Safco PanelMate 4158 User manual

A
B
C
D
E
MODEL NUM-
BER 4158
100415837: 1 of 1; Rev A; Rev Date 09-AUG-2016
PanelMate®Dry-Erase Board
For questions or concerns, please call
Safco Consumer Hot Line 1-800-664-0042
available Monday-Friday 7:30 AM to 5:00 PM (Central Time)
(English-speaking operators)
ASSEMBLY INSTRUCTIONS
Safco Products Company, New Hope, MN 55428
PART NO.
Frame 1 4158-01
Tray 1 4158-02
White Board 1 4158-03
Wire Hangers 2 4158-04
Hanger Tips 4 4158-08





LETTER
CODE DESCRIPTION QTY.
PARTS LIST
ASSEMBLED UNIT
WARNING:
Use ONLY
Dry-Erase Markers
on the White Board
surface.
C
B
E
D
Remove E Hanger Tips from the bottoms of D
Wire Hangers as shown below. Insert each wire
hanger into the two built-in clamps on each side by
gently pressing the clamp tabs down until the hang-
ers are in position. Replace the Hanger Tips onto the
bottoms of both of the
Wire Hangers.
1Hang the Dry-Erase Board onto your office panel
wall unit. Adjust the position of your Dry-Erase Board
on your wall by grasping the unit in both hands with
the back side facing away from you. With two fingers
of each hand simultaneously press the four clamp
tabs in and slide the unit up or down wire hangers to
the desired position, then release
the clamp tabs.
2
BACK VIEW
Hanger
Tips
Clamp Tabs
Clamp Tabs
A

Insert C White Board into A Frame with the white
surface facing toward the front. Carefully guide the
corners into the corner openings of the frame until it
stops completely.
1Slide the B Plastic Tray into position at the bottom
of the frame under the white board. Be sure to fully
seat the tray tabs on the back of the Tray into the
frame slots.
2
Writing surface
Frame
Corner
Openings
BACK VIEW TRAY BACK VIEW
Frame
Front
Tray
Tabs
Frame Front
Frame Slots
Tray
Frame and Tray
surround white board.
IMPORTANT READ and FOLLOW these instructions carefully!
CHECK ALL PACKAGING - there may be parts in it!
SORT and COUNT your parts - compare with the list below. If you find problems,
refer to the Product Warranty Registration form included with this product.
SAVE JUST IN CASE WE NEED THIS FOR ANOTHER SHEET:
