Saeco Minuto HD8867/11 User manual

OPERATING INSTRUCTIONS
Read carefully before using the machine.
Register your product and get support at
www.saeco.com/welcome
English
Type HD8867
EN
02
02

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to persons do not immerse
cord, plugs, or appliance in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.
7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10.Do not place on or near a hot gas or electric burner, or in a heated oven.
11.Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12.Do not use appliance for other than intended use.
13.Save these instructions.
SAVE THESE INSTRUCTIONS

CAUTION
This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.
1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2. Never use warm or hot water to fill the water tank. Use cold water only.
3. Keep your hands and the cord away from hot parts of the appliance during
operation.
4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6. Do not use caramelized or flavored coffee beans.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available
and may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the
counter top or table top where it can be pulled on by children or tripped
over.

2 ENGLISH
Congratulations on your purchase of a Saeco Minuto One
Touch Milk Carafe fully automatic coee machine!
To fully benet from the support that Saeco oers, please
register your product at www.saeco.com/welcome.
The machine is suitable for preparing espresso coee using
whole coee beans, and it is supplied with a milk carafe so
you can brew a perfect cappuccino in a quick and easy way.
In this user manual you will nd all the information you need
to install, use, clean and descale your machine.
CONTENTS
IMPORTANT..................................................................................................... 4
Safety Instructions....................................................................................................................................4
Warnings...................................................................................................................................................4
Cautions....................................................................................................................................................6
Compliance with Standards ......................................................................................................................7
INSTALLATION ................................................................................................. 8
Product Overview......................................................................................................................................8
General Description...................................................................................................................................9
PREPARING FOR USE.......................................................................................10
Machine Packaging.................................................................................................................................10
Machine Installation ...............................................................................................................................10
USING THE MACHINE FOR THE FIRST TIME ........................................................13
Circuit Priming ........................................................................................................................................13
Automatic Rinse/Self-Cleaning Cycle.......................................................................................................14
Manual Rinse Cycle..................................................................................................................................14
Measuring and ProgrammingWater Hardness........................................................................................18
“INTENZA+”Water Filter Installation ......................................................................................................19
Replacing the“INTENZA+”Water Filter...................................................................................................21
ADJUSTMENTS................................................................................................22
Saeco Adapting System...........................................................................................................................22
Adjusting the Ceramic Coee Grinder......................................................................................................22
Adjusting the Aroma (Coee Strength) ...................................................................................................23
Adjusting the Coee Dispensing Spout ...................................................................................................24
Adjusting the Coee Length ...................................................................................................................25

3 ENGLISH
BREWING ESPRESSO AND COFFEE ....................................................................26
Brewing Espresso and Coee Using Coee Beans....................................................................................26
Brewing Espresso and Coee Using Pre-Ground Coee...........................................................................27
MILK CARAFE..................................................................................................28
Filling the Milk Carafe .............................................................................................................................28
Inserting the Milk Carafe.........................................................................................................................29
Removing the Milk Carafe.......................................................................................................................29
Emptying the Milk Carafe........................................................................................................................30
BREWING A CAPPUCCINO ................................................................................31
Adjusting the Cappuccino Length............................................................................................................33
BREWING A CAPPUCCINO ................................................................................35
Adjusting the Latte Macchiato Length.....................................................................................................37
FROTHING MILK..............................................................................................39
Adjusting the Frothed Milk Length..........................................................................................................41
DISPENSING HOT WATER .................................................................................43
CLEANING AND MAINTENANCE ........................................................................45
Daily Cleaning of the Machine.................................................................................................................45
Daily Cleaning of the Water Tank.............................................................................................................46
Daily Cleaning of the Milk Carafe.............................................................................................................47
Weekly Cleaning of the Machine.............................................................................................................50
Weekly Cleaning of the Milk Carafe.........................................................................................................50
Weekly Cleaning of the Brew Group........................................................................................................55
Monthly Cleaning of the Milk Carafe.......................................................................................................58
Monthly Lubrication of the Brew Group ..................................................................................................63
Monthly Cleaning of the Brew Group with“Coee Oil Remover”.............................................................64
Monthly Cleaning of the Coee Bean Hopper..........................................................................................66
DESCALING.....................................................................................................67
ACCIDENTAL INTERRUPTION OF THE DESCALING CYCLE .....................................73
PROGRAMMING..............................................................................................74
The following settings can be adjusted...................................................................................................74
How to Program the Machine .................................................................................................................75
MEANING OF THE DISPLAY ICONS.....................................................................77
TROUBLESHOOTING........................................................................................82
ENERGY SAVING..............................................................................................85
Stand-by.................................................................................................................................................85
Disposal ..................................................................................................................................................85
TECHNICAL SPECIFICATIONS............................................................................86
WARRANTY AND SERVICE ................................................................................86
Warranty.................................................................................................................................................86
Service ....................................................................................................................................................86
ORDERING MAINTENANCE PRODUCTS ..............................................................87

4 ENGLISH
IMPORTANT
Safety Instructions
This machine is equipped with safety devices. Nevertheless,
read and follow the safety instructions carefully and only use
the machine properly as described in these instructions to
avoid accidental injury or damage due to improper use of the
machine. Keep this user manual for future reference.
The term WARNING and this icon warn against possible
severe injuries, danger to life and/or damage to the machine.
The term CAUTION and this icon warn against slight
injuries and/or damage to the machine.
Warnings
• Connect the machine to a wall socket with a voltage
matching the technical specications of the machine.
• Connect the machine to a earthed wall socket.
• Do not let the power cord hang over the edge of a table or
counter, or touch hot surfaces.
• Never immerse the machine, the mains plug or power cord
in water: Danger of electrical shock!
• Do not pour liquids on the power cord connector.
• Never direct the hot water jet towards body parts: Danger
of burning!
• Do not touch hot surfaces. Use handles and knobs.
• Remove the mains plug from the wall socket:
- if a malfunction occurs;
- If the machine will not be used for a long time;
- before cleaning the machine.

5 ENGLISH 5
Pull on the mains plug, not on the power cord. Do not
touch the mains plug with wet hands.
• Do not use the machine if the mains plug, the power cord
or the machine itself is damaged.
• Do not make any modications to the machine or its
power cord. Only have repairs carried out by a service
centre authorised by Philips to avoid any hazard.
• The machine should not be used by children younger than
8 years old.
• The machine can be used by children of 8 years and upwards
if they have previously been instructed on the correct use of
the machine and made aware of the associated dangers or if
they are supervised by an adult.
• Cleaning and maintenance should not be carried out by
children unless they are more than 8 years old and super-
vised by an adult.
• Keep the machine and its power cord out of reach of chil-
dren under 8 years old.
• The machine may be used by persons with reduced physi-
cal, sensory or mental capabilities or lacking sucient
experience and/or skills if they have previously been
instructed on the correct use of the machine and made
aware of the associated dangers or if they are supervised
by an adult.
• Children should be supervised to ensure that they do not
play with the machine.
• Never insert ngers or other objects into the coee
grinder.

6 ENGLISH
Cautions
• The machine is for household use only. It is not intended
for use in environments such as canteens, sta kitchens of
shops, oces, factories or other work environments.
• Always put the machine on a at and stable surface.
• Do not place the machine on hot surfaces, directly next to
a hot oven, heater units or similar sources of heat.
• Only put roasted coee beans into the coee bean hopper.
If ground coee, instant coee, raw coee or any other
substance is put in the coee bean hopper, it may damage
the machine.
• Let the machine cool down before inserting or removing
any parts.
• Never use warm or hot water to ll the water tank. Use
only cold non-sparkling drinking water.
• Never clean with scrubbing powders or harsh cleaners.
Simply use a soft cloth dampened with water.
• Descale your machine regularly. The machine indicates
when descaling is needed. Not doing this will make your
appliance stop working properly. In this case repair is not
covered under your warranty!
• Do not keep the machine at temperature below 0 °C.
Residue water in the heating system may freeze and cause
damage.
• Do not leave water in the water tank if the machine is
not used over a long period of time.The water can get
contaminated. Use fresh water every time you use the
machine.

