1. Introduction
Congratulations on buying the Unicook
Airis Stove Guard.
This guide describes the use, installation
and maintenance of:
• Airis Sense with Bluetooth
• Airis Sense Wi-Fi with Bluetooth
and Wi-Fi
Before reading, please check the
Unicook website for an updated version
of this user manual.
1.1 Manufacturer Information
The product is designed and
manufactured by Safera, a Finnish
company of experts in smart and safe
cooking.
1.2 Distributor
Unicook Ltd
Unit 1, Villa Farm
Tunbridge Wells
Kent, TN3 9UN
Support product
Tél.: 0208 798 3462
2. Information and
Warnings
Follow these instructions carefully
and pay particular attention to the
instructions marked in the following
way:
WARNING
Follow instructions marked with a
warning accurately to prevent injury
to persons and damage to property.
ATTENTION
Follow instructions marked with a
note carefully to prevent damage to
property.
HINT
Hints give you useful hints on using
the appliance.
Contents
1. Introduction
2. Information and Warnings
3. Stove Guard Description
4. Installation
5. Connecting the Safera App
6. Using the Stove Guard
7. Maintenance
8. Optional features
9. Troubleshooting
10. Technical Speciications
11. For private households in EU:
Information on Disposal for Users of
WEEE
12. Conformity
13. Firmware License Terms and
Conditions

3
carried out by a qualiied electrician.
If the connection cord is damaged,
it must be replaced by the service
personnel of the manufacturer or
their representative to avoid hazards.
If the appliance was stored in a cold
space, it must be allowed to warm
up to room temperature before
connecting it to mains power.
2.2 Battery Safety Information
WARNING
Failure to follow the instructions
below may cause the batteries to
leak luid and gas, or even explode:
• Do not expose batteries to excessive
heat, insert them with wrong
polarity, or try to recharge them.
• Always replace all batteries at once,
using the same make, model and
age for all batteries.
• Do not leave empty batteries inside
the device for prolonged periods.
• Recycle the empty batteries
according to local regulations, do
not place in domestic waste.
• If the leaked luid gets into your
eyes, do not rub them, as there
is a risk of losing eyesight. Rinse
your eyes with water and contact a
physician immediately.
• If the leaked luid gets into your
mouth, rinse with water and contact
a physician immediately.
• If the leaked luid gets on your
skin or clothes, rinse with copious
2.1 General Warnings
WARNING
This device is designed to the
standard EN 50615 Category B -
prevention of ires originating from
overheating of oil in pans and pots
on a hob. This device may not be
suitable for ires originating from
lammable materials left in proximity
of the hob or on the hob. This
device may not be suitable for ires
originating from an oven.
Using Unicook Airis does not remove
your responsibility for safe cooking.
Read chapter 12 and 13 carefully for
limitations.
Unicook Airis does not replace
statutory home ire alarms. Ensure
that ire safety at your home follows
the local regulations.
Always take care when using the
cooker and keep children and pets
away.
Flame cooking is prohibited under
the cooker hood.
Unicook Airis is meant for household
use only. The appliance must not
be used in professional kitchens or
with cookers and hobs meant for
professional use.
Unicook Airis is not user serviceable.
For safety and reliability reasons, do
not disassemble the product. Contact
Unicook for all service needs.
Unicook Airis controls the stove and/
or oven only if it is equipped and
correctly coupled with the power
control unit Ⓑ.
All electrical connections must be

4
• Cookers and hobs equipped with a
timer, afterheat indicator, child proof
lock or integrated switch-o system
Unicook Airis is compatible with cookers
no wider than 90 cm. Also cookers with
multiple fuels (eg. gas & electric) are not
supported.
Ⓐ
Ⓑ
ATTENTION
For the most up to date mounting
methods and stove compatibility,
please refer to the “Installation
Wizard” -section of the Safera App,
see chapter 5.
amounts of water to prevent burns.
3. Stove Guard
Description
3.1 Purpose of Use
Unicook Airis is designed to improve
the safety of domestic cooking. See
compatibility in chapter 3.3. It is highly
eective at preventing cooking ires.
Please note that the appliance is
designed to prevent cooking ires. In
case of a ire, you must follow appropriate
procedures to prevent further damage.
If necessary, call Emergency Services,
explain the situation calmly and follow
the instructions given to you.
3.2 Appliance Description
Unicook Airis can be mounted on the
wall above the cooker. See adjacent
igures.
Ⓐ Sensor unit, mounted above the
stove
Ⓑ Power control unit, connected to
the stove (various models available,
see chapter 4.2)
Ⓒ Power bracket with extra batteries
The Sensor unit Ⓐand the power
control unit Ⓑare connected via a
wireless connection.
3.3 Compatibility
Unicook Airis is compatible with most
electrical cookers, hobs and ovens
meant for household use:
• Traditional cast-iron cookers and hobs
• Ceramic cookers and hobs
• Induction cookers and hobs

5
❸ OK Button
Sensors ❺
Ⓐ Sensor unit
❹ Indicator light
❻ Adhesive tape and
protection strips
Batteries
Ⓒ Power bracket with
extra batteries

6
- Step 1/4 Prepare for the installation4.Installation
Here are the main steps of the
installation:
Step 1/4
Prepare for the installation
Step 2/4
Install the power control unit Ⓑ
Step 3/4
Install the sensor unit Ⓐ
Step 4/4
Finish the installation (two options):
• Quick setup in default installation
position
• Guided setup with the Safera App
4.1 Check the package content
Check the product and the contents of
the package before installation:
Ⓐ Sensor unit, mounted above the
stove
Ⓑ Power control unit, connected to
the stove (various models available,
see chapter 4.2)
Ⓒ Power bracket with extra batteries
9 x Batteries for sensor unit (AA/LR6)
User and installation manual
WARNING
Please contact your vendor if you
notice anything unusual about the
appliance.

7
4.Installation - Step 2/4
4.2 Install the power control unit Ⓑaccording to the following
instructions
Install the power control unit Ⓑ
PCU6.3F
Fixed 3-phase connection.
See pages 8-9.
PCU6.1F
Fixed 1-phase connection.
See pages 10-11.
PCU10.2.-F
2-phase connection with ixed
installation.
See pages 12-13.
WARNING
If you are replacing the cooker or the
power control unit Ⓑ, pair the power
control unit again using the Safera
App (see chapter 5).

8
PCU6.3F - Installation
Fixed 3-phase connection.
42 mm
239 mm
113 mm
OUTIN
PE
N
L1
L2
L3
PE
N
L
L
L
MAX 16A
MAX 16A
MAX 16A
MICRO DISCONNECTION
225,5 mm
78 mm
60 mm
60 mm
95 mm
WARNING
Turn the power o at the isolation
switch and ensure that all rings, and
if relevant the oven, is turned o.
OUT-wires are always energized when
the power control unit Ⓑis connected
to the mains power. If a wire is loose, it
must be properly covered.
Do not install the power control unit Ⓑ
where it will be exposed to excessive
heat: See operational ambient tem-
perature on the power control unit.
ATTENTION
Install the power control unit Ⓑso
that it is not exposed to moisture.
Check that all cables can move freely.

9
OFF
1
2
6
4
3
4xA
A
A
A
B
2xB
IN
L3
L2
L1
IN
OUT
IN
OUT
IN
OUT
N
PE
OUT
5
IN
Phase order can be freely chosen. If only two phases
are used, connect them to the terminals L1 and L2.

10
PCU6.1F - Installation
Fixed 1-phase connection.
OUTIN
PE
L/N
L
PE
N
L
230 V MAX. 35 A
MICRO DISCONNECTION
42 mm
239 mm
113 mm
225,5 mm
78 mm
60 mm
60 mm
95 mm
WARNING
Turn the power o at the isolation
switch and ensure that all rings, and
if relevant the oven, is turned o.
OUT-wires are always energized when
the power control unit Ⓑis connected
to the mains power. If a wire is loose, it
must be properly covered.
Do not install the power control unit Ⓑ
where it will be exposed to excessive
heat: See operational ambient tem-
perature on the power control unit.
ATTENTION
Install the power control unit Ⓑso
that it is not exposed to moisture.
Check that all cables can move freely.

11
L OUT
N
N
L
OUT
IN
IN
PE
OFF
12
6
4xA
A
A
A
B
42xB
3
5
OUT
X
IN

12
PCU10.2F - Installation
2-phase connection with ixed installation.
63 mm
122 mm 231 mm OUTIN
PE
L1
L2/N
PE
L1
L2/N
208-240 V MAX. 50 A
50-60 Hz
195 mm
140 mm
WARNING
Turn the power o at the isolation
switch and ensure that all rings, and
if relevant the oven, is turned o.
The supply to the hob/cooker is
always energised when the PCU is
connected to the mains power.
Do not install the power control unit where
it will be exposed to excessive heat: See
operational ambient temperature for the
power control unit Ⓒ.
The PCU can be installed behind an
oven, below a hob, under a plinth or
in a kitchen cupboard.
ATTENTION
The PCU must be installed in a
position where it cannot become
damp or wet.

13
A
A
A
A
A
A
B
B
B
B
IN
OUT
Ground wire is
connected to
the cover.
6Connect the plug
(IN) to the wall
socket.
3Connect the OUT and IN cables to the
screw terminals (cables not included).
26xA
Remove the cover
to access internal
wiring.
46xA
Replace the cover.
54xB
Mount
the power
control unit
Ⓒ on the wall
behind the
cooker or into
the cabinet
next to the
cooker.
Connect
the stove
plug to the
power control
unit (OUT).
7
Take o
fuses to
the stove.
OFF
1
L2/N
PE
IN
L1
PE
OUT
IN

14
4.Installation - Step 3/4 Install the sensor unit Ⓐ
4.3 Install the batteries in the sensor unit Ⓐto activate the wireless
connection to the power control unit Ⓑ
1. Open the sensor unit Ⓐby pushing one of the bracket's claws on the side gently
with a lat headed screw driver and pulling o the sensor unit Ⓐfrom the bracket.
2. Place three batteries in the sensor unit Ⓐand six batteries in the power bracket Ⓒ.
Notice the battery polarity marked on the sensor unit and on the bracket.
3. Place the sensor unit Ⓐover the power bracket Ⓒso that the cover snaps into
place on both psides.
4. Switch on the power supply to the power control unit Ⓑ. The sensor unit Ⓐand
the power control unit are now connected.

15
WARNING
Ensure the correct sensor direction:
sensors ❺should look towards the
cooker.
Make sure that there is no obstruction
in the sensor's ❺ield of view between
the sensor unit Ⓐ and the stove.
4.4 Mount the sensor unit Ⓐ
1. Remove grease and dirt from the
surface before attaching the sensor
unit Ⓐwith the adhesive tape ❻.
2. Remove the protection strips from
the adhesive tape ❻.
3. Mount the sensor unit Ⓐaccording
to the table below and adjacent
igures.
Installation Height (H)
Wall mount, cooker width
up to 60 cm
50 cm *
± 5 cm
Wall mount, cooker width
from 60 cm to 90 cm
60 cm
± 5 cm
* For Quick Installation use the default
position for electric cookers: no
coniguration is needed and you can
inish the installation by checking the
working order according to the chapter
4.6.
The sensor unit Ⓐshould be mounted
on the centerline of the cooker.
Make sure that the mounting location
is free of direct sunlight and other
sources of powerful light and heat.
H
+8°-8°
Sensors ❺
ield of view
max.
60 cm

