Safe Fleet FleetMind SSV9 Assembly instructions

© Safe Fleet | February 2021 | All rights reserved
Installation and Setup Guide
FleetMind
SSV9 DVR Monitor

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
2Part # 710-5001 R5
Contents
Introduction.........................................................4
Specications .......................................................4
Kit Contents.........................................................6
Back Panel ......................................................................................7
SD Compartment .................................................................................7
Right Side - USB Port..............................................................................8
Bottom Panel Connectors .........................................................................8
Camera Connection Cable .........................................................................9
Power and Trigger Cable ..........................................................................9
Making Connections.................................................11
Connections Overview ...........................................................................11
Camera Connection..............................................................................11
Trigger Connections .............................................................................12
Power Connection ...............................................................................12
Recommended Camera Locations and Settings ..........................13
Residential Front-Load (Curotto-Can) ..............................................................13
Commercial Front-Load ..........................................................................13
Roll-off and Rear-Load ...........................................................................14
Residential Side-Load ............................................................................14
System Conguration................................................15
System Menu Hierarchy ..........................................................................15
Accessing the System Conguration Menus ........................................................15
Setting Date/Time and Operating Language ........................................................17
Setting Video Parameters.........................................................................18
Specifying Record Settings .......................................................................21

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
3Part # 710-5001 R5
Specifying Alarm Settings ........................................................................23
Specifying Camera Settings.......................................................................25
Specifying Motion Detection Settings ..............................................................26
Specifying Monitor Display Settings................................................................28
Specifying Vehicle Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Specifying G-Sensor Settings .....................................................................31
User Management ..................................................33
System Information, Disk and File Management ..........................35
System Info.....................................................................................35
File Backup .....................................................................................36
Restore Default..................................................................................37
Encode Overview ................................................................................37
Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Adjusting On-Screen Display Settings ..............................................................39
Playing Back Videos.................................................40
Viewing Videos Directly on SSV9 Unit ..............................................................40
Viewing Videos on Windows PC ...................................................................45
Troubleshooting ....................................................46
LED signals .....................................................................................46
Startup and Runtime .............................................................................46
Touch screen and cameras .......................................................................47
Service & Support ...................................................48
Documentation and Warranty .....................................................................48
Technical Support ...............................................................................48

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
4Part # 710-5001 R5
Introduction
Introduction
This document introduces the SSV9 Six-Channel DVR Monitor and
provides instructions for its installation and system conguration.
The SSV9:
• Enables you to connect and record up to 6 cameras simultaneously.
• Supports NTSC and PAL standards.
• Comprises a built-in GPS receiver and G-sensor
• Supports 2 micro SD cards up to 128GB each.
Specications
Item Description
Panel Size 9” LED Digital Panel
Video system NTSC / PAL Automatic detection
Resolution 1280 X 3 (RGB) X720
Brightness 450 cd/m2
Contrast ratio 500:1
Screen mode 16:9
Field of view Top 85° / Bottom 85° / Left 85° / Right 85°
Video Inputs 6CH
Audio output 0.5W speaker
Dot pitch 0.15525(H) × 0.15525(V) mm
Active area 198.72(H) × 111.78(V) mm
Power supply DC9-36V / Automatic Power On/Off by ACC
Operating temperature (-20°C ~ +75°C )
Storage temperature (-30°C ~ +85°C )
Weight 600g
Trigger 6CH
External Dimensions L236.5XW 182XD35.9

