Busch-Jaeger Busch-Infoline 1563 U User manual

1473
-1-8302 │ Rev. 01 │ 17.12.2012
Operating Instructions
Busch
-Infoline®
Pos: 2 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Titelbl ätter/Infoline/ Titelblatt - 1563-1564 @ 25\mod_1341 325301048_15.docx @ 221953 @ @ 1
1563 U
Busch warning signal insert
1564 U
Light signal insert
=== Ende der Liste für Textmarke Co ver ===
Datasheet.Directory

Operating Instructions
Busch-Infoline®
Operating Instructions | 1473-1-8302
— 2 —
Pos: 4 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Inhaltsver zeichnis (--> Für alle Dokume nte <--)/Inhaltsverzeic hnis @ 19\mod_1320649044386_ 15.docx @ 109653 @ @1
1Safety.......................................................................................................................................................................3
2Intended use............................................................................................................................................................3
3Environment.............................................................................................................................................................3
4Technical data..........................................................................................................................................................4
5Setup and function...................................................................................................................................................4
5.1 Features of function and equipment........................................................................................................4
5.1.1 Busch Alarm signal insert 1563 U...........................................................................................................4
5.1.2 Light signal insert 1564 U........................................................................................................................4
5.2 Possible combinations ............................................................................................................................5
6Installation and electrical connection .......................................................................................................................6
6.1 Requirements for the electrician .............................................................................................................6
6.2 Electrical connection...............................................................................................................................7
6.3 Mounting the device insert......................................................................................................................8
6.4 Setting acoustic signalling with jumper (applies only to 1563 U).............................................................8
6.5 Setting signal sequence with jumper (applies only to 1563 U)................................................................9
=== Ende der Liste für Textmarke TOC ===

Operating Instructions
Busch-Infoline®
Safety
Operating Instructions | 1473-1-8302
— 3 —
Pos: 6 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Überschr iften (--> Für alle Doku mente <--)/1. Ebene/S - T/Sic herheit @ 18\mod_130261279179 0_15.docx @ 103357 @ 1 @ 1
1 Safety
Pos: 7 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Sicher heitshinweise und Hinweise ( --> Für alle Dokumente <--)/W arnhinweise/Sicherheit - 230 V @ 18\mod_13026068 16750_15.docx @ 103308 @ @ 1
Warning
Electric voltage!
Risk of death and fire due to electrical voltage of 230 V.
– Work on the 230V supply system may only be performed by authorised electricians!
– Disconnect the mains power supply prior to installation and/or disassembly!
Pos: 8 /#Neustruktur#/ Online-Dokumentatio n (+KNX)/Sicher heitshinweise und Hinweise ( --> Für alle Dokumente <--)/W arnhinweise/Sicherheit - Sc halldruck 70 dB @ 25\mod_134137963 6575_15.docx @ 222233 @ @ 1
Warning
High sound pressure level!
High sound pressure level of 70 dB at a distance of 1 m. Problems with concentration are possible
in this area.
- Safety distance must be adhered to!
Pos: 9 /#Neustruktur#/ Online-Dokumentation (+K NX)/Überschrif ten( --> Für alle Dokumente <--) /1. Ebene/A - F/Bestimmungsge mäßer Gebrauch @ 18\mod_130276332 1316_15.docx @ 103483 @ 1 @ 1
2 Intended use
Pos: 10 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Bestimmungsg emäßer Gebrauch (--> Für alle Dokumen te< --)/Busch-Dimmer/Bes timmungsgemäßer Gebrauc h @ 23\mod_1335350449857_1 5.docx @ 208763 @ @ 1
The device is to be used exclusively with the components that are supplied and licensed as described in chapter
"Setup and function".
Pos: 11 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/U - Z/ Umwel t @ 18\mod_130261415 8967_15.docx @ 103383 @ 1 @ 1
3 Environment
Pos: 12 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sicher heitshinweise und Hin weise( --> Für alle Dokumente <--)/Hinweis e - Umwel t/Hin weis - Umwe lt - Hinweis Elektr ogeräte @ 18\mod_1302763973 434_15.docx @ 103500 @ @1
Consider the protection of the environment!
Used electric and electronic devices must not be disposed of with domestic waste.
– The device contains valuable raw materials which can be recycled. Therefore, dispose of the
device at the appropriate collecting depot.
Pos: 13 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sicher heitshinweise und Hinweise ( --> Für alle Dokumente <--)/Hinweis e - Umwelt /Hin weis - Umwe lt - Entsorgung Elektro geräte @ 20\mod_1325760695 972_15.docx @ 136583 @ @1
All packaging materials and devices bear the markings and test seals for proper disposal. Always dispose of the
packaging material and electric devices and their components via the authorized collecting depots and disposal
companies.
The products meet the legal requirements, in particular the laws governing electronic and electrical devices and
the REACH ordinance.
(EU Directive 2002/96/EC WEEE and 2002/95/EC RoHS)
(EU REACH ordinance and law for the implementation of the ordinance (EC) No.1907/2006)
Pos: 14 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++@ 9\mod_12688 98668093_0.doc x@ 52149 @ @ 1