7 ENGLISH 7
Compliance with Standards
The machine complies with art.13 of the Italian Legislative
Decree dated 25 July 2005, no. 151“Implementation of the
Directives 2005/95/EC, 2002/96/EC and 2003/108/EC on the
restriction of the use of certain hazardous substances in elec-
trical and electronic equipment, as well as waste disposal”.
This machine complies with EU Directive 2002/96/EC.
This Philips appliance complies with all the applicable
standards and regulations relating to the exposure to
electromagnetic elds.

8
INSTALLATION
Product Overview
31
17
19
20
21
22
18
123
411 12 14
5
6
7
8
9
10
24 27
25 28
26 29
16
15
23
30
13

9 ENGLISH 9
General Description
1. Grinder adjustment knob
2. Coee bean hopper
3. Pre-ground coee compartment
4. Water tank + Lid
5. Coee bean hopper lid
6. Control panel
7. Coee dispensing spout
8. Full drip tray indicator
9. Cup holder grill
10. Drip tray
11. Coee grounds drawer
12. Brew group
13. Coee residues drawer
14. Service door
15. Water dispensing spout (removable)
16. Milk carafe
17. Power cord socket
18. Power button
19. Grease for the brew group (optional)
20. Power cord
21. Coee grinder adjustment key + Pre-ground coee measuring scoop
+ Tool to clean the coee outlet duct
22. Water hardness test strip
23. Cleaning brush (optional)
24. Espresso brew button
25. Coee brew button
26. Cappuccino brew button
27. Latte Macchiato brew button
28. "Aroma" - Pre-ground coee button
29. Menu button
30. ON/OFF button
31. Descaling solution- to be purchased separately

10 ENGLISH
PREPARING FOR USE
Machine Packaging
The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.
Machine Installation
1Remove the machine from the packaging.
2For best use, it is recommended to:
• Choose a safe, level surface where there will be no danger of over-
turning the machine or being injured.
• Choose a location that is suciently well-lit, clean and near an eas-
ily reachable socket.
• Allow for a minimum distance from the sides of the machine as
shown in the gure.
3Open the water tank lid.
4Lift the water tank using the handle.

11 ENGLISH 11
8Slowly pour the coee beans into the coee bean hopper.
Note:
Do not pour too many coee beans into the coee bean hopper as this will
reduce the grinding performance of the machine.
Caution:
Only coee beans must be put into the coee bean hopper. If ground
coee, instant coee, caramelized coee, raw coee beans or any
other substance is put in the coee bean hopper, it may damage the
machine.
9Put the lid back on the coee bean hopper.
10 Insert the plug into the socket located on the back of the machine.
11 Insert the plug on the other end of the power cord into a wall socket
with suitable power voltage.
1
2
5Rinse the water tank with fresh water.
6Fill the water tank with fresh water up to the MAX level and reinsert it
into the machine. Make sure it is fully inserted.
Caution:
Never ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.
7Lift the coee bean hopper lid.

12 ENGLISH
12 Switch the power button to “I” to turn on the machine. The“ ” button
ashes.
Yellow
13 To turn on the machine, simply press the“ ” button.
14 The control panel indicates that the circuit must be primed.
Note:
By keeping the button pressed for more than 8 seconds, the machine en-
ters the demo program. To exit the demo, disconnect the power cord and
turn the machine back on.

13 ENGLISH 13
USING THE MACHINE FOR THE FIRST TIME
When using the machine for the rst time, the following activities need to
happen:
1) The machine will prime the circuit;
2) The machine will perform an automatic rinse/self-cleaning cycle.
3) You need to perform a manual rinse cycle.
Circuit Priming
During this process, fresh water ows through the internal circuit of the
machine and the machine warms up. This takes a few minutes.
1Place an empty container under the coee dispensing spout and under
the water dispensing spout.
YellowYellowYellow Green
2Press the “ ” button to start the circuit priming cycle.
3The machine reminds you to install the water dispensing spout.
Press the " " button to conrm.
The machine starts dispensing water.
4The bar under the icon shows the operation progress. When the pro-
cess has been completed, the machine stops dispensing automatically.
5The control panel now shows the machine warm-up icon.

14 ENGLISH
Automatic Rinse/Self-Cleaning Cycle
When warm-up has been completed, the machine automatically performs
a rinse/self-cleaning cycle of the internal circuit with fresh water. This takes
less than a minute.
6Place a container under the coee dispensing spout to catch the small
amount of water which will be dispensed.
Yellow
7The machine performs an automatic rinse cycle. Wait for the cycle to
nish automatically.
Note:
You can stop dispensing by pressing the “ ” button.
Manual Rinse Cycle
During this process you activate the coee brewing cycle and fresh water
ows through the water circuit. This takes a few minutes.
1Place a container under the coee dispensing spout.
Green
8When the operations described above have been completed, the ma-
chine shows this display. You can now perform the manual rinse cycle.

15 ENGLISH 15
2Check that the machine shows this display.
3Select the pre-ground coee brewing function by pressing the “ ”
button. The machine shows this display.
Note:
Do not add any pre-ground coee into the compartment.
4Press the " " button. The machine will start dispensing water from
the coee dispensing spout.
5When dispensing has nished, empty the container. Repeat the opera-
tions from step 1 to step 4 twice, then continue with step 6.
GreenGreen
6Place a container under the water dispensing spout.
Green
7Press the “ ” button. The machine shows this display.

16 ENGLISH
10 Press the “ ” button to start dispensing hot water.
11 This icon is displayed. The machine reminds you to install the water
dispensing spout. Check that the water dispensing spout is correctly
installed. Press “ ” to conrm. The machine will start dispensing hot
water.
Green
Red
12 Dispense water until the no water icon appears.
Note:
The manual rinse cycle can be stopped by pressing the“ ” button.
Green
8Press the “ ” button.
9This icon is displayed.

17 ENGLISH 17
Green
13 At the end, ll the water tank again up to the MAX level. Now the
machine is ready to brew coee.
The display to the left will be shown.
Note:
The automatic rinse/self-cleaning cycle is initiated when the machine has
been in stand-by mode, or turned o , for more than 15 minutes.
When you have not used the machine for 2 or more weeks you also have
to perform the manual rinsing cycle At the end of the cycle, it is possible to
brew a coee.

18 ENGLISH
Measuring and Programming Water Hardness
Water hardness measuring is very important in order to dene the descal-
ing frequency and to install the “INTENZA+”water lter (for more details on
the water lter, see next chapter).
To measure the water hardness follow the steps below:
1Immerse the water hardness test strip (supplied with the machine) in
water for 1 second.
Note:
The test strip can only be used for one single measurement.
2Wait for one minute.
23 4
ABC
Intenza Aroma System
Machine Water Hardness Setting
1
3Check how many squares have changed colour to red and then refer to
the table.
Note:
The numbers on the water hardness test strip correspond to the water
hardness adjustment settings.
More precisely:
1 = 1 (very soft water)
2 = 2 (soft water)
3 = 3 (hard water)
4 = 4 (very hard water)
The letters correspond to the references that are located at the base of the
“INTENZA+” water lter (see next chapter).
Yellow
4
Press the “ ” button and scroll through the options by pressing the“ ”
button until the following icon is displayed.
Note:
The machine is supplied with a standard water hardness setting, suitable
for most types of water.