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
5Part # 710-5001 R5
Introduction
ITEM DEVICE PARAMETER PERFORMANCE
System Main processor Hi3520DV300
Operating system Embedded Linux OS
Operating language English
Operating interface Touch screen/ support mouse
Password security User password/Admin password
Audio & Video Video standard PAL/NTSC
Video compression H.264
Image resolution 1080N/720P/960H/D1/CIF
Playback quality 1080N/720P/960H/D1/CIF
Compound mode A variety of ways
Image display Single/split/QUAD/2ch display optional
Audio Compression G.711A
Audio recording Audio & Video synchronized recording
Recording & Playback Recording mode Manual/Alarm/Auto
Video bit rate Full frame 4096Mbps 6 classes image quality optional
Audio bit rate 8KB/s
Storage media SD card + SSD storage
Video inquiry Inquiry by channel/Recording type
Local playback Playback by le
Firmware upgrading Upgrading mode Manual/Automatic
Upgrading method USB disk
Interface AV input 6ch aviation interface
SSD 1SSD
SD card 2 SDXC High speed card (up to 256GB)
USB interface 1 USB 2.0 (support U disk/mouse/download)
Ignition input 1 ACC signal
UART 1 LVTTL Level
Disk lock 1

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
6Part # 710-5001 R5
Kit Contents
Kit Contents
Front Panel
Controls and Indicators
BUTTON FUNCTION
CH1/2/3 Cycles through Camera Channels 1, 2 and 3 one by one in full screen
CH4/5/6 Cycles through Camera Channels 4, 5 and 6 one by one in full screen
2-SPLIT screen Cycles through Camera Channels “1 and 2”, “3 and 4”, “5 and 6”,“3 and 2”, “4 and 2”
4-SPLIT SCREEN Cycles through Camera Channels “1,2,3 and 4”, “3,4,5 and 6”
6-SPLIT SCREEN Displays all six camera channels

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
7Part # 710-5001 R5
Kit Contents
Back Panel
Showing GPS connector, lock, SD compartment open.
SD Compartment

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
8Part # 710-5001 R5
Kit Contents
Right Side - USB Port
Bottom Panel Connectors

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
9Part # 710-5001 R5
Kit Contents
Camera Connection Cable
Power and Trigger Cable

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
10 Part # 710-5001 R5
Kit Contents
Trigger Functions
TRIGGER FUNCTION
CH1 When trigger is activated: Display Channel 1 camera, no delay when trigger off.
CH2 When trigger is activated: Display Channel 2 camerawith color guides, no delay when trigger
off.
CH3 When trigger is activated: DisplaySplit ScreenChannel 3 camera on left and Channel 2 camera
on rightwith grid,5 second delay when trigger off.
CH4 When trigger is activated: DisplaySplit ScreenChannel 2 camera on leftwith gridand Channel 4
camera on right5 second delay when trigger off.
CH5 When trigger is activated: Display Channel 5 camera, no delay when trigger off.
CH6 When trigger is activated: Display Channel 6 camera, no delay when trigger off.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
11 Part # 710-5001 R5
Making Connections
Making Connections
Connections Overview
Camera Connection
Connect up to 6 cameras to the SSV9 using camera connectors CH1 through CH6.
 NOTE: Camera channels
Channels 2, 3, and 4 are special purpose cameras. To ensure full functionality, assign these channels appropriately, as
dened in the legend in the table on the following page.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
12 Part # 710-5001 R5
Making Connections
CAMERA TRIGGER SIGNALS (DIGITAL INPUTS) LEGEND
Channel Camera Purpose
1,5, 6 General purpose cameras.
2
Reverse. Color back-up guides superimposed on view.
3Left turn signal. Delayed cancellation of image display/record.
4Right turn signal. Delayed cancellation of image display/record.
See the Power and Trigger Cable section for functionality of all triggers.
Trigger Connections
Trigger wires must be connected to the vehicle’s outputs.
Ensure that cameras with special associated trigger signals (i.e., Reverse, Left Turn, Right Turn) are connected to the output
terminals receiving the appropriate vehicle input signals to the terminal block.
Power Connection
There are three wires in the power harness that control how the device boots up.
• Yellow – Battery
• Red – ACC or Battery
• Black – Ground
If it is required that the unit stay on even when the ignition is off, the red wire can be connected
to the same tap point as the yellow wire.
It is recommended that the 12 V tap is after the battery disconnect. (i.e., turning battery disconnect off eliminates 12 V to the
mobile platform; turning battery disconnect on reapplies 12 V). Other names for the battery disconnect are night switch and
kill switch.
 CAUTION: Do not connect to ignition!
The 12 V yellow power wire should not be connected to the vehicle’s ignition key switch.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
13 Part # 710-5001 R5
Recommended Camera Locations and Settings
Recommended Camera Locations and Settings
Optimal camera conguration will ultimately depend on customer preference and the requirements involved for the various
types of waste collection. As a guideline, FleetMind proposes the following congurations based on actual installations
performed by our installation team.
The congurations presented here are “minimal” congurations, i.e., not all 6 cameras need be used in each scenario. You
can use as many cameras as you deem appropriate for your particular application.
Residential Front-Load (Curotto-Can)
Commercial Front-Load

