Saeco INCANTO Series User manual

Test program
“INCANTO” model
Incanto base
Incanto
®
Rapid steam
Incanto with SBS
®
Rapid steam
Incanto Digital
®
Rapid steam

2
Test program INCANTO………………………………………………………………………….
3
Test program INCANTO rapid steam…………………………………………………………
5
Test program INCANTO Digital…………………………………………………………………
7
Test program INCANTO with SBS……………………………………………………………..
9
Index

3
Test program INCANTO
In test program it is very easy to locate the broken parts, and the time to adjust it becomes lesser.
To enter in test program the machine has to be turned off, and the hot water steam knob closed
.

  
For entering in Test program push the following key’s
Push the key’s 3 and 4 and turn on the
machine by the main switch.
Rotation anticlockwise of the gear motor
Key 1
Check the right rotation anticlockwise of the gear motor
and that the brewing unit is going upwards correctly.
Check also that the gear motor isn’t noisy
When the gear motor is in work position, the key N°1 will be urned
on.
Rotation clockwise of the gear motor.
Key 2
Check the right rotation clockwise of the gear motor
and that the brewing unit is going downwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in home position, the key N° 2 will be turned
on
Function coffee
grinder
Key 3
Check that the coffee grinder is rotating clockwise.
When the doser is full, the led of the key number 3 will be turned
on.
Check the noise of the coffee grinder

4
Opening of the doser
Key 4
Check the right function of the doser.
Check that the doser isn’t noisy.
When the doser is activated the led of the key number 3 will be
turned off.
Absorbing resistance coffee boiler
Key’s 1 + 5
Check through the ampere meter if coffee boiler is absorbing
.
Function of the pump
Key 4 + water knob open
Check the right function of the pump.
Check the noise of the pump
.
Functions of the led
Key’s 1+5 water knob open
Check the functions and the lightness of all the led.
Reed sensor for water level.
The water tank has to be empty.
Start taking it off very slowly.
The led D6:
First it has to be turned off
then it has to be turned on
then it has to be turned off again.
Opening the service door.
Open the service door and check that the key number 5 is turned on.
Drip tray.
Take off the drip tray and check that it’s turned on the led number
7 and the key number 5
Brewing unit
Take off the brewing unit and check that the key number 4 is turned
on

5
Test program INCANTO rapid steam
In test program it is very easy to locate the broken parts, and the time to adjust it becomes lesser.
To enter in test program the machine has to be turned off, and the hot water steam knob closed
.

  
For entering in Test program push the following key’s.
Push the key’s 3 and 4 and turn on the
machine by the main switch.
Rotation anticlockwise of the gear motor
Key 1
Check the right rotation anticlockwise of the gear motor
and that the brewing unit is going upwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in work position, the key N° 1 will be the
turned on
Rotation clockwise of the gear motor.
Key 2
Check the right rotation clockwise of the gear motor
and that the brewing unit is going downwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in home position, the key N° 2 will be turned
ON.
Function coffee
grinder
Key 3
Check that the coffee grinder is rotating clockwise.
When the doser is full, the led of the key number 3 will be turned
on. Check the
noise of the coffee grinder.
Opening of the doser
Key 4
Check the right function of the doser.

6
Absorbing resistance coffee boiler .
Key’s 1 + 5
Check through the ampere meter if the coffee boiler is absorbing.
Absorbing resistance coffee boiler
Key’s 2 + 5
Check through the ampere meter if the steam boiler is absorbing.
Function of the pump
Key 4 + water knob open
Check the right function of the pump.
Check the noise of the pump
Functions of the led.
Key’s 1+5 water knob open
Check the functions and the lightness of all the led.
Reed sensor for water level
The water tank has to be empty.
Start taking it off very slowly.
The led D6:
First it has to be turned off
then it has to be turned on
then it has to be turned off again
Opening the service door
Open the service door and check that the key number 5 is turned on
.
Drip tray
Take off the drip tray and check that it’s turned on the led number
7 and the key number 5.
Brewing unit
Take off the brewing unit and check that the key number 4 is turned
on.

7
Test program INCANTO Digital
In test program it is very easy to locate the broken parts, and the time to adjust it becomes lesser.
To enter in test program the machine has to be turned off, and the hot water steam knob closed.






 


For entering in Test program push the following key’s
Push the key’s 3 and 5 and turn on the
machine by the main switch.
The display is indicating the version of the software.
Let go of the key’s. Now the machine is in test program.
Rotation anticlockwise of the gear motor
Key 1
Check the right rotation anticlockwise of the gear motor
and that the brewing unit is going upwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in work position.
on the display it will appear number 1.
Rotation clockwise of the gear motor.
Key 2
Check the right rotation clockwise of the gear motor
and that the brewing unit is going downwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in home position.
on the display it will appear number 2.
Function coffee
grinder
Key 3
Check that the coffee grinder is rotating clockwise.
When the doser is full.
on the display it will appear number 3
Check the noise of the coffee grinder
Opening of the doser
Key 4
Check right function of the doser.
Check that the doser isn’t noisy.
Activating the doser pushing the key number 4, the number 3 has to
be switched off.
Absorbing resistance coffee boiler
Key’s 2 + D6
Check through the ampere meter, if the coffee boiler is absorbing

8
Absorbing resistance steam boiler
Key’s 3 + D6
Check through the ampere meter, if the steam boiler is absorbing
Function of the pump
Key’s 1 +D7 + water knob open
Check the right function of the pump.
Check the noise of the pump.
Boiler temperature
Key’s 4 + D6 + D7
With this function it is possible to check
the present temperature of the boiler.
Reed sensor for water level
The water tank has to be empty.
Start taking it off very slowly.
The number 7 on the display:
has to be turned off
then it has to be turned on
then it has to be turned off again.
Opening the service door
Open the service door and check that the key number 9 is turned off.
Drip tray
Take off the drip tray and check that the numbers 5 and 9 on the
display is turned off
Brewing unit
Take off the brewing unit and check that the key number 6 is turned
off

9
Test program INCANTO with SBS
In test program it is very easy to locate the broken parts, and the time to adjust it becomes lesser.
To enter in test program the machine has to be turned off, and the hot water steam knob closed.






 


For entering in Test program push the following key’s.
Push the key’s 3 and 5 and turn on the
machine by the main switch.
The display is indicating the version of the software.
Let go of the key’s.
Rotation anticlockwise of the gear motor
Key 1
Check the right rotation anticlockwise of the gear motor
and that the brewing unit is going upwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in work position.
on the display it will appear number 1.
Rotation clockwise of the gear motor.
Key 2
Check the right rotation clockwise of the gear motor
and that the brewing unit is going downwards correctly.
Check also that the gear motor isn’t noisy.
When the gear motor is in home position.
on the display it will appear number 2
.
Function coffee
grinder
Key 3
Check that the coffee grinder is rotating clockwise.
When the doser is full,
on the display it will appear number 3
Check the noise of the coffee grinder.
Opening of the doser
Key 4
Check the right function of the doser.
Check that the doser isn’t noisy.
Activating the doser pushing the key number 4, the number 3 has to
be switched off.

10
Absorbing resistance coffee boiler
Key’s 2 + D6
Check through the ampere meter, if the boiler is absorbing
Absorbing resistance steam boiler
Key’s 3 + D6
Check through the ampere meter, if the steam boiler is absorbing.
Function of the pump
Key’s 1 +D7 +water knob open
Check the right function of the pump.
Check the noise of the pump
Boiler temperature
Key’s 4 + D6 + D7
With this function it is possible to check
the present temperature of the boiler
Reed sensor for water level
The water tank has to be empty.
Start taking it off very slowly.
The number 7 on the display:
has to be turned off
then it has to be turned on
then it has to be turned off again.
Opening the service door
Open the service door and check that the key number 9 is turned off.
Drip tray
Take off the drip tray and check that the numbers 5 and 9 on the
display is turned off
Brewing unit
Take off the brewing unit and check that the key number 6 is turned
off.

11
Diagnosis Menu INCANTO DIGITAL & INCANTO DIGITAL SBS
HERE YOU CAN CHANGE AND SET DIFFERENT PARAMETERS AND MACHINE SETTINGS.
TO ENTER THE TEST MODE, PLEASE, PRESS BUTTONS 1 + 3 + 5 WHEN MACHINE IS SWITCHED OFF AND THEN, KEEPING THE FINGERS ON
THE BUTTONS SWITCH THE MACHINE ON. IN THE MENU, PLEASE, FOLLOW THE INDICATING ARROWS TO THE POINT “DIAGNOSIS” AND SELECT
WITH MENU/OK BUTTON. WITH THE ARROW BUTTONS YOU CAN SELECT THE PARAMETERS. WITH THE MENU BUTTON AND THE ARROW
BUTTONS YOU CAN CHANGE THE SETTING VALUES.
Maschine Parameter
Range
Function
1
Large coffee
N° Impuls 600
50 - 800
Quantity of coffee per cup counted with  owmeter impulses
600 Impulses are appx.. 200 ml
2
Small coffee
N° Impuls 200
50 - 800
Quantity of coffee per cup counted with  owmeter impulses
600 Impulses are appx.. 200 ml
3
Coffee
N° Impuls 350
50 - 800
Quantity of coffee per cup counted with  owmeter impulses
600 Impulses are appx.. 200 ml
4
Heater
Parameter K1 8
1 - 50
Temperature curve management
> refraim from adjusting !
5
Heater
Parameter K2 30
1 - 50
Temperature curve management
> refraim from adjusting !
6
Heater
Sensor Adjustment 96°C
94 -96 -98
> refraim from adjusting !
8
Temp. Normal
°C 86
70 - 130 °C
Selected temp. By continous coffee cycle.
9
Temp. High
°C 101
70 - 130 °C
Selected temp. when brewing coffee after 6 min.
10
Temp. 1° coffee
°C 105
70 - 130 °C
Selected temp. When the machine is switch ON or the boiler
temperature is lower than 50°C
11
Temp. Steam
°C 125
70 - 130 °C
Steam temperature
12
Temp. Increase
°C 0
0 - 50 °C
Controls the right level of temperature
> refraim from adjusting
15
Total grounds
0
0 - 50
Counter
16
Stop grounds
13
0 - 50
Display shows „empty dregs drawer“
17
Total Water
ml 1240
Total water quantity  owed trough coffee boiler
18
Water desc.
ml 1240
Total water quantity  owed trough coffee boiler from last descaling
cycle
21
Hot water  owrate
14 l/h
6 - 34
Flowrate of the pump
22
Hot water pump regul.
63000
Pump regulation setting factors. Automatically set-up by the machine.
23
Waterreserve counter
n° impulses 0
0 - 2500
Counter for water level in the water tank
24
Waterreserve stop
n° impulses 600
0 - 2500
Machine shows FILL WATERTANK after have reached the value
26
Machine status
36
Machine functionaly state.
27
Prod. Date
Day 8
Production date
28
Prod. Date
Month 10
Production date
29
Prod. Date
Year 2003
Production date
30
Serv. Date
Day 10
Service date
31
Serv. Date
Month 11
Service date
32
Serv. Date
Year 2003
Service date
>>
TO EXIT THE DIAGNOSIS MENU, PLEASE, USE ESC BUTTON OR SIMPLY SWITCH OFF THE MACHINE