Operating Instructions
Busch-Infoline®
Technical data
Operating Instructions | 1473-1-8302
— 4 —
Pos: 15 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/S - T/Technische Date n @ 11\mod_1279185386320_15. docx @ 83019 @ 1 @ 1
4 Technical data
Pos: 16 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Technisc he Daten/Infoline/ Technische Daten - 1563-1564 @ 25\mod_1341325 347703_15.docx @ 221980 @ @ 1
General
Nominal voltage 9.5 - 28 V AC / 9.5 - 35 V AC
Rated frequency 50/60 Hz
Nominal current 60 mA AC / 30 mA DC
Sound pressure (applies only to 1563 U) 70 dB / 1 m
Sound frequency (applies only to 1563 U) 2.3 kHz
Protection class IP 20
Type of protection for device SELV
Operating temperature range 5 ... 40 °C
Pos: 17 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/A - F/Aufbau und Funktion @ 11\mod_1279185 435352_15.doc x@ 83027 @ 1 @ 1
5 Setup and function
Pos: 18 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/A - F/Funktions- und Auss tattungsmerkmale @ 23\mod_1 336557630140_15.d ocx @ 209136 @ 31 @ 1
5.1 Features of function and equipment
Pos: 19 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++1 LeerzeileAbstand ++++++++++++@ 24\mod_13379292890 45_0.docx @ 213673 @ 33 @ 1
Pos: 20 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 3. Ebene/1563 U-12 Busch-Warnmelde-Ei nsatz @ 26\mod_1341497526019_ 15.docx @ 222720 @ 3 @ 1
5.1.1 Busch Alarm signal insert 1563 U
Pos: 21 /#Neustruktur #/Online-Dokumentation (+K NX)/Aufbau und Funktion/I nfoline/Funktione n - 1563 @ 25\mod_1341325369500_1 5.docx @ 221994 @ 3 @ 1
For optical and acoustic alarm signalization. Type of signalling (call / alarm call, in accordance with DIN VDE
0834) selectable via internal jumper. Acoustic signalling via the internal jumper can be deactivated.
Alarm activation is triggered by applying the operating voltage.
Alarm signal:
– Acoustic and optical signal (according to DIN VDE 0834) in discontinuous change (switch-off function).
– Permanent acoustic and optical signal, or with interruption.
Pos: 22 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 3. Ebene/1564 U-1x Lichtsi gnal-Einsatz @ 26\mod_1341 497606863_15. docx @ 222748 @ 3 @ 1
5.1.2 Light signal insert 1564 U
Pos: 23 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Aufbau und Funk tion/Infoline/F unktionen - 1564 @ 26\mod_1341497 575566_15.docx @ 222733 @ @1
The insert serves for optical alarm / status signal. The light signal lights up at a permanent alarm. Alarm activation
is triggered by applying the operating voltage.
Alarm signal:
– Permanent light signal.
Pos: 24 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Doku mente <--)/++++++++++++Seitenumbruch++++++++++++ @ 9\mod_126889866 8093_0.docx @ 52149 @ 2 @ 1

Operating Instructions
Busch-Infoline®
Setup and function
Operating Instructions | 1473-1-8302
— 5 —
Pos: 25 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/G - L/Kombina tionsmöglichkeiten @ 19\mod_1320312 769153_15.docx @ 109520 @ 2 @ 1
5.2 Possible combinations
Pos: 26 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Kombinati onsmöglichkeiten/I nfoline/Kombina tionsmöglichkeiten - 1563-156 4 @ 25\mod_1341325390281_ 15.docx @ 222008 @ @1
Busch warning signal
insert
Light signal insert
1563 U 1564 U
1518 U
X
1518 U
X
1511 U
X
1511 U
X
1515 U-12
X
1515 U-12
X
1531 U
X
1531 U
X
1573 C-21x
X
1573 C-21x
X
1573 CN-84
X
1573 CN-84
X
Pos: 27 /#Neustruktur #/Online-Dokumentation (+K NX)/Steuermodule - On line-Dokumentatio n (--> Für alle Dokumente <--)/++++++++++++Seitenumbruch ++++++++++++@ 9\mod_12688 98668093_0.docx @ 52149 @ 1 @ 1

Operating Instructions
Busch-Infoline®
Installation and electrical
connection
Operating Instructions | 1473-1-8302
— 6 —
Pos: 28 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 1. Ebene/M - O/Montage und e lektrischer Ansc hluss@ 23\m od_1336477157864_15.d ocx @ 209033 @ 1 @ 1
6 Installation and electrical connection
Pos: 29 /#Neustruktur #/Online-Dokumentation (+K NX)/Sicherheitshin weise und Hinweise (--> Für alle Dokumente <--) /Warnhinweise/Sic herheit - Niederspannungs- und 23 0 V-Leitungen @ 23\mod_13365 58868201_15.docx @ 209164 @ 2 @ 1
Warning
Electric voltage!
Risk of death due to electrical voltage of 230 V during short-circuit in the low-voltage line.
– Low-voltage and 230 V lines must not be installed together in a flush-mounted socket!
Pos: 30 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Sicher heitshinweise und Hi nweise ( --> Für alle Dokumente <--)/W arnhinweise/Sicherhei t - Fachkenntnisse @ 23\mod_1336 559183027_15.doc x@ 209179 @ 2 @ 1
6.1 Requirements for the electrician
Warning
Electric voltage!
Install the device only if you have the necessary electrical engineering knowledge and experience.
• Incorrect installation endangers your life and that of the user of the electrical system.
• Incorrect installation can cause serious damage to property, e.g. due to fire.
The minimum necessary expert knowledge and requirements for the installation are as follows:
• Apply the "five safety rules" (DIN VDE 0105, EN 50110):
1. Disconnect from power;
2. Secure against being re-connected;
3. Ensure there is no voltage;
4. Connect to earth and short-circuit;
5. Cover or barricade adjacent live parts.
• Use suitable personal protective clothing.
• Use only suitable tools and measuring devices.
• Check the supply network type (TN system, IT system, TT system) to secure the following
power supply conditions (classic connection to ground, protective earthing, necessary
additional measures, etc.).
Pos: 31 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++@ 9\mod_12688 98668093_0.docx @ 52149 @ 2 @ 1

Operating Instructions
Busch-Infoline®
Installation and electrical
connection
Operating Instructions | 1473-1-8302
— 7 —
Pos: 32 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/A - F/Elektrischer Anschlus s @ 21\mod_1328177051724_15. docx @ 138042 @ 2 @ 1
6.2 Electrical connection
Pos: 33 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++1 LeerzeileAbstand ++++++++++++@ 24\mod_13379292890 45_0.docx @ 213673 @ @1
Pos: 34 /#Neustruktur #/Online-Dokumentation (+ KNX)/Anschluss/Infoli ne/Anschluss - 1563-1564 @ 25\mod _1341325410891_15.doc x @ 222022 @ 2 @ 1
Circuit diagrams
Fig. 1: Circuit diagrams for Busch-Alarm signal insert and light signal insert
1NO contact for alarm activation
Terminal assignment
Busch-Alarm signal insert 1563 U / light signal insert 1564 U
Terminal designation Assignment
nc Not occupied
3 Triggering the optical and acoustic alarm signal, 15 V AC for alarm activation
4
Pos: 35 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++@ 9\mod_12688 98668093_0.doc x@ 52149 @ 2 @ 1

Operating Instructions
Busch-Infoline®
Installation and electrical
connection
Operating Instructions | 1473-1-8302
— 8 —
Pos: 36 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/M - O/Montage des Geräteei nsatzes @ 25\mod_134140138 1988_15.docx @ 222339 @ 22 @ 1
6.3 Mounting the device insert
Pos: 37 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Montage/I nfoline/Montage -Geräte Eins ätze 1563-1564 @ 25\mod_13413254 30234_15.docx @ 222036 @ 2 @ 1
1. Mount the devices in a flush-mounted box according to DIN 049073-1.
2. Fix the devices in the flush-mounted box with screws.
3. Mount the elements of the cover plate in the sequence shown in the illustration.
Fig 2: Overview of installation
Pos: 38 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--) /2. Ebene/A - F/Akustische Si gnalisierung mit Steckbr ücke einstellen (gi lt nur für 1563) @ 26\mod_134155 2781785_15.doc x@ 222783 @ 2 @ 1
6.4 Setting acoustic signalling with jumper (applies only to 1563 U)
Pos: 39 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Montage/I nfoline/Alarmverha lten 1563-1564 @ 25\mod_1341325 451109_15.doc x@ 222050 @ 2 @ 1
Fig. 3: 1563 U Busch-Alarm signal insert
Position Acoustic signaling
Jumper top Acoustic signalling off
Jumper bottom Acoustic signaling on
Pos: 40 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Steuermodu le - Online -Dokumentation (--> Für alle Dokument e <--)/++++++++++++Seitenumbruch++++++++++++ @ 9\mod_1268898668093_0.doc x @ 52149 @ 2 @ 1

Operating Instructions
Busch-Infoline®
Installation and electrical
connection
Operating Instructions | 1473-1-8302
— 9 —
Pos: 41 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Überschr iften (--> Für alle Dokumente <--)/ 2. Ebene/S - T/Signalfolge mit S teckbrücke einstelle n (gilt nur für 1563) @ 26\mod_1341 487089482_15.docx @ 222589 @ 22 @ 1
6.5 Setting signal sequence with jumper (applies only to 1563 U)
Pos: 42 /#Neustruktur #/Online-Dokumenta tion (+KNX)/Montage/I nfoline/optische A larmsignalisierung 15 63-1564 @ 26\mod_1341487151 029_15.docx @ 222633 @ 2 @ 1
Fig. 4: 1563 U Busch-Alarm signal insert
Position
Signal sequence
Jumper bottom
Jumper top
=== Ende der Liste für Textmarke Con tent ===