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
14 Part # 710-5001 R5
Recommended Camera Locations and Settings
Roll-off and Rear-Load
Residential Side-Load




© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
15 Part # 710-5001 R5
System Conguration
System Conguration
System Menu Hierarchy
Accessing the System Conguration Menus
In order to set up system conguration parameters, you must use the system menus.
1. Touch and hold the lower area of the screen to display the control panel.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
16 Part # 710-5001 R5
System Conguration
2. Press System.
3. Use the admin user name and, if required, enter the password.
For rst-time access, the default password 456789 is dened. You can change the password later using the User
Accounts menu.
The Main Menu displays.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
17 Part # 710-5001 R5
System Conguration
Setting Date/Time and Operating Language
1. From the main menu press System Settings.
The System Settings menu displays.
2. Select General Settings.
The General Settings menu enables you to set date and time parameters and choose an operating language.
3. You can set the date and time manually or automatically.
• To set date and time manually:
i. Touch their respective elds to display the numeric keypad.
ii. Use the keypad to specify new values; use the arrow keys to move the cursor position forward and backward.
iii. Press Enter when done.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
18 Part # 710-5001 R5
System Conguration
• To set date and time automatically using UTC time (Coordinated Universal Time, formerly Greenwich Mean Time, or
GMT) reported by the GPS:
i. Select the GPS time adopt checkbox.
The time on the SSV9 unit is coordinated with UTC time.
ii. To display local time for your current time zone, you must use the plus or minus checkboxes and the hours/
minutes numeric menu to specify the deviation from UTC.
For example: USA Eastern time is either UTC -5 or UTC -4, depending whether DST is in effect.
4. Select a date format.
5. Select a time format.
6. Select a language.
7. To save your changes, press Save.
Setting Video Parameters
1. From the System Settings menu, select Video Settings.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
19 Part # 710-5001 R5
System Conguration
The Video Settings menu enables you to specify video properties for each of the six channels, which are selectable
from the channel drop-down list.
After you select a channel from the list, you can apply properties for that channel as described in the following steps.
2. Set the video encoding size, which determines the level of video compression.
3. Select a view option from the horizontal mirror drop-down list (normal or mirror).
4. Select a desired option from the vertical ip drop-down list (normal or ip).
5. Select the frame rate—number of frames per second (fps). Generally, the higher the FPS, the smoother the motion
appears.
6. Select video encoding quality.

© Safe Fleet | February 2021 | All rights reserved
SSV9 Installation and Setup Guide
20 Part # 710-5001 R5
System Conguration
7. Select a type of bit stream, either xed or dynamic, according to your requirements. Dynamic can be used to adapt to
changing network conditions in order to provide playback with fewer stalls and/or re-buffering.
8. Set the bit stream rate.
9. Set overlay positions. SSV9 provides 4 overlays for video that can be turned on or off and repositioned on the screen:
• time
• channel
• (license) plate
• GPS
a. Use the checkboxes to turn on or off the overlays.
b. To reposition the overlays:
i. Press set position. The screen refreshes, showing a preview image.
ii. Touch a new position on the screen. The overlay moves to the new position.
iii. Press the back button to return to the Video Settings screen.
10. Once you have nished specifying all settings, press Save.