16
4.5 Conigure the sensor unit Ⓐ
You have two options to set up
the sensor unit Ⓐ in your kitchen
environment:
1. The sensor unit Ⓐ is installed in the
default installation position
• Unicook Airis is pre-conigured
for default installation height of
50 cm on a wall above an electric
cooker up to 60 cm wide.
• When default installation is used,
no coniguration is needed and
you may inish the installation
by checking the working order
according to the chapter 4.6.
2. The sensor unit Ⓐ is installed in
other than the default installation
position or cooker type
• The sensor unit Ⓐ needs to be
conigured by using the Safera
App (see chapter 5).
4.Installation - Step 4/4 Finish the installation
4.6 Check the working order
1. Turn on one plate with medium high
power. With an induction cooker use
a suitable pan.
2. Press and hold the OK button ❸for
5 seconds: the system should cut o
the cooker power.
3. Test there is no power to the hob by
attempting to switch on a ring. If ok,
switch o the hob.
4. Return the cooker power by pressing
the OK button ❸: the indicator light
❹should lash green once. If not, see
Troubleshooting in chapter 9.
5. Working order checked successfully:
Date Installer

17
5. Connecting the
Safera App
With the Safera App you can easily set
up the sensor unit Ⓐto it your speciic
kitchen environment.
With the App you can also update the
sensor unit Ⓐwith the latest irmware
(recommended) and use the advanced
features of Unicook Airis (see chapter
6).
5.1 Connect the Safera App
with Unicook Airis
1. Download and install Safera App
to your mobile phone (search for
“Safera App” in the App Store or Play
Store).
2. Open the Safera App and choose
"Connect to a New Device".
3. Press the OK button ❸on the sensor
unit Ⓐ. The indicator light ❹starts
lashing blue.
4. Choose “Safera” or “Safera Sense”
which should appear on the list.
5. If asked for Bluetooth pairing, allow
it. Android version will also ask for
location permission, which is needed
to use Bluetooth.
5.2 Update the sensor unit's Ⓐ
irmware
Check for irmware updates: open the
main menu, choose “Firmware Update”
and install the update if available.
ATTENTION
It’s highly recommended to check
for and install a irmware update if
available during the installation.
5.3 Set up the sensor unit Ⓐ
with the Safera App
In the Safera App open the main menu
and the “Installation Wizard”.
The App will guide you through
questions regarding your kitchen and
cooker type and then set up the sensor
unit Ⓐfor your installation environment.
By completing the wizard you have
successfully inished the installation
and the stove guard is ready for use.
Fill in the installation date and installer
name to the chapter 4.6. in previous
page.

18
6. Using the Stove
Guard
6.1 Cooking Safety
Unicook Airis monitors the stove
area and improves cooking safety by
sounding an alarm and switching o the
cooker power if it detects a potentially
dangerous cooking situation. These
situations may be, for example, an
overheating pan or prolonged lack of
human presence during cooking.
When you hear the alarm:
1. Check the situation calmly. If there
is no danger, you can prevent the
cooker power from being switched
o by pressing the OK button ❸
during the alarm and continuing to
cook.
2. If you do not press the OK button ❸
in 15 seconds, the stove guard will
switch o the cooker and the oven:
after switching o, a repetitive signal
will sound and the indicator light ❹
will lash red for 15 minutes.
3. When there is no more danger, you
can return the power to the cooker
and oven by pressing the OK button
❸. First, turn the hob switches to the
o position.
4. Ensure that the hazardous situation
will not reoccur.
WARNING
Please note that not all possible
hazards may be detected. Also note
the limitations in chapters 12 and 13 .
6.2 Remote alarm
With Airis Sense Wi-Fi, you may activate
the remote alarms by setting up a Wi-Fi
connection via Safera App (see chapter
5.1 how to connect the Safera App) and
creating a Safera Cloud account which
allows you to set up the remote alarm
settings.
6.3 Smart Cooking
By connecting the Safera App (iOS),
you may use the smart cooking features
which assist you in cooking with
automated timers and temperature
assistant. Install the Safera App
according to the chapter 5.1.

