ENSTROM 480 AND 480B OPERATOR’S MANUAL
AND
FAA APPROVED
ROTORCRAFT FLIGHT MANUAL SUPPLEMENT
SAFE FLIGHT®
POWERLINE DETECTION SYSTEM
* * * * *
REPORT NO. 28-AC-042
HELICOPTER SERIAL NO.
HELICOPTER REGISTRATION NO.
* * * * *
THIS SUPPLEMENT MUST BE CARRIED IN THE
HELICOPTER AT ALL TIMES IF EQUIPPED WITH THE
SAFE FLIGHT® POWERLINE DETECTION SYSTEM.
CHAPTERS 1, 2, 3, AND 4 ARE FAA APPROVED.
FAA APPROVED BY:
CHARLES L. SMALLEY, MANAGER
CHICAGO AIRCRAFT CERTIFICATION OFFICE
CENTRAL REGION
FEDERAL AVIATION ADMINISTRATION
FAA APPROVAL DATE: MARCH 11, 2011
THE ENSTROM HELICOPTER CORPORATION
2209 22ND STREET
MENOMINEE, MICHIGAN 49858-3515
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT i
Report No. 28-AC-042 Feb 24/11
LOG OF REVISIONS
Rev.
No.
Date FAA Approved
Original Mar 11/11
APPROVED FOR THE MANAGER
CHICAGO AIRCRAFT CERTIFICATION OFFICE
CENTRAL REGION
FEDERAL AVIATION ADMINISTRATION
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ii ENSTROM 480/480B RFM SUPPLEMENT
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT iii
Report No. 28-AC-042 Feb 24/11
ROTORCRAFT FLIGHT MANUAL SUPPLEMENT
POWERLINE DETECTION SYSTEM
TABLE OF CONTENTS
CHAPTER DESCRIPTION PAGE
Supplement Cover Page
Log of Revisions ......................................... i
Table of Contents ..................................... iii
List of Effective Pages ............................... v
INTRODUCTION.............................INTRO-1
CHAPTER 1 OPERATING LIMITATIONS .....................1-1
CHAPTER 2 NORMAL PROCEDURES ........................2-1
CHAPTER 3 EMERGENCY PROCEDURES .................3-1
CHAPTER 4 PERFORMANCE DATA ...........................4-1
CHAPTER 5 RESERVED ............................................5-1
CHAPTER 6 WEIGHT/BALANCE AND LOADING .......6-1
CHAPTER 7 HELICOPTER AND SYSTEMS
DESCRIPTION AND OPERATION............7-1
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

iv ENSTROM 480/480B RFM SUPPLEMENT
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT v
LIST OF EFFECTIVE PAGES
Report No. 28-AC-042 Feb 24/11
PAGE DATE
i Feb 24/11
ii Feb 24/11
iii Feb 24/11
iv Feb 24/11
v Feb 24/11
vi Feb 24/11
INTRO-1 Feb 24/11
INTRO-2 Feb 24/11
1-1 Feb 24/11
1-2 Feb 24/11
2-1 Feb 24/11
2-2 Feb 24/11
3-1 Feb 24/11
3-2 Feb 24/11
4-1 Feb 24/11
4-2 Feb 24/11
6-1 Feb 24/11
6-2 Feb 24/11
7-1 Feb 24/11
7-2 Feb 24/11
7-3 Feb 24/11
7-4 Feb 24/11
PAGE DATE
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

vi ENSTROM 480/480B RFM SUPPLEMENT
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT INTRO-1
Report No. 28-AC-042 Feb 24/11
INTRODUCTION
Intro-1. General
This supplement contains operating instructions,
procedures, and limitations for the Safe Flight® Powerline
Detection System. The supplement is divided into two basic
parts, the FAA approved RFM Supplement and
Supplemental Data provided by the Enstrom Helicopter
Corporation (Enstrom). Chapters 1, 2, 3, and 4 make up the
FAA approved RFM Supplement. It is required by Federal
Regulations that this supplement be carried in the
helicopter at all times if the Powerline Detection System is
installed.
For additional information regarding the supplement format
and text emphasis or definitions, refer to the basic flight
manual. Abbreviations noted in this supplement are listed
in Table Intro-1.
Intro-1. List of Abbreviations
CW Clockwise
PDS Powerline Detection System
RFM Rotorcraft Flight Manual
SENS Sensitivity
VDC Volt Direct Current
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

