove any cover panels from the amplier as there are no user serviceable components inside. Refer servicing
and updating to qualied service personnel only.

2
FRONT PANEL LAYOUT
Figure 2 - Front Panel Layout
1. ILLUMINATED LOGO. Illuminates when the amplier exits the STANDBY Mode.
2. STANDBY SWITCH. After the rear panel MAIN POWER switch(es) are turned on, touch the front panel button to exit
the standby mode and enter the operational mode. Press again to return to STANDBY.
3. METER ON/OFF SWITCH. Turns the virtual VU Meter/Spectrum Display on and off
4. METER DISPLAY SWITCH. Selects the VU Meter or the Frequency Spectrum Display
5. VIRTUAL VU METER/FREQUENCY SPECTRUM DISPLAY
1
22
5
1
33 44
5

1
2
3
4
5
6
7 8
9
10
11
12
13
1
2
3
4
5
6
7 8
9
10
11
12
13
66
78 78
3
1. LEFT CHANNEL VIRTUAL VU METER
2. RIGHT CHANNEL VIRTUAL VU METER
3. LEFT CHANNEL FREQUENCY SPECTRUM DISPLAY
4. RIGHT CHANNEL FREQUENCY SPECTRUM DISPLAY
5. FREQUENCY INDICATOR Divides the frequency spectrum into 40 1/3 octave bands.
6. IMPEDANCE SETTING Displays 4 or 8 Ω. Set on the rear panel to match the speaker’s nominal impedance.
7. AVERAGE POWER POINTER Tracks the amplier’s average (RMS) power output.
8. PEAK POWER POINTER Tracks the amplier’s peak power output.
9. PEAK POWER OUTPUT IN WATTS Displays the numerical value of the amplier’s peak power output.
10. RELATIVE PEAK POWER OUTPUT Displays the amplier’s peak power output relative to its rated output.
11. AVERAGE POWER OUTPUT Displays the numerical value of the amplier’s average power output.
12. RELATIVE AVERAGE POWER OUTPUT Displays the amplier’s average power output relative to its rated output.
13. FREQUENCY OUTPUT DISPLAY Shows the amplier’s output level in 1/3 octave frequency bands.

3.3V - 24V
T+/S -
GND
FAN
ON/TEMP
CHANNEL ONE
AC MAINS INPUT
Serial # :
Designed, Engineered, and Manufactured
In the United States of America
Los Angeles, CA
CHANNEL TWO
AC MAINS INPUT
REMOTE DC INPUT
BALANCED
INPUT
BALANCED
INPUT
Channel One
Channel Two
WARNING :
HAZARDOUS ENERGY,
MAKE PROPER SPEAKER CONNECTIONS;
SEE OWNERS MANUAL BEFORE USING
SPEAKON® OUTPUT
WBT® LOW MASS
TERMINALS
SPEAKON® OUTPUT
1+
2+
POS
1-
2-
NEG
1+
2+
POS
1-
2-
NEG
WBT® LOW MASS
TERMINALS
WARNING :
HAZARDOUS ENERGY,
MAKE PROPER SPEAKER CONNECTIONS;
SEE OWNERS MANUAL BEFORE USING
SPEAKON® OUTPUT
WBT® LOW MASS
TERMINALS
SPEAKON® OUTPUT
1+
2+
POS
1-
2-
NEG
1+
2+
POS
1-
2-
NEG
WBT® LOW MASS
TERMINALS
WARNING :
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
ATTENTION :
POUR ÉVITER TOUT RISQUE DE FEU OU
CHOC ÉLECTRIQUE, NE PAS EXPOSER CET
APPAREIL À LA PLUIE OU À L'HUMIDITE.
120 VAC ~ 60Hz
2 X 20 AMP CIRCUIT BREAKERS
220/240 VAC ~ 50Hz
2 X 12 AMP CIRCUIT BREAKERS
POWER CONSUMPTION
2 X 2400 WATTS
Scientific Audio Electronics, Inc.
2 Channel Pure Balanced Amplifier
Founded in 1967
Two Horsepower
1
2
3
4
7
8
17
10 129 15
11 13 14 16
18
1
2
3
4
7
8
17
10 129 15
11 13 14 16
18
LOAD
8Ω
4Ω
5
6
5
6
4
REAR PANEL LAYOUT
Rear Panel Layout
1. BALANCED (XLR) Input jack
2. POSITIVE (+) BINDING POST (WBT type). Connect positive speaker wire for one speaker to this post.
3. SECOND POSITIVE (+) BINDING POST. Connects positive speaker wire to the second positive speaker terminal when
Bi-Wiring. When Bi-Wiring, please be certain to remove the jumper between the woofer and high-frequency section of
the loudspeaker.
4. SPEAKON LOUDSPEAKER OUTPUT. Connects CHANNEL ONE output to the appropriate loudspeaker.
5. NEGATIVE (-) BINDING POST (WBT type). Connect negative speaker wire for one speaker to this post.
6. SECOND NEGATIVE (-) BINDING POST. Connects negative speaker wire to the second negative speaker terminal
when Bi-Wiring. When Bi-Wiring, please be certain to remove the jumper between the woofer and high-frequency sec-
tion of the loudspeaker.
7. 120 VOLT INDICATOR. A GREEN MARK here indicates the amplier is to be connected to a 120V circuit. Use with 220
to 240V will damage the amplier.
8. 220 TO 240 VOLT INDICATOR. A GREEN MARK here indicates the amplier is to be connected to a 220 to 240V cir-
cuit. The amplier will not operate if used with 120V and may be damaged in the process.
9. METER RANGE SWITCH. Adjusts power indications on the meter. Set to 8Ω or 4Ω depending on the impedance of the
speakers hooked-up to the amplier.
10. CHANNEL ONE MAIN POWER SWITCH AND MAGNETIC CIRCUIT BREAKER. Disconnects AC to Channel One. It is
recommended that this be left ON at all times during regular use with the exception of whenever cables are connected/
disconnected or when the unit is not going to be used for an extended period of time. In the rare case where amplier
protection is needed, this switch may turn the unit off.
11. AC POWER INLET. Use the included power cords to connect Channel 1 to an appropriate AC power source.
12. FAN ON/OFF SWITCH. The SAE 2HP-D is designed for convection cooling. Where convection cooling is not sufcient
or the amplier is used for sustained high-power operation, set the fan to ON.
13. STANDBY REMOTE TRIGGER JACK. With the main power switch(es) set to ON, when the rear panel STANDBY
TRIGGER jack receives a 5-12 VDC signal the amplier(s) will exit the Standby mode and turn on. When the signal is
removed, the amplier will return to Standby.
14. GROUND TERMINAL. Use to interconnect component chassis when necessary.
15/16. DUPLICATES ITEMS 10 and 11 for Channel Two.
17. FAN OUTLET. Forced air used for cooling exits the amplier here.
18. SERIAL NUMBER. Shows the unit’s serial number.