19
6.4 Indicator light ❹
LED color Sound Function
Red lashing fast Yes, high
pitch
Cooker danger
Red lashing
once
Yes, low
pitch 3-tone
Battery low
Blue lashing No Airis is looking for a Bluetooth connection to a mobile
phone
Blue light,
constant
No Sensor unit Ⓐis in software update mode. Keep your
mobile phone close and do not shut down the Safera App
during software update.
Green light,
constant
No Sensor unit Ⓐ is entering software update mode. If the
green light does not turn blue in two minutes, remove and
re-insert batteries.
Purple light,
constant
No Sensor unit Ⓐis in Optional Accessory Pairing Mode
Yellow light,
constant
No Factory reset in progress, may take a couple of minutes
Blue lash Yes,
medium
pitch 3-tone
Water leakage alarm, see chapter 8.2.

20
7. Maintenance
7.1 Regular maintenance
To ensure continued safe and reliable
operation, follow these maintenance
instructions at least once every 12
months or more frequently if needed:
1. Press the OK button ❸to perform
self-diagnostics: when the sensor unit
Ⓐis in working order, the indicator
light ❹will lash in green. Any other
color indicates a problem – please see
chapter 9 Troubleshooting.
2. If there is visible dirt or grease in the
sensor unit Ⓐ, wipe the sensor unit
with a soft cloth moistened with
water or a mild detergent, such as
washing up liquid. Avoid pressing the
appliance buttons and sensors ❺.
3. It’s highly recommended to always
have the latest irmware version of
the sensor unit Ⓐinstalled, so check
that your Safera App and the device
irmware is up to date (see chapter
5.2).
7.2 Battery life and low battery
In normal use, the batteries should last
between 2 to 3 years (Airis Sense) and 1
to 2 years (Airis Sense Wi-Fi). Frequent
usage of the sensors and the Bluetooth
connection with the smartphone app
and a low quality wii-connection will
tend to decrease battery lifetime.
The sensor unit Ⓐbeeps and the
indicator light ❹lashes red when the
batteries are depleting (typically within
2 weeks of expiration). Replace the
batteries according to the following
instructions.
You may reset the low battery alarm for
12 hours by pressing the OK button ❸.
If the batteries are not replaced,
Unicook Airis switches itself o when
the batteries are fully depleted. If the
system is equipped with the power
control unit Ⓑ, it will also shut down the
electric power to the stove.
7.3 Battery replacement
1. Open the sensor unit Ⓐby pushing
the cover lock on the side gently with
a lat headed screw driver and pulling
o the sensor unit Ⓐfrom the bracket.
2. Place three AA/LR6 Alkaline batteries
in the sensor unit Ⓐand six batteries
in the power bracket Ⓒ. Notice
the battery polarity marked on the
sensor unit and on the bracket.
3. Place the sensor unit Ⓐover the
power bracket Ⓒso that the cover
locks snaps into their places on both
sides.
Other manuals for PCU6.3-F
4
This manual suits for next models
2
Table of contents
Other SAFERA Security Sensor manuals
Popular Security Sensor manuals by other brands

green-i
green-i PDS-PRM Product guide

Olympus
Olympus EPOCH 6LT User Interface Guide

DSC
DSC PG9974(P) installation instructions

Buckingham
Buckingham 4812 Series Instructions & warnings

Pepperl+Fuchs
Pepperl+Fuchs GLP30-RT/40b/103/123/143 manual

Johnson Controls
Johnson Controls Tyco Kantech T.REX Installation sheet

PCB Piezotronics
PCB Piezotronics ICP 108B03 Installation and operating manual

SENSTAR
SENSTAR UltraWave E4FG0101 Product guide

Crow
Crow SH-FLOOD-9F instruction manual

Safe Signal
Safe Signal WFDNFS Installation and maintenance instructions

Dräger
Dräger Flame 2100 Instructions for use

Alarmtech
Alarmtech MC 746-E instruction manual