INTRO-2 ENSTROM 480/480B RFM SUPPLEMENT
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT 1-1
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
CHAPTER 1. OPERATING LIMITATIONS
1-1. General
NOTE
The use of this device does not alter the
published aircraft limitations in any way.
Refer to Section 1 of the basic Rotorcraft
Flight Manual.
1. The Powerline Detection System is designed for
either 50 Hz or 60 Hz power lines. The aircraft must be
equipped with the appropriate system for the power lines in
its operational area.
2. The Powerline Detection System will not warn
against lines, wires or strike hazards that do not emit an
electric field at a power line frequency. Some examples are:
a. Guy wires.
b. Telecommunications cables.
c. Direct Current (DC) power lines.
d. Unenergized power lines.
e. 50 Hz power lines if equipped with a 60 Hz detector.
f. 60 Hz power lines if equipped with a 50 Hz detector.
3. Due to static electrical build up on the aircraft, the
system may be unreliable at dew points below 0°C (32°F)
and should not be relied upon.
1-2. Marking and Placard
1. The following placard is required to be installed in
the aircraft, adjacent to the Powerline Detection System:
WARNING: THE PDS IS A PILOT AID ONLY
AND SHOULD NOT BE RELIED UPON AS A
SOLE MEANS OF AVOIDING POWER LINES
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

1-2 ENSTROM 480/480B RFM SUPPLEMENT
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT 2-1
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
CHAPTER 2. NORMAL PROCEDURES
2-1. General
1. The Powerline Detection System is meant to be a
pilot aid.
2. The pilot should continue to use all other power
line avoidance procedures.
2-2. Preflight
1. Check the antenna condition and security.
2-3. Prior to Engine Start
1. With electrical power applied to the aircraft, and
the avionics master switch ON, a small green light mounted
on the Powerline Detector will illuminate to indicate that
electrical power is applied to the unit.
2. Rotate the SENS control CW to maximum.
3. Place the PDS TEST switch on the instrument
panel to TEST.
4. The audio warning will activate. The visual warning
light will activate on the front panel of the Powerline
Detector.
5. Push the WARN/MUTE annunciator switch on the
Powerline Detector to activate the mute function disabling
the audio warning.
6. The yellow mute light will activate. Reset the mute
by pushing the annunciator switch a second time and the
yellow light will extinguish. Normally this latter, unmuted,
condition is used during takeoff.
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

2-2 ENSTROM 480/480B RFM SUPPLEMENT
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT 3-1
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
CHAPTER 3. EMERGENCY PROCEDURES
3-1. Emergency Procedures
1. Refer to the basic RFM.
3-2. Abnormal Procedures
1. Loss of power to the Powerline Detection System
will disable the unit. Fly the aircraft normally without the
system operational.
2. If the Powerline Detection System fails with an
inappropriate continuous warning and the mute switch fails
to cancel this warning, pull the circuit breaker on the
circuit breaker panel marked PDS.
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

3-2 ENSTROM 480/480B RFM SUPPLEMENT
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT 4-1
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
CHAPTER 4. PERFORMANCE DATA
4-1. General
1. Refer to the basic RFM.
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

4-2 ENSTROM 480/480B RFM SUPPLEMENT
FAA Approved: Mar 11/11
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

ENSTROM 480/480B RFM SUPPLEMENT 6-1
Report No. 28-AC-042 Feb 24/11
CHAPTER 6. WEIGHT/BALANCE AND LOADING
6-1. General
1. A new weight and balance should be recalculated
per the instructions in Chapter 6 of the basic flight manual
using the information provided in Table 6-1.
Table 6-1. Weight and Balance Information
Equipment Weight
(lbs)
Arm
(in)
Moment
(in-lbs)
Powerline Detector 0.80 71.64 57.3
Antenna 0.33 297.09 98.0
Antenna Coupler 0.25 300.34 75.1
Misc.; connectors, wire,
etc. 0.50 185.00 92.5
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.

6-2 ENSTROM 480/480B RFM SUPPLEMENT
Report No. 28-AC-042 Feb 24/11
INTENTIONALLY LEFT BLANK
UNCONTROLLED COPY WHEN DOWNLOADED OR PRINTED
This electronic document is not linked to a subscription for revision control or distribution. Refer to the Optional Equipment
Supplement Publications Status link under the Technical Support Page of the Enstrom Helicopter website for the current revision
level of this Rotorcraft Flight Manual Supplement.