5
OPERATION
Before turning on the 2HP-D, ensure that all precautions and warnings have been carefully reviewed and adhered to. Damage
to the amplier caused by improper operation, wiring and/or ventilation will not be covered under warranty and SAE will not
be liable for any consequential damage or loss.
Connecting your 2HP-D
With the 2HP-D’s rear panel main power switches turned off, connect the signal outputs of the preamp/processor to the
balanced input of the amplier. Connect the output to the input of the speaker that is intended to be driven.
Please refer to gure 5.
The 2HP-D has a second binding post output connector. This may to be connected to the second speaker input terminal on
your loudspeaker system (if available). If using this second speaker input terminal, please be certain to remove the metal
jumper between the woofer and high-frequency sections of your speaker.
Connect a 12V trigger source to the STANDBY trigger input of the 2HP-D to enable remote turn-on and turn-off.
Setup and Operation
Turn the output volume of the preamp/processor, or other source device, down all of the way.
Turn on 2HP-D’s MAIN POWER switches, located on the rear panel.
When the end of the switch with | indicating “ON” is depressed that half of the amplier is in the STANDBY mode. When in
standby, the amplier draws less than 1 watt from the wall outlet.
Touch the front-panel power button. Both the switch and the SAE logo illuminate. After a wait of about 45 seconds, the
soft-start turn-on sequence is complete and the amplier is ready for use.
Slowly bring the output volume of the preamp/processor up to an audible level.
Remote Triggers
When the rear panel STANDBY trigger jack receives a 5-12 VDC signal, the 2HP-D will change its state from standby to
operate. When the signal is removed, the amplier will return to STANDBY.

6
Appendix A Troubleshooting Guide
If the 2HP-D should function abnormally during operation, please review the items in the following checklist. Please be sure
to thoroughly check all other connected components such as speakers and preampliers, as well as cables. If the problem
persists, please consult your dealer or distributor.
Symptom Possible Cause(s) Remedy
No power or front panel lights and no
sound.
The power cable is not inserted
100% into AC input connector.
Ensure that the AC cord(s) are fully
inserted into the amplier and that
the wall outlet is active.
Circuit breaker is open (AC outlet). Check the AC outlet circuit breaker
and reset, if necessary, or contact
your dealer.
No audio output. Overheating, DC at output,
Catastrophic failure
The amplier will turn off with the
rear panel switch indicating O. For
any but a catastrophic failure, the
amplier can be reset by removing
the fault and completing the turn-on
sequence again.
Warm Normal operation
Hot Normal operation Use rear-panel switch to turn-on the
fan.

7
Appendix B Specications
Analog Audio Inputs One Balanced (XLR) jack per channel
Input Impedance 47 k Ohms. Balanced for each phase
Input Sensitivity 2.82V RMS input for 600W into 8 ohms
Gain 27.8 dB
Polarity Balanced; Pin-2 = Positive, Pin-3 = Negative for Non-Inverting Output
Speaker Outputs WBT Low-Mass Binding posts 4 per channel; One 4-Pole Speakon connector per channel
Modes /Process Standby: Amplier is ready to be turned on via front panel switch or remote trigger.
Overcurrent, D.C., and/or thermal protection: Amplier will cycle.
Catastrophic D.C. or output stage failure: Amplier will shut down.
Power Output
Per Channel, All Channels Driven 8 ohms 4 ohms 2 ohms
20 Hz-20 kHz, < 0.01% THD 600 WRMS 1200 WRMS 1200 WRMS
1 kHz, 0.01% THD, (Watts) 746 WRMS 1350 WRMS 1350 WRMS
1 kHz, 0.01% THD, (HP) 1 HP 1 ¾ HP 1 ¾ HP
1 kHz, 1% THD 860 WRMS 1400 WRMS 2000 WRMS
CEA 2006 1 kHz Burst Power 1100 WRMS 2000 WRMS 3400 WRMS
Distortion
THD + N, 20 Hz—20 kHz 0.01% 0.01% 0.01%
THD + N at 1 kHz
At Rated Power 0.005% 0.006% 0.008%
At 10W 0.0015% 0.003% 0.003%
Intermodulation Distortion
(SMPTE or Twin-tone) Less than 0.01%
Frequency Response +0, -3dB, 5 Hz to 150 kHz, 8 Ω
Damping factor >600 at 100 Hz;
Signal to noise ratio 128 dB referenced to rated output (A-Weighted)
Slew rate >60V per microsecond
Crosstalk > 110 dB
Power Requirements 117V AC, 50/60 Hz or 230V AC, 50/60Hz depending on version
Power Consumption Less than 1W x 2 at Standby; 1800W maximum x 2
Trigger Input 3-24 VDC; Steady State
Dimensions (WxHxD) 19” x 8¾” x 20” add 1” for feet and 1½” for connectors; 483 mm x 222mm x 508 mm
Add 25.4mm for feet and 38mm for connectors.
Weight 127 lbs; 57.6 kG

8
90 DAY LIMITED WARRANTY TERMS AND CONDITIONS
(7-Year Optional Extended Service Contract)
SAE Limited Warranty
Terms and Conditions
All SAE products are warranted against defects in materials and workmanship for 90 days from the date of purchase by the
original owner. The date of purchase shall be established by the original owner presenting to the SAE Customer Service
Facility the original owner’s purchase receipt or sales slip showing from whom the product was purchased, the date of purchase
and the purchase price of the unit.
In the event that proof of purchase cannot be established as stated in the preceding sentence, the warranty period shall
commence on the date of manufacture, provided the serial number on the unit has not been altered in any manner.
During the warranty period, SAE will repair, or at its option, replace at no charge, components that prove to be defective
provided the product is returned in accordance with the shipping instructions that are contained in the unit. The unit is to
be sent PREPAID in the original carton and packing along with a detailed description of the problem to SAE in the event it
needs factory servicing. SAE will return it prepaid to you upon completion of the service.
Optional Extended Warranty Program
The standard 90-Day Limited Warranty will be extended to a 7-Year Limited Warranty (on all Power Ampliers) if the following
conditions are met:
The SAE product is purchased from an authorized SAE reseller. The customer completes the registration card. The customer
returns the completed registration card AND copy of original bill of sale to SAE within 14 days of purchase.
This extended warranty is transferable to subsequent purchasers as long as all Optional Extended Warranty conditions are met.
Transferability
The above warranties are transferable to subsequent owners as long as all the conditions are met under the Optional Extended
Warranty Program. The warranty is not transferable if the unit(s) was originally purchased from an unauthorized seller.
The above warranties do not apply if the product has been damaged by accident or misuse or as a result of modication by
other than the SAE factory service facility.
SAE shall not be held liable for incidental or consequential damages of any kind arising from the sale or use of its products.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or ex-
clusion may not apply to you.
THERE ARE NO WARRANTIES GIVEN BY SAE THAT EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. ALL
IMPLIED WARRANTIES OF FITNESS FOR PURPOSE SOLD, MERCHANTABILITY, DESCRIPTION, QUALITY PRODUCTIVE-
NESS OR ANY OTHER MATTERS ARE LIMITED TO THE TERM OF THE EXPRESS WARRANTIES HEREIN STATED.]
Some states do not allow limitations on how long an implied warranty may last, so the above limitation may not apply to you.
Obligation to Make Changes
Products are sold on the basis of specications applicable at the time of sale. SAE shall have no obligation to modify or to
update products once sold. This warranty gives you specic rights and you may also have other rights that vary from state
to state. This warranty is applicable only in the United States.
Warranty Outside the United States
SAE has formal distribution agreements in many countries. The SAE importer in those countries has assumed the respon-
sibility for servicing SAE products. Please contact the dealer or distributor in the country where you purchased your product
for service issues.

(844) 4HEARSAE
[e-mail]
www.hear-sae.com
