Safe Fleet RVS Trong 6000 Series User guide
Trong™ -
Dual Camera Extendable Mobile DVR
With GPS Tracking and Live Remote Viewing
6000 SERIES
Set Up Manual
ENGINEERED FOR
VEHICLE SAFETY.
TM
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
2 3
INTRODUCTION
WIFI
This manual explains how to set up your Trong with our free Trong
Mobile App. This app allows you to access yourTrong recording
device via a WiFi signal provided by the device.
1. To Locate theTrong App, select the App Store in your phone, and
search "Trong".
2. The next step is connecting your phone to the Trong device via WiFi.
1) Open your phone WiFi settings in your phone. If theTrong has
power, it will send a Wi Signal.
2) Select the Wi Hotspot labeled "Trong".
3) You will be prompted to enter a WiFi password. Password:
8007641028
Here is an example showing how the TrongWi signal will appear in
iOS (This will also work with AndroidWi Setup):
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
4 5
SD FORMATTING
SD FORMATTING
3. Format your SD cards. Navigate to "Settings" in the app. Next
click on "Control."
4. If you are using 1 SD Card, select "Format SD 1".
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
6 7
SD FORMATTING
3G/4G
5. Once SD Card 1 is selected, click "OK" to conrm formatting.
If you have two SD cards, repeat for SD Card 2.
6. To connect to your Trong Device remotely using a 3G/4G SIM Card,
you'll need to set up your Device via the Trong App.
1) Go to Settings Tab.
2) Select "Network Settings"
3) On next page, select "3G/4G Network"
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
8 9
APN
APN
7. In 3G/4G Network menu, select "APN".
An APN is a code that identies the Sim Card network. This is
based on the cell/data carrier. T-mobile is set as default. Input the
appropriate APN for your Sim Card carrier.
At the time of creating this manual, carrier APNs are as follows:
T-Mobile: "fast.t-mobile.com"
AT&T: "phone" or "broadband"
Verizon: "vzwinternet"
8. Now that your APN is set, you'll have to make sure that you're
connecting to the correct server, the RVS server.
Return to "Network Settings" Menu.
Go to "Server Settings"
conrm server is correct: Dvr.Mobilemulelive.com
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
10 11
ALARM/TRIGGER
ALARM TYPES
9. To set an Alarm/Trigger, navigate to Alarm Settings from Settings Tab. 10. There are three alarm types:
• Speed - Alarm that is triggered when the speed of the vehicle
exceeds the set limit. Default Speed source is GPS Antenna.
• I/O - Alarm that is triggered when an I/O sensor wire receives
power (only available with Extender Harness) (p.14)
• G-Sensor - Alarm that is triggered when movement/G-force
exceeds a certain limit. This is useful for hard stops and sharp turns,
as well as collisions.
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
12 13
Speed Menu
Speed Menu
11. Speed Menu
Speed Source: How your Trong detects speed.
Leave "GPS" selected as default.
Speed Unit: Select MPH or KMH
GPS Mode: Default setting and should not be changed
Alarm Type: Parking/Low Speed/High Speed
Open: Activates Alarm
Limit: An alarm is triggered when this speed is exceeded
Hold: Length in seconds sensor must be triggered before an event occurs
Delay: How long the trigger period is registered as one trigger event
REC Upload: Send footage to server
Photograph: (Checkbox) Determines which cameras take a snapshot
upon triggering (if any)
Record Locked: (Checkbox) Protects cameras footage upon triggering
(if any)
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
14 15
ALARM
ALARM
12. I/O Alarm
I/0-1: Choose which I/O sensor to use for setup
Alarm Type: Urgent/Front Door/Back Door/etc
Trigger Mode: Alarm Urgency (Voltage Level)
Hold: Length in seconds sensor must be triggered it is indicated as an
event
Delay: Length in seconds trigger period is registered as one trigger event
Photograph: (Checkbox) Determines which cameras take a snapshot
upon triggering (if any)
Record Locked: (Checkbox) Protects cameras footage upon triggering
(if any)
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
16 17
G-SENSOR
GSENSOR
13. G-Sensor
Choose which axis that sensor should read to detect movement/
transform coordinates.
X: Horizontal / Y: Vertical / Z: Forward/Backward
Choose the limit (sensitivity) for which the event is triggered via number
value.
The higher the value, the higher the sensitivity. Experiment for desired
sensitivity, as this setting is your preference.
Open: Activate Axis
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
18 19
TRONG FAQ
TRONG FAQ
14. Trong FAQ
1. My camera looks backwards, how do I reverse the image?
The "Mirror" Function allows you to ip the camera image vertically
and horizontally.
1) Go To System Settings
2) Select Recording Settings
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
20 21
TRONG FAQ
TRONG FAQ
4) Select which Channel/Camera you'd like to adjust on the top line.3) Select MainbitStream
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
22 23
TRONG FAQ
TRONG FAQ
5)
a. Select "Mirror".
b. Adjust as desired.
A: In the Record Parameters page, select Camera Type, and select the
correct format for the cameras you are adding. If you are using AHD
cameras, please select 2*1080P & 2*720P. If you are using our standard
cameras, please select 2*1080P & 2*D1
Once this is done, please Reboot/Restart the Trong
15. Trong FAQ (Q 2)
Q: I plugged In my 2 additional Cameras and they are showing
up black.
a
b
REAR VIEW SAFETY ENGINEERED FOR VEHICLE SAFETY.
TM
24 25
TRONG FAQ
TRONG FAQ
16. Trong FAQ (Q 3)
Q: Camera 1 & 2 are showing black.
A: Under "Record parameters", please select TV System and select NTSC.
Then please Reboot/Restart the Trong
NOTES
If you have any questions
about this product, contact:
Rear View Safety, Inc.
1797 Atlantic Avenue
Brooklyn, NY 11233
800.764.1028
